MAXIMUM Security CURTAIN-Mini User manual

Operating & Installation Guide
CURTAIN-Mini
Remote Controlled
Outdoor/Indoor intrusion detector with
curtain field-of-view
MAXIMUM Security (1984) Ltd.
v
www.maximum.co.il

2/ 12
FEATURES
Super narrow protective screen of 30Anti-maskingDual-tech, PIR & MicrowaveRemote Controlled- Detector settingscan also be controlled by Remote
Control (option).
900mounting bracket (provided)Extremely reliable & highly immune tofalse alarms
Selectable PIR detection sensitivitySelectable Microwave sensitivityAuto temperature compensationAutomatic adaptation to backgroundnoise
Powerful microprocessor controlledHigh level of RFI/EMI immunity

3/ 12
CONGRATULATIONS
We thank you for choosing a product of
MAXIMUM Security (1984) Ltd.
Based on over 30 years experience in
R&D and in production of advanced
security systems, we are proud to
introduce to you the best Outdoor / Indoor
motion detector ever presented, for
industrial, commercial and residential
security.
To ensure proper operation and
maximum use of all its benefits, please
read all parts of this installation and
operating manual, and follow the step-
by-step instructions.
INTRODUCTION
CURTAIN-Mini creates a super narrow
protective screen of 30(like a curtain) to
secure openings and open fields against
intruders.
This type of protection allows free
movement of people within the protected
site- without setting off an alarm.
CURTAIN-Mini is waterproof and can be
installed outdoors or indoors.
In addition to an unprecedented amazing
and reliable detection capability,

4/ 12
CURTAIN-Mini is equipped with excellent
protection against any attempt to disable
its operation by blocking (masking) its
near field-of-view, whether the alarm
system is Armed or Disarmed (Anti-
masking protection).
The protection against masking the near
field-of-view of the detector is achieved by
a continuous active infrared beams scan.
CURTAIN-Mini will detect almost any type
of material that blocks (masks) its near
field-of-view.
It will also detect transparent objects such
as clear glass and plastic bags.
It will activate an alert even if its lens was
sprayed with paint or covered by a sticker.
CURTAIN-Mini combines two detection
technologies- Microwave and Passive
Infrared (PIR), and verifies any intrusion
by both methods.
An advanced and unique algorithm
enables it to work in the most difficult
environmental conditions and where high
security is required, while maintaining
unprecedented immunity to false alarms.

5/ 12
CRUTIAL NOTES
1. The protected area must be
safeguarded by additional detection
means and internal detectors.
2. Similar to other products, this
product can be cheated and
defeated.
3. This product, as any other, may
malfunction or become damaged
during regular use or a result of
vandalism.
4. A comprehensive inspection of the
product in terms of proper activity
and performance should be
conducted on a weekly basis by
individual qualified in writing by the
manufacturer to do so.
5. Snow, Rain, dew, sun, dust and
water may trigger the detector.

6/ 12
APPLICATION -3
10 m
10 m

7/ 12
DETECTOR’S FIELD-OF-VIEW
DIAGRAMS
2m
10m
15m
Microwave
800
0
Side view
PIR "AND"
Microwave
PIR
PIR
PIR
P
I
R
P
I
R
P
I
R
P
I
R
10m
15m
Microwave
0
Top view
PIR "AND"
Microwave
63 cm
30
Detection range of up to 12meter is
for indoor installation

8/ 12
DETECTION SENSITIVITY
ADJUSTMENT and WIRING

9/ 12
PREPARING THE ANTI-MASKING
CHANNEL FOR OPERATION
(Obligatory for proper Anti-masking
operation!!!)
To enable proper operation of the masking
detection (Anti-masking), it is necessary to
allow the detector to automatically study
and analyze the environmental conditions
of its protected area.
This is an obligatory action that should be
performed by the installer, ensuring proper
operation of the Anti-masking channel!!!
Study procedure to be performed in
two cases:
1. Upon connecting the power supply to
the detector (after about 1 minute, the
time it takes the detector to stabilize
when first fed by power supply).
2. Upon the position of DIP switch No. 1
(LED indicator) is changed.
The study procedure:
Immediately close the detector’s case (within 15 seconds maximum).
Keep at least 1 meter away fromdetector's front, until the study
procedure is complete, about 1 minute.

10 / 12
LED indication during the study
procedure
The Red+Green LED indicators blinkrapidly for about 60 seconds.
A break of about 20 seconds (GreenLED indicator are activated).
The Red+Green LED indicators blinkrapidly for about 10 seconds.

11 / 12
PERFORM A TEST
To be carried out when the case is closed
and the LED indicators are enabled (DIP
switch No.1 switched to ON).
Test procedure for human movement
detection (Alarm):
oWalk in the protected area.
oCompulsory reaction of the detector:
Upon each true detection event, the
“Alarm Relay” will operate for 2
seconds. The Red+Green LED
indicators will blink simultaneously
during those 2 seconds.
Test procedure for masking detection
(Anti-masking)
oAt a distance of about 10 cm from the
front of the detector, place a white
piece of paper (or any other object).
oCompulsory reaction of the detector:
The Green LED will immediately blink
continuously as long as the masking
object exists.
If the masking object exists for more
than 90 seconds, the orange LED will
glow continuously and the "MASK”
(Anti-masking) relay will operate for at
least 2 seconds and for as long as
masking exists.

12 / 12
SPECIFICATIONS
Power supply………………21V DCCurrent drain…. Standby: 20mA (Max.)Operation: 30 mA (Max.)
Alarm relay contacts endurance
…………………………15V DC / 20 mA
Anti-masking relay contacts endurance

…………….……..…… 15V DC / 20 mA
TAMPER Switch endurance
………………………….. 24V DC / 0.1A
Warm-up time………..….…… 1 MinuteAlarm period.………........…. 2 SecondsAnti-masking relay response time
……………………..90 Seconds (Max.)
Anti-masking relay activation period:All time of masking (at least 2 seconds)
Motion detection coverage
Outdoors…..………...........10 meter, 30
Indoors…..…………..........12 meter, 30
Operating Temperature:(-)200~(+)700CMicrowave operating frequency
…...………………………… 24.125 GHz
