MaxLite BL-CLR Series User manual

Operating Instructions BL-CLR eries
MaxLite Classic Round Bollard 36”
• To reduce the risk of death, personal injury or property damage from
fire, electric shock, falling parts, cuts/abrasions, and other hazards
read all warnings and instructions included with and on the fixture
box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon
this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• DO NOT NSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WARNING:
RI K OF ELECTRICAL HOCK
• Turn off electrical power at fuse or circuit breaker box before wiring fixture to the power supply.
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label information.
• Make all electrical and grounded connections in accordance with the National Electrical Code
and any applicable local code requirements.
• All wiring connections should be capped with UL approved wire connectors.
CAUTION:
RI K OF INJURY
• Wear gloves and safety glasses at all times when removing luminaire from carton, installing, servicing
or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may be hazardous to children.
CAUTION:
RI K OF FIRE
• Keep combustable and other materials that can burn away from luminaire and lamp/lens
• Do not mount to flammable or combustible surfaces.
llustrations in the manual are for installation purposes only. t may not be identical to the fixture purchased.
Models:
This instruction manual applies to the BL-CLR eries
© Copyright 2019. MaxLite, nc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [e-mail]
Page: 1
REV: 06/07/19
®
General afety Information
Picture is for illustration
purposes only. Your model
may vary.

© Copyright 2019. MaxLite, nc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [e-mail]
Page: 2
REV: 06/07/19
General Wiring Diagram
CAUTION: Turn off electrical power at
fuse or circuit breaker box before wiring
fixture to the power supply.
Connecting panels to AC source supply:
All units must be individually connected to
the AC supply.
Black = Line
White = Neutral
Green = Ground
Installation & Operation
1. Place the anchor bolt assembly (three (3) anchor bolts
secured to the supplied cardboard template with nuts on
either side) over the conduit and secure for the concrete
pour. Ensure that the base of the concrete is elevated from
the surrounding area to keep the bollard from standing in
water.
2. Pour concrete while ensuring that the template is as level
as possible. Allow the concrete to cure (see Fig. 1).
3. Remove the four (4) set screws from the bottom of the
fixture and remove the base plate (see Fig. 2). Disconnect
the orange quick-connect between the terminal block and
the LED driver if necessary.
4. Once the concrete is set, place the base plate onto the
anchor bolts and secure it with the supplied nuts and
washers (see Fig. 3).
5. Connect the power supply wires from the conduit to the
terminal block according to the wiring diagram.
6. Mount the fixture on the base, reconnect the orange
quick-connect if necessary, and secure it with the four (4)
set screws removed from the bottom of the fixture in step 3.
(+) LINE
(-) COMMON
GROUND GREEN
WHITE
BLACK
Light
Fixture
Base
Set Screw
Anchor Bolt
Conduit
Pad Plate
Base
Nut
Washer
Operating Instructions BL-CLR eries
MaxLite Classic Round Bollard 36”
®

MaxLite nc. warrants its products for a minimum period of FIVE (5) years from the date of original purchase from
MaxLite or its authorized distributor/dealer (the “Warranty Period”), as follows: f a Product fails to operate during the
Warranty Period as a result of defects in materials or workmanship, MaxLite will, at its option, repair it, replace it with
the same or like Product.
Please refer to Maxlite’s website (at http://maxlite.com/resources/warranties) for the complete
terms and conditions of our warranty.
Limitation of Liability
THE FOREGO NG WARRANTY S EXCLUS VE, AND S THE SOLE REMEDY FOR ANY AND ALL CLA MS,
WHETHER N CONTRACT, N TORT OR OTHERW SE AR S NG FROM THE FA LURE OF PRODUCT AND S N
L EU OF ALL OTHER WARRANT ES, EXPRESS OR MPL ED, NCLUD NG ALL WARRANT ES OF
MERCHANTAB L TY OR F TNESS FOR A PART CULAR PURPOSE, WH CH WARRANT ES ARE HEREBY
EXPRESSLY D SCLA MED TO THE EXTENT PERM TTED BY LAW AND, N ANY EVENT, SHALL BE L M TED TO
THE WARRANTY PER OD SPEC F ED ABOVE. THE L AB L TY OF MAXL TE SHALL BE L M TED TO THE TERMS
OF THE EXPRESS WARRANTY SET FORTH HERE N. N NO EVENT W LL MAXL TE BE L ABLE FOR ANY
SPEC AL, NC DENTAL OR CONSEQUENT AL DAMAGES NCLUD NG, W THOUT L M TAT ON, DAMAGES
RESULT NG FROM LOSS OF USE, PROF TS, BUS NESS OR GOODW LL, LABOR COSTS, REMOVAL OR
NSTALLAT ON COSTS, DECREASE N THE L GHT OUTPUT OF THE LAMP, AND/OR DETER ORAT ON N THE
LAMP’S PERFORMANCE, WHETHER OR NOT MAXL TE HAS BEEN ADV SED OF THE POSS B L TY THEREOF.
UNDER NO C RCUMSTANCES SHALL MAXL TE’S ENT RE L AB L TY FOR A DEFECT VE PRODUCT EXCEED
THE PURCHASE PR CE OF THAT PRODUCT. WARRANTY SERV CES PROV DED UNDER THESE TERMS AND
COND T ONS DO NOT ENSURE THE UN NTERRUPTED OPERAT ON OF PRODUCTS; MAXL TE SHALL NOT BE
L ABLE FOR DAMAGES CAUSED BY ANY DELAYS NVOLV NG WARRANTY SERV CE.
This Limited Warranty gives you specific legal rights and you may also have other rights that may vary from state to
state. Because some states or jurisdictions do not allow the exclusion or limitation of liability for consequential or
incidental damages, this limitation may not apply to you.
Warranty Information
