MaxLite DBL Series User manual

Operating Instructions DBL Series
MaxLite LED Dusk-To-Dawn Barn Light Fixture
• To reduce the risk of death, personal injury or property damage from
fire, electric shock, falling parts, cuts/abrasions, and other hazards
read all warnings and instructions included with and on the fixture
box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon
this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• For Residential installation: If you are unsure about the installation or
maintenance of the luminaires, consult a qualified licensed electrician
and check your local electrical code.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WA NING:
RISK OF ELECTRICAL S OCK
• Turn off the power when your perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label information.
• Make all electrical and grounded connections in accordance with the National Electrical Code and any
applicable local code requirements.
• All wiring connections should be capped with UL approved wire connectors.
CAUTION:
RISK OF INJURY
• Wear gloves and safety glasses at all times when removing luminaire from carton, installing, servicing
or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may be hazardous to children.
CAUTION:
RISK OF FIRE
• Keep combustable and other materials that can burn away from luminaire and lamp/lens
Models:
DBL Series
© Copyright 2020. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: inf[email protected]
Page: 1
REV: 4/21/20
®
General Safety Information

SPD
LED Driver
ouse Grounding
V-(Black)
V+(Red)
AC INPUT
N
L
GNDGND
L
N
GNL
photocell sensor
Brown
(L / Li)
Blue
(N)
Red
(Load/Lo)
Operating Instructions DBL Series
MaxLite LED Dusk-To-Dawn Barn Light Fixture
© Copyright 2020. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: inf[email protected]
Page: 2
REV: 4/21/20
®
General Wiring Diagram
CAUTION: Turn off electrical power at fuse or circuit breaker box before wiring
fixture to the power supply.
Connecting panels to AC source supply:
All units must be individually connected to
the AC supply.
Black = Line
White = Neutral
Green = Ground

CCT Switch Nut
5000K 3000K
4000K
5K 3K
4K
Lamp Body
Main Power
Screw
Universal Clamp
Main Power
1-5/8” or 2-3/8”
Lamp Post
Black
White
Green
L
N
G
Wiring Guide
Photocell
Wall or
Pole Mounting Bracket
Self-tapping Screws Four holes to fix
into wall or poles
Mounting Bracket
Universal Clamp Square-type Bracket
Lamp-Post Mounting Instructions
1. To adjust color temperature: remove nut and gasket from back of fixture, adjust CCT switch to desired color and
replace nut and gasket. (Fig. 1)
IMPO TANT: MUST MAKE SU E THE NUT AND GASKET A E CLOSED TIGHTLY TO P EVENT
WATE LEAKS!
2. Take off the square-type bracket and universal clamp. (Fig. 2)
3. Feed the main power through the lamp-post, then wire the main power. After finishing, mount lamp-body to the
lamp-post and universal clamp securely with screws. Universal clamp fits with either 1.65” or 2 3/8” OD
(outside diameter) arm. Flip clamp to appropriate side to match the arm OD size. (Fig. 3)
Note: depending on version, lamp-post arm may or may not be included. It is available as an accessory
if needed.
4. Screw photocell onto the fixture. (Fig. 4)
Note: depending on the version, there might be a button photocell instead of twist lock style.
5. Place the self-tapping screws into the mounting bracket, line up with holes
on the wall (or pole) and screw it firmly in place. (Fig. 5)
Operating Instructions DBL Series
MaxLite LED Dusk-To-Dawn Barn Light Fixture
© Copyright 2020. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: inf[email protected]
Page: 3
REV: 4/21/20
®

Wall Mounting Instructions
1. To adjust color temperature: remove nut and gasket from back of fixture, adjust CCT switch to desired color
and replace nut and gasket. (Fig. 6)
IMPO TANT: MUST MAKE SU E THE NUT AND GASKET A E CLOSED TIGHTLY TO P EVENT
WATE LEAKS!
1. Take off the square-type bracket and universal clamp. (Fig. 7)
2. Place the self-tapping screw into the mounting holes, line up with
the holes in the wall and screw them firmly in place. (Fig. 8)
3. Knock out the square-type bracket and fix the metal pipe into it. Wire the
main power and fix the square-type bracket to the lamp body firmly when
finished. (Fig. 9)
4. Screw photocell onto the fixture. (Fig. 10)
Note: depending on the version, there might be a button photocell instead of twist lock style.
Operating Instructions DBL Series
MaxLite LED Dusk-To-Dawn Barn Light Fixture
© Copyright 2020. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: inf[email protected]
Page: 4
REV: 4/21/20
®
Wall
Mounted holes
Self-tapping Screw
Main Power
Black
White
Green
L
N
G
Wiring Guide
Lamp Body
Metal Pipe
Square-type Bracket
Knockout
Photocell
Lamp Body
Universal Clamp Square-type Bracket
CCT Switch Nut
5000K 3000K
4000K
5K 3K
4K

Operating Instructions DBL Series
MaxLite LED Dusk-To-Dawn Barn Light Fixture
© Copyright 2020. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: inf[email protected]
Page: 5
REV: 4/21/20
®
MaxLite Inc. warrants its products for a minimum period of FIVE (5) years from the date of original purchase from
MaxLite or its authorized distributor/dealer (the “Warranty Period”), as follows: If a Product fails to operate during the
Warranty Period as a result of defects in materials or workmanship, MaxLite will, at its option, repair it, replace it with
the same or like Product.
Please refer to Maxlite’s website (at http://maxlite.com/resources/warranties) for the complete
terms and conditions of our warranty.
Limitation of Liability
T E FOREGOING WARRANTY IS EXCLUSIVE, AND IS T E SOLE REMEDY FOR ANY AND ALL CLAIMS,
W ET ER IN CONTRACT, IN TORT OR OT ERWISE ARISING FROM T E FAILURE OF PRODUCT AND IS IN
LIEU OF ALL OT ER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ALL WARRANTIES OF
MERC ANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, W IC WARRANTIES ARE EREBY
EXPRESSLY DISCLAIMED TO T E EXTENT PERMITTED BY LAW AND, IN ANY EVENT, S ALL BE LIMITED TO
T E WARRANTY PERIOD SPECIFIED ABOVE. T E LIABILITY OF MAXLITE S ALL BE LIMITED TO T E TERMS
OF T E EXPRESS WARRANTY SET FORT EREIN. IN NO EVENT WILL MAXLITE BE LIABLE FOR ANY
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES INCLUDING, WIT OUT LIMITATION, DAMAGES
RESULTING FROM LOSS OF USE, PROFITS, BUSINESS OR GOODWILL, LABOR COSTS, REMOVAL OR
INSTALLATION COSTS, DECREASE IN T E LIG T OUTPUT OF T E LAMP, AND/OR DETERIORATION IN T E
LAMP’S PERFORMANCE, W ET ER OR NOT MAXLITE AS BEEN ADVISED OF T E POSSIBILITY T EREOF.
UNDER NO CIRCUMSTANCES S ALL MAXLITE’S ENTIRE LIABILITY FOR A DEFECTIVE PRODUCT EXCEED
T E PURC ASE PRICE OF T AT PRODUCT. WARRANTY SERVICES PROVIDED UNDER T ESE TERMS AND
CONDITIONS DO NOT ENSURE T E UNINTERRUPTED OPERATION OF PRODUCTS; MAXLITE S ALL NOT BE
LIABLE FOR DAMAGES CAUSED BY ANY DELAYS INVOLVING WARRANTY SERVICE.
This Limited Warranty gives you specific legal rights and you may also have other rights that may vary from state to
state. Because some states or jurisdictions do not allow the exclusion or limitation of liability for consequential or
incidental damages, this limitation may not apply to you.
Warranty Information
