MaxLite maxLED MLLWP40LED50DS 150 Series User manual

© Copyright 2015. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [e-mail]
Page : 1
REV: 6/02/2015
Operating Instructions MLLWP Series
MaxLite®LED LARGE WALL PACK (CUTOFF & STANDARD)
General Safety Information
• To reduce the risk of death, personal injury or property damage
from fire, electric shock, falling parts, cuts/abrasions, and other
hazards read all warnings and instructions included with and on the
fixture box and all fixture labels.
• Before installing, servicing, or performing routine maintenance
upon this equipment, follow these general precautions.
• Commercial installation, service and maintenance of luminaires
should be performed by a qualified licensed electrician.
• For Residential installation: If you are unsure about the installation
or maintenance of the luminaires, consult a qualified licensed
electrician and check your local electrical code.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junction box.
WARNING:
RISK OF ELECTRICALSHOCK
• Turn off electrical power at fuse or circuit breaker box before
wiring fixture to the power supply.
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label information.
• Make all electrical and grounded connections in accordance with the National Electrical Code and any applicable local code
requirements.
• All wiring connections should be capped with UL approved wire connectors.
CAUTION:
RISK OF INJURY
• Wear gloves and safety glasses at all times when removing luminaire from carton, installing, servicing or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may be hazardous to children.
CAUTION:
RISK OF FIRE
• Keep combustible and other materials that can burn away from luminaire and lamp/lens.
• MIN 90°C SUPPLY CONDUCTORS.
Illustrations on the manual are for installation purposes only. It may not be identical to the fixture purchased.
MLLWP40LED50DSXXXX-150 120-277V 50/60 Hz
MLLWP70LED50DSXXXX-150 120-277V 50/60 Hz
MLLWP60LED50XXXX-150 120-277V 50/60 Hz
MLLWP40LED50XXXX-150 120-277V 50/60 Hz
Model options:
If XX=UH, voltage input 347-480V
If XXXX = PC12, voltage input 120V 50/60 Hz
If XXXX = PC27, voltage input 208-277V 50/60 Hz

© Copyright 2015. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [e-mail]
Page : 2
REV: 6/02/2015
Operating Instructions MLLWP Series
MaxLite®LED LARGE WALL PACK (CUTOFF & STANDARD)
General Wiring Diagram
CAUTION: Turn off electrical power at fuse or circuit breaker box before wiring fixture to the power supply.
Connecting panels to AC source supply:
All units must be individually connected to the AC supply. (see page 1 for voltage by model)
Black = Line
White = Neutral
Green = Ground
AC wiring instructions
1. Feed wires through wire way and secure using connector (not supplied).
2. Connect supply wires to quick connect originating from INPUT side of driver. Black/Hot supply to quick connect with black wire.
White/Neutral supply to quick connect with white wire. Be sure to confirm connections are secure.
3. Connect ground wire to quick connect with green wire. Be sure to confirm grounding connection is secure.

© Copyright 2015. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]
Page : 3
REV: 06/02/2015
Operating Instructions MLLWP Series
MaxLite®LED LARGE WALL PACK (CUTOFF & STANDARD)
Installation & Operation
Disconnect the power by turning off the circuit breaker or by removing the appropriate fuse at the fuse box.
Turning the power off using the light switch is not sufficient to prevent electrical shock.
1. Drill three mounting holes into mounting surface using a 3/8” drill bit. Use template to locate mounting holes.
2. Use a screwdriver to loosen (2) screws securing fixture door. Remove fixture rear housing from fixture.
3. Use a flat head screw driver to remove appropriate wire way covering from back plate of housing.
4. Take care to avoid damaging driver, wires and quick connectors and drill holes through castings over fixture mounting holes.
5. Affix fixture to mounting surface by installing anchors (not supplied) through fixture mounting holes into holes drilled into the mounting
surface. Be sure to use an anchor appropriate for the mounting surface in which the fixture is installed.
6. Add ¼” bead of exterior grade silicone sealant around the perimeter of the wall pack on
the wall to inhibit any moisture from attachment screws.
7. Reattach fixture front to fixture rear housing.
8. Connect driver OUTPUT leads to quick connect originating from LED array. Red output
to quick connect with red wires, black output to quick connect with black wires.
9. Reattach fixture using two screws removed in installation step 2.

© Copyright 2015. MaxLite, Inc. All Rights Reserved.
12 York Ave, West Caldwell, NJ 07006 Tel: [phone] Fax: [phone] Email: [email protected]
Page : 4
REV: 06/02/2015
Operating Instructions MLLWP Series
MaxLite®LED LARGE WALL PACK (CUTOFF & STANDARD)
Warranty
LIMITED WARRANTY FOR CERTAIN MAXLITE® LED LIGHTING FIXTURES, SPECIFICALLY WALL PACKS; FLOOD LIGHT; AREA
LIGHT; CANOPY; GARAGE; PARKING; SECURTIY LIGHT; VAPOR TIGHT AND ROADWAY.
This limited warranty is provided by the MaxLite company described below ("Seller") to you as the original purchaser of the LED lighting
product that is identified on Seller's invoice reflecting its original purchase (the "Product"). The Seller is the MaxLite Company identified
as such on the invoice. This limited warranty may be transferred to subsequent purchasers of the Product, provided that such Product
is resold in new condition and in its original packaging. Seller warrants that the Product, when delivered in new condition and in its
original packaging, will be free of defects in material and workmanship for a period of FIVE (5) YEARS from the date of original
purchase or the number of hours used has not exceeded the L70 life stated for each LED fixture. The determination of whether the
Product is defective shall be made by Seller in its sole discretion with consideration given to the overall performance of the Product. A
Product shall not be considered defective solely as a result of the failure of individual LED components to emit light if the number of
inoperable components is less than 10% of the total number of LED components in the Product.
If Seller determines the Product is defective, Seller will elect, in its sole discretion, to refund you the purchase price of the Product,
repair the Product or replace the Product. This limited warranty does not apply to loss or damage to the Product caused by: negligence;
abuse; misuse; mishandling; improper installation, storage or maintenance; damage due to fire or acts of God; vandalism; civil
disturbances; power surges; improper power supply; electrical current fluctuations; corrosive environment installations; induced
vibration; harmonic oscillation or resonance associated with movement of air currents around the Product; alteration; accident; failure to
follow installation, operating, maintenance or environmental instructions prescribed by Seller or applicable electrical codes; or improper
service of the Product performed by someone other than Seller or its authorized service provider. This limited warranty excludes field
labor and service charges related to the repair or replacement of the Product. THIS LIMITED WARRANTY IS VOID IF THE PRODUCT
IS NOT USED FOR THE PURPOSE FOR WHICH IT IS DESIGNED.
Seller reserves the right to utilize new, reconditioned, refurbished, repaired or remanufactured products or parts in the warranty repair
or replacement process. Such products and parts will be comparable in function and performance to an original product or part, as
determined by Seller in its sole discretion, and warranted for the remainder of the original warranty period.
In order to make a warranty claim, you must notify Seller in writing within sixty (60) days after your discovery of the defect, provide proof
of purchase such as the invoice and comply with Seller's other warranty requirements. Upon receiving that notice, Seller may require
you to promptly return the Product to Seller, or its authorized service provider, freight prepaid. Your warranty claim should be addressed
to MaxLite, Inc., 12 York Ave. West Caldwell NJ 07006.
This limited warranty only applies to specified LED fixtures. Backup batteries, photocells, mounting accessories and other fixture
accessories can be found at www.MaxLite.com/lighting/products/warranty.
THE FOREGOING WARRANTY PROVISIONS ARE EXCLUSIVE AND ARE GIVEN AND ACCEPTED IN LIEU OF ANY AND ALL
OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY WARRANTY AGAINST
INFRINGEMENT AND ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SELLER BE LIABLE FOR INCIDENTAL, COMPENSATORY, CONSEQUENTIAL, INDIRECT, SPECIAL OR
OTHER DAMAGES. SELLER'S AGGREGATE LIABILITY WITH RESPECT TO A DEFECTIVE PRODUCT SHALL IN ANY EVENT BE
LIMITED TO THE MONIES PAID TO SELLER FOR THAT DEFECTIVE PRODUCT.
This warranty is effective for purchases of Product on or after the effective date set forth below. Seller reserves the right to modify this
warranty from time to time. Any modification of this warranty shall be effective for all orders placed with Seller on or after the effective
date of such revised warranty.
Effective Date: May 12, 2014
