MaxTech TH5C User manual

Timer
TH5C
Operation Manual
1Panel Function
Upper display (PV)
Displaying counting value or
parameter
Below display (SV)
Displaying setting value or parameter
Shift key
Moving digit or switching display
( pushing it for 3 sec to enter set
mode )
Decreasing key
Increasing key
Rst Reset key
Use for resetting or entering SV
LED
Run：flickering when counting
Out：lighting when output “on”
K/P：lighting when key locked
Reset：lighting when reset operation
Start：lighting when starting
Gate：lighting when stopping
H：lighting when hour selected
M：lighting when minute selected
S：lighting when second selected
Run
Out
K / P
Rst SET
Rst
Start
Gate
H
M
S
TH5C
2Set Time Method
Setting time can be changed during counting or stop counting.
Pushing 1 sec for LED flickering then push or to increase or decrease the set time.
Rst
Pushing to move digit position, it is cycle .
It must push key to enter the SV after setting.
3Parameter Flow Chart & Function
Setting value can be changed during counting or stop counting
Pushing key for 3 sec then use & key to select the mode.
Push 3 sec
Returning to initial
display after 20 sec
no operation.
Time ranges
Time range selection
9.999sec 9999min
99.99sec 999.9hr
999.9sec 9999hr
9999sec 99min59sec
999.9min 99hr59min
S
SM
S
……. H
M
Use setting time range.
Select time range
Up / Down counting
Output mode
Output time
Input time
Key lock mode
Output contactor
Return 1tE (time range)
Use setting up / down counting.
Up Down
Use setting output mode.
Select time operation
* Refer to output mode diagram. TH5C without A1, A2, A3, B1, B2, C, D, F
A A1 A2 A3 b b1 b2 C d E F
Use setting time range.
* Output mode C, D, E, F without this function
Hold 0.1S 0.5S 1S 5S 10S 15S 20S
Use setting time range.
* 1ms=1/1000sec * TH5C-8 without this function
1ms 20ms
ALL UNLOCK RESET ADJ SET
Use setting lock mode.
* Push + for 3 sec to perform lock or release lock
Use setting the output contactor.
* TH5C-8S and TH5C-11S without this function
2C 1A1C
http://www.maxthermo.com
4Timing Charts
Either one-shot output or sustained output can be selected
Timing starts when the start signal goes ON.
While the start signal is ON, the timer starts
when the power comes ON or when the
reset input goes OFF.
The control output is controlled using a
sustained or one-shot time period.
Timing starts when the start signal goes ON.
and is reset when the start signal goes OFF
While the start signal is ON, the timer starts
when the power comes ON or when the
reset input goes OFF.
The control output is controlled using a
sustained or one-shot time period.
Mode A :
Signal ON Delay
(Timer resets when
power comes on)
Mode A1 :
Signal ON Delay2
(Timer resets when
power comes on or
when START signal
goes off)

Timing starts when the start signal goes ON.
The control output is controlled using a
sustained or one-shot time period.
The start signal disables the timing function
(i.e.,same function as the gate input)
Timing starts when the start signal goes ON.
The start signal disables the timing function
(i.e.,same function as the gate input)
The control output is controlled using a
sustained or one-shot time period.
Timing starts when the start signal goes ON.
The status of the control output is reversed
when time is up (OFF at start)
While the start signal is ON, the timer starts
when the power comes ON or when the
reset input goes OFF.
Timing starts when the start signal goes ON.
The status of the control output is reversed
when time is up (OFF at start)
While the start signal is ON, the timer starts
when the power comes ON or when the
reset input goes OFF.
Timing starts when the start signal goes ON.
The status of the control output is reversed
when time is up (OFF at start)
While the start signal is ON, the timer starts
when the power comes ON or when the
reset input goes OFF.
Timing starts when the start signal goes
ON or OFF.
The status of the control output is ON when
the start signal goes ON or OFF.
The control output is ON when the start
signal is ON (except when the power is OFF
or the reset is ON).
Timing starts when the start signal comes ON.
The control output is reset when time is up.
While the start signal is ON, the timer starts
when the power comes ON or when the
reset input goes OFF.
Start signal enables timing
( timing is stopped when the start signal is
OFF or when the power is OFF)
A sustained control output is used.
5Dimensions
Y type ( Flush Mounting )：Using Y48 Frame &US-08Socket
P3G-08 Socket or P3G-11 Socket ( for TH5C-11S/11D use only )
7Type Selection
Unit：mm ( inch )
N type ( Surface Mounting )：Using P2CF-08,PF085A Socket or
PF113A Socket ( for TH5C-11S/11D use only )
6Terminal Arrangement
Confirm that the power supply meets specifications before use.
Mode A3 :
Signal ON Delay
(Timer doe not resets
when power comes on)
Mode A2 :
Power ON Delay
(Timer resets when
power comes on)
Mode B :
Repeat Cycle 1
(Timer resets when
power comes on)
Output can be sustained
or one-shot.
Mode B1:
Repeat Cycle 2
(Timer does not reset
when power comes on)
Output can be sustained
or one-shot.
Mode D:
Signal OFF delay
(Timer resets when
power comes on)
Mode E:
Interval
(Timer resets when
power comes on)
Mode F:
Cumulative
(Timer does not reset
when power comes ON.)
Mode B2:
Repeat Cycle ON start
(Timer does not reset
when power comes on)
Output can be sustained
or one-shot.
Mode C:
Signal ON/OFF delay
(Timer reset when
power comes on)
