This document is a condensed version of the full Product Reference Manual.
This version only includes the Maxtor Information about the Product. Information
that can be found in the ANSI specification is not included in this document to
reduce its over all size. Also eliminated are the Table of Contents and Glossary.
This condensed version is created to allow faster downloading from Maxtor's
Internet home page and MaxFax services.

Revisions Manual No. 1390
VER.ONCENOITCESNOITPIRCSED ETAD
AB29887
llA
laitinI esaeler .3 / 01 89/

BeforeYou Begin
Thank you for your interest in the Maxtor DiamondMax™ 2880 AT hard disk drives. This manual provides
technical information for OEM engineers and systems integrators regarding the installation and use of DiamondMax
hard drives Drive repair should be performed only at an authorized repair center. For repair information, contact
the Maxtor Customer Service Center at 800-2MAXTOR or 408-432-1700.
Before unpacking the hard drive, please review Sections 1 through 4.
CAUTION
Maxtor DiamondMax 2880 hard drives are precision products. Failure to
follow these precautions and guidelines outlined here may lead to
product failure, damage and invalidation of all warranties.
1 BEFOREunpackingorhandling a drive, takeallproper electro-static discharge (ESD)
precautions,includingpersonnelandequipmentgrounding.Stand-alonedrivesaresensitiveto
ESDdamage.
2 BEFOREremoving drives from theirpackingmaterial,allow them to reachroom
temperature.
3 Duringhandling,NEVER drop,jar,or bumpadrive.
4 Onceadriveisremoved fromtheMaxtorshippingcontainer,IMMEDIATELYsecurethedrive
throughitsmountingholes within a chassis.Otherwise,storethe drive on apadded,grounded,
antistaticsurface.
5 NEVERswitchDCpoweronto the drivebyplugginganelectrically live DCsourcecableinto
thedrive'sconnector.NEVERconnectalivebusto the drive'sinterfaceconnector.
Please do not remove or cover up Maxtor factory-installed drive labels.
They contain information required should the drive ever need repair.

DIAMONDMAX2880–INTRODUCTION
1 – 4
SECTION 1
Introduction
Maxtor Corporation
Maxtor Corporation has been providing high-quality computer storage products since 1982. Along the way,
we’ve seen many changes in data storage needs. Not long ago, only a handful of specific users needed more than
a couple hundred megabytes of storage. Today, downloading from the Internet and CD-ROMs, multimedia,
networking and advanced office applications are driving storage needs even higher. Even home PC applications
need capacities measured in gigabytes, not megabytes.
Products
Maxtor’s products meet those demanding storage capacity requirements with room to spare. They feature
proven compatibility and reliability. While DiamondMax™ 2880 is the latest addition to our family of high
performance desktop hard drives, the DiamondMax™ 2160 and DiamondMax™ 1750 series hard drives
deliver industry-leading capacity, performance and value for many PC applications.
Support
No matter which capacity, all Maxtor hard drives are supported by our commitment to total customer
satisfaction and our No Quibble®Service guarantee. One call – or a visit to our home page on the Internet
(http://www.maxtor.com) – puts you in touch with either technical support or customer service. We’ll
provide you the information you need quickly, accurately and in the form you prefer – a fax, a downloaded
file or a conversation with a representative.
Manual Organization
This hard disk drive reference manual is organized in the following method:
❏Section 1 – Introduction
❏Section 2 – Description
❏Section 3 – Specifications
❏Section 4 – Installation
❏Section 5 – AT Interface
❏Section 6 – Host Software Interface
❏Section 7 – Interface Commands
❏Section 8 – Service and Support
❏Appendix – Glossary
Abbreviations
VRBBANOITPIRCSEDVRBBANOITPIRCSED
ATAtnemhcattaTABMetybagem
ipbhcnirepstibces/stibMdnocesrepstibagem
SHCrotces-daeh-rednilycces/BMdnocesrepsetybagem
bdslebicedzHMztrehagem
ABddethgiewA,slebicedsmdnocesillim
AMDsseccayromemtceridBSMtibtnacifingistsom
CCEedocnoitcerrocrorreVmstlovillim
icfhcnirepsegnahcxulfsnsdnocesonan
GnoitareleccaOIPtuptuo/tupnidemmargorp
BGetybagigMPRetunimrepsnoitulover
zHztrehipthcnirepskcart
BKetybolikAMDUsseccayromemtceridartlu
ABL)gni(sserddakcolblacigolcesµdnocesorcim
BSLtibtnacifingistsaelVstlov
AmserepmaillimWsttaw

DIAMONDMAX2880–INTRODUCTION
1 – 5
Conventions
If there is a conflict between text and tables, the table shall be accepted as being correct.
Key Words
The names of abbreviations, commands, fields and acronyms used as signal names are in all uppercase type
(e.g., IDENTIFY DRIVE). Fields containing only one bit are usually referred to as the “name” bit instead of
the “name” field.
Names of drive registers begin with a capital letter (e.g., Cylinder High register).
Numbering
Numbers that are not followed by a lowercase “b” or “h” are decimal values. Numbers that are followed by
a lowercase “b” (e.g., 01b) are binary values. Numbers that are followed by a lowercase “h” (e.g., 3Ah) are
hexadecimal values.
Signal Conventions
Signal names are shown in all uppercase type.
All signals are either high active or low active signals. A dash character (-) at the end of a signal name
indicates that the signal is low active. A low active signal is true when it is below ViL and is false when it is
above ViH. A signal without a dash at the end indicates that the signal is high active. A high active signal is
true when it is above ViH and is false when it is below ViL.
When a signal is asserted, it means the signal is driven by an active circuit to its true state.
When a signal is negated, it means the signal is driven by an active circuit to its false state.
When a signal is released, it means the signal is not actively driven to any state. Some signals have bias
circuitry that pull the signal to either a true or false state when no signal driver is actively asserting or negating
the signal. These instances are noted under the description of the signal.

PRODUCTDESCRIPTION
2 – 1
SECTION 2
Product Description
Maxtor DiamondMax™ 2880 AT disk drives are 1-inch high, 3.5-inch diameter random access storage devices
which incorporate an on-board ATA/Ultra DMA controller. High capacity is achieved by a balanced
combination of high areal recording density and the latest data encoding and servo techniques.
Maxtor's latest advancements in electronic packaging and integration methods have lowered the drive's power
consumption and increased its reliability. Advanced magneto-resistive read/write heads, an state-of-the-art head/
disk assembly using an integrated motor/spindle design allow up to four disks in a 3.5-inch package.
Exceptionally high data transfer rates and 9.0 ms access times make these performance series disk drives especially
well-suited to high speed desktop and server applications.
DiamondMax 2880 Key Features
ANSI ATA-4 compliant PIO Mode 4 interface (Enhanced IDE)
Supports Ultra DMA Mode 2 for up to 33 MB/sec data transfers
256 KB buffer with multi-adaptive cache manager
9.0 ms seek time
Zone density and I.D.-less recording
High reliability with
> 500,000 hour MTBF
Outstanding shock resistance at 200 Gs
High durability with 50K constant start/stop cycles
Advanced multi-burst on-the-fly Error Correction Code (ECC)
Extended data integrity with ECC protected data and fault tolerant servo synchronization fields
Supports EPA Energy Star Standards (Green PC Friendly) with ATA powering savings commands
Auto park and lock actuator mechanism
Low power consumption
S.M.A.R.T. Capability
Note: Maxtor defines one megabyte as 10
6
or one million bytes and one gigabyte as 10
9
or one billion bytes.

PRODUCTDESCRIPTION
2 – 2
Product Features
Functional / Interface
Maxtor DiamondMax™ 2880 hard drives contain all necessary mechanical and electronic parts to interpret control
signals and commands from an AT-compatible host computer. See Section 3 Product Specifications, for complete
drive specifications.
Zone Density Recording
The disk capacity is increased with bit density management – common with Zone Density Recording. Each
disk surface is divided into 16 circumferential zones. All tracks within a given zone contain a constant
number of data sectors. The number of data sectors per track varies in different zones; the outermost zone
contains the largest number of data sectors and the innermost contains the fewest.
Read/Write Multiple Mode
This mode is implemented per ANSI ATA/ATAPI-4 specification. Read/Write Multiple allows the host to
transfer a set number of sectors without an interrupt request between them, reducing transfer process
overhead and improving host performance.
UltraDMA - Mode 2
Maxtor DiamondMax 2880 hard drives fully comply with the new ANSI Ultra DMA protocol, which greatly
improves overall AT interface performance by significantly improving burst and sustained data throughput.
Multi-word DMA (EISA Type B) - Mode 2
Supports multi-word Direct Memory Access (DMA) EISA Type B mode transfers.
Sector Address Translation
All DiamondMax 2880 drives feature a universal translate mode. In an AT/EISA-class system, the drive may
be configured to any specified combination of cylinders, heads and sectors (within the range of the drive's
formatted capacity). DiamondMax 2880 drives power-up in a translate mode:
LEDOMLYCDHTPSenoZLmocPWYTICAPAC
8D25119233,226136)*()*(BM025,11
7D80019045,916136)*()*(BM080,01
6D54809383,616136)*()*(BM554,8
6D04809672,616136)*()*(BM004,8
5D02709759,316136)*()*(BM002,7
5D84609555,216136)*()*(BM084,6
4D67509661,116136)*()*(BM067,5
4D01509529,96136)*()*(BM221,5
3D23409473,86136)*()*(BM023,4
2D88209385,56136)*()*(BM088,2
2D65209069,46136)*()*(BM065,2
(*) The fields LZone (Landing Zone) and WPcom (Write Pre-comp) are not used by the Maxtor hard drive
and the values may be either 0 or the values set by the BIOS. All capacities listed in the above table are based
on 106or one million bytes.

PRODUCTDESCRIPTION
2 – 3
Logical Block Addressing
The Logical Block Address (LBA) mode can only be utilized in systems that support this form of translation.
The cylinder, head and sector geometry of the drive, as presented to the host, differs from the actual physical
geometry. The host AT computer may access a drive of set parameters: number of cylinders, heads and
sectors per track, plus cylinder, head and sector addresses. However, the drive can’t use these host parameters
directly because of zoned recording techniques. The drive translates the host parameters to a set of logical
internal addresses for data access.
The host drive geometry parameters are mapped into an LBA based on this formula:
LBA = (HSCA - 1) + HHDA x HSPT + HNHD x HSPT x HCYA (1)
= (HSCA - 1) + HSPT x (HHDA + HNHD x HCYA) (2)
where HSCA = Host Sector Address, HHDA = Host Head Address
HCYA = Host Cylinder Address, HNHD = Host Number of Heads
HSPT = Host Sectors per Track
The LBA is checked for violating the drive capacity. If it does not, the LBA is converted to physical drive
cylinder, head and sector values. The physical address is then used to access or store the data on the disk and
for other drive related operations.
Defect Management Zone (DMZ)
Each drive model has a fixed number of spare sectors per drive, all of which are located at the end of the
drive. Upon detection of a bad sector that has been reassigned, the next sequential sector is used.
For example, if sector 3 is flagged, data that would have been stored there is “pushed down” and recorded
in sector 4. Sector 4 then effectively becomes sector 3, as sequential sectors are “pushed down” across the
entire drive. The first spare sector makes up for the loss of sector 3, and so maintains the sequential order of
data. This push down method assures maximum performance.
On-the-Fly Hardware Error Correction Code (ECC)
33 bits, single burst, guaranteed
Software ECC Correction
81 bits, single burst, guaranteed
33 bits, double bursts, guaranteed
Automatic Park and Lock Operation
Immediately following power down, dynamic braking of the spinning disks delays momentarily allowing the
read/write heads to move to an inner mechanical stop. A small fixed magnet holds the rotary actuator in
place as the disk spins down. The rotary actuator is released only when power is again applied.

PRODUCTDESCRIPTION
2 – 4
Cache Management
Buffer Segmentation
The data buffer is organized into two segments: the data buffer and the micro controller scratch pad.
The data buffer is dynamically allocated for read and write data depending on the commands received.
A variable number of read and write buffers may exist at the same time.
Read-Ahead Mode
Normally, this mode is active. Following a read request, disk read-ahead begins on the first sector and
continues sequentially until the allocated buffer is full. If a read request is received during the read-ahead
operation, the buffer is examined to determine if the request is in the cache. If a cache hit occurs, read-
ahead mode continues without interruption and the host transfer begins immediately.
Automatic Write Reallocation (AWR)
This feature is part of the write cache and reduces the risk of data loss during deferred write operations. If a
disk error occurs during the disk write process, the disk task stops and the suspect sector is reallocated to a
pool of alternate sectors located at the end of the drive. Following reallocation, the disk write task continues
until it is complete.
Write Cache Stacking
Normally, this mode is active. Write cache mode accepts the host write data into the buffer until the buffer
is full or the host transfer is complete. A command complete interrupt is generated at the end of the transfer.
A disk write task begins to store the host data to disk. Host write commands continue to be accepted and
data transferred to the buffer until either the write command stack is full or the data buffer is full. The drive
may reorder write commands to optimize drive throughput.

PRODUCTDESCRIPTION
2 – 5
Major HDA Components
Drive Mechanism
A brush-less DC direct drive motor rotates the spindle at 5,400 RPM (±0.1%). The dynamically balanced
motor/spindle assembly ensures minimal mechanical run-out to the disks. A dynamic brake provides a fast
stop to the spindle motor upon power removal. The speed tolerance includes motor performance and motor
circuit tolerances.
Rotary Actuator
All DiamondMax™ 2880 drives employ a rotary voice coil actuator which consists of a moving coil, an
actuator arm assembly and stationary magnets. The actuator moves on a low-mass, low-friction center shaft.
The low friction contributes to fast access times and low power consumption.
Read/Write Electronics
An integrated circuit mounted within the sealed head disk assembly (near the read/write heads) provides up
to eight head selection (depending on the model), read pre-amplification and write drive circuitry.
Read/Write Heads and Media
Low mass, low force magneto-resistive read/write heads record data on 3.5-inch diameter disks. Maxtor uses
a sputtered thin film medium on all disks for DiamondMax 2880 drives.
Air Filtration System
All DiamondMax 2880 drives are assembled in a Class 100 controlled environment. Over the life of the drive,
a 0.1 micron filter and breather filter located within the sealed head disk assembly (HDA) maintain a clean
environment to the heads and disks. DiamondMax 2880 drives are designed to operate in a typical office
environment with minimum environmental control.
Microprocessor
The microprocessor controls the following functions for the drive electronics:
Command execution
Cache management
Data correction and error recovery
Diagnostic execution
Data sequencing
Head positioning (including error recovery)
Host interface
Index detection
Spin speed control
Seeks
Servo
S.M.A.R.T.

PRODUCTDESCRIPTION
2 – 6
NOITARUGIFNOCREPMUJ05J84J64J44J24J
evalS/retsaM
*metsysevirdelgnisnievirdylnO
*metsysevirdlaudnievirdretsaM
metsysevirdlaudnievirdevalS
C
C
O
tceleSelbaC
*delbasiD
delbanE
O
C
noitatimiLrednilyC2904
*delbasiD
delbanE
O
C
devreseRyrotcaFO
devreseRyrotcaF O
desolC=CtluafeD=*yeK
)dellatsnirepmuj( nepO=O )dellatsnirepmujon(
Figure 2-1
PCBA Jumper Location and Configuration
4092 Cylinder Limitation
On some older BIOS', primarily those that auto-configure the disk drive, a hang may occur when the drive
cylinder value exceeds 4096. The 4092 Cylinder Limitation jumper reduces the capacity in the Identify Drive to
4092 allowing large capacity drives to work with older BIOS'. A software driver is required to access the full
capacity of the drive.
Subsystem Configuration
Dual Drive Support
Two drives may be accessed via a common interface cable, using the same range of I/O addresses. The drives
are jumpered as device 0 or 1 (Master/Slave), and are selected by the drive select bit in the
Device/Head register of the task file.
All Task File registers are written in parallel to both drives. The interface processor on each drive decides
whether a command written to it should be executed; this depends on the type of command and which
drive is selected. Only the drive selected executes the command and activates the data bus in response to
host I/O reads; the drive not selected remains inactive.
A master/slave relationship exists between the two drives: device 0 is the master and device 1 the slave.
When J50 is closed (factory default, figure 2-1), the drive assumes the role of master; when open, the drive
acts as a slave. In single drive configurations, J50 must be closed.
Cable Select Option
CSEL (cable select) is an optional feature per ANSI ATA specification. Drives configured in a multiple drive
system are identified by CSEL’s value:
– If CSEL is grounded, then the drive address is 0.
– If CSEL is open, then the drive address is 1.
Jumper Location/Configuration
Darkened jumper pins indicate factory-installed (default) shunts.

PRODUCTSPECIFICATIONS
3 – 7
SECTION 3
Product Specifications
Models and Capacities
Performance Specifications
LEDOM 8D251197D800196D548096D048095D027095D846094D675094D015093D234092D882092D65209
ecafretnI/rellortnoCdetargetnI EDIE/4-ATA
dohteMgnidocnE 71/61LLR4RPE
evaelretnI 1:1
metsySovreS deddebmE
epyT/eziSreffuB BK652
S MARD
ecafruSrepsenoZataD 61
sdaeH/secafruSataD8
7
665544322
ytisneDlaireA ni/bM000,2
2
ecafruSrepskcarT )srednilyC( 220,01
ytisneDkcarT ipt008,9
ytisneDxulF 12-661
8 icfk
ytisneDgnidroceR 02-651
5 ipbk
kcolB/rotceSrepsetyB 215
kcarTrepsrotceS 02
0 3- 03
evirDrepsrotceS
656,015,22023,696,91460,415,61052,604,61656,860,41052,656,21823,552,11004,400,01299,044,8466,726,5000,000,5
LEDOM
8D251197D800196D468096D048095D027095D046094D675094D525093D234092D882092D65209
semiTkeeS )lacipyt(
1
kcart-ot-kcarT sm0.1<
egarevA sm0.9
mumixaM sm81<
ycnetaLegarevA sm65.5
deepSlanoitatoR )%1.0±( MPR004,5
daehrevOdnammoCrellortnoC .0<
5 sm
etaRrefsnarTataD
ecafretnImorf/oT
)2edoM-AMDartlU(
otpu
0.33 ces/BM
ecafretnImorf/oT
)2edoM-AMDdrow-itluM/4OIP(
ces/BM7.61otpu
aideMmorf/oT ces/BM2.51otpu
emiTtratS )ydaeRevirDot0( lacipytces0.9
1
dedulcnitondaehrevorellortnoC
Drive Configuration
LEDOM
8D251197D800196D548096D048095D027095D846094D675094D015093D234092D882092D65209
yticapaCdettamroF )edoMABLBM(
025,11080,01554,8004,8 7,2 00084,6067,5221,5023,4088,2065,2
01saetybagemenosenifedrotxaM
6
01saetybagigenodnasetybnoillimenoro
9
.setybnoillibenoro

PRODUCTSPECIFICATIONS
3 – 8
Physical Dimensions
Figure 3 - 1
Outline and Mounting Dimensions
RETEMARAPDRADNATSCIRTEM
thgieHhcni20.1sretemillim9.52
htgneLsehcni77.5sretemillim6.641
htdiWsehcni20.4sretemillim1.201
thgieWsdnuop3.1smargolik95.0

PRODUCTSPECIFICATIONS
3 – 9
Power Requirements (Average)
Power Mode Definitions
Spin-up
The drive is spinning up following initial application of power and has not yet reached full speed.
Seek
A random access operation by the disk drive.
Read/Write
Data is being read from or written to the drive.
Idle
The drive is spinning, the actuator is parked and powered off and all other circuitry is powered on.
The drive is capable of responding to read commands within 40 ms.
Standby
The spin motor is not spinning. The drive will leave this mode upon receipt of a command that requires
disk access. The time-out value for this mode is programmable. The buffer is active to accept write data.
Sleep
This is the lowest power state – with the interface set to inactive. A software or hardware reset is required
to return the drive to the Standby state.
EPA Energy Star Compliance
Maxtor Corporation supports the goals of the U.S. Environmental Protection Agency’s Energy Star program
to reduce the electrical power consumption of computer equipment.
Environmental Limits
RETEMARAPGNITAREPOEGAROTS/GNITAREPO-NON
erutarepmeTC°55otC°5 .3.205dohtem,E018-DTS-LIMrep)C°04-(erutarepmetwol
,3.105dohtem,E018-DTS-LIMrep)C°17(erutarepmethgih
.snoitidnocdecudni-toh;yrogetaccitamilc
tneidarGlamrehT (ruohrepC°52 )mumixam
ytidimuHevitaleR %59ot%5 gnisnednoc-non( )
bluBteW 72°C )mumixam(
edutitlAteef000,01ot002-
gnirruccoyllarutanynahtiw(
nihtiwetarytidimuhdnaerutarepmet
)egnarsiht
tset)edutitla(erusserpwol,3.005dohtem,E018-DTS-LIMreP
ogractfarcriatropsnart,2noitidnoctset;egarots.Ierudecorp
.erusserptnemtrapmoc
esioNcitsuocA )edomeldI( rewopdnuosegarevaABd63
)enohporcim01,9777OSIrep(
EDOM%8±V21%5±V5REWOP
pu-nipS )kaep( Am0061Am002W2.02
keeSAm026Am033W0.9
etirW/daeRAm512Am053W3.4
eldIAm542Am522W1.4
ybdnatSAm7Am542W3.1
peelSAm7Am041W8.0

PRODUCTSPECIFICATIONS
3 – 10
Reliability Specifications
AFR
< 1.7% The annualized average failure rate (AFR) applies to the period prior
to the expiration of component design life, and is based on failures
chargeable to Maxtor.
MTBF
> 500,000 hours Maxtor does not differentiate between various usage profiles (e.g.,
power-on hours, power saving modes, non-operating periods or
operating temperatures within the published specification.)
Quality Acceptance Rate
TBD (< 1,500 DPPM) The quality acceptance rate indicates the percentage of Maxtor
products successfully installed by our customers, and/or the number
of defective parts per million (DPPM) encountered during the entire
installation process.
Start/Stop Cycles
50,000 (minimum) This indicates the minimum cycles for reliable start/stop function at a
≥60% confidence level.
Data Reliability
< 1 per 1014 bits read Data errors (non-recoverable). Average data error rate allowed with all
error recovery features activated.
Component Design Life
5 years (minimum) Component design life is defined as a.) the time period before
identified wear-out mechanisms impact the failure rate, or b.) the time
period up to the wear-out point when useful component life expires.
Shock and Vibration
RETEMARAPGNITAREPOGNITAREPO-NON
kcohSlacinahceMsrorreon,sm0.2,sG02 egamadon,sm0.2,sG002
noitarbiVmodnaRcisab,4.415dohtem,E018-DTS-LIMreP
.eliforpDSPsixalacitrev,noitatropsnart
G400.0tazH003-01
2
zH/
G6000.0tazH005-103
2
zH/
G510.0tazH01
2
zH/
G510.0tazH04
2
zH/
G51000.0tazH005
2
zH/
noitarbiVeniStpewS
zH02-5
zH003-12
edutilpmaelbuodsehcni940.0
)kaep-0(edutilpmakaepG0.1

PRODUCTSPECIFICATIONS
3 – 11
EMC/EMI
Radiated Electromagnetic Field Emissions - EMC Compliance
The hard disk drive mechanism is designed as a subassembly for installation into a suitable enclosure and is
therefore not subject to Subpart J of Part 15 of FCC Rules (47CFR15) or the Canadian Department of
Communications Radio Interference Regulations. Although not required, the disk mechanism has been
tested within a suitable end-use product and found to comply with Class B limits of the FCC Rules and
Regulations of the Canadian Department of Communications.
The CE Marking indicates conformity with the European Union Low Voltage Directive (73/23/EEC) when
the disk mechanism is installed in a typical personal computer. Maxtor recommends that testing and analysis
for EMC compliance be performed with the disk mechanism installed within the user's end-use application.
Canadian Emissions Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set
out in the radio interference regulations of the Canadian department of communications.
Le present appareil numerique n'emet pas de bruit radioelectriques depassant les limites applicables aux
appareils numeriques de Class B prescrites dans le reglement sur le brouillage radioelectrique edicte par le
ministere des communications du Canada.
Radiated Magnetic Field Emissions
Minimum of VDE Class B and MIL-STD-461/462, Method RE01 (stand-alone test configuration).
Radiated Electromagnetic Field Immunity
IEC 801-3, Class 2 compliance.
Radiated Magnetic Field Immunity
Per MIL-STD-461/462, Method RD01(15 Hz to 100 kHz, stand-alone test configuration).
Standard Test Methods
Traditional hard drive specifications are open to incorrect interpretation, but internationally recognized standard
test methods accurately measure how products perform in real-world conditions. These methods have gained
worldwide acceptance since they reflect actual environments, have well-defined test requirements, are easily
understood and provide repeatable results. They objectively demonstrate to our customers the reliable, durable
design of Maxtor hard drives. Each international test specification provides the basic method and condition
information needed for reference by a knowledgeable Test and Qualification Engineer.
Acoustic specifications such as sound pressure are misleading because the test methods used are not controlled
by recognizable standards. The sound pressure measurement itself is the least meaningful indicator of noise
emissions as it relates to the human ear. The specification of sound power, loudness and sharpness are
considered the most accurate acoustic measurement methodologies recognized by the leading acoustic
measurement experts. ISO 7779, sound power, is a repeatable test method providing results reproducible in any
properly equipped acoustic lab.
Safety Regulatory Compliance
All Maxtor DiamondMax™ 2880 drives comply with relevant product safety standards such as CE, CUL, TUV
and UL rules and regulations. As delivered, DiamondMax 2880 hard disk drives are designed for system
integration before they are used.

INSTALLATION
4 – 12
SECTION 4
Handling and Installation
Pre-formatted Drive
This Maxtor hard drive has been formatted at the factory. Do not use a low-level formatting program.
Important Notice
There are a number of system BIOS’s currently in use which do not support hard drives with more than 4095
cylinders (2.1 gigabytes). This section contains information describing the conditions which may identify this
limitation. In order to obtain the full capacity of your Maxtor drive, you will need to follow the recommended
installation instructions.
Hard Drive Handling Precautions
◆During handling, NEVER drop, jar, or bump a drive. Handle the drive by its sides and avoid touching the printed circuit
board assembly (PCBA).
◆Hard drives are sensitive to electrostatic discharge (ESD) damage. Use proper ESD practices by grounding yourself
and the computer system the hard drive will be installed in.
◆Allow the hard drive to reach room temperature BEFORE installing it in your computer system.
◆ NEVER switch DC power onto the drive by plugging an electrically live DC source cable into the drive's connector.
NEVER connect a live connector to the hard drive's IDE interface connector.
Electro-Static Discharge (ESD)
To avoid some of the problems associated with ESD, Maxtor advises that anyone handling a disk drive use a
wrist strap with an attached wire connected to an earth ground. Failure to observe these precautions voids the
product warranty.
Manufacturers frequently experience “unsolved” component/hardware malfunctions often caused by ESD. To
reduce the incidence of ESD-related problems, Maxtor recommends that any electronics manufacturing plans
include a comprehensive ESD program, the basic elements and functions of which are outlined here:
ESD Program Element ESD Program Function
Management Institute and maintain
Chief coordinator Organize and enforce
Multi-department committee Evaluate and improve
Employee training Educate and inform
ESD program supplies typically include: wrist- and foot-worn grounding straps; counter-top and floor antistatic
matting; wrist strap testers; ESD video and training materials. Sources for such supplies include:
Static Control Systems – 3M Charleswater
225-4S, 3M Center 93 Border St.
St. Paul, MN 55144 West Newton, MA 02165-9990
Maxtor also offers a complete video training package, “Care and Handling of Maxtor Disk Drives.”
Contact your Maxtor representative for details.

INSTALLATION
4 – 13
Unpacking and Inspection
Retain any packing material for reuse. Inspect the shipping container for evidence of damage in transit. Notify
the carrier immediately in case of damage to the shipping container.
As they are removed, inspect drives for evidence of shipping damage or loose hardware. If a drive is damaged
(and no container damage is evident), notify Maxtor immediately for drive disposition.
Figure 4 - 1
Multi-pack Shipping Container

INSTALLATION
4 – 14
Figure 4 - 2
Single Pack Shipping Container (Option A)
Figure 4 - 3
Single Pack Shipping Container (Option B)
Repacking
If a Maxtor drive requires return, repack it using Maxtor packing materials, including the antistatic bag.
Physical Installation
Recommended Mounting Configuration
The DiamondMax™ 2880 drive design allows greater shock tolerance than that afforded by larger, heavier
drives. The drive may be mounted in any attitude using four size 6-32 screws with 1/8-inch maximum
penetration and a maximum torque of 5-inch pounds. See Figure 3-1 for mounting dimensions. Allow
adequate ventilation to the drive to ensure reliable operation.

INSTALLATION
4 – 15
1Before You Begin
IMPORTANT – PLEASE READ !
Please read this Installation Sheet completely before installing the Maxtor hard drive. It gives general information for installing a Maxtor hard drive in a
typical computer system. If you don’t understand the installation steps, have a qualified computer technician install the hard drive. DO NOT use any low-level
formatting software on this drive.
Handling Precautions


 Allow the hard drive to reach room temperature
BEFORE installing it in your computer system.
쇵쇵
쇵쇵
쇵 Hard drives are sensitive to electrostatic discharge (ESD) damage.
Handle the drive by its sides. DO NOT touch the printed circuit board assembly.
ᏜᏜ
ᏜᏜ
Ꮬ
NEVER drop, jar, or bump the drive.
ᏜᏜ
ᏜᏜ
Ꮬ
DON’T connect/disconnect any drive cables when the power is on.
Tools for Installation
The following tools are needed to complete the installation of your Maxtor hard drive:
◆For drive capacities 8.4 GB or less, a DOS 5.0
(or higher) or Windows 95 bootable system
diskette
◆For drive capacities greater than 8.4 GB,
a Windows 95 bootable system diskette
◆A small (#2) Phillips head screw driver
◆Small needle-nose pliers or tweezers
◆Your computer user’s manual
Capacity Barriers
Due to operating system limitations, DOS cannot access the full capacity of drives larger than 8.4 GB. The Microsoft Windows 95 operating system or
equivalent (full installation), NOT a Windows 95 upgrade from DOS (Windows 3.1 or 3.11), is required to obtain the full capacity of any hard drive larger
than 8.4 GB.
Protecting Your Existing Data
Have you backed up your hard disk?
Periodic backup of important data is always a good idea. Whenever your computer is on, there is the potential for losing data on your hard drive. This is
especially true when running disk utilities or any software that directly manipulates your files. Maxtor recommends that you make a backup copy of the
files on any existing hard drives. If required, this data may then be copied to the Maxtor hard drive after it has been installed in your computer. Refer to your
computer user’s manual for detailed data backup instructions.
Capacity Calculations
Maxtor defines one megabyte as 106or one million bytes (1,000,000) and one gigabyte as 109or one billion bytes (1,000,000,000).
FDISK, CHKDSK, Windows, BIOS and hard drive manufacturers may show different capacity values for the hard drive as they use different methods and
numbering systems to calculate hard drive capacities. The two most common numeric representations of the hard drive capacity are presented in the base 10
(decimal) and base 2 (binary) numbering systems.
The formula to calculate the capacity of a drive is: Cylinders * Heads * Sectors * 512
This is a decimal number representing the total number of bytes (characters) that can be stored on the hard drive. To convert this number to binary megabytes
(MB) or gigabytes (GB), this value must be divided by the decimal value of a binary MB or GB. The decimal equivalent of 1 MB (220) is 1,048,576 and 1 GB (230) is
1,073,741,824.
Example for a 3.5 GB hard drive:
6,800 * 16 * 63 * 512 = 3,509,452,800 bytes or 3.5 GB using 106 or decimal values.
The equivalent in binary MB is 3,509,452,800 / 1,048,576 = 3,346 MB.
The equivalent in binary GB is 3,509,452,800 / 1,073,741,824 = 3,268 GB.
