Maxxtools PH09-S-P User manual

Model: PH09-S-P
WARNING: FOR OUTDOOR USE ONLY
INSTRUCTION MANUAL

OUTDOOR HEATER PARTS LIST
PARTS NAME QUANTITY
WINNING NUT 1
MESH GUARD 1
NUT 4
BURNER 1
HANDLE 1
TANK HOUSING 1
HOSE and REGULATOR 1
M5X10MM BOLT and NUT 8
WHEEL 1
M8X16 BOLT 4
BASE 1
STEEL CONNECTOR 1
Tools Required
Phillips head screwdriver
2 adjustable spanners
Note: Remove any transit
protection material
STEP 1
STEP 2
STEP 3
STEP 4
AREA HEATER ASSEMBLY
Attach wheel assembly to base
with two M8X16mm bolt and
nut..
Assemble the tank on the base
with four M8 x 16mm and eight
M5X10mm bolt and nut..
Put the burner on the tank,
assemble the burner on the tank
with four M4X8mm bolt and nut.
Put the mesh guard around the
burner, the side with door should
be face with the ignite. Fix the
mesh guard in the hole on the
tank with M4 nut.
STEP 5
Assemble the handle on the same
side with wheel, use two M6 bolt
and nut.
STEP 6
Screw the butterfly nut on the
top of mesh guard.
TANK
WHEEL
STEEL
CONNECTOR
BASE
MESH GUARD
WINNING NUT
M5x10mm
BOLT AND NUTS
M8x16mm
BOLT
NUT
BURNER
TANK HOUSING
HOSE AND
RESULATOR
HANDLE
