MAXXUS 4.2i
Treadmill
INSTALLATION & OPERATING MANUAL

2 3
Index 2
Safety Instructions 3
Overview of the Device 4
Assembly Material and Tools 4
Scope of Delivery 4
Assembly 5 – 6
Folding Mechanism 6 – 7
Transport 8
Mains Cable 9
Safety Key 9
What to do in an Emergency 10
Care, Cleaning & Maintenance 11
Lubricating the Treadmill Belt 12
Adjusting the Treadmill Belt 13
Re-Tensioning the Treadmill Belt 13
Cockpit 14 – 20
Heart Rate Measurement 21
Warning about Pulse and Heart Rate Monitoring 22
Pulse Monitoring using Hand Sensors 22
Heart Rate Monitoring using a Chest Belt 22
Training Recommendations 23 – 24
Technical Details 25
Disposal 25
Recommended Accessories 25
Explosion Drawing 26
Parts List 27 – 28
Warranty 29
Repairs Contract / Notication of Damage Claim 30
Notes 31
© 2015 by MAXXUS Group GmbH & Co. KG
All rights reserved
This publication may not be reproduced, stored in retrieval system, or transmitted on whole or in part, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written permission of Maxxus Group GmbH & Co. KG.
Errors, colour and technical modication subject to change, reproduction as well as electronic duplication only with written permission of MAXXUS Group GmbH & Co. KG.
Safety InstructionsIndex
Please read and observe all sections of this Operating Manual. Thorough attention should be paid to the safety, service and
maintenance instructions and adherence to the given training information at all times.
It is very important to adhere strictly to the service and maintenance instructions contained in this Manual.
This training device is only to be used for it‘s intented purpose.
If this equipment is used for any other purposes than intended, there will be a possible risk of accident, damage to health or
damage to the training device. The Distributor cannot be held responsible in this case.
Electrical Connection
−A mains voltage of 220-230V is required to operate this training device.
−The training device is only to be connected to the mains with the mains cable supplied using a 16A individually fused
and earthed socket installed by a qualied electrician.
− The training device is only to be switched on and o󰀨 using the ON/OFF switch.
−Always remove the electric plug from the socket before moving the training device.
−Remove the electric plug from the socket before commencing any cleaning, maintenance or other works.
−Do not connect the mains plug to a socket on a socket strip or on a cable drum.
−If using a cable extension please ensure that this complies with VDE guidelines and regulations.
−Always place the mains cable so it cannot be damaged or cause a tripping hazard.
−In operating or standby mode, electrical devices such as mobile phones, PCs, Televisions (LCD, plasma, tube, etc.),
game consoles etc. will emit electro-magnetic radiation. For this reason, all these types of devices should be kept
away from your training device as they could lead to malfunction, disturbances or false outputs being shown in heart
rate measurements.
Training Environment
−Select a suitable space for your training device to provide an optimum amount of free space and highest level of safe-
ty. You should leave a free space of at least 200 cm long and 100 cm wide behind the training device. A minimum of
100 cm free space to each side and in front of the training device should be allowed for.
−Make sure that the area is well ventilated and that an optimum amount of oxygen is available during training. Avoid
drafts.
−Your training device is not suitable for outside use and so storage and training can only take place in a temperate, dry
and clean room.
−Operation and storage of your training device in wet areas such as in swimmingpools, saunas etc. is not possible.
− Make sure that your training device is is kept on at, hard and clean ground both in operation and at stillstand. Any
uneven surfaces must be romoved or made good.
− It is recommended that a oor covering (carpet, mat, etc.) should be placed under the device to protect damageable
oors such as wood, laminates, oor tiles etc. Please ensure that this underlay cannot slip or slide.
−Do not put this training device on pale or white coloured carpets or rugs as the feet of the device may leave marks.
−Make sure that your training device and mains cable are kept out of contact with hot items and are kept at a safe dis-
tance from any sources of heat eg. central heating, hot stoves, furnaces, ovens or open res.
Personal Safety Instructions for Training
−The safety key must be inserted correctly before each training session can begin.
−Remove the safety key and mains cable from the training device when not in use to avoid inappropriate or uncontrolled
use by any other third party, eg. children.
− Stop training immediately if you feel physically unwell or are experiencing any breathing di󰀩culties.
−Always start your training session at a low workload increasing it slowly but steadily throughout. Reduce the workload
again towards the end of your training session.
−Suitable sports shoes and clothes should always be worn during training sessions. Make sure that loose clothes do not
get caught up in the treadmill belt or rollers.
−Your training device is only to be used by one person at a time.
− Check each time before a training session to see if your device is in perfect condition. Never use your training device if
it is faulty or defect.
−You are only permitted to carry out repairs to the device yourself after having contacted our Service Department and
on receipt of explicit permission to do so. Only original spare parts may be used at any time.
−Your training device must be cleaned after each use. Remove all dirt including body sweat or any other liquids.
−Always make sure that liquids (drinks, body sweat, etc.) do not get into the vibrating plate or into the cockpit as this can
cause damage to the mechanical and electronic components.
−Your training device is not suitable to be used by children.
−Third parties, in particular children and animals, must be kept at an appropriate safety distance during training.
−Check before each training session if there are any items underneath the training device and remove them without fail.
Never use the training device when items are underneath it.
−Do not allow children to misuse your training device as a toy or climbing frame at any time.
−Ensure that no body parts of your own or other third parties ever come into contact with any of the moving mecha-
nisms.
The construction of this training device is based on state of the art technology and highest modern technical safety stand-
ards. This training device is to be used by adults only!
Extreme misuse and/or unplanned training can cause damage to your health!

M
8X
65
M
8
X65
M
8X
65
M
8X
65
M8X15
M8x50
4R
4L
M8x15
4 5
Overview of the Device Assembly
Carefully unpack all delivered parts. Have someone there to help you as some of the training device parts are bulky and
heavy.
Check that all the parts and xing materials (screws, nuts, etc.) have been delivered.
Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of assembly are not
covered by the warranty or guarantee. Therefore, read through the assembly instructions carefully before you start assem-
bling, follow each assembly step exactly as described and keep to the correct sequence of assembly as instructed.
Assembly of the training device must be carried out thoroughly by an adult person only.
Assemble the training device in a location which is level, clean and clear of obstructions.2 people are required to carry out
the assembly.
Training can only start when the training device has been fully assembled.
Step 1:
Lift both upright side frames (4L / 4R) simultaneously until they are pressed into the bearings on the base frame. The bore-
holes on the side frames should be in line with the boreholes on the base frame.
Screw in two socket head screws M8x50 at each side of the frame (4L/4R) and one M8x15 socket head screw at the front
of each side of the frame.
Assembly Material & Tools
Scope of Delivery
Foot Rail
Hand Pulse Sensor
Cockpit
Safety Key
Side Frames
Storage Pocket
Motor Housing
Running Deck
If preferred, the tools supplied may be supplemented or replaced by your own tools.
Make sure that each tools are an exact tting to the parts.
Socket Head Screw
M8x50
2 Pieces
Socket Head Screw
M8x15
4 Pieces
Spanner for Socket Head
Screw S6
Allen Key
Base Frame
Tablet-PC Holder
Safety Key
Maintenance Oil
Set of Screws

M8x15
4R
4L
6 7
Assembly Folding Mechanism
Step 2:
Lift the cockpit up and x it with an oval socket head screw M8x15 on both sides of the frame (4L/4R).
Folding Mechanism
Step 3:
Fix the tablet holder on the front of the cockpit below the display.
Hydraulic Cylinder
The folding mechanism consists of a high pressure hydraulic cylinder lled with oil. If the cylinder becomes damaged, then
the safety of the folding system is no longer guaranteed. It is vital in this case to replace the damaged hydraulic cylinder
before lifting the treadmill deck again.
This treadmill is equipped with a folding mechanism. To save space fold the
treadmill deck up and down as follows:
Folding up the Treadmill Deck
Step 1:
Make sure that the deck incline level is at “0”, switch the treadmill
o󰀨 at the main switch and remove the mains plug from the socket.
WARNING:
Never fold up the treadmill deck without ensuring that the incline
is on level “0” and the treadmill is switched o󰀨.
Step 2:
Hold onto the rear end of the treadmill deck and lift it upwards.
Make sure that you are standing with your feet rmly on the
ground.
Step 3:
Push up the deck until you hear it lock into the catch.
Check that it is locked safely in the upright position by gently
shaking the deck.
Folding Down the Treadmill Deck
Step 1:
Take hold of the rear end of the deck with both hands. Press
down the safety lever on the catch with your foot to release the
lock. Pull the treadmill deck down gently to the oor.
Step 2:
The treadmill deck is equipped with a Soft-Fold-System
This allows the deck to move slowly down until it reaches contact
with the oor. You should never leave the deck to fold down
unsupervised.
WARNING:
Never allow children to fold up or fold down the treadmill.
Always make sure that there are no items or living beings under
the treadmill deck whilst it is being raised or lowered.
Hydraulic Cylinder

Clip
Safety Key
8 9
Transport
When folded, the treadmill can be moved easily and without much
e󰀨ort.
Move the treadmill as follows:
Step 1:
Fold up the treadmill as instructed in the “Folding Mechanism”
section
Take hold of the top ends of the deck on both sides with your left
and right hands and pull the deck towards you until the weight of
the deck is resting
on the transport rollers.
Make sure that you are standing with your feet rmly on the
ground.
Step 2:
The treadmill can now be moved easily and without much e󰀨ort.
Make sure that there are no items or living beings in the way
when you are moving the treadmill.
Make sure that your feet are steadily on the ground when moving
the treadmill.
Step 3:
To set the treadmill safely down again, lift the deck right up until
the front frame base is completely on the ground.
WARNING:
The treadmill should only be moved by an adult.
Mains Cable
Mains Cable
Connect the mains plug on the mains cable to an electrical sock-
et.
This device is only to be connected to an earthed socket installed
by a qualied electrician. Do not use a socket strip to connect
the treadmill belt. If an extension cable is required, then it must
comply with VDE regulations and guidelines.
Main Switch
The main switch is located next to the mains connection on the
front of the treadmill. Use this switch to turn the treadmill on and
o󰀨.
Switch position „I“ = treadmill turned on.
Main Switch position „0“ = treadmill turned o󰀨
Fault-Current Button Switch
Main Switch
Fault-Current Switch (depending on the model)
There is a fault-current button-switch next to the main switch on the front of the motor cover to prevent the treadmill from
being damaged by electrical surges in the network. This button-switch is triggered o󰀨 by if a surge in the electrical supply
occurs and acts as a circuit breaker. In this case the treadmill will be completely switched o󰀨. If this occurs, switch o󰀨 the
treadmill at the main switch, and pull the mains cable out of the socket with the plug. Press the button on the fault-current
switch back in. Re-connect the mains cable with the plug and switch the treadmill back on at the main switch.
Fuse (depending on the model)
There fuse next to the main switch on the front of the motor cover to prevent the treadmill from being damaged by electrical
surges which can occur in the network. In this case the treadmill will be completely switched o󰀨. If this occurs, switch o󰀨 the
treadmill at the main switch, and pull the mains cable out of the socket with the plug. Check the fuse and replace it if neces-
sary. Re-connect the mains cable with the plug and switch the treadmill back on at the main switch.
Safety Key
The treadmill will only operate if the safety key is correctly in
contact with contact point in the cockpit. The treadmill will stop
automatically if the safety key is no longer in contact. Before
each training session make sure to attach the safety key to
your clothing with the clip.If you either want to stop the treadmill
quickly, cannot keep up with the speed, or any other emergency
arises, pull the string to remove the safety key out of the cockpit.
If the safety key is connected to your clothing it will automati-
cally be pulled out of the cockpit if you fall. It is therefore vital to
make sure that the clip is securely fastened to your clothing and
cannot somehow be pulled o󰀨. Adjust the length of the string to
hang down losely during training. It is not possible to operate the
treadmill without the safety key being correctly inserted. Always
remove the saftey key when your treadmill is not in use to ensure
that it cannot be used by any other third party, for example by
children, without your permission or unsupervised.
The treadmill will stop automatically if the safety key is pulled out
of the cockpit during training. The incline will remain in the adjust-
ed position and can only be lowered after the safety key has been
re-connected.
Safety Key

10 11
Care, Cleaning and Maintenance
WARNING
Turn o󰀨 your training device and remove the plug from the mains before you carry out any maintenance, cleaning, servic-
ing, repairs or similar on your training device. Check without fail that your device is completely disconnected from the mains
and turned o󰀨 before you start with any work. Only reconnect your training device back to the mains when all works are
completed and the device has been completely put back together again.
Before re-starting the training device or before starting it back up again after a longer training
break interval
Make sure that the treadmill is standing rmly on the ground. There should be no items on or underneath the device. Check
that there is an even lm of lubricant (silicon) on the treadmell deck. If this is not the case, then apply a lm of silicon provid-
ed by the distributor.
Service and Cleaning Intervals:
Clean the treadmill belt each time after training with a damp cloth to remove any sweat and or liquids. Do not use solvents.
Dry o󰀨 the cleaned areas thoroughly.
Treadmill Belt Lubrication Check: 1 x per Week
If the lubrication is not su󰀩cient, lubricate it immediately and adapt the interval between checks accordingly. The lubrica-
tion checks require to be done more often at shorter intervals. If the device has a folding mechanism and has been left in a
folded position for a long period of time, check to see if it is lubricated su󰀩ciently.
Belt Track Check: 1 x per Week
The belt track must be checked reularly. If the belt is running o󰀨 to one side, this should be corrected immediately. Find and
read the appropriate instructions on how to do this in this Manual.
Cleaning the Motor Compartment: 1 x per Month
To clean the motor compartment undo the screws on the motor cover and lift it up.
WARNING: Only do this if the training device is switched o󰀨 and the plug on the mains cable is removed from the socket.
Remove all visible dust with a small vacuum cleaner nozzle. Do not under any circumstances use any cleaning liquids or
compressed air.
Fixing Materials Check: 1 x per Month
Check the screws, nuts and bolts at least once a month and tighten them if necessary.
Why is maintenance work on my treadmill so important?
In order to have long term enjoyment with your treadmill it is important to carry out some basic maintenance on a regular
and thorough basis. The required intervals depend strongly on how much your training is used. For this reason, the mainte-
nance may need to be carried out at much shorter intervals than the ones recommended.
What can happen if maintenance works are not done properly?
When in use friction is caused between the treadmill belt and the deck. Any type of friction causes wear and will reduce
the service life of your training device. Friction is reduced by lubricating between the deck and the belt and this in turn will
increase the service life of the treadmill. If the belt is run with too little lubrication, signicant heat will be produced on the
running deck. The surface of the deck and the running belt will get damaged. Friction may then become so high that a static
charge may occur and it is highly likely that, if touched, it can be discharged via the frame into the body. This is not only
very unpleasant but it can also destroy the electronic components in the treadmill.
Why do I have to clean the motor compartment?
Movement of the treadmill belt and motor ventilator cause the belt to draw in dust from the enviroment. Dust will gather both
underneath and in the device. At some point so much dust could collect in the device to cause a short-circuit in the electron-
ic components. To avoid this happening, it is necessary to clean the device regularly.
Damages caused by failure or lack of maintenance and care are excluded from the warranty
and guarantee.
The costs of repairing an training device which has not been properly maintained can very quickly amount to several hun-
dred Euro.
A high price which can be avoided by carrying out regular care and maintenance.
Safety Distance
Safety Distance
Select a suitable place to keep your training device with a free safety area space of at least 200 cm long and 100 cm wide
behind the training device. Furthermore, during training, a safety distance down the length of the treadmill with a minimum
width of 100 cm should be kept to the right and/or lefthand side of the treadmill.
What to do in an Emergency
Stop training immediately if you realise that you cannot keep up with the pace, if you start feeling sick or if any other emer-
gency situation arises, pull the safety key out with the string to make an emergency stop.
Hold on rmly with both hands onto the handrails and place your feet on each side of the tread belt.
If you trip during training, hold onto the handrails immediately with both hands, support yourself with your hands and arms
on the handrails and put your feet on the footrails on either side of the belt.
You should practice this several times so that you will know what to do if an emergency situation arises.
Wear the safety key every time you use the treadmill. Make sure that all third parties are familiar with the safety instructions
and that they always use the safety key correctly whilst they are training!

g
g
12 13
Adjusting the Treadmill Belt
The treadmill belt must always be switched o󰀨 with the mains cable plug removed from the socket before starting any mainte-
nance, cleaning, repairs or any other works!
Lubricating the Treadmill Belt
The most important maintencance work to do to a treadmill is regular and timely lubrication and care and mainte-
nance of the belt. Damages or defects caused by failure or lack of maintenance and care are in no way covered by
the warranty or guarantee.
The treadmill belt must always be lubricated if a signicant increase of friction is detected. This will become apparent if the
belt makes jerking movements during training or if fault message E1 appears in the display on the cockpit.
Insu󰀩cient lubrication or care and the resulting increase in friction will inevitably lead to an increase in wear and cause
damage to the treadmill belt, deck, motor and circuit board.
How often you use the treadmill will generally determin how often you have to carry out the maintenance measures. As this
varies from person to person, we would recommend that you keep a maintenance book. You should set a specic day every
week in the rst 6 months of use to check the treadmill belt lubrication. Lift up the front third part of the belt and feel with
your hand if there is still lubrication in the middle of the belt. If lubrication is present then write „ok“ next to the date in your
maintenance book. If there is little or no lubrication present then lubricate the belt and write this down in your maintenance
book accordingly. In time it will be possible to see at what time intervals lubrication is required.
Even if you do not want to keep a maintenance book, you must check the lubrication of the the treadmill belt
at least once a week!
If the treadmill is not used, of the treadmill remains folded-up for some longer period of time you must check the lubrication
of the belt before use and lubricate it if necessary.
To achieve optimum lubrication of the belt use the MAXXUS maintenance oil bottle, remove the normal screw bottle top (Di-
agram 1) and screw on the thin tube top (Diagram 2). Before lubricating the belt, make sure that the treadmill is switched-o󰀨
and that the belt is no longer moving. Lift up the belt (Diagram 3).
The belt should be lubricated from both sides. Lift up the belt from one side high enough so that you can reach the middle
of the belt with the end of the thin tube on the silicone oil bottle. Apply a wavey line of silicone oil from the middle of the belt
towards the sides. You should apply three to four lines of silicone oil running from the middle of the belt to the sides. At each
lubrication process you should not apply more than 10 to max 20ml of silicone oil. If too much silicon is applied this may
lead to the treadmill belt slipping through. In this case remove the excess oil from the deck and drive rollers with a dry cloth.
Only use the silicone bottle supplied or MAXXUS® maintenance oil
(available from www.maxxus.de) to lubricate the treadmill belt.
Do not at any time use any other types of silicone or lubricants! After completing a lubrication process, walk and run on the
treadmill with the belt running at a speed of 3 - 4 km/h for approx. 3 to 5 minutes. Whilst doing this, change your position
constantly from left to right and in the middle of the belt to distribute the silicone oil well.
Following lubrication do not fold up the treadmill for at least 3 days.
Motor Housing
Centre of the
running deck
Diagram 1 Diagram 2 Diagram 3
Diagram 4
Area to lubricate
Treadmill deck Treadmill belt
Back rollers
To achieve as long a service life as possible, the belt should always be kept
running straight and in the middle of the deck. Check therefore before each
training session if the belt is straight and running in the middle of the deck or
if it has changed position. Possible reasons for it changing position are:
−The ground on which the treadmill is standing is either uneven or at an
incline.
−Personal running style (eg. distribution of weight to one side, in or out-
turned feet etc)
The treadmill belt can be adjusted in the following way:
1. Start-up the treadmill belt and let it run at a constant speed of 4 km/h.
2.1 If the belt is running towards the left, turn the left adjustment screw
located at the back end of the belt by 1/8 turn clockwise and the right
adjustment screw 1/8 turn anti-clockwise. Wait for a short while to see
the results as this will not immediately be apparent.
The running direction of the belt will already be changed with a turn of
1/8 of the adjustment screw. Therefore, only adjust the screws a little at
a time.
2.2 If the belt is running towards the right, turn the right adjustment screw
by
1/8 turn clockwise and the left adjustment screw 1/8 turn anti-clockwise.
3. If the belt is now running in the middle of the deck, the adjustment will
be correct. If this is still not the case, repeat the steps described in 2.1
and 2.2 until the belt is running in the middle.
If the belt cannot be adjusted, please contact a specialist immediately.
If the belt has become so displaced that it is rubbing along one the foot
rails, this will cause interferences and defects to the treadmill belt. Dam-
ages caused by failure or insu󰀩cient adjustments to be made to the
treadmill belt will not be covered by the warranty or guarantee without
fail.
If the belt is slipping on the drive rollers during operation (this will be made
apparent by the belt jolting noticeably during running) the belt requires to be
retensioned. The belt is retensioned using the same adjustment screws as
when adjusting the belt.
1. Start-up the treadmill belt and let it run at a constant speed of 4 km/h.
2. Turn one adjustment screw after the other by 1/8 of a turn in a clockwise
direction.
3. Try to slow down the belt by walking on it as if you are walking down a
steep slope. If the front roller is stll turning through, repeat the tension-
ing process once again. The treadmill belt should be tensioned so that
the front roller only turns through with heavy braking.
Re-tensioning the Treadmill Belt

14 15
One-Touch Keys
Your treadmill cockpit has one-touch keys to adjust the incline and speed.
With these one-touch keys you can quickly and easily select specica speeds and inclines.
Handrail Control
The handrails are tted with control keys for speed and incline and with these you can regulate
the speed and incline.
STOP Key
Stops and ends the current training session.
START Key
Starts the quick-start function or the selected training program.
Pause Function:
The belt can be stopped during training by pressing the START key once. The cockpit switches the treadmill into Pause Mode for 5
minutes. When the START key is pressed again, the training session will continue from the same place it was stopped.
After a 5 minute pause the cockpit will automatically reset all values to zero.
If you wish to continue your training session from pause mode, simply press the START key again.
PROGRAM Key (P)
Key to select the programs.
MODE Key (M)
Key to select the training guidlines
Heart Rate Monitoring
Your treadmill cockpit is tted with a Polar compatible receiver as a standard tting for use
with an uncoded, Polar compatible chest belt. Chest belts are available as an accessory.
Hand Pulse Sensors
For short term monitoring of the pulse. Please do not take hold of the hand sensors whilst wearing
a chest belt as this can cause faulty monitoring.
Switching-On the Treadmill
Connect the the mains plug on the mains cable to a 16A single fused socket installed by a qualied
electrician. Switch the treadmill belt on using the On/O󰀨 Key. This can be found on the rear of the motor housing.
Standby Mode
If the treadmill is not used for more than 4:30 minutes without being switched o󰀨, the cockpit will automatically
switch into Standby Mode. The cockpit can be reactivated from Standby Mode by pressing any key.
Please note that devices also consume electricity in standby mode. Switch o󰀨 your treadmill completely when not in use.
Switching-O󰀨 the Treadmill
To turn o󰀨 the treadmill press the On/O󰀨 key again. Pull the plug out of the socket.
WARNING: Before switching o󰀨 the treadmill, make sure that the incline is at Level “0”.
Quickstart
Switch on the treadmill and press the START key. The treadmill will start up automatically
following a countdown period. The Training time will then commence. You can regulate the speed
with the SPEED key and the incline with the INCLINE key whilst training. Press the STOP key if
you want to interrupt or end the training session.
The display on the cockpit gives you information about the following training values:
CAL* Energy consumption in kcal
INCL Incline
PULSE when using hand sensors: Pulse
When using a Transmitter Chest Belt*: Heart Rate
*not included in scope of delivery - available as accessory
*Information about the Counting of Calories
The calculation of energy consumption is based on a generalised formula. It is not possible to determine the exact individual energy consumption as to do this
would require a huge number of personal data. The given energy consumption is a general calculated value and is not determined individually by the current
user.
Display
The cockpit display is a 5" Blue-Backlight LCD-Display. The blue backlight makes it possible to read the display if in darker
surroundings and gives a clear view of the training data.
INCLINE ↑ / ↓ Key
With this key you can adjust the incline in 1% stages.
↑ = Increase the incline ↓ = Decrease the incline
SPEED +/-
With the +/- keys you can adjust the speed at 0.1 km/h stages.
= Increase the speed = Decrease the speed
Cockpit Cockpit
TIME Training time
SPEED Speed in km/h
DIS Training distance in km

16 17
Available Memory U01, U02 and U03
These are 3 free memory spaces for individual training proles.
Step 1: Program Selection
After switching on the treadmill select which memory you want from U01, U02 or U03. In the display the appropriate pro-
gram will appear and the value “30:00” will blink. Now press the M key.
Step 2: Speed and Incline Selection
The speed (1.0km/h) and incline (Level 0) values will be blinking in the display. Below the program display a “01” will appear
which represents the rst of a total of 10 training session segments.
Enter the required speed by pressing the control key for speed and then the required incline by pressing the key for incline.
Conrm your input by pressing the MODE key.
Now the value for speed and incline will blink again and shown as segment “02”.
Repeat the procedure and enter the values for segments 02 to 10 in the same way.
Step 3: Training Time Selection
When you have conrmed your input for segment 10 with the M key, a value of “30:00” will start blinking in the time display.
Enter the required training time from between 5:00 and 99 minutes using the +/- key for speed.
Step 4: Program Start
Now press the START key.
A countdown will appear in the display. Each countdown digit is supported by an acoutic signal.
At the end of the countdown the training time and treadmill starts automatically.
The End of a Training Session
The treadmill will stop automatically at the end of the selected training time.
Heart Rate Controlled Program (HRC)
This program is a heart rate-controlled training program. Here the user enters the required target heart rate
This given rate is then continually compared to the user's actual heart rate via the cockpit.
If the actual heart rate is lower than the required target heart rate, the treadmill will automatically increase its speed. If the
actual value is higher, the treadmill will automatically slow down. The main requirement necessary to use this program are
consistent and exact heart rate measurements.
For this reason, this program can only be used together with an uncoded heart rate chest belt which are available as an
accessory. It is not possible to use this program using hand sensors. Read more about this in these instructions under the
section heading “Heart Rate Monitoring ”.
Step 1: Program Selection
After switching on the treadmill select the required program from HRC1, HRC2 and HRC3 by pressing the P key.
Now “HRC” will appear at the top and HRC 1 = “01”, HRC 2 = “02” and HRC 3 = “03” in the middle part
of the display. These three programs have di󰀨erent maximum speeds and so the maximum speed in each program will not
be exceeded.
HRC 1 = max. 9.0 km/h HRC 2 = max. 11.0 km/h HRC 3 = max. 13.0km/h
The value of “25” will blink in the display.
Step 2: Input of User Age
Now enter the age of the user by pressing the +/- keys for speed.
Conrm your entry by pressing the M key.
Step 3: Input of Target Pulse
The target heart rate calculated by the cockpit will appear in the display.
The amounts to 60% of the maximum heart rate.
If you want to train at this calculated value, conrm it by pressing the M key.
If you want to train with your own target heart rate, enter this by pressing the +/- keys
for speed. Conrm this by pressing the M key.
Read more about this under the section heading “PULSE & HEART RATE” in these instructions.
Step 4: Time Input
In the TIME display the value of 30:00 minutes will blink. Enter the required training time from between 05:00 and 99:00
minutes by pressing the +/- key for speed.
Step 5: Prole Start
Now press the START key.
A countdown will appear in the display. Each countdown digit is supported by an acoustic signal.
At the end of the countdown the training time and treadmill starts automatically.
The End of a Training Session
The treadmill will stop automatically at the end of the selected training time.
Manuel Training ()
Step 1: Selecting a Program
After the treadmill is switched on “MANUAL” will appear in the display. If the treadmill
is already switched on and a di󰀨erent program is appearing in the display, simply press the STOP key.
Step 2: Entering the target value
Here it is possible for you to enter your target training time, target training distance, or target
calorie consumption.
Entering a Training Time:
Press the MODE key. The value of 30:00 minutes will blink in the time display. Enter the
required training time from between 05:00 to 99:00 minutes.
Entering a Training Distance:
Press the MODE key twice. The value of 1.0 Kilometre will blink in the DISTANCE display. Enter the
required training distance from between 1.0 to 99.0 kilometres using the control key for incline or speed.
Entering a Calorie Consumption:
Press the MODE key three times. The value of 50 calories will blink in the CALORIES display. Enter the required calorie
consumption from between 20 to 990 kcals by pressing the control key for incline or speed.
Please be aware that you can only ever enter a target value.
Step 3: Training Start
Select the required training target with the START key. A countdown will appear in the display. Each countdown digit is sup-
ported by an acoustic signal. At the end of the countdown the treadmill will start automatically.
End of Training Session
The treadmill will stop automatically when the training target has been reached.
Training Prole P1 - P36
Training with previously programmed training prole.
Step 1: Prole Selection
After switching on the treadmill press the P key and select the training prole required from P1 to P36.
Step 2: Time Input
In the display TIME value 30:00 minutes will blink. Enter the required training time between 05:00 to 99:00 minutes by
pressing the control key for incline or speed.
Step 3: Prole Start
Press the START key.
A countdown will appear in the display. Each countdown digit is supported by an acoutic signal.
At the end of the countdown the training time and treadmill starts automatically.
End of Training Session
The treadmill will stop automatically when the training target has been reached.
The structure of the training programs can be found on pages 19 and 20.
Cockpit Cockpit

BMI
19 - 24
20 - 25
21 - 26
22 - 27
23 - 28
24 - 29
123456 7 8 9 10
km/h 1 3 5557753 2
Incline 228 6 6 4 4622
km/h 2 3 5855684 3
Incline 332 2 8 8 4444
km/h 2 3 7855584 3
Incline 125 7 7 4 4622
km/h 2 2 5888853 2
Incline 339 9 9 9 9622
km/h 3 4 8 9 10 10 10 7 4 3
Incline 228 6 6 6 661 1
km/h 3 4 67779 10 5 3
Incline 188 7 7 7 7531
km/h 3 4 4 10 4 9 4 11 3 2
Incline 1 1 6 6 6 8 8 10 6 2
km/h 3 5 79357 5 11 5
Incline 333 7 7 3 3355
km/h 3 7 10 4 7 11 5 4 12 6
Incline 367 3 8 8 3844
km/h 3 5 9 10 6 696 11 3
Incline 275 5 8 8 8844
km/h 4 5 11 968 9 11 6 5
Incline 163 3 7 7 4466
km/h 4 6 10 10 10 7 7 10 6 5
Incline 389 5 5 8 8444
km/h 2 4 6668864 3
Incline 339 7 7 5 5733
km/h 3 4 6966795 4
Incline 443 3 9 9 5555
km/h 3 4 8966695 4
Incline 236 8 8 5 5733
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
P13
P14
P15
km/h 4 5 9 10 11 11 11 854
Incline 3 3 9 7 7 7 7 7 2 2
km/h 4 5 7 888 10 11 6 4
Incline 2 9 9 8 8 8 8 6 4 2
km/h 4 5 5 11 5 10 5 12 4 3
Incline 2 2 7 7 7 9 9 11 7 3
km/h 4 6 8 10 4 6 8 6 12 6
Incline 4 4 4 8 8 4 4 4 6 6
km/h 4 8 11 5 8 12 6 5 12 7
Incline 4 7 8 4 9 9 4 9 5 5
km/h 4 6 10 11 7 7 10 7 12 4
Incline 3 8 6 6 9 9 9 9 5 5
P18
P19
P20
P21
P22
P17
km/h 3 3 6 999964 3
Incline 4 4 10 10 10 10 10 7 3 3
P16
18 19
Program SegmentCalculation of Body Mass Index
Step 1: Program Selection
After switching on the treadmill select Program F using the P key.
“F” will blink in the display.
Step 2: Gender Input
F1 will be shown in the display. Enter the user's gender by pressing the +/- keys for
speed. “1” represents “male” and “2” for “female”
Conrm your entry using the M key.
Step 3: Age Input
F2 will be shown in the display. Enter the user's age by pressing the +/- keys for speed.
Here it is possible to enter up to 99 years old.
Conrm your entry using the M key.
Step 4: Height of User
F3 will be shown in the display. Enter the user's height by pressing the +/- keys for
speed. Here it is possible to make entries from between 100 to 220 cms.
Conrm your entry using the M key.
Step 5: Weight of User
F4 will be shown in the display. Enter the user's weight using the +/- keys for speed.
Here it is possible to to make entries of up to 150 kilograms
Conrm your entry with the M key.
Step 6: Program Start
F5 will be shown and blinking in the display “---”. Take the hand pulse sensors in both
hands and hold them rmly for approx. 10 seconds.
Step 7: End of Program
Following the successful measurement, the BMI will be shown (Body Mass Index)
Body-Mass-Index (BMI)
This value is calculated from the ratio of body weight to body height and serves to
evaluate a person's body weight in relation to their body height. Please be aware that
the BMI can only be taken as a rough guide as the physical build, gender, and individual
composition of fat and muscle is not taken into account here. “Ideal” BMI depends on a
person’s age.
The table shows BMI values for di󰀨erent age groups.
Cockpit Cockpit
Age
19 - 24 Years
25 - 34 Years
35 - 44 Years
45 - 54 Years
55 - 64 Years
> 64 Years

km/h 5 6 12 10 7 9 10 12 7 6
Incline 2 7 4 4 8 8557 7
P23
1 2 345678 9 10
km/h 5 7 11 11 11 8 8 11 7 6
Incline 4 9 10 66995 5 5
km/h 3 577799 7 5 4
Incline 4 4 10 88668 4 4
km/h 4 5 7 10 778 10 6 5
Incline 5 5 4 4 10 10 666 6
km/h 4 5 9 10 777 10 6 5
Incline 3 4 799 6 6 8 4 4
km/h 4 4 7 10 10 10 10 7 5 4
Incline 5 5 11 11 11 11 11 8 4 4
km/h 5 6 10 11 12 12 12 965
Incline 4 4 10 88888 3 3
km/h 5 68999 11 12 7 5
Incline 3 10 10 9 99975 3
km/h 5 6 6 12 6 11 6 12 5 4
Incline 3 3 888 10 10 12 8 4
km/h 5 7 9 11 5 7 9 7 12 7
Incline 555995557 7
km/h 5 9 12 6 9 12 7 6 12 8
Incline 589 5 10 10 5 10 6 6
km/h 5 7 11 12 8 8 11812 5
Incline 497 7 10 10 10 10 6 6
km/h 6 7 12 11 8 10 11 12 8 7
Incline 385599668 8
km/h 6 8 12 12 12 9 9 12 8 7
Incline 5 10 11 7 7 10 10 666
P24
P25
P26
P27
P28
P29
P36
P30
P31
P32
P33
P34
P35
200
150 195
130 146 190
110 127 143 185
107 124 139 180
105 120 135 165
102 117 131 170
99 114 128 165
96 111 124 160
94 107 120 155
91 104 116 150
88 101 113 145
85 98 109 140
83 94 105 135
80 91 101 100
77 88 98
74 85
72
20 25 30 35 40 45 50 55 60 65 70 75 80 85 90
20 21
Cockpit
Calculating your personal heart rate when training
Calculate your personal heart rate when training as follows:
220 - Age = maximum heart rate
This value represents your maximum heart rate and serves as a basis from which to calculate
your personal training heart rate. Set the calculated heart rate at 100%
Wellness and Health - target zones = 50 to 60% of the maximum heart rate.
This training zone is ideally suitable for people who are over-weight and/or older beginners, or people starting again after a longer
break from training. Training in this zone the body will burn approx. 4-6 calories per minute to produce energy.
The percentage ratio per calorie is approx. 70% fat, 25% carbohydrate, and 5% protein.
Fat burning - target zone = 60 to 70% of the maximum heart rate
This training zone is suitable for athletes and sports people who aim to lose weight.
Training in this zone the body will burn approx. 6-10 calories per minute to produce energy.
The percentage rate per calorie is approx. 85% fat,10% carbohydrate, and 5% protein.
Condition & Fitness - target zone = 70 to 80% of maximum heart rate
This training zone is ideally suitable for althletes and sports people who aim to improve their stamina and/or condition.
Training in this zone the body will burn approx. 10-12 calories per minute to produce energy.
The percentage rate per calorie is approx. 35% fat,60% carbohydrate, and 5% protein.
For optimum e󰀨ects in training results you should calculate the average value of the selected target zone (also see above table):
Wellness & Health - target zone average value = 55% of maximum heart rate
Fat burning - target zone average value = 65% of maximum heart rate
Kondition & Fitness - target zone average value = 75% of maximum heart rate
Heart Rate Monitoring
Heart Rate per Minute
Age
of maximum heart rate
of maximum heart rate
of maximum heart rate
of maximum heart rate
100%
75%
65%
55%
Program Segment

22 23
Preparation Before Training
Before you start training make sure that not only your training device is in perfect condition, your body must also be pre-
pared for training. Therefore, if you have not done any endurance training for some time, you should consult your GP and
undergo a tness check-up. Also discuss your training target; they will certainly be able to give you valuable advice and
information. This applies to people who are over 35, have problems with overweight, heart or circulatory system problems.
Training Plan
Essential to e󰀨ective, target orientated, and motivating training is to have a forward-looking trainings plan.
Plan your tness training as an integral part of your daily routine. If you don’t have a xed plan, training can easily interfere
with regular commitments or continually be put o󰀨 to another unspecied time.
If possible, create a long term monthly plan and not just from day to day or week to week. A training plan should also
include su󰀩cient motivation and distraction during training sessions. An ideal distraction is to watch TV during training as
this diverts your attention both visually and acoustically. Make sure that you reward yourself and set realistic targets such as
to losing 1 or 2kgs in four weeks or to increase your training time by 10 minutes within two weeks for example. If you reach
your targets, then reward yourself with a favourite meal which you have not allowed yourself till then.
Warm-Up Before Training
Warm-up on your training device for 3-5 minutes at minimum resistance. This will best prepare your body for the up-coming
exertion in training.
Cool-Down After Training
Do not just get o󰀨 your training device immediately the training session is nished. Like with the warm-up stage you should
continue for 3-5 minutes at minimum resistance to cool down. After training you should stretch your muscles thoroughly.
Front Thigh Muscles
Support yourself with your right hand against the wall or on your training device. Bend your
knee and raise your left foot backwards so you can hold it with your left hand. Your knee should
be pointing straight down to the oor. Pull your leg backwards until you feel a light pulling in
your thigh muscles. Hold this position for 10 to 15 seconds. Let your foot go and stand it back
on the oor. Repeat the exercise with your right leg.
Inner Thigh Muscles
Sit on the oor. Pull the soles of your feet together in front of you raising your knees slightly.
Grasp the upper sides of your feet and place your elbows on your thighs. Press your thighs
down towards the oor with your arms until you feel a light pulling in your thigh muscles. Hold
this position for 10 to 15 seconds. Make sure to keep your upper body straight throughout the
exercise. Release the pressure from your thighs and slowly stretch out your legs to the front.
Stand up slowly steadily.
Legs, Calves and Buttocks
Sit on the oor. Stretch out your right leg and bend your left leg to place the sole of your foot
on your right thigh. Bend your top body over so you can stretch out your right hand to touch
your right toes. Hold this position for 10 to 15 seconds. Let go of your toes and sit slowly and
steadily up straight again. Repeat this exercise with your left leg.
Leg and Lower Back Muscles
Sit on the oor with your legs stretched out. Stretch forward with your hands and try to grasp
the tips of your toes with both hands. Hold this position for 10 to 15 seconds. Let go of your
toes and slowly and steadily sit back up straight again.
Training Recommendations
CAUTION - Pulse and heart rate monitoring systems may not be accurate. Excessive training can lead to serious damages
to your health or death. If you feel unwell and/or near to collapse, you should stop training immediately.
Make sure that all persons using your training device are familiar with this information and that they have understood it and
apply it without fail.
Most training devices are equipped with hand pulse sensors. These are usually located in the cockpit or on the handrails.
Hand sensors make short term measurements of the pulse rate. To do this hold on to the sensors with both hands simul-
taneously. After a short while the current pulse rate will be shown in the display. This monitoring system is based on blood
pressure changes caused by the heartbeat. The changes in blood pressure cause changes in the electrical resistance in
the skin which is then measured by the hand sensors. These changes are converted to an average value and shown as the
current pulse rate in the display.
CAUTION:
With a large percentage of the population the change in the resistance of the skin caused by the heartbeat is so minimal
that the measurements do not give any qualied results. Areas of hard skin on hands, wet hands and the unavoidable vibra-
tions in the body whilst training, can prevent correct measurements being taken. If this is the case, a pulse rate may either
not appear or it will be shown incorrectly in the display.
Please check if this incorrect or missing measurement occurs with several other people. If the faulty reading only happens
with one person, the device is not defective. In this case we recommend using a chest belt to give a constant and correct
pulse rate in the display. Chest belts are available as an optional accessory.
Many MAXXUS® training devices already come equipped receivers.
Chest belts (we only recommend using un-coded POLAR® chest belt) allow wireless heart rate measurements to be made.
Chest belts are available as accessories.
This optimum and ECG exact method of monitoring monitors the heart rate directly from the skin via a transmitter in the
chest belt.
The chest belt sends the impulses via an electro-magnetic eld to a receiver built into the cockpit.
We recommend always to use a chest belt for the heart rate monitoring when using programs which are heart controlled.
CAUTION:
Monitoring of current heart rates using a chest belt only serve to show the actual heart rate during training. These values
say nothing about safe or e󰀨ective heart rates for training. This type of monitoring is in no way suitable for medical diagno-
sis or purposes.
Before you start training, talk to your GP about the best way to put together and implement a training plan which suits you.
This applies above all to people who:
−have not actively done sport for a longer period
−are overweight
−are more than 35 years old
−have high or low blood pressure
−have heart problems
If you have a pacemaker or wear a similar type of device, you must seek advice about using heart rate chest belts from the
specialist who is treating you.
Warning about Pulse and Heart Rate Monitors
Pulse Rate Monitoring using Hand Sensors
Heart Rate Monitoring using a Chest Belt

24 25
Technical Details
Cockpit:
Display for:
– Time – Speed
– Distance – Incline
– Calorie consumption – Pulse (when using hand sensors)
– Heart Rate (when using a chest belt - available as optional accessory)
Technical Details:
Motor: DC-Motor
Constant Motor Power: 1.75PS / 1.29kW
Drive Type: Grooved Belt
Speed: 1.0 - 16.0 km/h, adjustable in 0.1 km/h stages
Incline: 0 - 12%, in 1.0% electronically adjustable in stages
Treadmill Deck: approx. 1.250 x 440 mm
Total Dimensions: approx. 1.653 x 735 x 1.295 mm (LxBxH)
Total Dimensions, folded: approx. 1.125 x 735 x 1.305 mm (LxBxH)
Total Weight: approx. 62 kg
Maximum User Weight allowed: 110 kg
Power Supply: 220-230V - 50Hz
Area of Application: Home Use - exclusively for private use!
European Disposal Regulations 2002/96/EG
Do not dispose your training device in the normal household rubbish.
Dispose the device at a communal waste disposal facility or at a registered waste disposal company.
Observe current regulations which apply accordingly. If in doubt seek advice from your local government o󰀩ce or county
council as to where you can dispose of the device properly and in an environmentally sound manner.
Batteries / Rechargeable Batteries
Batteries and rechargeable batteries should never be disposed of in the household rubbish.
Please be aware that all batteries can contain toxic substances and all consumers are obliged by law to dispose these at an
appropriate collection point either at your local government o󰀩ce, county council or retail outlet.
If in doubt seek advice from your local government o󰀩ce or county council as to where you can dispose batteries properly
and in an environmentally sound manner. Only dispose of batteries when they are empty.
These accessories are best suited for use with your training device. All prod-
ucts are available from our online shop at www.maxxus.de or direct from our
showroom.
POLAR® Transmitter Chest Belt T34
Chest belt with optimised transmission range for determining heart rates.
This accessory is required to use the pulse-controlled programs and for con-
tinual determination of current heart rate.
MAXXUS® Floor Protection Mat
Due to its extreme density and material thickness this mat provides perfect
protection for oors and oor coverings against damaging, scratches and
soiling through body sweat. Noise caused by running and movement is signif-
icantly reduced.
Available in the following sizes:
−160 x 90 cm
−210 x 100 cm - suitable for treadmills
MAXXUS® Silicone
Optimum lubricant and separating agent for treadmill belts and decks.
Available in the following sizes:
−50 ml
−250 ml
Intake of Liquids
The intake of su󰀩cient liquids before and during training is vital. During a 30-minute training session it is possible to lose
up to 1 litre of liquid. To compensate for this loss, you can drink a mix of one third apple juice to two thirds water to replace
all electrolytes and minerals which your body loses through sweat. 30 minutes before you begin training you should drink
approx. 330 ml. Make sure that you take in enough liquids during training.
Training Frequency
Experts recommend doing endurance training 3 to 4 days a week to keep your heart and circulatory systems t. You will of
course reach your training target quicker if you train more regularly.
Make sure that you allow for su󰀩cient breaks in your training plan to give your body time to recover and regenerate. After
each training session you should take at least a one-day break. The rule of “less is often more” even applies to tness and
endurance training!
Intensity of Training
In addition to making the mistake of training too often most mistakes are made in training intensity.
If your target is to train for a triathlon or marathon, your training intensity will certainly be very high. As this is not the aim for
many people, but more usually targets like, weight reduction, heart and circulatory system training, improvement of condi-
tion, reduction of stress etc, then training intensity should be adjusted to these targets appropriately. It is best to work at the
appropriate heart rate for each training target. The information in this manual in the section relating to heart rates and the
table will help you further with this.
Length of Training Sessions
For optimum endurance or weight reduction training a training session would be between 25 and 60 minutes long. Begin-
ners and returnees to training should start with shorter training session of maximum 10 minutes for the rst week and then
slowly increase these times from week to week.
Training Records
To optimise your training and make it as e󰀨ective as possible you should work out a training plan, before you start training,
which you either write down or create a table for in your computer. Here you should make a record of training session with
distance travelled, training time, resistance and pulse rate as well as personal data e.g. body weight, blood pressure, rest-
ing pulse (taken in the morning as soon as you awake), and how you feel during the training session.
Here is a recommended weekly plan.
Training Recommendations
Date Day Training Duration Training Distance Energy Consumption Ø Heart Rate Comments
Weekly Results:
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Week: _____ Year: 20____
Disposal
Recommended Accessories

3
44
13 13
13
13
14
14
16
18
18
19
19
31
34 34
34
35 35
36
36
41
42
72
73
73
40
82
82
28
7
8
9
10
10
11
12
12
12
13
15
16
17
17
21
20
22
22
22
22
22
22
76
76
76
23
23
24
24
24
25
28
28 28
28
28
28
29 29
29
30
30
30
30
30
30
30
30
30
30
30
30
31
32
32
32
33
34
34
34
35
31
37
38 44
46
47
48
49
50
51
53
54
55
56
57
58
59
60
61
62
63
63
65
66
66
69
70
71
71
71
71
71
71
72
72
72
74
74
75
75
75
77
78 75
75
28
28
79
28
83
83
84 84
24 78
39
67
67
5
52
45
45
43 68
68
26
26
25
25
87
87
87
87
87
87
76
86
1
1
1
2
1
1
1
1
1
2
2
3
8
2
1
3
2
4
2
1
1
6
6
7
19
2
4
6
6
15
3
4
Baseframe
Platformframe
Inclineframe
Uprightpost
Consoleframe
Ezfit linkingparts
Motorbase frame
Bolt welding
Hexfull threadscrew M8×75
AllenC.K.S.half threadscrew M10×80×40
Allensocketfull threadscrewM8×15
Allensocketfull threadscrewM8×75
AllenC.K.S.full threadscrewM8×15
Allensocketfull threadscrewM8×25
AllenC.K.S.half threadscrew M8*30*20
AllenC.K.S.half threadscrew M8*50*20
AllenC.K.S.half threadscrewM8*40*20
AllenC.K.S.half threadscrewM8*50*20
AllenC.K.S.full threadscrewM10×25
AllenC.K.S.half threadscrewM10*45*20
AllenC.K.S.half threadscrew M10*35*20
Allenself-tappingscrewM6×50×Φ16
PhilipsC.K.S.full threadscrew M5×10
PhilipsC.K.S.full threadscrew M4×10
PhilipsC.K.S.self-tappingscrewST4×16
PhilipsC.K.S.self-tappingscrewST4×50
Philipsself-tappingscrewST3×25
Philipsself-tappingscrewST4×15
Philipsself-tappingscrewST3×10
Flat washerΦ8
Flat washerΦ10
SpringWasher
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
2
2
2
1
4
6
4
2
2
8
6
1
2
1
1
Communicationwire(L-1200mm)
Communicationwire(L-700mm)
Handlepulse(incline)
SpeedsensorL-300
Handlepulseset
Controller
Safetykey
Powercord
Powercord
Switch
Fuse(withwire)
Handlepulse(speed)
Powercord
Frontroller
Rearroller
Cylinder
Motor
Runningbelt
Inclinemotor
Runningdeck
Motorbelt
Motorcover
Cover spacingpieceframe
Archclamp
Rearcover
Siderail
Foamgrip
Ellipseend cap
End cap
Squarecushion
Squarecushion
Feetpad
Wheel
Wheel
Siderail guider
Philipsself-tappingscrewST5.5*15
Wire protector
Binder
Power cord buckle
PCBboard
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
3
8
3
2
1
1
1
1
Lock washer Φ5
Hexself-locking nut M8
Hexself-locking nut M10
Powder metallurgy set Φ17×Φ10×7
Spring
Magnetic Ring
Console housing
Communication wire(L-800mm)
33
34
35
36
37
38
39
40
26 27
Explosion Drawing Parts List

81 Keyboard 1
82 Outl t 1
e
83 Plasticflat washer 2
84 Cover spacingpiece 2
85 IPAD pallets 1
86 Springwasher 3
87 PhilipsC.K.S.full threadscrew ST4×12 13
28 29
Parts List
For MAXXUS® Support Team to help you as quickly as possible with service, we will require certain information about your
tness device and from you. To nd the exact spare parts required, we will need the product name, date of purchase and
serial number.
If necessary, please ll out completely the Repairs Contract/Damage Report formula attached in this User Manual and send
it to us per post or per fax.
Areas of Application & Warranty Periods
Depending on the model, tness devices from MAXXUS® are suitable for use in di󰀨erent areas. Find the appropriate area
of use for your tness device from the “Technical Data” in this User Manual. Home Use:
Exclusively for private use
Warranty Period: 2 Years
Semi-Professional Use:
Use under instruction in hotels, physiotherapy practices, etc.
Use in a tness studio or similar establishment is hereby excluded!
Warranty Period: 1 Year
Professional Use:
Use in a tness studio or similar establishment under supervision by trained personnel.
Warranty Period: 1 Year
Use of your training device in an area which is not suitable for your device will cause immediate expiry of its guarantee and
cancel your right to claim warranty!
Sole private use and warranty period of 2 years assumes that the purchase invoice is made out to the end user.
Proof of Purchase and Serial Number
To claim your right to service works within the warranty period we will in each case require proof of purchase. Keep your
proof or purchase or purchase invoice in a safe place and in warranty cases, send us a copy without further request
together with your Repairs Contract/Damage Notication. This will ensure that we can process the service work as quickly
as possible. So that we can identify which model version requires to be serviced correctly, we will require; Product Name,
Serial Number and Date of Purchase.
Terms and Conditions of Warranty:
The warranty period for your training device starts on the date of purchase and applies solely to products which were
purchased directly from the MAXXUS Group GmbH & Co KG or one of the MAXXUS Group GmbH & Co KG direct and
authorised distribution partners.
The warranty covers defects caused by production or material faults and only apply to devices purchased in Germany. The
warranty does not apply to damages or defects caused by culpable improper use, negligent or purposeful destruction, lack
or failure to carry out maintenance and/or cleaning measures, force majeure, operational causes and so normal wear and
tear, damages caused by penetration of liquids, damage caused by repairs or modications made with spare parts from a
di󰀨erent supplier. The warranty also does not apply for damages due to faulty assembly or damages which occur because
of faulty assembly. Certain component parts will wear and tear during use or from normal wear and tear. This includes for
example:
▪ Ball bearings ▪ Bearing bushings ▪ Bearings ▪ Drive belts
▪ Switches and push-buttons ▪ Treadmill belts (bands) ▪ Treadmill decks (running deck) ▪ Rollers
Signs of wear and tear on wearing parts are not items covered under the warranty.
If your training device requires to be collected from you, you will be required to dismantle and make available the device
and receive and re-assemble the device yourself. These works are not in any way covered by the warranty. Prior to sending
any component parts to our service address, please contact hte service department and ensure the parts are well packed.
Service Outside the Warranty and Ordering Spare Parts
The MAXXUS® Service Team is happy to be of assistance to help solve any problems with faults which may arise following
expiry of the warranty period, or in cases of defects arising which are not covered by the warranty.
In this case please contact us per email direct to: [email protected]
Orders for Spare Parts or Worn Parts should be sent along with information on the Product Name, spare part description
and number and the quantity required to: [email protected]
Please be informed that additional xing materials such as screws, bolts, washers etc are not including in the scope of
delivery for individual spare parts. These should be ordered separately.
*Version: June/2016
Warranty*

30 31
Notes
Device Details
Product Name: MAXXUS 4.2i
Series Number: _______________________________________
Date of Purchase: _____________________________________
Accessories: _________________________________________
Type of Use:
Private Use
Personal Details
Company: ___________________________________________
First Name: __________________________________________
Street: ______________________________________________
Post Code: __________________________________________
Country: ____________________________________________
E-Mail: _____________________________________________
Fax. No.*: ___________________________________________
Product Group: Treadmill
Invoice Number: ______________________________________
Where Purchased: ____________________________________
Commercial Use
Contact Person:_______________________________________
Second Name:________________________________________
House Number: _______________________________________
Town/City: ___________________________________________
Tel.No.: _____________________________________________
Mobile No.*:__________________________________________
Repairs Contract / Notication of Damage Claim
*These details are optional; all other details are obligatory and must be lled-in.
Description of Fault
Please give a short and as accurate as possible description of the fault:
(eg. When, where and in what way did the fault occur. Regularity, and for what lenth of time, and in what form of use, etc ...)
A copy of proof of purchase / invoice / receipt is attached.
I acknowledge the General Business Terms and Conditions of MAXXUS® Group GmbH & Co. KG.
I hereby instruct the company MAXXUS® Group GmbH & Co. KG to repair the above-mentioned fault.
In Warranty cases I will not be charged for the costs. The costs for repairs which are excluded from liability for defects in quality will be
charged to me and must be settled immediately. In cases of repairs carried out on site, our sta󰀨 are entitled to collect payment. This
agreement is conrmed with here with my signature.
Date Location Signature
Please be aware that contracts can only be processed if this form has been completed in full. Be sure to attach a copy of your purchase
invoice. Send the fully completed Repairs Contract / Notication of Damage Claim to:
Post*: Maxxus Group GmbH & Co KG, Service Department, Zeppelinstr. 2, 64331 Weiterstadt
Fax: [phone]
E-Mail**: [email protected]
* Please stamp with su󰀩cient postage - letters which are not sent postage paid will unfortunately not be accepted.
** Submission per E-Mail is only possible as a scanned document with original signature.

32
Maxxus Group GmbH & Co. KG
Zeppelinstr. 2
D-64331 Weiterstadt
Germany
E-Mail: [email protected]
www.maxxus.de
