Mayline 5 COLUMN CRNR XR BASE User manual

(1)
NOTE: Please count and inspect all pieces before disposing of any carton or packing materials.
When ordering components, specific size information may be required.
Contact a Mayline Customer Ser ice Representati e. 1-800-822-8037
HARDWARE BAG (PART No. A8180) *For individual item, order by part number
ASSEMBLY INSTRUCTIONS
5 COLUMN CRNR XR BASE
REF. # QTY. DESCRIPTION PART No.
E1 40 M6 X 16mm SCREW X419
E2 40 STAR WASHER W29
E3 6 GLIDE Q607
E4 8 #10 X 3/4 SCREW X11
E5 28 #10 x 1" SCREW X12
E6 4 #6 X 5/8 SCREW X10
E7 12 1/4-20 X 1/2 SCREW X352
E8 12 1/4-20 KEPS NUT T126
E9 8 CABLE CLAMP F191
E10 4 #8 x 1.75" SCREW X533
COMPONENTS:
REF. # QTY. DESCRIPTION PART No.
1 5 LIFT ACTUATOR Z460
2 2 XR FOOT, 30" A8174
3 1 XR FOOT, 14" A7299
4 1 ACT. SUPPORT, LEFT A8176
5 1 ACT. SUPPORT, RIGHT A8177
6 1 BRACKET ASM., CORNER A7292
7 1 CHANNEL CROSS 520CC** (50"), 520CC**01 (40")
8 3 TOP PLATE B6969
9 2 TOP PLATE, 14" B8498
10 1 CONTROL BOX, 2 LEG Z537
11 1 CONTROL BOX, 3 LEG Z538
12 2 MEMORY SWITCH Z463
13 2 MAIN CABLE Z467
14 2 1000mm MOTOR CABLE Z464
15 3 2500mm MOTOR CABLE Z466
** enotes Color
OPTIONAL HARDWARE
REF. # QTY. DESCRIPTION PART No.
16 1-2 Anti-Collision Dongle Z498
I908 REV. 02 06-2016

(2)
1. Place two Lift Actuators Columns (1) upside down with
the cord toward the floor with support clips are facing inward.
CAUTION: Make sure strain relief is snapped into place on
actuator.... Do not pinch Cord Assembly.
2. Position the 30" XR Foot (2) o er Columns.
Note: Direction does not matter.
3. Attach the XR Foot (2) to the two Actuator Columns (1)
with four M6 x 16 mm Screws (E1) and Star Washers (E2).
Attached two Glides (E3) to bottom of foot.
Repeat for two more Lift Actuator Columns and Foot.
4. Place final Lift Actuator Column (1) upside down with the
cord toward the floor. CAUTION: Make sure strain relief is
snapped into place on actuator.... Do not pinch Cord
Assembly.
5. Position the 14" XR Foot (3) o er the Column. Attach the
to the Actuator Column (1) with four M6 x 16 mm Screws
(E1) and Star Washers (E2). Attached two Glides (E3) to
bottom of foot.
6. Place the assembled columns upright and attach the Left
(4) and Right (5) Actuator Supports between the Columns.
Position the Supports so the Channel Brackets face toward
each other. Slide the Support brackets onto the tapered
support clip on each Actuator Column. Gently tap the Act.
Supports in place with a Rubber Mallet to assure a tight fit.
7. Attach the Corner Bracket (6). Slide the Corner Bracket
onto the tapered channel clip on the column (1). Gently tap
Bracket in place with a Rubber Mallet to assure a tight fit.
NOTE: In the e ent that you must reposition the Actuator
Cord. Gently remo e the cord and strain relief from the
notch in the top of the Actuator Column (1). Position the
cords so that they are toward the center of the assembled
base. Insert the strain relief into the appropriate Actuator
notch.

(3)
8. Attach Top Plates (8), (9) to each Actuator Column as shown with four M6 x 16 mm Screws (E1)
and Star Washers (E2).
9. Attach the Cross Channels (7) to the Actuator Support Channel Brackets (3), (4) and Corner Bracket
(6) and with 1/4-20 X 1/2 Screws (E7) and 1/4-20 KEPS Nuts (E8). Note: 4 screws are used in Corner
Bracket, and 2 into Support Channel.
10. Attach Memory Switch (12) and Main Cable (13) to Control Boxes (10) and (11). Attach 1ea
2500mm Motor Cable (15) and 1000mm Motor Cable (14) to the 2 Port Control Box (10). Attach 2ea
2500mm Motor Cable and 1ea 1000mm Motor Cable to 3 Port Control Box (11).

(4)
NOTE:
a) #10 x 3/4" Screws (E4) are pro ided for Cable Clamp installation only.
b) #10 x 1" Screws (E5) are pro ided for Work Surface attachment only.
c) #8 x 1 3/4" Screws (E10) are pro ided for Control Box installation only.
PRIOR TO ATTACHING A WORKSURFACE. Place the REAR SURFACE Memory Switch cable o er
the top of the Cross Channel.
ATTENTION:
MAYLINE includes screws for the installation of a Work
Surface with a minimal thickness of 1 inch (25.4mm).
11. Align the holes in the Tops with the holes in the Top Plates (8), (9) and secure in place with eight #10 x
1" Screws (E5).
12. Choose a desired location for the Control Boxes (10), (11) and attach with two #8 x 1 3/4" Screws (E10)
per Control Box. Connect the motor cables to the columns.
13. Place the Memory Switche(s)ze
(12) in a comfortable and accessible location on the underside of the Top(s) and attach it with two #6 x 5/8
Screws (E6).
14. Route the Actuator Column cables and the Switch cable away from mo ing components and secure
them in place with Cable Clamps (E9) and Screws (E4).

(5)
15. Attach Anti Collision Dongle Option (when ordered).
To install the Anti Collision Dongle (16), simply plug the dongle into one of the two
control (switch) ports on the Control Box (10,11). The function is only acti e when
the dongle is mounted - if you remo e the dongle you disable the function.
Note: Situations where anti-collision does not work.
1) If the collision happens during the initialization stage.
2) If the collision happens within the first 1000 msec or after the control button has
been released.
3) If the collision time span is too long, i.e. if the collision is with a soft object.
INSTRUCTIONS for
DESK SWITCH w/ PROGRAMMABLE
MEMORY
1. Initialize system by pressing down and holding for 5 to 10
seconds after table bottoms out.
2. Push 'UP' to desired height.
3. To sa e this position in Memory:
A.) Press (Set)
B.) Press (do not hold) button , , or
Position is now sa ed under the number chosen.
4. To change to different height, press or .
This position may be sa ed by repeating Step 3 and using
one of the other buttons or using the same button to change
the pre ious setting. Up to 3 positions may be stored.
5. To go to new height position, press or , or press stored
height under , , or . Unit will automatically stop at
the stored position.
S
1
321
2 3
21 3 S
