Maytag MEDZ400TQ1 User manual

TOP AND CONSOLE PARTS
1
For Model: MEDZ400TQ1
(Designer White)
8−07 Printed in U.S.A. (LT) Part No. W10160974 Rev. A
27" Electric Dryer

TOP AND CONSOLE PARTS
2
For Model: MEDZ400TQ1
(Designer White)
W10160974
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10112937 Use & Care Guide
W10117402 Tech Sheet
W10117403 Guide,
Quick Start
2 8563730 Top
3
W10110972 Harness, Main
4
W10117384 Panel, Console
(Includes Illus.
15.)
5 3394427 Clip, Harness
6 8565237 Bracket, Console
7 353424 Connector, Sensor
8 94614 Terminal
9 3936144 Plug, Terminal
10 94613 Terminal
11 3390647 Screw, 8−18 x 1/2
12
W10117387 Lens, Display
13 3395683 Connector,
(Motor)
14
W10117416 Assembly,
User Interface
15
W10112569 Badge
16
W10112899 Knob, Assembly
17 8574968 Channel, Water
18 3400238 Screw, 2−28 x 1/2

CABINET PARTS
3
For Model: MEDZ400TQ1
(Designer White)
W10160974

CABINET PARTS
4
For Model: MEDZ400TQ1
(Designer White)
W10160974
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8576583 Cover,
Terminal Block
2 8533974 Screw Ground
3 3357011 Screw, 10−16 x 1/2
4 3397659 Block, Terminal
5 3394881 Switch, Broken
Belt
7 8565054 Panel, Side (L.H.)
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 697750 Plug, Multivent
13 3388672 Pulley Assembly
14 279318 Terminal, Brass
& Tinned (3)
(Includes Illus. 33)
15 8066120 Lever, Snap
Switch
16 3394081 Wire, Belt Switch
17 343641 Screw, 10−16 x 1/2
18 233520 Washer, Thrust
19 8574875 Assembly,
Door Switch
20
W10121334 Washer
21 8066115 Cover−Plate
22 8565083 Ramp, Door
24 8565048 Panel, Side (R.H.)
26 8565059 Panel, Rear
27 8538263 Motor, Assembly
60 HZ.
28 3398948 Wire, Jumper
(Broken Belt
Switch)
29 8578220 Pulley 60 HZ.
30
W10112954 Belt, Drive
31 8572546 Kit,
Stack Assembly
32 3387118 Bracket, Motor
33 279393 Terminal Block
Screw Kit (For
Terminal Block)
34 49026 4" − 90 Elbow
35 8565043 Plug,
Front Panel
36 8563747 Exhaust Pipe
& Bracket
37 8563750 Exhaust Pipe
(Short)
38 8563749 Exhaust Pipe
(Long)
39 3388674 Idler Bracket
40 8519459 Clip, Toe Panel
41 8540621 Toe Panel
42 98129 Screw,
6−20 x 1 1/16
43 3390647 Screw, 8−18 x 1/2
44 3387242 Seal, Front Panel
45 3393008 Screw, 10−16 x 1/2
46 8565122 Strike−Door
47 8563727 Control Bracket
48
W10132445 Control Board
49 90767 Screw, 8−18 x 3/8
50 8565046 Base, Cabinet
51
W10117421 Front Panel
(Includes
Illus. 44)
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
52 279818 White

BULKHEAD PARTS
5
For Model: MEDZ400TQ1
(Designer White)
W10160974

BULKHEAD PARTS
6
For Model: MEDZ400TQ1
(Designer White)
W10160974
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3
W10153413 Door, Lint
Screen
4 3406653 Harness, Sensor
5 697354 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut,3/8 x 16(R.H.)
10 3402841 Lens,
Drum Light
11 693995 Screw, 8−18 x 3/8
12 8533971 Screw, 8−18 x 5/16
13 8066208 Clip−Spring
14 8544771 Heater Element
15 279457 Terminal Wire
Kit (For Heater
Element Wiring
Harness Repair)
16
W10001120 Nut, 3/8−16 (L.H.)
17 8520836 Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 8563728 Exhaust Pipe
23
W10153423 Housing, Outlet
Assembly
24 8529007 Plug,
Rear Bulkhead
25
W10153420 Complete Drum
Assembly
26
W10109200 Screw, 11−16 x 3/4
27 697694 Seal, Drum
28 695240 Screw, 8−18 x 1/2
29 90767 Screw, 8−18 x 3/8
30 8519221 Channel Bracket,
Rear Bulkhead (2)
31 8571651 Bracket, Upper
Rear Bulkhead
32 489463 Screw, 8−18 x 5/8
33 3406124 Bulb, Light
34 3387223 Electrode, Sensor
35 8578825 Bracket,
Drum Light
36
W10136369 Socket Assembly
37 697772 Wheel, Blower
38 8572105 Clip−Exhaust
39 3394986 Spring, Lint
Screen Door
40 3392519 Thermal Fuse
(91 C)
42 8577274 Thermistor
43 487909 Screw, 8−15 x 1/2
44 8544362 Housing, Blower
45 8066168 Lint Duct Assembly
46 8544769 Housing, Slot
Heater Box
47 8318314 Thermal Cut−Off
(Includes
Illus. 48)
48 3391914 Thermostat 295 F
(146 C)
49 8544770 Housing, Tab
Heater Box
50 8544776 Flange,
Heater Box
51 3387230 Screw, 10−16 x 1
52 8066099 Bracket,
Heater Box
53
W10153409 Baffle, Drum
54 8565061 Bulkhead, Front
55
W10153412 Grille, Outlet
56 697770 Seal, Cover Plate
57
W10049370 Lint, Screen

DOOR PARTS
7
For Model: MEDZ400TQ1
(Designer White)
W10160974
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8565119 Plug Strip
(Inner Door)
2 8578887 Door Hinge
Assembly
3
W10119053 Door, Screen
Intermediate Assy.
4 9742177 Screw, 8−18 x 5/8
5 3400618 Screw, 6−32 x 3/8
6 3393258 Screw, 10−16 x 1/2
7
W10117478 Handle, Door
(Includes Illus.
19.)
8
W10017850 Screw,
10−32 x .455
9 8519354 Retainer (Lower)
10 8578933 Door Assembly
(Inner)
(Includes
Illus. 1 & 14 )
11 355515 Screw,
8−18 x 11/16
12
W10112916 Door, Outer Ring
13 8565117 Window
14 690081 Door Catch
Assembly
15 8579663 Seal, Window
16 8565114 Door,
Intermediate
17 8534022 Screw
18 8519356 Retainer (Upper)
19
W10112927 Pad,
Door Handle
20 Door Seal
(Not Servicable)

OPTIONAL PARTS (NOT INCLUDED)
8
For Model: MEDZ400TQ1
(Designer White)
W10160974
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
ACCESSORY PARTS
8529894 Hold Down Kit
8522199 Kit, Dryer
Vent Testing
80047 Kit,
Dryer Repair
8563738 Dry Rack
