MB QUART NAUTIC NHT2-116 Instruction Manual

Quick Start
Installation Guide
NHT2-116
NHT2-120
NAUTIC
NAUTIC

Dimensions
CAUTION
Always consider consulting a professional audio installer
before installing new speakers. Many manufacturers locate
speakers behind interior panels that require special tools to
remove. Be careful and take your time.
If you are using the speaker wire supplied with your new
speakers make sure that you run the speaker wires only
through safe areas. Do not let speaker wire make contact with
metal edges or hot engine components.
Congratulations on your choice of a MBQuart speaker.
This “Quick Start” Installation guide is meant to help
you complete a basic installation. For more detailed
information on system setting, speaker and subwoofer
FRQ¿JXUDWLRQDQGIXOOVSHFL¿FDWLRQVE\PRGHOYLVLWRXU
website at mbquart.com
,W¶VDJRRGLGHDWRFRQ¿UPWKDW\RXKDYHSXUFKDVHGWKHFRUUHFWVL]H
VSHDNHUVWR¿W\RXUDSSOLFDWLRQ,I\RXKDYHDQ\UHVHUYDWLRQVDERXWEHLQJ
able to complete the installation yourself, we recommend contacting a
professional.
Before you start
230mm
9.04”
120.65mm
4.75”
41.4mm
1.63”
292.1mm
11.5”
215mm
8.47”
203.2mm
8”
101.6mm
4”
174.5mm
6.87”
201.5mm
7.94”
41.4mm
1.63”

The NHT2 clamping system is designed for
towers and support structures that utilize ROUND
WXELQJ2YDOWXELQJDQGÀDWVWUXFWXUHVZLOOQRW
work with this clamp. The NHT2 clamp can be
used with tube diameters from 1.5” up to 2.75”.
Included are separate bushing sets for all tube
sizes at 1/8” increments. Refer to the table below
WRGHWHUPLQH\RXUFRQ¿JXUDWLRQ
Choose a suitable
mounting location
Mounting Location
Tube
Diameter
Tube
Circumference
Clamp Top
Bushing
Bottom
Bushing
1.5 4.71 A 1.50 1.50
1.625 5.10 A 1.63 1.63
1.75 5.50 A 1.75 1.75
1.875 5.89 A none 1.88
2 6.28 B 2.00 2.00
2.125 6.68 B 2.13 2.13
2.25 7.07 B 2.25 2.25
2.375 7.46 B 2.38 2.38
2.5 7.85 B 2.50 2.50
2.625 8.25 B 2.68 2.68
2.75 8.64 B none none

Carefully select a route for the audio signal
ZLUHV,IXVLQJH[LVWLQJVSHDNHUZLUHVFRQ¿UP
that the wire is in good shape and not
shorted. In the case of an illuminated model,
route a positive and negative wire from a
switched +12V source. Avoid routing wires
through dangerous areas.
Route signal and
illumination wires
Wiring
Black ...................................... Audio signal negative
Black w/white stripe ................ Audio signal positive
Your NHT2 speakers can be aligned to “hang
straight” on an angled tube by loosening, rotating
and re-mounting the speaker. Just behind the
speaker mounting holes is a series mounting holes
that can be used to align the speaker in the pod.
Adjust the speaker
alignment
Grill alignment

MB Quart products are designed and engineered in the USA by
www.maxxsonics.com
WARRANTY
Maxxsonics, LLC. warrants this product, to the original consumer purchaser, to be free from
defects in material and workmanship for a period of one (1) year from the date of purchase.
Maxxsonics, LLC. will, at it’s discretion, repair or replace defective products during the warranty
period. Components that prove to be defective in materials and workmanship under proper
installation and use must be returned to the original authorized Maxxsonics, LLC. retailer from
where it was purchased. A photocopy of the original receipt must accompany the product being
returned. The costs associated with removal, re-installation and freight are not the responsibility of
0D[[VRQLFV //&7KLVZDUUDQW\LVOLPLWHGWRGHIHFWLYHSDUWVDQGVSHFL¿FDOO\H[FOXGHVDQ\LQFLGHQWDO
or consequential damages connected therewith. To view the full warranty, please visit the website.
