McFarlane RD-4000 Series Troubleshooting guide

MANUFACTURERS OF QUALITY AGRICULTURAL EQUIPMENT SINCE 1936
OPERATOR’S MANUAL
AND
PARTS LISTING
FOR THE
RD-4000 Series
Reel Disk
VERSION: 7-12
starting at serial number 16537
TO THE OWNER AND OPERATORS
Before assembling or operating this unit, READ THIS MANUAL THOROUGHLY. To obtain
the best performance of the unit, familiarize yourself with each component and adjustment.
Store this manual where it can be readily available for future reference. In the event that the
harrow or any part of the unit should be sold, be sure that the new owner receives a copy of
this manual for their reference.
1330 DALLAS STREET, P.O. BOX 100
SAUK CITY, WISCONSIN 53583
PHONE: [phone]
TOLL FREE: [phone] FAX: [phone]

2
TABLE OF CONTENTS
INTRODUCTION ...............................................................................................................3
LIMITED WARRANTY .....................................................................................................3
CONTACT INFORMATION..............................................................................................3
SAFETY .......................................................................................................................... 4-6
BEFORE OPERATION.......................................................................................................6
DURING OPERATION ......................................................................................................7
FOLLOWING OPERATION .......................................................................................... 7-8
HIGHWAY AND TRANSPORT OPERATIONS ..............................................................8
OPERATING INSTRUCTIONS ................................................................................... 9-13
MAINTENANCE AND SERVICE............................................................................. 13-15
TROUBLESHOOTING.....................................................................................................16
BOLT TORQUE AND TIRE SPECIFICATIONS............................................................17
PARTS DIAGRAMS - HITCH ................................................................................... 18-19
PARTS DIAGRAMS – MAIN AXLE ........................................................................ 20-23
PARTS DIAGRAMS – LEVEL LIFT...............................................................................24
PARTS DIAGRAMS – HYDRAUIC DEPTH STOP .......................................................25
PARTS DIAGRAMS – WING REST ......................................................................... 26-28
PARTS DIAGRAMS – WING FRAME ..................................................................... 29-31
PARTS DIAGRAMS – DISK GANG......................................................................... 32-34
PARTS DIAGRAMS – CENTER COVERING DISK .....................................................35
PARTS DIAGRAMS – SPIRAL REEL ...................................................................... 36-37
PARTS DIAGRAMS – HARROW LIFT ARM.......................................................... 38-39
PARTS DIAGRAMS – ROLLING BASKET............................................................. 40-41
PARTS DIAGRAMS – HARROW SECTION .................................................................42
HYDRAULIC DIAGRAMS AND LISTS .................................................................. 43-48
LIGHTING DIAGRAM.………………………………………………………………..49
WHEEL HUB DIAGRAMS AND LISTS................................................................... 50-52
LAYOUT DIAGRAMS............................................................................................... 53-59
WARRANTY REGISTRATION FORM ........................................................ LAST PAGE

3
INTRODUCTION
Thank you for purchasing your new McFarlane tillage tool. We know that you will get many years of
dependable service from this modernly designed unit.
You may have had a particular application in mind when you purchased this unit. There are actually
many uses for the McFarlane harrow including incorporation of herbicides and pesticides, leveling and
smoothing tilled soil, and covering of broadcast seeds. Contact your dealer if you would like more
information or have questions concerning these or other applications.
LIMITED WARRANTY
FULL ONE - YEAR WARRANTY OF
RD-4000 Series Reel Disk
If within one year from the date of purchase, this transport cart and/or its accompanying harrow sections
fail due to defect in material or workmanship, McFarlane Mfg. Co., Inc. will repair it, free of charge.
Warranty service is available by simply contacting the nearest McFarlane dealership throughout the
United States or Canada.
This warranty applies only while this product is used in the United States or Canada.
This warranty gives you specific legal rights, and you may have other rights which vary from state to
state.
McFarlane Mfg. Co., Inc., Sauk City, Wisconsin 53583
CONTACT INFORMATION
If you have questions not answered in this manual, require additional copies, or the manual is damaged,
please contact your local dealer or:
McFarlane Mfg. Co., Inc.
1330 Dallas Street
P.O. Box 100
Sauk City, WI 53583
PHONE: [phone]
TOLL FREE: [phone]
FAX: [phone]
EMAIL: [email protected]
INTERNET: www.flexharrow.com

4
SAFETY
TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS
USED TO CALL ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY
AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN
RESULT IN INJURY OR DEATH.
THIS SYMBOL MEANS
ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
SIGNAL WORDS:
Note the use of the signal words DANGER, WARNING, and CAUTION with the safety messages. The
appropriate signal word for each has been selected using the following guidelines:
DANGER: Indicates an imminently hazardous situation that, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a potentially hazardous situation that, if not avoided, may result in minor or
moderate injury.

5
SAFETY FIRST!
Equipment Safety Guidelines
Safety of the operator is one of the main concerns in designing and developing a new piece of
equipment. Designers and manufacturers build in as many safety features as possible. However, every
year many accidents occur which could have been avoided by a few seconds of thought and a more
careful approach to handling equipment. You, the operator, can avoid many accidents by observing the
following precautions. To avoid personal injury, study the following precautions and insist that those
working with you, or for you, follow them.
Replace any CAUTION, WARNING, DANGER, or instruction safety decal that is not readable or
missing.
Do not attempt to operate this equipment under the influence of drugs or alcohol.
Review the safety instructions with all users annually.
This equipment is dangerous to children and persons unfamiliar with its operation. The operator should
be a responsible adult familiar with farm machinery and trained in this equipment’s operations. Do not
allow persons to operate or assemble this unit until they have read this manual and have
developed a thorough understanding of the safety precautions and of how it works.
To prevent injury, use a tractor equipped with a Roll Over Protective System (ROPS). Do not paint
over, remove, or deface any safety signs or warning decals on your equipment. Observe all safety signs
and practice the instructions on them.
Never exceed the limits of the transport cart or the harrows. If their ability to do a job, or to do so
safely, is in question - DO NOT TRY IT.
Lighting and Marking
It is the responsibility of the customer to know the lighting and marking requirements of the local
highway authorities and to install and maintain the equipment to provide compliance with the
regulations. Add extra lights when transporting at night or during periods of limited visibility.
Safety Sign Care
Keep safety signs clean and legible at all times.
Replace safety signs that are missing or have become illegible.
Replacement parts that display a safety sign should display the same sign.
Safety signs are available from your Distributor, Dealer Parts Department, or the factory.
How to Install Safety Signs:
Be sure that the installation area is clean and dry.
Decide on the exact position before you remove the backing paper.

6
Tire Safety
Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion
which may result in serious injury or death.
Do not attempt to mount tires unless you have the proper equipment and experience to do the job.
Inflating or servicing tires can be dangerous. Whenever possible, trained personnel should be called to
service and/or mount tires.
Always order and install tires and wheels with appropriate capacity to meet or exceed the weight of the
unit. Be sure to inflate tires to tire manufacturer’s specifications
Tires that are provided by the manufacturer are designed for speeds LESS THAN 20mph. Do Not
exceed or tire failure will occur.
Remember:
Your best assurance against accidents is a careful and responsible operator. If there is any
portion of this manual or function you do not understand, contact your local authorized dealer or
the manufacturer.
Before Operation:
Carefully study and understand this manual.
Do not wear loose fitting clothing which may catch in moving parts.
Always wear protective clothing and substantial shoes.
It is recommended that suitable protective hearing and (eye protection) sight protectors be worn.
Keep wheel lug nuts or bolts tightened.
Assure that the tires are inflated evenly.
Give the unit a visual inspection for any loose bolts, worn parts, or cracked welds, and make necessary
repairs. Follow the maintenance safety instructions included in this manual.
Before using the hydraulics on the cart, be sure all fittings and connections are tight.
Be sure that there are no tools lying on the unit.
Make sure that the area is clear of children, animals, and other obstacles before using.
Don’t hurry the learning process or take the unit for granted. Ease into it and become familiar with your
new equipment. Practice operation of your new unit. Completely familiarize yourself and other
operators with its operation before using.
Securely attach to towing unit. Use a high strength, appropriately sized hitch pin with a mechanical
retainer and attach safety chain.
Do not allow anyone to stand between the tongue or hitch and the towing vehicle when backing up to
the equipment.

7
During Operation:
SAFETY CHAIN - If equipment is going to be transported on a public highway, a safety chain should
be obtained and installed. Always follow state and local regulations regarding a safety chain when
towing farm equipment on a public highway. Be sure to check with local law enforcement agencies for
your own particular regulations. Only a safety chain (not an elastic or nylon/plastic tow strap) should be
used to retain the connection between the towing and towed machines in the event of separation of the
primary attaching system.
Install the safety chain by crossing the chains under the tongue and secure to the draw bar cage or hitch
or bumper frame.
Beware of bystanders, particularly children! Always look around to make sure that it is safe to start
the engine of the towing vehicle or move the unit. This is particularly important with higher noise levels
and quiet cabs, as you may not hear people shouting.
NO PASSENGERS ALLOWED - Do not carry passengers anywhere on, or in, the tractor or
equipment, except as required for operation.
Keep hands and clothing clear of moving parts.
Do not clean, lubricate, or adjust your equipment while it is moving.
When altering operation, even periodically, set the tractor or towing vehicle brakes, shut off the engine,
and remove the ignition key.
Pick the levelest possible route when transporting across fields. Avoid the edges of ditches or gullies
and steep hillsides.
Periodically clear the equipment of brush, twigs, or other materials to prevent buildup of dry
combustible materials.
Maneuver the tractor or towing vehicle at safe speeds.
Avoid overhead wires or other obstacles. Contact with overhead lines could cause serious injury or
death.
Do not walk or work under raised wings unless securely positioned in wing rests.
Keep all bystanders, pets, and livestock clear of the work area, particularly when raising or lowering
harrow sections.
Operate the towing vehicle from the operator’s seat only.
As a precaution, always recheck the hardware on equipment periodically. Correct all problems. Follow
the maintenance safety procedures.
DO NOT turn while the unit is in the ground.
DO NOT operate the unit in frozen ground.
Following Operation:
When disconnecting, stop the tractor or towing vehicle, set the brakes, lock the lift cylinders with the
lock brackets, lock the wings in the wing rests, relieve hydraulic fluid pressure, shut off the engine and
remove the ignition keys. Make sure all jack and support stands are in place before removing hitch
pins.
Store the unit in an area away from human activity on a hard level surface.

8
Do not park equipment where it will be exposed to livestock for long periods of time. Damage and
livestock injury could result.
Do not permit children to play on or around the stored unit.
Highway and Transport Operations:
Make sure all transport lock provisions are in place and jack/parking stands are in their storage position
before transporting the unit.
Adopt safe driving practices:
Keep the brake pedals latched together at all times. NEVER USE INDEPENDENT BRAKING
WITH MACHINE IN TOW AS LOSS OF CONTROL AND/OR UPSET OF UNIT MAY
RESULT.
Always drive at a safe speed relative to local conditions and ensure that your speed is low enough for an
emergency stop to be safe and secure. Keep speed to a minimum.
Reduce speed prior to turns to avoid the risk of overturning.
Avoid sudden uphill turns on steep slopes.
Always keep the tractor or towing vehicle in gear to provide engine braking when going downhill. Do
not coast.
Do not drink and drive!
Comply with state and local laws governing highway safety and movement of farm machinery on public
roads.
Use approved accessory lighting flags and necessary warning devices to protect operators of other
vehicles on the highway during daylight and nighttime transport. Various safety lights and devices are
available from your dealer.
The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their
use. Local laws should be checked for all highway lighting and marking requirements.
When driving the tractor and equipment on the road or highway under 20 mph at night or driving during
the day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
Remember, tires supplied by the manufacturer are designed to operate LESS THAN 20mph. Do Not
exceed or tire failure will occur.
Be a safe and courteous driver. Always yield to oncoming traffic in all situations, including narrow
bridges, intersections, etc. Plan your route to avoid heavy traffic.
Be observant of bridge loading ratings. Do not cross bridges rated lower than the gross weight at which
you are operating.
Watch for obstructions overhead and to the side while transporting.
Always operate equipment in a position to provide maximum visibility at all times. Make allowances
for increased length and weight of the equipment when making turns, stopping, etc.

9
OPERATING INSTRUCTIONS
To maximize the unit’s performance, it should be towed at speeds ranging from six to nine (6-9) mph.
This keeps the field debris moving through the harrow sections and avoids clogging. The best results
will be obtained after the paint has been scoured from the soil engaging components.
Transporting the unit
Getting the unit ready for transport (figure 1)
Lift the entire unit up and fold the wings into the wing rests.
Install the wing fold lock pins (1) and Bridge Pin (2). Refer to the diagram below.
Push the cylinder lock brackets (3) into place on the main frame lift cylinders (4) using the cylinder lock
handle (6). Rotate the handle lock (7) down and secure it with the bridge pin (5).
Getting the unit ready for field use: (figure 1)
Remove the cylinder lock brackets (3) from the main frame lift cylinders (4)by pulling on the cylinder
lock handle (6). Be sure to rotate the handle lock (7) down and secure it with the bridge pin (5).
Remove the wing fold lock pins (1) and Bridge Pins (2) and store them on the hitch storage bracket (8).
Unfold the wings and then lower the unit to the ground.
Figure 1
Setting the unit for field use
Leveling the wings (figure 2)
Adjust the turnbuckle (1) on the back side of the wing wheel mount brackets to level the wings from
side to side. This prevents the disk gangs from gouging and ridging. It also ensures a consistent
operating depth across the width of the unit.
* It is recommended that the unit be set level first. After making a pass through the field, disk gang
depth can be adjusted deeper or shallower for varying field conditions.

10
Figure 2
Setting disk gang depth (figure 3)
Adjust the hitch turnbuckle (1) with the turnbuckle wrench (2) provided to level the unit from front to
back. This ensures that the disk gang is set at the same depth as the spiral reels. Make a note of the mark
on the depth gauge (3) that is located on the turnbuckle lock (4).
Use the turnbuckle wrench (2) to adjust the hitch turnbuckle (1) to raise or lower the disk gangs. Each
mark on the depth gauge represents a 1” change in disk depth.
*It is not recommended that the disk gangs be run deeper than 4”. If more soil loosening is required,
increase the aggressiveness of the disk gang angle described in the next section.
Setting disk gang aggressiveness (figure 3)
Lower the unit until the disk gang contacts the ground. Remove the two bolts (5) that secure the outside
end of the disk gang.
Pivot the disk gang forward or backward to change the amount of soil the disk gang moves. Forward
will produce more loose soil while backward will produce less. Use the number markings to ensure that
all gangs are set to the same angle.
After all disk gangs have been set to the same angle, replace the two bolts (5) that secure the outside of
the disk gang.
* It is recommended that the disk gang angle number 2 be used first. After running the unit, increase the
aggressiveness of the disk gangs to loosen more soil.
* It may be necessary to reduce speed at the steeper gang angles to prevent ridging.

11
Figure 3
Setting the center disks (figure 4)
Adjust the center disks inward or outward to prevent ridges or gaps from forming in the center of the
unit. The angle of the center disks can also be changed by loosening the back bolt of the mounting
bracket and twisting to the desired angle.
* It may only be necessary to change the angle when the disk gangs are at the steeper angles.
Adjusting the spiral reel depth (figure 4)
Actuate the lift cylinders to the approximate desired depth.
Turn the single point depth control crank (2) to fully depress the pin on the hydraulic stop valve. Note
that one turn on the crank is a 1/4” change in working depth.
* Note that the spiral reels will generally run at the same depth as the disk gangs. Adjust the depth stops
to prevent the spiral reels from going too deep.
Figure 4

12
Adjusting the harrow section aggressiveness (figures 5 and 6)
In the least aggressive direction there are three attachment points for the pull chains on the harrow
section. Moving it up will cause the section to lay more flat (less aggressive) and moving it down will
cause the teeth to stand up more straight (more aggressive).
* Typically, the section should be set more aggressive for increased soil leveling and less aggressive in
heavy residue conditions. In some situations that do not require the extra leveling of the harrow section,
such as heavy fall residue, the sections can be removed.
Figure 5
Reversing the harrow sections and pulling them from the opposite end can change the angle of attack.
The steeper the angle of attack, the more aggressive the harrowing will be. It is recommended the least
aggressive angle be used with the pull hook in the top position as shown.
Figure 6
Adjusting the rolling basket height and tension (figure 7)
Remove the lynch pin (1) and flip the turnbuckle lock (2) up out of the way.
Adjust the turnbuckle (3) with turnbuckle wrench provided and lock back into place.

13
Figure 7
* Adjust the spring tension just tight enough to prevent it from loosening and falling out when in the
raised position. Set the rolling basket height by lowering the unit onto a flat surface and adjusting the
basket to just touch the ground. During operation the spring should only lightly stretch, approximately
1/16” gap between the spring coils. Too much spring tension will cause premature failure, especially
when going through waterways or ditches.
Performing Maintenance:
Good maintenance is your responsibility. Poor maintenance is an invitation to trouble.
Before working on this machine, stop the tractor or towing vehicle, set the brakes, lower into field
position, relieve the hydraulic fluid pressure, shut off the engine and remove the ignition keys.
Always use safety support and block the wheels. When performing maintenance, never use a jack to
support the machine. Assist the jack with blocks or other adequate support.
Use extreme caution when making adjustments.
When disconnecting hydraulic lines, shut off hydraulic supply and relieve all pressure.
Never use hands to locate a hydraulic leak on attachments. Use a piece of cardboard or wood.
Hydraulic fluid escaping under pressure can penetrate the skin.
Openings in the skin and minor cuts are susceptible to infection from hydraulic fluid. If injured by
escaping hydraulic fluid, see a doctor at once. Gangrene can result. Without immediate medical
treatment, serious infection and reactions can occur.
When installing, replacing, or repairing hydraulic system cylinders or parts, make sure that the entire
system is charged and free of air before resuming operations. Failure to bleed the system of all air can
result in improper machine operation, causing severe injury.
After servicing, be sure all tools, parts, and service equipment are removed.
Never replace hex bolts with less than grade five bolts unless otherwise specified.

14
Where replacement parts are necessary for periodic maintenance and servicing, genuine factory
replacement parts must be used to restore your equipment to original specifications. The manufacturer
will not claim responsibility for damages as a result of the use of unapproved parts.
If equipment has been altered in any way from original design, the manufacturer does not accept any
liability for injury or warranty.
MAINTENANCE AND SERVICE
Maintenance Schedule
After the first 12 hours of use, check tightness of bolts, especially those on the C-springs. Torque
specifications are listed in appendix A and the gang arbor bolt torque is defined in the “Disk Gang and
Blades” section below.
Prior to each use, check for loose bolts and replace lost or worn parts.
Parts diagrams and listings for service and repair references may be found in appendix B.
Grease hinge pins every 15 hours.
Grease spiral reel and disk bearings every 50 hours (sparingly).
Grease rolling basket bearings every 50 hours (sparingly).
Grease wheel bearings every 50 hours (sparingly) and check for endplay. Repack annually.
Note: Clean grease fittings and replace those that are broken or missing. Over greasing may damage
bearing seal and cause premature bearing failure.
Grease Fitting Locations
Number indicates grease interval in hours of operation.

15
Disk Gang & Blades
It will be necessary to check and tighten the disk gang arbor bolts to prevent excessive wear. It is
recommended that the gang arbor bolts be tightened to a torque between 600 and 800 ft-lb. A torque of
600 ft-lb would be equivalent to using a 4’ wrench with a 150lb person hanging freely on the end. A
torque of 800 ft-lb would be equivalent to a 200lb person using a 4’ wrench.
Replace the disk blades when they are worn to no smaller than 17” in diameter. It may be necessary to
add a 1-3/8” machine washer (listed in the disk gang parts listing in appendix C) if the hole in the shaft
does not line up with the castle nut.
Spiral Reel Blades
To replace a spiral reel blade, simply remove the bolts that secure it to the reel bracket and replace with
a new blade. Note the blade orientation.
BEVELED EDGE TRAILING
FRONT
ROTATION
Note: After the first 12 hours of use, retighten all of the spring bolts.

16
TROUBLESHOOTING AND ADJUSTMENT GUIDE
Problem Solution
Unit not running to desired
depth.
Be sure unit is completely lowered to the ground.
Lower disk gang to no more than 3” below the depth of the
spiral reel using the hitch turnbuckle.
Increase disk gang angle to loosen more soil
Soil not fully worked to
desired depth.
Lower disk gang to no more than 3” below the depth of the
spiral reel using the hitch turnbuckle.
Increase disk gang angle to produce more loose soil.
Increase travel speed to 8 – 9 mph.
Unit bounces or leaves
surface uneven in loose
soil.
Decrease depth of the spiral reels by carrying some of the
weight on the wheels. Use the depth stops on the main frame
lift cylinders only. The disk gang can then be lowered using the
hitch turnbuckle to the desired depth of soil tilling.
Center frame section not
working to desired depth
Raise the wing frame using the turnbuckles on the wing wheels
to prevent the wings from working deeper than the center
section.
Outside disk gang gouges. Level the wing frame using the turnbuckles on the wing wheels
to raise the outside of the disk gang.
Disk gang ridges between
adjacent passes.
Level the wing frame using the turnbuckles on the wing wheels
to raise the outside of the disk gang.
Reduce travel speed.
Reduce gang angle.
Spiral reel plugs in wet soil
conditions.
Decrease depth of the spiral reels by carrying some of the
weight on the wheels. Use the depth stops on the main frame
lift cylinders only. The disk gang can then be lowered using the
hitch turnbuckle to the desired depth of soil tilling.
Excessive clogging in
harrow during operation.
Increase ground speed to 8 – 9 mph.
Pull harrow sections from the less aggressive end.
Move the section pull chain attachment point to the top hole on
the front of the harrow sections, making it less aggressive.
For dry and fluffy residue, the pull chain attachment point on
the section may need to be moved to the bottom hole. This will
allow for more residue flow under the harrow bars.

17
BOLT TORQUE SPECIFICTIONS
Coarse Thread Series Fine Thread Series
Nut Size
and
Threads
per Inch
Nut
Tightening
Torque
(lb.ft.)
Nut Size
and
Threads
per Inch
Nut
Tightening
Torque
(lb.ft.)
Grade C Nuts Grade C Nuts
Max. Min. Max. Min.
1/4 - 20 14.7 10 1/4 - 28 14.7 10
5/16 - 18 22.3 15.2 5/16 - 24 23.4 18.4
3/8 - 16 39 28 3/8 - 24 41 30
7/16 - 14 60 44 7/16 - 20 60 44
1/2 - 13 88 63 1/2 - 20 98 70
9/16 - 12 134 98 9/16 - 18 134 98
5/8 - 11 172 127 5/8 - 18 176 127
3/4 - 10 295 218 3/4 - 16 295 218
7/8 - 9 440 317 7/8 - 14 440 317
1 - 8 651 506 1 - 14 703 610
TIRE & LUG TORQUE SPECIFICTIONS
Tire Size
Ply
Rating
Tire
Pressure Lug Size
Lug
Tightening
Torque (lb.ft.)
Max. Min.
18.5X8.5-8 6 ply 50 psi ½ nut 85 75
7.60-15 8 ply 52 psi ½ x 1 85 75
9.5L-15 8 ply 44 psi ½ x 1 85 75
11L-15 8 ply 36 psi ½ x 1 85 75
12.5L-15 10 ply 44 psi 9/16 x 1 80 90
12.5L-15 12 ply 52 psi 9/16 x 1 80 90
12.5L-15 18 ply 72 psi 5/8 nut 85 100
12.5L-15 F ply 90 psi 5/8 nut 85 100
36x16-17.5 14 ply 75 psi 5/8 nut 85 100

18
HI TCH FRAME
FOR RD-4000 SERI ES
Key Part No. Description Notes/ Revisions
1
1
1
RD-4411
RD-4409
RD-4418
HI TCH, 4X6 (4012-4014)
HI TCH, 4X6 (4016-4030)
HI TCH, 6X6 (4035-4045)
2 RT-2107 HI NGE PI N, 1-1/ 2x9-5/ 8
3 BHY-5635 9/ 16 - 12 X 3 1/ 2 GRADE 8 BOLT
4 NLT-5612 9/ 16-12 TOP LOCK NUT
5 RT-2112 PI VOT END TURNBUCKLE, 3 7/ 8” DOM
6 RT-3145 HI TCH TURNBUCKLE - 30"
7 RT-2111 HI TCH END TURNBUCKLE, 2 EAR
8 RT-2114 TURNBUCKLE LOCK, 3"
9 BH-5028 1/ 2 X 2 3/ 4 GRADE 5 HEX BOLT
10 RT-2113 TURNBUCKLE PI N - 1 1/ 4 X 5 1/ 4
11 RD-4309 HYDRAULI C HOSE RACK CLAMP
12 BH-4420 7/ 16 X 2 HEX BOLT
13 NLT-4414 7/ 16 TOP LOCK NUT
14 LW-0025 1/ 4 LOCK WASHER
15 NH-2520 1/ 4 HEX NUT
16 PH-8860 HI TCH PI N, 7/ 8 x 6 w/ # 6 BRI DGE PI N
17 RT-2416 TURNBUCKLE WRENCH, 1 1/ 4"
18 LB-1110 LI GHT PLUG STORAGE

19
HI TCH FRAME (continued)
19 BH-2510 1/ 4 X 1 HEX BOLT
20 RD-4308 HYDRAULI C HOSE RACK
21 NLT-1008 1” TOP LOCK NUT
22
22
22
PPI -200
PPI -300
PPI -400
HI TCH BASE CAT I I ( 4012-4016)
HI TCH BASE CAT I I I ( 4020)
HI TCH BASE CAT I V (4025-4045)
See drawbar hitch diagram
for details
23 BHY-1070 1 X 7 GRADE 8 HEX BOLT
24
24
24
CH-1816
CH-1820
CH-1830
SAFETY CHAI N, 16,100lbs (4012-4030)
SAFETY CHAI N, 20,200lbs (4035)
SAFETY CHAI N, 30,400lbs (4045)
25 RT-2054 BUSHI NG, 1 7/ 8"ODx1 1/ 4"I Dx1"
26 RT-3103 SAFETY CHAI N WASHER
27 BHY-1085 1 X 8 1/ 2 GRADE 8 HEX BOLT
28 RT-3144 JACK, SQ-15", 2000#
29
29
BU-1265
BU-1267
1/ 2 x 6 x 5 U-BOLT (4012 – 4030)
1/ 2 x 6 x 7 1/ 4 U-BOLT (4035 – 4045)
30 RD-4306 DOCUMENT TUBE
31 MM-1204 4” HOSE CLAMP
32 NLT-5013 1/ 2-13 TOP LOCK NUT
HI TCH
Key
Part No. Description Notes/ Revisions
1
1
1
PPI -200
PPI -300
PPI -400
HI TCH BASE, CAT. I I
HI TCH BASE, CAT. II I
HI TCH BASE, CAT. IV
2 PPI -208 HI TCH CLEVI S CAT. I I & I I I only
3 PPI -203 V -PLATE CAT. I I – I V
4 PPI -201 CUSHI ON
5 PPI -202 TOP PLATE, CAT. I I
5 PPI -302 TOP PLATE, CAT. I I I – I V
6 BHY-7525 3/ 4 X 2 1/ 2 GRADE 8 BOLT
7 BHY-7555 3/ 4 X 5 1/ 2 GRADE 8 BOLT CAT. I I & I I I only
8 NLT-7510 3/ 4 TOP LOCK NUT CAT. I I & I I I only

20
MAI N FRAME AXLE
FOR RD-4012, 4014, 4016, 4020, 4025 AND 4030
