MDT AKS-0410.01 User manual

MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
1
3/2012
Manual
MDT Switch Actuators
StandardSwitchActuatorsSeries
AKS-0410.01
AKS-0416.01
AKS-0810.01
AKS-0816.01
AKS-1210.01
AKS-1216.01

HeavyC‐loadsSwitchActuatorsSeries
AKI-0416-01
AKI-0816-01
AKI-1216-01
CompactSwitchActuatorsSeries
AKK-01UP.01
AKK-02UP.01
AKK-0216.01
AKK-0406.01
AKK-0810.01
AKK-0816.01
AKK-0810A.01
AKK-1610.01
AKK-1616.01

TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
2
1Content

1Content.................................................................................................................................................2
2Overview.............................................................................................................................................4
2.1Overviewdevices...........................................................................................................................4
2.2Exemplarycircuitdiagrams...........................................................................................................5
2.3Structure&Handling.....................................................................................................................6
2.4Functions.......................................................................................................................................7
2.4.1Overviewfunctions.................................................................................................................7
2.5.SettingsattheETS‐Software........................................................................................................8
2.6.Startingup....................................................................................................................................8
3Communicationobjects........................................................................................................................9
3.1Communicationobjectsperchannel.............................................................................................9
3.2Centralcommunicationobject....................................................................................................10
3.3Defaultsettingsofthecommunicationobjects..........................................................................10
4ReferenceETS‐Parameter..................................................................................................................11
4.1GeneralSettings..........................................................................................................................11
4.2Channelselection........................................................................................................................12
4.3Identicalparameter.....................................................................................................................13
4.3.1Relayoperatingmode..........................................................................................................13
4.3.2Centralfunction....................................................................................................................14
4.3.3Behavioratblock/unblock....................................................................................................14
4.3.4Behavioratbuspowerup/down..........................................................................................16
4.4Switchingoutput.........................................................................................................................17
4.4.1Overview...............................................................................................................................17
4.4.2On/Offdelay.........................................................................................................................19
4.4.3Logicalfunctions...................................................................................................................20
4.4.4Scenefunction......................................................................................................................21
4.5Staircase......................................................................................................................................26
4.5.1Overview...............................................................................................................................26
4.5.2Staircasetime.......................................................................................................................28
4.5.3PrewarningundWarning.....................................................................................................29
4.5.4Manualswitchoff.................................................................................................................30
4.5.5Extendstaircasetime...........................................................................................................30
5Index...................................................................................................................................................31
5.1Registerofillustrations................................................................................................................31
5.2Listoftables.................................................................................................................................32


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
3

6Attachment.........................................................................................................................................33
6.1Statutoryrequirements...............................................................................................................33
6.2Routinedisposal..........................................................................................................................33
6.3Assemblage..................................................................................................................................33
6.4Datasheet....................................................................................................................................34



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
4
2Overview

2.1Overviewdevices

Themanualreferstothefollowingdevices,whichareinourassortmentofswitchactuators.Actually
wecanofferyouthefollowingswitchactuators(OrderCoderespectivelyprintedinboldtype):

AKS‐0416.01Switchactuator4‐fold,4TE,230VAC,16A,C‐Load100µF,standarddesign
AKS‐0410.01Switchactuator4‐fold,4TE,230VAC,10A,C‐Load100µF,standarddesign
AKS‐0816.01Switchactuator8‐fold,8TE,230VAC,16A,C‐Load100µF,standarddesign
AKS‐0810.01Switchactuator8‐fold,8TE,230VAC,10A,C‐Load100µF,standarddesign
AKS‐1216.01Switchactuator12‐fold,12TE,230VAC,16A,C‐Load100µF,standarddesign
AKS‐1210.01Switchactuator12‐fold,12TE,230VAC,10A,C‐Load100µF,standarddesign
AKI‐0416.01Switchactuator4‐fold,4TE,230VAC,16A,C‐Load200µF,industrialdesign
AKI‐0816.01Switchactuator8‐fold,8TE,230VAC,16A,C‐Load200µF,industrialdesign
AKI‐1216.01Switchactuator12‐fold,12TE,230VAC,16A,C‐Load200µF,industrialdesign
AKK‐0810A.01Switchactuator8‐fold,surfacemounted,230VAC,10A,compactdesign
AKK‐01UP.01Switchactuator1‐fold,flush‐mounted,230VAC,16A,compactdesign
AKK‐02UP.01Switchactuator2‐fold,flushmounted,230VAC,6A,compactdesign
AKK‐0216.01Switchactuator2‐fold,2TE,230VAC,16A,compactdesign
AKK‐0416.01Switchactuator4‐fold,4TE,230VAC,16A,compactdesign
AKK‐0816.01Switchactuator8‐fold,4TE,230VAC,16A,compactdesign
AKK‐0810.01Switchactuator8‐fold,4TE,230VAC,10A,compactdesign
AKK‐1616.01Switchactuator16‐fold,8TE,230VAC,16A,compactdesign
AKK‐1610.01Switchactuator16‐fold,8TE,230VAC,10A,compactdesign



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
5

2.2Exemplarycircuitdiagrams

Illustration1:ExemplarycircuitdiagramAKS‐1216.01
Always2channelshavecommonL‐connectionsatthestandarddesign.


Illustration2:ExemplarycircuitdiagramAKI‐1216.01
EveryL‐connectionisbroughtoutseparatelyattheindustrialdesign.


Illustration3:ExemplarycircuitdiagramAKK‐1610.01
AlwaysfourchannelshavecommonL‐connectionsatthecompactdesign.


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
6

2.3Structure&Handling

Theswitchactuators(here:AKI1216.01)containofonestatusLEDperchannel.ThisLEDindicates
thestateofthedependingoutput.Furthermoreeveryoutputcanbeswitchedmanual,independent
ofthecurrentparameterization.ThelinesAKSandAKIhavebuttonsforeverychannel.Incontrast
thelineoftheAKKhasonlyfourbuttons,independenttothenumberofchannels.Twobuttonsare
forchoosingthechannel,wherebythechosenchannelisindicatedbyaflashingstatusLED.The
buttonsupanddownareforswitchingthechannelonandoff.Theprogrammingbuttonactivates
theprogrammingfunction.AnactivatedprogramingfunctionisindicatedbyalitprogrammingLED.

Illustration4:Overviewhardwaremoduleswitchactuator(e.g.AKK‐1610.01)

ThelinesAKSandAKIhavebistablerelays.ThelineAKKhasmonostablerelays.
Atthebistablerelaysthecurrentswitchingstatealsostaysincaseofabreakdownofthe230V
auxiliaryvoltageandatanupdateoftheparameterization.
Themonostablerelaysfallbacktotheiroutputstatewhenthepowerbreaksdownorthe
parameterizationisupdated.


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
7

2.4Functions

Allofthechannelshaveidenticalfunctions(havealookatthefunctionaloverview).Thenumbersof
channelsdependstothehardwaredesign,whichcanhave2,4,8,12or16channels.The
identificationisstandardlyinconsecutivealphabeticorder.
Thereare3differentstatesforeverychannelpossible:
notactive
Thechannelhasnofunction.Sotherearenocommunicationobjectsforthischannelshown.
Switch
Ifthechannelischosenasswitch,therewillbedifferentparameterizationoptionsfor
configuringtheswitchingprocess.
Staircase
Now,thechannelcanbecomeastaircaselightfunction.Thisfunctioncausesanautomatic
switchoffofthechannelafteranadjustedtime.

2.4.1Overviewfunctions

GroupoffunctionsFunctions
Groupaddressesnumberofobjects/connections=
dynamic(freelyassignableoftheuser)
Resetbehaviorbehavioratbuspowerbreakdown
behavioratbuspowerup
startuptimeout
Relaymodenormallyclosed/normallyopened
Switchfunctionsswitching
centralswitchingfunction
Timefunctionson‐delay
off‐delay
Staircaselightfunctionstimeforstaircase
pre‐warning(withadjustablewarningand
pre‐warningtime)
manualoff
retriggerableon/off
Superordinatefunctionsblockingfunction
logicfunctions(AND/OR)
Scenesscenefunctionforupto8scenesperchannel
Statusfunctionsfeedbackfunction
Chart1:Overviewfunctionalpossibilities



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
8

2.5.SettingsattheETS‐Software
Selectionattheproductdatabase:

Manufacturer:MDTTechnologies
Productfamily:Actuator
Producttype:SwitchActuators
MediumType:TwistedPair(TP)
Productname:addictedtotheusedtype,e.g.:AKI‐1216.01switchactuator12‐fold,8TE,16A
Ordernumber:addictedtotheusedtype,e.g.:AKI‐1216.01

2.6.Startingup

Afterwiring,theallocationofthephysicaladdressandtheparameterizationofeverychannelfollow:
(1) Connecttheinterfacewiththebus,e.g.MDTUSBinterface
(2) Switchingthepowersupply
(3) Setbuspowerup
(4) Presstheprogrammingbuttonatthedevice(redprogrammingLEDlights)
(5) LoadingofthephysicaladdressoutoftheETS‐Softwarebyusingtheinterface(redLEDgoes
out,aswellthisprocesswascompletedsuccessful)
(6) Loadingoftheapplication,withrequestedparameterization
(7) Ifthedeviceisenabledyoucantesttherequestedfunctions(alsopossiblebyusingtheETS‐
Software)


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
9

3Communicationobjects

3.1Communicationobjectsperchannel

Thecommunicationobjectsperchannelaredisplayed,whentheyareactivatedtroughthe
parameterization.Thereare8numbersreservedforeverychannel,evenifnotallofthemareneed.
Sothefirstchannelhasthenumbersfrom0to7,thesecondfrom8to15andsoon.The
communicationobjectsareneedfortheconnectiontothegroupaddressesandtoprogramyour
project.
ThefollowingillustrationshowsthecommunicationobjectsforthechannelsAandB.ChannelAis
selectedasswitch.Logicfunctions,blockingobjectandscenesareactivated.ChannelBisselectedas
staircase.Onlytheblockingfunctionisactivated:

Illustration5:Communicationobjectsperchannel(ChannelA–switch;ChannelB–staircase)


Thefollowingcommunicationobjectscanbeshownforachannelselectedasswitch:
Nr.FunctionUsageDatatype 
0Switchon/offswitchesthechannelon/offDPT1.001In,Write
2BlockblocksthechannelDPT1.001In,Write
4ScenecallsactivatedscenesDPT18.001In,Write
5StatusfeedbackfunctionDPT1.001Out,Read
6Logic1onlyshownatactivatedlogicfunctionDPT1.001In,Write
7Logic2onlyshownatactivatedlogicfunctionDPT1.001In,Write
+8nextchannel  
Chart2:Communicationobjects“switch”


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
10

Thefollowingcommunicationobjectscanbeshownforachannelselectedasstaircase:
Nr.FunctionUsageDatatype 
1Staircaseswitchesthestaircasefunctionon/offDPT1.001In,Write
2BlockblocksthechannelDPT1.001In,Write
5StatusfeedbackfunctionDPT1.001Out,Read
+8nextchannel  
Chart3:Communicationobjects“staircase”

3.2Centralcommunicationobject

Thecentralfunctionisalwaysshownalsoifitisnotusedinanyofthechannels.Thecommunication
objectforthecentralfunctionisatthebottomofthecommunicationobjects.Ithasalwaysthefirst
numberafterthecommunicationobjectsforthechannels.Soatan8‐foldswitchactuator,ithasthe
number64.
Thecommunicationobjectofthecentralfunctioncallsallchannels,whichhaveanactivatedcentral
function.

Thefollowingcommunicationobjectexistsonlyonceandisforchannels:
Nr.FunctionUsageDatatype 
CentralfunctionnumberaccordstothehardwaredesignDPT1.001In,Write
Chart4:Centralcommunicationobject 

3.3Defaultsettingsofthecommunicationobjects

Thefollowingchartshowsthedefaultsettingsofthecommunicationobjects:
Defaultsettin
g
s
Nr.NameObjectFunction Length PriorityCR W T U
0ChannelAswitchon/off 1Bit LowXX
1ChannelAStaircase 1Bit LowXX
2ChannelABlock 1Bit LowXX
4ChannelAScene 1Byte LowXX
5ChannelAStatus 1Bit LowXX X
6ChannelALogic 1 1 Bit LowXX
7ChannelALogic 2 1 Bit LowXX
+8nextchannel
96
128
Centralfunctionswitchon/off1BitLowX X
Chart5:Communicationobjects–defaultsettings

Youcanseethedefaultvaluesforthecommunicationobjectsfromtheupperchart.Accordingto
requirementsthepriorityoftheparticularcommunicationobjectsaswellastheflagscanbe
adjustedbytheuser.Theflagsallocatesthefunctionoftheobjectsintheprogrammingthereby
standsCforcommunication,RforRead,Wforwrite,TfortransmitandUforupdate.


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
11

4ReferenceETS‐Parameter

4.1GeneralSettings

Thefollowingparameterexistsonlyonceandaffectstoallchannels:

Illustration6:Generalsettings

Theparameterstartuptimeoutadjuststhetimebetweenanuploadandthefunctionalstartofthe
device.Theusedhardwarereactsonlyafterexpirationoftheadjustedtime.Allinputcommands
beforethestartuptimeoutexpire.

Thefollowingchartshowsthedynamicrangeofthisparameter:
ETS‐textDynamicrange
[defaultvalue]
comment
Startuptimeout1‐60s
[1s]
Timebetweenanuploadandthe
functionalstartofthedevice
Chart6:Generalsettings



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
12

4.2Channelselection

Thefollowingillustrationshowsthemenuforselectingthechannels:

Illustration7:Channelselection

Thereare3possiblestatesforeverychannel,whichcanbeadjustedatthemenu“channel
preselection”.Thefollowingparameterizationaccordstothechosenstateofachannel.Butifyou
chosseachannelas“notactive”,therewillbenofurtherparameterizationoptionsavailable.

Thechartshowsthesettingoptionsforevereychannel:
ETS‐textDynamicrange
[defaultvalue]
comment
ChannelA‐[O]notactive
Switch
Staircase
Operatingmodeofthe
channels
Chart7:Channelselection



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
13

4.3Identicalparameter

Thefollowingparameters,whicharedescribedattheheadings4.3.x,areaswellavailableat
channelsselectedasswitchasatchannelsselectedasstaircase.

4.3.1Relayoperatingmode

Thefollowingillustrationshowsthesettingoptionsforthisparameter:

Illustration8:Operatingmode

Thefollowingchartshowsthedynamicrangeforthisparameter:
ETS‐textDynamicrange
[defaultvalue]
comment
Modenormallyopened
normallyclosed
Relayoperatingmodeofthe
channel
Chart8:Operatingmode


Thefollowingdiagramshowsthebehavioroftherelayoperatingmodenormallyclosedandnormally
opened.TheinputforthechannelsisaKNX‐telegram,whichsendsalternating0‐signalsand1‐signals:



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
14

4.3.2Centralfunction

ThefollowingillustrationshowsthesettingoptionsattheETS‐Software:

Illustration9:Centralfunction

Thefollowingchartshowsthedynamicrangeforthisparameter:
ETS‐textDynamicrange
[defaultvalue]
comment
Centralfunctionnotactive
active
switchesthecentralfunction
on/offforthischannel
Chart9:Centralfunction


Thecentralfunctioncanbeswitchedon/offforeverychannel.Forswitchingonthisfunction,you
havetochoosetheoption“active”.Bycallingthecentralcommunicationobject,allchannelswithan
activatedcentralfunctionareswitchedonwiththeircurrentparameterization.Soswitch‐ondelays
orstaircasefunctionsarestillkept.
Thecentralfunctioncanmakeprogrammingmuchmoreeasierandyourprojectcanbecomemore
clear.

Thefollowingchartshowstheassociatedcommunicationobject:
NumberNameLength Usage
Centralfunction1Bitcentralswitchingofthechannels
numberdependstothenumberofchannels
Chart10:Communicationobjectcentralfunction


4.3.3Behavioratblock/unblock

ThefollowingillustrationshowsthesettingoptionsattheETS‐Software:

Illustration10:Blockingfunction

Thefollowingchartshowsthedynamicrangeforthisparameter:
ETS‐textDynamicrange
[defaultvalue]
comment
Behaviorwhenlocked
Behaviorwhenunlocked
On
Off
nochange
Behaviortoa
blocking/unblockingprocess
Chart11:Behavioratblock/unblock


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
15

Theblockingfunctiongetsactive,whenthecorrespondingcommunicationobjectbecomesalogical
“1”.Bysendingalogical“0”,theblockingfunctioncanbedeactivatedagain.
Theparameter“Behaviorwhenlocked”definesanactionfortheoutputatactivatingtheblocking
process.Therearethesettingon,offandnochangeavailable.Thesamesettingsarealsoavailable
forthe“Behaviorwhenunlocked”.Thisactioniscalledwhentheblockingfunctionisdeactivated
again.

Thefollowingchartshowsthecorrespondingcommunicationobject:
NumberNameLength Usage
2Block1Bitblocksthechannel
Chart12:Communicationobjectblockingfunction

Thefollowingdiagramdescribestheblockingprocess.Forthe“Behaviorwhenlocked”,theactionon
wasparameterizedandforthe“Behaviorwhenunlocked”theactionoffwasparameterized:


TheKNXtelegramshowswhichvaluesaresendtotheblockingobject.Bysendingalogical“1”,the
blockingfunctionisactivatedandthechannelisswitchedon.Theblockingfunctionisdeactivated
againbysendingalogical“0”.Sothechannelisswitchedoff.


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
16

4.3.4Behavioratbuspowerup/down

ThefollowingillustrationshowsthesettingoptionsattheETS‐Software:

Illustration11:Behavioratbuspowerup/down

Thefollowingchartshowsthedynamicrangeforthisparameter:
ETS‐textDynamicrange
[defaultvalue]
comment
Behavioratbuspowerup/
Behavioratbuspowerdown
On
Off
nochange
Adjustment,howthechannel
shallreactincaseofabus
powerbreakdown/return
Chart13:Behavioratbuspowerup/down

Everychannelcanoccupyacertainstateaswellincaseofabuspowerbreakdownasincaseofabus
powerreturn.Thechannelcanbeswitchedofforon,butalsostayinitscurrentstatebychoosing
theparameter“nochange”.
Toavoidproblemsincaseofabuspowerbreakdown,youshouldadjustthisparametervery
conscientious.Becausethereisnocontrollingpossibleaslongasthebuspowerisdown.


TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
17

4.4Switchingoutput

Thefollowingparameters,whicharedescribedattheheadings4.4.x,areonlyavailableatchannels
selectedasswitch.

4.4.1Overview

Bychoosingachannelasswitch,asubmenu,calledChannelASwitching,appearsforthischannelat
theleftdropdownmenu.
Thesubmenuisshownatthefollowingillustration:

Illustration12:Switchingoutput




TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
18

Thechartshowsthepossiblesettingsforswitchingoutputs:
ETS‐textDynamicrange
[defaultvalue]
comment
Modenormallyopened
normallyclosed
Operationmodeofthechannel
On‐Delay0…30000sec
[0=nodelay]
Switchondelayofthechannelin
seconds
Off‐Delay0…30000sec
[0=nodelay]]
Switchoffdelayofthechannelin
seconds
Centralfunctionnotactive
active
Activatesthecentralfunctionforthis
channel
BehaviorwhenlockedOff
On
nochange
Actionforactivatingtheblocking
process
BehaviorwhenunlockedOff
On
nochange
Actionfordeactivatingtheblocking
process
BehavioratbuspowerdownOff
On
nochange
Actionforabuspowerbreakdown
BehavioratbuspowerupOff
On
nochange
Actionforabuspowerreturn
Logicfunctionnotactive
withoneobject
withtwoobjects
Activationofthelogicfunctionwithone
ortwoobjects
LogicoperationAnd
Or
Selectionofthelogicfunction
onlyavailable,whenthelogicfunction
wasactivated
Scenenotactive
active
Activationofthescenefunction
byactivationthisparameteranewsub
menuappears
(havealookat4.4.4)
Chart14:Switchingoutput



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
19

4.4.2On/Offdelay

ThefollowingillustrationshowsthesettingoptionsattheETS‐Software:

Illustration13:On/Offdelay

Theon‐delaycausesadelayedswitchofthechannel.Atsendinganon‐signaltothechannel,firstthe
adjustedondelaytimeexpiresandafterwardsthechannelwillbeswitchedon.
Theoffdelayworksonthesameprinciple.Atsendinganoff‐signal,firsttheadjustedoffdelaytime
expiresandafterwardsthechannelwillbeswitchedoff.
Bothfunctionsworkaswellaloneascombined.Byadjusting“0seconds”foradelaythefunctionis
switchedoff.
Thefollowingdiagramdescribesthecombinationofonandoffdelay:



TechnicalManualSwitchActuatorsAKI/AKS/AKK
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
Tel.: [phone] • Fax: [phone] • [email protected] • www.mdt.de
20

4.4.3Logicalfunctions

ThefollowingillustrationshowsthesettingoptionsattheETS‐Software:

Illustration14:Logicalfunctions

Thelogicfunctioncanbeactivatedwithoneortwoobjects.Theobjectsaretheinputsofthelogic
block.FurthermoreyoucanchoosebetweenanAND‐functionandanOR‐function.
Whenyouhaveactivatedthelogicfunction,thelogicblockhastobesatisfiedbeforeswitchingthe
channel.Aslongasthelogicfunctionisnotsatisfied,thechanneldoesnotreacttoanysignal.

Thefollowingchartshowstherelevantcommunicationobjects:
NumberNameLength Usage
6Logic11BitLogicobject1,isthefirstinputforthelogic
block
7Logic21BitLogicobject2,isthesecondinputforthelogic
block
Chart15:Communicationobjectslogic

Accordingtothechosenlogicoperationonlyoneorbothobjectshavetobecomea1‐signal.
Thefollowingchartshowsthebothlogicoperationswithtwoobjects:
AND‐ConnectionOR‐Connection
Logic1Logic2Channel
switchable?
Logic1Logic2Channel
switchable?
00No00No
01No01Yes
10No10Yes
11Yes11Yes
 Chart16:Logicoperations



