debritom+QuickCard - EN
1. Turn on debritom+
debritom+ON Activate foot pedal 1x to
connect with debritom+
2. debritom+set-up
2a
„click“
2b
2c 2d 2e
Insert pump as shown until it stops/turn clockwise until click
Attach the luer connection - make sure the
connection is tighten securely
Attach rinsing fluid, connect the connecting tube to pump
Connecting tube: close clamp/spike into rinsing fluid/open venting cover
Open clamp
3. Test of water jet
Press foot on/off switch
•For a vusual test of water jet (flat or
point, water jet thickness)
•To test the water jet intensity on your
hand – start with a distance of 25 cm
(approx. twice the hanpiece-length).
Guide the jet starting at the wound
edge, and move the jet slightly back
and forth.
•If something doesn‘t work, replace the
handpiece
4. Optimal working parameters
Intensity levels at START for each handpiece : Level 4
(Level 1-5/weak-strong)
debritom+handpiece standard jet REF 2000.0003
Working distance recommended 8 - 15cm
debritom+handpiece flat jet narrow REF 2000.0004
Working distance recommended 4 - 10cm
debritom+handpiece flat jet wide REF 2000.0005
Working distance recommended 3 - 8cm
Working angle: 3 – 45 degrees to wound surface
TIP flat jet: The flat jet should be applied like a spatula to the wound.
5. Intensity-
Level
Intensity
Intensity
6. Patient change / end of the treatment
6a Patient change, pump one day
6b End of the treatment
Close clamp Remove handpiece and dispose of it Attach LuerCap
For next patients
=> 2d
Remove connecting tube/Remove pump and handpiece as one unit and dispose of it
debritom+OFF
Contraindication
• Malignant tumours
• Open blood vessel lesions, unprotected vascular systems
• Eyes, nose and ears
• Exposed nervous/neurovascular beams
• Complex and/or highly contaminated wounds
• Patients with HIV, hepatitis C or other transmissible diseases/infection
Warning: In the following cases, the risks when using the device increase:
• Patients with a higher tendency to bleeding and arterial ulcers
• Patients with infected wounds
In such cases, the doctor must decide whether and in what form the treatment should
be provided
debritom+QuickCard - EN
7. Error messages
NOTE: The on/standby button lights up red as an error message occurs.This button can be used to acknowledge the fault after rectification.
Battery foot on/off switch almost empty
Troubleshooting: Replace batteries (Battery type 2 x LR03/AAA, chapter 11)
Pump in use for too long time period
Troubleshooting: Replace pump
Handpiece in use for too long or trying to use with different single use pump
Troubleshooting: Replace handpiece
Handpiece missing or handpiece not recognized
Troubleshooting: Replace handpiece. If the error can not be resolved, contact the Medaxis service department immediately.
Nozzle blocked or motor overheated
Troubleshooting: Change handpiece and pump if necessary. If the error can not be resolved, contact the Medaxis
service department immediately.
Pump not inserted correctly
Troubleshooting: Replace pump and reinsert it correctly, or replace it.
General system error
Troubleshooting: Please contact the Medaxis service department immediately.
No foot on/off switch detected
Troubleshooting: Press the foot on/off switch. If foot on/off switch cannot be detected, re-pair. (See chapter 11)
8. Symbols on debritom+display
press
confirm
4
Search for Bluetooth device for pairing
Pressing the on/standby and ‚+‘ buttons for > 1 s at debritom+ will show the ‚Search for Bluetooth device‘
symbol for pairing a new or replacement of the foot on/off switch.
Bluetooth signal of foot on/off switch detected - confirm
As soon as debritom+has detected the Bluetooth signal of the foot on/off switch, this symbol appears on the display.
debritom+connected with foot on/off switch
This symbol appears on the display as the foot on/off switch is connected to debritom+.
Intensity levels
The intensity levels can be adjusted between 1 - 5. (1 weakest/5 strongest)
This QuickCard does not replace the Instruction for use REF 9000.5503
Medaxis AG
Bahnhofstrasse 9 T +41 62 823 88 00 www.medaxis.ch
medaxis AG / REF 9000.5000_e / 22.11.2018 / EN
