Medela Harmony Assembly instructions

Instructions & assembly.
Instrucciones.
Instructions et
assemblage.
Harmony™
Manual breastpump
Sacaleches manual
Tire-lait manuel

Table of Contents-English
Harmony Parts & Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Ordering Parts............................................. 2
Before You Begin ..........................................4
Prior to Each Use ..........................................4
Hygiene..................................................4
Single User Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Harmony Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Harmony Assembly.......................................6-7
Using Your Breastpump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
When to Use..............................................9
Upgrading to Electric Pumping . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-11
Tips for Success & Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . .12
Storing & Handling Breastmilk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Warming/Thawing Breastmilk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Índice
Piezas y armado del sacaleches Harmony . . . . . . . . . . . . . . . . . . 16-18
Pedido de piezas........................................17
Antes de empezar .......................................19
Antes de cada uso.......................................19
Higiene ...............................................19
Advertencia sobre el uso individual. . . . . . . . . . . . . . . . . . . . . . . . . . .19
Desarmado del sacaleches Harmony . . . . . . . . . . . . . . . . . . . . . . 20-21
Armado del sacaleches Harmony. . . . . . . . . . . . . . . . . . . . . . . . . 21-22
Cómo usar el sacaleches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Cuándo usar el sacaleches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Cómo empezar a usar un sacaleches eléctrico. . . . . . . . . . . . . . . 25-26
Consejos para alcanzar el éxito y solucionar problemas . . . . . . . . . . . 27
Cómo almacenar y manipular la leche materna. . . . . . . . . . . . . . . . . . 28
Cómo calentar/descongelar la leche materna . . . . . . . . . . . . . . . . 29-30
Información sobre la garantía . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Table des matières
Pièces et assemblage du tire-lait Harmony . . . . . . . . . . . . . . . . . . . . 31-33
Commande de pièces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Avant de commencer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Avant chaque utilisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Hygiène ..................................................... 34
Mise en garde - Utilisatrice unique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Désassemblage du tire-lait Harmony . . . . . . . . . . . . . . . . . . . . . . . . . 35-36
Assemblage du tire-lait Harmony . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36-37
Utilisation du tire-lait . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Quand utiliser le tire-lait Harmony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Passage à une expression électrique avec le tire-lait
Symphony® de Meleda ..................................... 40-41
Conseils pratiques et dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Conservation et manipulation du lait maternel . . . . . . . . . . . . . . . . . . . . 43
Réchauffement/décongélation du lait maternel . . . . . . . . . . . . . . . . 44-45
Garantie .................................................... 45

The Harmony™ Breastpump
The Harmony is a breakthrough in manual breastpump
technology. It is the first and only manual pump with
2-Phase Expression® technology – a dual pumping
pattern that comes closer than ever to the way a baby
naturally breastfeeds.
The first phase, called the stimulation phase, mimics
a baby’s initial rapid, shallow sucking that encourages
fast let-down. The second phase, the expression phase,
simulates a baby’s more relaxed, deeper sucking that
promotes efficient milk removal.
The Harmony breastpump is the BPA-free manual
pump of choice, preferred by 9 out of 10 moms. All
Medela products that come into contact with breastmilk
are BPA-free.
Your Harmony breastpump is designed to provide you
gentle comfort while pumping. The contoured handle is
ergonomically designed to fit either
hand comfortably. The handle
also swivels, allowing you to
position your hand and the
pump more easily and
comfortably on each breast.
As a one-piece unit, there is
no assembly or extra pieces
to clean and store.
Harmony…blending quiet,
effective pumping with
ease, gentle comfort
and convenience.
1

Harmony™ Breastpump Parts
& Assembly
A. Handle ......................... #8007170
A1. Let-down symbol
B. Diaphragm, Stem, O-Ring assembly . .#8207234
C. PersonalFitTM breastshield . . . . . . . . . . .#8107084
D. Pump body . . . . . . . . . . . . . . . . . . . . . .#8007196
E. White membrane . . . . . . . . . . . . . . . . . .#8207013
F. Yellow valve . . . . . . . . . . . . . . . . . . . . . . #8100475
G. Breastmilk bottle . . . . . . . . . . . . . . . . . .#8117009
H. Bottle stand . . . . . . . . . . . . . . . . . . . . . . #8100462
J1. Solid lid. . . . . . . . . . . . . . . . . . . . . . . . . .#8107057
J2. Disc for bottle collar . . . . . . . . . . . . . . . .#8100473
J3. Collar ...........................#8107182
Note: Handle (A) & diaphragm/stem (B) do not need to be
disassembled and cleaned after each use, unless it is apparent the
assembly has become soiled. White o-ring on stem does not need
to be removed.
Ordering Parts
In the US and Canada, if your retailer does not carry
the parts you need, you can place a credit card order
by phone by calling 1-800-435-8316 (US & Canada),
1-815-363-1166 (US only) or 1-905-608-7272 (Canada).
VISA, MasterCard, American Express and Discover
Card are accepted. In other countries, please contact your
local distributor. Please visit our website,
www.medela.com for a list of worldwide distributors.
2

3
Breastpump Parts
A1
D
A
CB
E
F
J1
G
J3
J2
H

Before You Begin
Before using your Harmony™ for the first time:
The Harmony sanitized version does not require washing before
first use.
Disassemble parts – refer to diagram on page 3 and
photos on page 5-6. Sanitize in boiling water for 10 minutes.
Prior to each use:
Disassemble the PersonalFit™ breastshield, pump body, valve,
membrane and bottle.
All parts are to be disassembled and washed separately for the
pump to function efficiently.
Under normal use, the pump handle (A) and diaphragm/
stem (B) only need to be cleaned periodically or when it is
apparent they have become soiled. Hint: Do not remove small
white o-ring from stem.
Wash remaining parts in dishwasher or in soapy water and
rinse well. Air dry parts on clean towel and cover when
not in use.
Do not use with Quick Clean™ Micro-Steam™ bags. Wash only
according to the instructions above.
Hygiene:
Wash hands thoroughly before pumping. If your physician
recommends it, clean breast and surrounding area with a
damp cloth. Do not use soap or alcohol, which can dry the
skin and cause cracked nipples.
Using a breastpump should never be uncomfortable. If you
experience any pain, contact your healthcare provider or
lactation specialist immediately.
Single User Caution:
The Harmony breastpump is a personal care item that should
not be shared between users.
4

Harmony™ Disassembly
1. Remove the PersonalFit™
breastshield (C) from the
pump body (D).
2. Remove the pump handle
assembly (A-B) from the
pump body (D). Check to
see if it needs cleaning.
3. Hold the pump body (D) and
unscrew from the bottle (G).
4. Pull yellow valve (F)
from pump body (D)
by twisting gently.
5

Harmony™ Disassembly (continued)
6
5. Remove white membrane
(E) from yellow valve (F).
Harmony Assembly
1. Snap white membrane (E)
button into small opening
on yellow valve (F) until
membrane lies completely
flat on valve. (Both parts
should be completely dry
before assembly.)
2. Push yellow valve (F)
securely onto inner ring of
pump body (D).
3. Screw bottle (G) onto pump
body (D).

7
4. If the handle components
(A & B) have been
disassembled: place the
oval shaped base of the
stem into the diaphragm (B).
Hint: Make sure the oval
shape is lined up correctly
in the diaphragm.
5. Place silicone diaphragm/
stem (B) into pump handle
(A) and press down firmly
around entire edge to ensure
proper seal. The lines on the
diaphragm should line up
with the yellow dots on the
handle.
6. Insert stem of handle
assembly into opening on
top of pump body (D) and
push until you feel it snap in.
7. Insert PersonalFit™
breastshield (C) into
top opening on
pump body (D).
Correct Incorrect

8
1. Center breastshield over
nipple. Caution: pushing
shield too firmly into breast
may actually reduce milk flow.
2. The adjustable handle can be
positioned for your maximum
pumping comfort. The level of
vacuum is controlled by the
compression and the speed
of the handle stroke. You
decide the pumping rhythm
that is best for you.
3. Start pumping in the
stimulation mode, by pressing
down on the milk drops
symbol on top of the pump
handle. Press and release
quickly until you see milk flow
begin. This mode mimics
baby’s initial rapid sucking
and is designed to stimulate
milk flow/let-down.
4. Once let-down has begun,
switch to the expression
mode by pressing the bottom
of the pump handle. This will
give you a longer stroke that
mimics baby’s deeper, more
relaxed sucking and is
designed to maximize
milk flow.
5. Once you are finished pumping, parts should be
cleaned following directions on page 4.
Using Your Harmony™ Breastpump

9
When to Use the Harmony™ Breastpump
The Harmony Breastpump…
• allows you to pump manually on an occasional
basis. That is, you are available to nurse your
baby for most feedings each day, except
for a few occasions during the week.
• is ideal to collect breastmilk for a feeding
that will be missed due to an evening out.
• is also ideal to relieve occasional breast
engorgement or sore nipples.
When long-term pumping is required, e.g. when the baby
is not available to feed at the breast at least part of the
time each day (a premature infant, for example), it is
recommended that you use a hospital-grade electric
breastpump such as the Symphony® breastpump. This
pump may be rented for short to extended periods of
time, depending upon your needs. For the names
and locations of Medela electric breastpump rentals,
please call 1-800-TELL YOU (1-800-835-5968) in
the US or Canada.

Upgrading to Electric Pumping with the
Medela Symphony® Breastpump.
Symphony Breastpump Setup
Requires membrane cap #8100769, membrane #8200094
and tubing #8007213. Sold separately.
1. Remove handle
assembly from
Harmony™
breastpump.
2. Insert end of tubing
into opening on top
of Harmony pump.
10

Symphony Breastpump Setup (cont.)
Requires membrane cap #8100769, membrane #8200094
and tubing #8007213. Sold separately.
3. Assemble protective
membrane and
membrane cap.
4. Insert yellow end of
tubing into port on
membrane cap.
5. Push membrane cap
firmly into place on
pumping mechanism.
Adjust for comfort
once pumping
begins.
11

Tips for Success and Troubleshooting
1. Prior to pumping, relax, take a few deep breaths and
think of your baby.
2. Using a breastpump should be easy and comfortable.
The first few times may seem a bit awkward, but you
will quickly find your best position and pumping speed.
3. Each mother reaches let-down at a different pace.
Sometimes, you may not need to use the stimulation
mode at all and can start with expression pumping.
4. If you feel the pump is not giving sufficient suction, you
can check several things:
a. Make sure the white membrane (E) lies completely
flat in place on the yellow valve (F) and is clean.
b. Make sure the stem
assembly (B) on the
pump handle is seated
all the way into the pump
body (D) until it will go
no farther. Make sure the
white o-ring is in place in
the stem handle (B).
c. Make sure the pump body (D) is firmly screwed
onto the bottle (G) and that the breastshield (C) is
firmly seated into the pump body (D).
d. Make sure the oval base of the stem (B) is properly
seated in the oval base of the
diaphragm (B).
e. Finally, make sure the diaphragm (B) is pushed all
the way onto the circular rim on the underside of
the handle (A).
f. If assistance is still needed after reviewing this
booklet, please contact Medela Customer Service
at [phone] or [phone]
Monday-Friday, 7:30 am to 8:00 pm Central Time.
12

Storing and Handling Breastmilk
Storage:
(Please check with your hospital for specific storage
instructions, if needed.)
1. Wash hands before touching
bottles and avoid touching
the interior of bottles or caps.
2. Pump or express into
clean bottles.
3. If you do not intend to use
the expressed breastmilk
within a few days, freeze it.
4. Label bottles with the collection date if you are not
using the milk immediately.
5. Freeze milk in small portions, 2 to 4 ounces per
bottle. Smaller amounts thaw more quickly.
6. When freezing milk, do not fill bottles more than 3/4 full
to allow room for liquid to expand. Cool milk
prior to freezing. Never refreeze breastmilk that has
been frozen.
7. Use solid lids and seal bottles tightly if you intend to
refrigerate breastmilk for several days or freeze it.
8. Refer to the following chart for maximum storage
periods under varying conditions.
13

Breastmilk Storage Guidelines
Warming/Thawing Breastmilk
1. Place sealed container of frozen or refrigerated
breastmilk in a bowl of warm water for about 30
minutes. Or hold under warm running water.
2. Do NOT thaw breastmilk in a microwave oven. High
temperatures can destroy important nutrients in the
breastmilk and there is a danger of scalding baby.
3. Once thawed or warmed, swirl container to blend
fat, which may have separated during storage. Test
for temperature on the inside of your wrist. It should
be lukewarm.
4. Feed thawed milk immediately or store in refrigerator
for up to 24 hours. Do not let thawed breastmilk sit
out at room temperature.
5. If you are traveling or transporting breastmilk to the
baby’s caregiver, a cooler carrier equipped with ice
packs will help keep breastmilk cool until you reach
your destination.
14
References: www.breastmilkguidelines.com

15
For a breastfeeding specialist or to locate Medela rental
or retail locations, call the Breastfeeding National Network
(BNN) at 1-800-TELL YOU or visit the Medela website at
www.medela.com.
The Medela Customer Service Team can be reached at
1-800-435-8316.
30 Day Limited Warranty
This product is warranted by Medela, Inc. to the original retail
purchaser to be free from defects in material and workmanship
for the period of 30 days from the date of purchase. In the event
of a defect, Medela will repair or, at Medela’s option, replace
this product, without charge for such replacement, parts or
labor. Purchaser shall bear all expense for returning this product
to Medela. This warranty does not apply to any product used
commercially or which has been subjected to misuse, abuse or
alteration. ANY AND ALL IMPLIED WARRANTIES, INCLUDING
THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO A
DURATION OF 90 DAYS FROM DATE OF PURCHASE. SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE. Before you make a claim
under this warranty, it may save time and expense to call Medela
Customer Service (toll-free) at 1-800-435-8316. You may also call
this number for additional information concerning this warranty. If
you wish to make a claim under this warranty, you must return this
product to Medela with a return authorization number received from
Medela Customer Service, prepaid, together with your dated bill of
sale or other proof of purchase and a brief statement of the problem
to the following address: Medela, Inc., P.O. Box 660, McHenry, IL
60051-0660 ATTENTION: SERVICE DEPARTMENT

16
El sacaleches Harmony™ Breastpump
El sacaleches Harmony es un gran adelanto en lo que
respecta a la tecnología de sacaleches manuales, ya que
es el primer y único sacaleches manual con tecnología
2-Phase Expression® (extracción en dos fases): un sistema
de extracción dual que se asemeja, como nunca antes, a la
manera en que naturalmente succionan los bebés.
La primera fase, llamada etapa de estimulación, imita el
ritmo de succión poco profunda y rápida inicial del bebé, lo
cual contribuye a que la leche baje con mayor rapidez. La
segunda fase, llamada etapa de extracción, imita el ritmo de
succión más profunda y relajada del bebé, lo cual contribuye
a extraerse leche en forma eficaz.
El sacaleches Harmony es el sacaleches manual sin bisfenol
A (BPA, por sus siglas en inglés) que eligen y prefieren 9 de
cada 10 mamás. Todos los productos de Medela que entran
en contacto con la leche materna no contienen bisfenol A.
Su sacaleches Harmony está creado para brindarle
comodidad y delicadeza durante la extracción. La manija
redondeada tiene un diseño ergonómico que se adapta
fácilmente a cualquiera de las manos.
Además, la manija giratoria permite
con mayor sencillez y comodidad
colocar la mano y el sacaleches
en cada seno. Dado que se
trata de una única pieza,
no hay que armarlo ni limpiar o
almacenar piezas adicionales.
Harmony… el sacaleches que combina
una extracción silenciosa y eficaz con
sencillez, delicadeza, comodidad y
conveniencia.

17
Piezas y armado del sacaleches
Harmony™ Breastpump
A. Manija ............................................................... #8007170
A1. Símbolo de bajada de leche
B. Diafragma, Vástago, con aro tórico ................. #8207234
C. Embudo PersonalFit ....................................... #8100402
D. Estructura del sacaleches ................................ #8007196
E. Membrana blanca............................................. #8207013
F. Válvula amarilla .................................................. #8100475
G. Biberón para leche materna ............................ #8117009
H. Base para el biberón ........................................ #8100462
J1. Tapa dura ........................................................ #8107057
J2. Disco para el collar del biberón ..................... #8100473
J3. Collar ............................................................... #8107182
Nota: No es necesario desarmar y limpiar la manija (A) y el
diafragma/vástago (B) después de cada uso, a menos que
claramente se noten sucios. No es necesario retirar el aro tórico
blanco del vástago.
Pedido de piezas
En los Estados Unidos y Canadá: si el vendedor
minorista no tiene las piezas que usted necesita, puede
comprarlas con tarjeta de crédito llamando al 1-800-
435-8316 (Estados Unidos y Canadá), 1-815-363-1166
(Estados Unidos solamente) o 1-905-608-7272 (Canadá).
Se aceptan las tarjetas de crédito VISA, MasterCard,
American Express y Discover Card. En otros países:
comuníquese con el distribuidor de su localidad. Visite
nuestro sitio web www.medela.com para obtener una lista
de distribuidores internacionales.

18
Piezas del sacaleches
A1
D
A
CB
E
F
J1
G
J3
J2
H
