Medela Symphony User manual

EFFICIENCY
EN Instructions for use – home use |SV Bruksanvisning –hemmabruk
DA Brugsanvisning –til hjemmebrug |FI Käyttöohjeet –kotikäyttö
NO Bruksanvisning –til hjemmebruk | PL Instrukcja obsługi – użytkowanie w domu
Symphony
®

Thank you for choosing the Symphony Breastpump. Breastmilk is the natural choice for your baby,
but there are reasons and situations where breastfeeding is not possible. For over 50 years, it has
been Medela’s conviction that these mothers and babies can be supported. In close co-operation
with breastfeeding experts, Medela, one of the market leaders, has researched and developed
breastpumps that perfectly meet breastfeeding mothers’ needs. For mothers who insist on the best
for their babies and themselves. Because you care.
Tack för att du valt Symphony Bröstpump. Bröstmjölk är det naturliga valet för ditt barn, men det
kan finnas olika anledningar till att man inte kan amma och situationer där det inte går att amma. I över
50 år har det varit Medelas övertygelse att stödja och hjälpa dessa mammor och barn. I nära
samarbete med amningsexperter har Medela, som en av marknadsledarna, bedrivit forskning och
utvecklat bröstpumpar för ammande mammors behov. För mammor som vill ha det bästa för sina
barn och sig själva. För att du bryr dig om.
Tak, fordi du har valgt Symphony-brystpumpen. Brystmælk er det naturlige valg til dit barn, men det
er ikke under alle forhold og i alle situationer, at amning er muligt. I over 50 år har Medela været
overbevist om, at det er muligt at støtte disse mødre og børn. I tæt samarbejde med ammeeksperter
har Medela, der er et af de førende navne på markedet, forsket i og udviklet brystpumper, der
fuldstændigt opfylder ammende mødres behov. Til mødre, der kræver det bedste til deres børn og sig
selv. Fordi det er vigtigt for dig.
Kiitos, että valitsit Symphony-rintapumpun. Rintamaito on luonnollinen valinta lapsellesi, mutta on
syitä ja tilanteita, jotka estävät rintaruokinnan. Medela on jo 50 vuoden ajan ollut vakuuttunut siitä,
että näitä äitejä ja lapsia voidaan tukea. Tiiviissä yhteistyössä rintaruokinnan asiantuntijoiden kanssa
markkinajohtajiin lukeutuva Medela on tutkinut ja kehittänyt rintapumppuja, jotka sopivat täydellisesti
imettävien äitien tarpeisiin. Äideille, jotka vaativat parasta lapsilleen ja itselleen. Koska välität.
Takk for at du valgte Symphony-brystpumpen. Morsmelk er det naturlige valget for barnet ditt, men
i enkelte situasjoner er amming ikke mulig. Gjennom mer enn 50 år har det vært Medelas
overbevisning at disse mødrene og barna kan hjelpes. Medela er blant de ledende på markedet, og
har i tett samarbeid med eksperter på amming utviklet brystpumper som oppfyller behovene til
ammende mødre. For mødre som insisterer på det beste til sine barn og seg selv. Fordi du bryr deg.
Dziękujemy za wybranie odciągacza pokarmu Symphony. Mleko matki jest najlepsze dla każdego
dziecka, jednak czasami z różnych przyczyn bezpośrednie karmienie piersią nie jest możliwe. Już
od ponad 50 lat firma Medela z wielkim zaangażowaniem wspiera matki i ich nowonarodzone dzieci
w takiej sytuacji. Firma Medela, jeden z liderów rynku, we współpracy z ekspertami w dziedzinie
karmienia piersią przeprowadziła badania i opracowała odciągacze pokarmu, które są optymalnie
dostosowane do potrzeb kobiet karmiących piersią. Dla matek, które pragną tego, co najlepsze dla
siebie i swoich niemowląt. Bo Tobie zależy.

EN
04–33
SV
34–63
DA
64–93
FI
94–123
NO
124–153
PL
154–183

4
Table of Contents
1. Intended use/ Population – Contraindication 5
2. Meaning of symbols 6
3. Important safety information 8
4. Product description 10
5. Cleaning 12
5.1 Before using for the rst time and after every use 12
5.2 Before using for the rst time and once a day 14
5.3 Cleaning the breastpump and case 15
5.4 Disinfecting the breastpump 15
6. Preparing for pumping 16
6.1 Card and Cord Protector 16
6.2 Mains operation 16
6.3 Changing the program card 17
6.4 Assembling the pump set 18
7. Expression 22
7.1 Preparing for single pumping 22
7.2 Expression 22
7.3 Preparing for hands-free expression with the Easy Expression Bustier 24
7.4 Preparing for double pumping 26
8. Storing and thawing breastmilk 28
8.1 Storage 28
8.2 Freezing 28
8.3 Thawing 28
9. Feeding breastmilk 29
10. Troubleshooting 30
11. Warranty and maintenance/disposal 31
12. Complete care during breastfeeding time 32
13. Technical specications 184

5
The intended use and indications of breastpumps
Breastpumps are intended to be used by lactating women in the hospital or home
environment for expressing breastmilk. Breastpumps are indicated to alleviate
the symptoms of engorgement by expressing milk. In case of mastitis breastpumps
support the healing process by removing breastmilk from the affected breast.
Breastpumps are indicated to relieve sore and cracked nipples and to bring out
at or inverted nipples. Also, breastpumps enable mothers to provide breastmilk
for babies who cannot feed directly at the breast for a variety of reasons such as
latch-on problems, cleft palate or premature babies.
Intended patient population/user
Adolescent paediatric or adult lactating women. Many women nd it convenient,
or even necessary, to use a breastpump to express and store their breastmilk once
they have returned to work, are travelling or are otherwise separated from their baby.
Women are often delighted to learn that a breastpump can be used as a supplement
to breastfeeding and that some pumps are designed to mimic the suckling of a
nursing baby.
Contraindications
There are no known contraindications for the Symphony breastpump.
1. Intended use/Population – Contraindication

6
2. Meaning of symbols
i
The warning symbol identies all instructions that are important for safety.
Failure to observe these instructions can lead to injury or damage to the breastpump.
When used in conjunction with the following words, the warning symbol stands for:
i
Warning
Can lead to serious injury or death.
Caution
Can lead to minor injury.
Note
Can lead to material damage.
Info
Useful or important information that is not related to safety.
Symbols on the packaging
This symbol indicates that the material is part of a recovery/recycling
process.
This symbol indicates a carton package.
This symbol indicates to keep the device away from sunlight.
This symbol indicates to handle the fragile device with care.
°C
This symbol indicates the temperature limitation for operation,
transport and storage.
This symbol indicates the humidity limitation for operation,
transport and storage.
This symbol indicates the atmospheric pressure limitation
for operation, transport and storage.
This symbol indicates to keep the device dry.
This symbol indicates that the packaging contains products intended to
come in contact with food according to regulation 1935/2004.

7
This symbol indicates unique GSI Global Trade Item Numbers (GTIN).
Symbols on the device
This symbol indicates to follow instructions for use.
0123 This symbol indicates the compliance with the essential
requirements of the Council Directive 93/42/EEC of 14 June 1993
concerning medical devices.
This symbol indicates the manufacturer.
This symbol indicates do not dispose the device together
with unsorted municipal waste (for EU only).
This symbol indicates the compliance with additional USA and
Canada safety requirements for medical electrical equipment.
This symbol indicates a type BF applied part.
SN This symbol indicates manufacturer's serial number of the device.
REF This symbol indicates manufacturer's catalogue number of the
device.
IP21 This symbol indicates the protection against ingress of solid foreign
objects and against harmful effects due to the ingress of water.
This symbol indicates the date of manufacture
(four digits for the year and two digits for the month).
This symbol indicates that the Symphony is a class II device.
This symbol indicates fuse (to identify fuse boxes or their location).
This symbol indicates that the fuse box is safety tested.
This symbol indicates open the cover of the mains socket.

8
3. Important safety information
Failure to follow these instructions/safety information can lead to danger
from the device. Subject to technical changes.
Device
Danger of electrocution! Keep the device dry! Never immerse in water
or other liquids!
The Symphony breastpump is not heat-resistant: keep away from radiators
and open ames.
Do not expose the motor unit to direct sunlight.
There are no user-serviceable parts inside the Symphony.
Repairs must be performed only by an authorised service agency.
Do not repair yourself! No modications to the device are permitted.
Never use a damaged device. Replace damaged or worn parts.
MAX.
3000 h
The operating life of the Symphony breastpump is 3000 hours.
The service life is seven years if used normally.
Electrical use
Separation from the mains is only assured through the disconnection
of the power cord from the wall socket outlet.
Keep the power cord away from heated surfaces.
Do not reach for any electrical device if it has fallen into water.
Unplug immediately.
The Symphony breastpump should never be left unattended
when plugged into a power source.

9
3. Important safety information
Use
Use the Symphony breastpump only for its intended use as described
in this manual.
Never operate an electrical device if it has a damaged power cord,
if it is not working properly, if it has been dropped or damaged,
or dropped into water.
Do not use the Symphony breastpump while bathing or showering.
Do not use the Symphony breastpump while sleeping or overly drowsy.
Do not drive whilst hands-free pumping.
Supervision is necessary when the Symphony breastpump
is used in the vicinity of children.
Contact your lactation consultant or physician if you experience
problems or pain.
Radio frequency communications equipment such as wireless home net-
work devices, mobile phones, cordless telephones and their base stations
and walkie-talkies can affect the Symphony breastpump. Due to electro-
magnetic compatibility (EMC) a distance of at least 1 meter between the
Symphony breastpump and the wireless equipment is recommended.
Important:
l Plastic bottles and component parts become brittle when frozen and
may break when dropped.
l Also, bottles and component parts may become damaged if mishandled,
e.g. dropped, over-tightened, or knocked over.
l Take appropriate care in handling bottles and components.
l Do not use the breastmilk if bottles or components become damaged.

10
4. Product description
Symphony single or double pump set
(Applied parts)*
The Symphony single or double pump set is an
accessory for the Symphony breastpump. The pump
set must only be used by one mother; use by more
than one mother could pose a health risk.
The double pump set contains two pieces of each
part.
The pump set contains:
The PersonalFit breastshield, size M (24mm). You
can nd more information on the correct choice of
breastshield at www.medela.com/personalt or scan
the QR code on page 32.
1x lid with opening
810.7062
1x disc
810.0473
1x PersonalFit™
Breastshield M (24 mm)
(for other breastshield sizes
see Chapter 12, page 32)
810.7084
1x PersonalFit™ Connector
810.7088
1x valve head
810.0475
2x valve membrane
820.7013
1x milk bottle
(150 ml, printed)
811.0021
1x silicon tubing
(105 cm)
800.0828
1x protective cap
810.0474
1x membrane cap
810.0667
1x protective membrane
820.0094

11
Rental pump required: Symphony
Card & Cord
Protector
810.0589
Socket for car
connection cable
Case
600.7073
Ideal accessories*
Calma – the unique breastmilk feeding solution, the ideal way to feed your child expressed breastmilk.
Calma is the result of extensive research and development.
Easy Expression Bustier makes hands-free pumping easier, especially with simultaneous expression
from both breasts. It is available in 4 different sizes (S, M, L, XL).
More information on all Medela products can be found at www.medela.com
Bottle holder
810.0552
Power cord
928.0040 Euro
928.0041 AUS / NZ
928.0042 UK Program card,
Standard 2.0
800.0540 DE
800.0541 EN
800.0542 FR
800.0543 IT
800.0544 NL
* Accessories available for order can be found on page 32. Articles may not be available in all countries. For
further information about Medela products, visit www.medela.com and look for location nders in your country.

12
4
Rinse all parts with cold,
clear water (approx. 20 °C)
for 10–15 seconds.
Disassemble the pump set
into individual parts (see
diagram). The tubing, protec-
tive membrane and cap do not
normally need to be washed.*
5.1 Before using for the rst
time and after every use
5. Cleaning
l Only use drinking-quality water for
cleaning.
l Take apart and wash all parts that come
in contact with the breast and breastmilk
immediately after use to avoid dry up of
milk residues and to prevent growth of
bacteria.
Caution
i
l The pump set requires no
maintenance.
l Take care not to damage parts of the
pump set during cleaning.
l If the individual parts of the pump set are
cleaned in a dishwasher, parts may be
discoloured by food pigments. This has
no impact on the function.
lInspect the tubing after each pumping
session for condensation and/or milk.
Follow the instructions on page 30 if
there is condensation or milk in the
tubing.
* Medela recommends to clean all parts
of the pump set (incl. tubing, etc.)
before used for the rst time as shown
in Chapter 5.2.
Note
1

13
5
3
Dry with a clean cloth or
leave to dry on a clean cloth.
If you clean the individual parts
of the pump set in the dish-
washer, place them on the top
rack or in the cutlery section.
Clean all parts with plenty
of warm water and basic dish-
washer agent (approx. 30 °C).
2
Rinse all parts with cold,
clear water (approx. 20 °C).
or
As an alternative to steps 2, 3 and 4.
6

14
5. Cleaning
Dry with a clean cloth or
leave to dry on a clean cloth.
Disassemble the pump set
into individual parts.
The tubing, protective mem-
brane and cap do not normally
need to be washed.*
5.2 Before using for the
rst time and once a day
More information on page 12, chapter 5.1. steps 2 – 4.
1
3
l Only use drinking-quality water for
cleaning.
l Take apart and wash all parts that come
in contact with the breast and breastmilk
immediately after use to avoid dry up of
milk residues and to prevent growth of
bacteria.
lfor chapter 5.3 Cleaning the
breastpump and case:
Unplug the breastpump before cleaning.
Caution
i
lfor step 2a (Chapter 5.2):
When boiling, a teaspoon of citric acid
may be added to the water to avoid a
build-up of limescale.
l Store the pump set in a clean bag/
container until next use. Or store it in
clean paper or a cloth.
l Do not spray or pour liquid directly onto
the pump.
* Medela recommends to clean all parts
of the pump set (incl. tubing, etc.)
before used for the rst time as shown
in Chapter 5.2.
Note

15
11
Wipe off with a clean, damp (not wet)
cloth. Alcohol based disinfecting agent
may be used.
Wipe off with a clean, damp (not wet)
cloth. Water and basic dishwasher
agent or non-abrasive detergent may
be used.
5.4 Disinfecting
the breastpump
5.3 Cleaning the
breastpump and case
2b
Use QuickClean bags* in
the microwave in accordance
with the instructions.
2a
Cover all parts with water
and boil for ve minutes.
or
* Accessories available for order can be found on page 32.
For more information please refer to www.medela.com
disinfect

16
6. Preparing for pumping
lfor chapter 6.2 Mains operation:
Only use the power cord that comes
with the Symphony.
l Make sure the voltage of the power cord
is compatible with the power source.
Warning
l Only use the pump with the appropriate
program card (Standard or Preemie+*).
Optional for pump with battery:
l Built-in battery must be charged for 12
hours on receipt of the device.
l The pump can be used during charging.
l If the pump is to remain unused for a
long time, charge the battery every two
months (for 12 hours each time).
lThe optimum service life of the battery is
achieved if it is not fully discharged on a
regular basis or if the pump is charged
while not in use.
Info
i
1
6.1 Card and Cord Protector
To remove, unscrew the card
and cord protector and slide it
out of the guide rail.
1
Insert the power cord into
the power socket on
the back of the pump.
6.2 Mains operation
Pumping time
(fully-charged battery) approx. 60 min.
Charging time
(for full charge) 12 hours

17
6. Preparing for pumping
23
Insert the cord into the card and
cord protector in a loop around
the pin.
Make sure there is enough play
to plug the cord in.
Push the card and cord protector
over the guide rail on the back until
it stops and tighten the screw.
As soon as the card compartment
is revealed, the card can be removed
and replaced or changed.
6.1 Card and Cord Protector
6.3 Changing
the program card
1
2
Plug the power cord into
the mains socket.
*More information at www.medela.com

18
4
Screw the bottle onto
the connector.
6.4 Assembling
the pump set
6. Preparing for pumping
Carefully push the membrane
onto the valve head until
it engages.
1
l Wash hands thoroughly (at least one
minute) with soap and water before
touching the breast, clean pump parts
and clean pump set.
Caution
i
l Use Medela original accessories only.
l Check pump set components for wear
or damage before use.
Note
l Carry out all the steps with care and
assemble the pump set correctly.
Otherwise a good vacuum may not be
achieved.
Info
i

19
6
3
Insert the tubing into
the corresponding opening
in the connector.
Place the protective membrane
onto a at surface and carefully
push the membrane cap down
until it engages.
Push the valve head and
membrane onto the connector.
 Position valve head laterally.
Push the breastshield onto
the connector.
2
5

20 7
Insert the tubing adapter into
the opening in the membrane
cap.
6. Preparing for pumping
10
Centre the tubing connector in
the recess in the pump housing.
Make sure that the membrane
cap engages and lies ush to
the surface.
lfor step 11:
Always close the lid when pumping.
The lid keeps the membrane cap pushed
down to prevent a loss of vacuum that
could occur if the membrane cap came
off.
Info
i
