Medical Breakthrough 9 User manual

TM
Medical Breakthrough 9
Massage Chair
USER MANUAL

02
04
05
06
06
07
09
09
12
13
13
14
15
22
23
23
24
25
25
27
27
28
28
Thanks for purchasing the Medical Breakthrough 9™ Massage Chair. Please read this manual
carefully in order to know how to use it correctly. Please pay close attention to the safety warning
section and keep this manual handy for future use.
Note: Dr. Recommendation, USA reserves the right to revise the design and description of the Medical
Breakthrough 9 & the manual without any further notice. Also, note that the color of your massage
chair may be different than the color shown in this manual
TM
Medical Breakthrough 9
TM
Medical Breakthrough 9
Table of Contents
Instruction manual
Safety and maintenance:
Name and function of components
Functions
Method of usage
1.Standard equipped
1.1. LCD manual controller control the massage chair
1.2.Switch on the machine
1.3.Start to massage
1.4.Switch off massage function
2.Tablet PC control the massage chair
2.1.Preparation
2.2.Switch on the machine
2.3.Massage function control operation
2.4.Backrest and calf rest adjustment
2.5.Setting
2.6.APP download
2.7.Wireless Bluetooth music player
2.8.Switch off massage function
Armrest assembly instruction
The disassemble and using of head and back cushion
Floor protection
Moving the chair
Product specification
TABLE OF CONTENTS

Please do not use the chair under high temperatures or in moist environments.
Please do not use the chair in a transition between hot and cold environments. Let it return
to room temperature for at least one hour first.
Please do not use the chair in a dusty environment.
Please do not use the chair where there is not enough space for use or where there is
poor ventilation.
People who are not suitable to use this product
Instruction manualInstruction manualInstruction manual
TM
Medical Breakthrough 9
Safety and Maintenance
Important Safety Warnings
Environmental Usage
Persons with any other medical conditions in addition to those specified below need to consult
their physician prior to use:
Osteoporosis
Heart Disease
Electronic medical equipment such as a heart pacemaker
Fever
Pregnancy or women in menses
Skin injuries or skin disease
Mental disease
Heat sensitivity
Irregular curvature of the spine or other spine abnormalities
Malignant tumors
Additional Safety Information:
Do not use the chair if you are wet
The appliance has a heated surface. Persons insensitive to heat must be careful when
using the appliance.
To prevent injuries, children and/or pets should not play around the chair when it is in operation.
Users must stop and turn the power off immediately if they feel ill.
If you feel that the chair is functioning abnormally, turn off the power switch and unplug the power
cord. Call our tech support department immediately. DO NOT attempt to disassemble or repair
the chair.
Keep all body parts away from the internal mechanisms.
STOP using the chair and UNPLUG the power cord if any part of the fabric cover is torn or worn out,
causing exposure of the mechanisms. Please contact tech support immediately.
Users with recent chemically treated hair or those using any topical hair products should place
a towel between their hair and the upholstery in order to protect the material.
It is not recommended that those under the age of 16 use the chair.
People who weigh over 300 pounds that use the chair will void the warranty.
Do not use the chair if the back pad is flipped over, exposing the rollers.
Please use a well-grounding power supply that is suitable for this product.
Please unplug after using or before cleaning to avoid injury or damage.
Please operate this product according to this instruction manual.
Do not use accessories which are not recommended.
Do not use this product outdoors.
Please read this instruction manual carefully before operating the product.
20 minutes of usage each time is recommended.
Please do not fall asleep while using this product.
Please do not use the product if drunk or when not feeling well.
Please do not use the product within one hour after having a meal.
Please do not make the massage function too strong in order to avoid injury.

Solution of ordinary malfunctions: Solution of ordinary malfunctions
It is a nature movement voice if the motor sounds while in usage.
If the controller cannot work normally, please check the plug and socket to see if they are
connected strongly and to make sure the switch is turned on.
If the rated working time is over, the product will automatically activate the power-off button;
if this product works continuously for a long time, the temperature protector will make the product
automatically power-off; wait at least half an hour to restart the chair.
Instruction manual Instruction
Check the voltage if it is suitable to the specification of this product.
Do not use wet hand to pull the plug.
Do not make water go inside this product to avoid electric shock or cause damage
to this product.
Do not damage the wires or change the circuit of this product.
Do not use a wet cloth to clean the electric parts such as the switch and plug.
Stay away from this product under a power cut state to avoid injury because the power
could come back on suddenly.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
Safety
Maintenance
Solution of ordinary malfunctions
Instruction manualInstruction manualInstruction manual
TM
Medical Breakthrough 9
Safety and Maintenance
Damage caused by the user attempting to disassemble the chair or replacing spare parts
themselves will void the warranty.
This product should be maintained by certain appointed agents. DO NOT attempt to
disassemble or repair the chair yourself.
Please do not forget to cut the power after usage.
Do not use this product if the socket loosens.
If this product will be left unused for a long time, please curl up the wires and store this product
in a dry and dustless environment.
Do not store this product under high temperatures or near fire and avoid longtime direct
sunshine to it.
If the detachable cord / supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
Please clean this product with a dry cloth. Do not use thinner, benzene or alcohol.
The mechanical components of this product are specially designed and made, so it is not
necessary for it to be specially maintained.
Do not roll or pull this product above uneven ground; it should be lifted before moving.
Please use it intermittently; do not make this product work continuously for too long.

Instruction manual
TM
Medical Breakthrough 9
1
2
3
9
10
5
6
18
19
13
12
15
20
14
8
4
16
11
17
21 22
7
Name and function of components
1.Pillow Pad
2.3D Digital Audio
3.Arm Air Bag Assembly
4.Seat Cushion
5.Calf Massage Assembly
6.Foot Massage Assembly
7.Negative Oxygen Ion Function
8.Upper Arm Air Bag Assembly
9.Back Cushion
10.Armrest
11.Led Colorful Lights
12.Controller Pocket
13.Back Cover
14.Controller
15.Driving Box Cover
16.Safety switch
17.Caster Wheels
18.Power Cord and Plug
19.Power socket
20.Fuse Box
21.Power Switch
22.Controller Cord Socket
Name and function of compoents

Medical Breakthrough 9 is designed with a set of smart 3D mechanical hands, which can move
up and down, stretching back and forth, and has four-wheel drive with a muted design.
The shoulder part is designed with an automatic detection and micro adjustment
function. This has a body curve and massage point automatic detection that can automatically
adjust to the distance of the massage hands' moving back and forth according to the
detected body curve and massage points in order to make the massage more humanistic
and scientific.
Comfort, ease, ache relieve, fast experience, relax, music sync, waist stretch, full
air pressure and other specific massage functions.
Set with two kinds of memo massage functions: M1 and M2.
Manually select the upper body massage; three massage position options of overall,
partial and fixed position; six massage methods of shoulder grasping, kneading,
tapping, shiatsu, kneading & tapping and 3D; five massage speed levels available;
under tapping and shiatsu massage status, the width of the massage hands can be
adjusted in five levels.
Arm air massage function (built-in 18 air bags), upper arm air massage function
(built-in 4 air bags), with 3 intensity adjustments.
Lower body air pressure massage function: back air pressure massage function
(4 airbags built-in), buttock air pressure massage (16 airbags built-in), calf rest air
pressure massage function (36 airbags built-in), with 3 intensity adjustments.
The upper arm has two grades for the width adjustment function. When you adjust to the
last grade, push into the arm for your hand and arm
device to automatically reset. That way you can adapt to the different
shoulder breadth of the users.
Back heating function; use carbon fiber as an infrared heating source.
The footrest can be extended to suit various heights.
With slide rail structure on backrest, make a zero-space design to maximally save
your place.
Calf rest lifting, backrest lifting and auto lying models adjustment.
LED colorful lights on armrest with negative oxygen ionizer on the upper arm.
Intelligent terminal (cell phone or tablet PC) control the massage chair by Bluetooth.
MP3 player function; upper arm built in 3D digital audio.
Connect the smart device via Bluetooth to play music.
Auto massage program download.
Place 8 natural energy magnets in the calf airbags.
Instruction manual
TM
Medical Breakthrough 9
Functions
Functions

1. Negative oxygen ion function (button on left upper arm).
Innovative negative oxygen ionizer design on head part, it can emit negative
oxygen ion ceaseless.
By the national infrared and industrial electric products quality supervision and
inspection center verification, its negative oxygen ion concentrations up to 240
thousand /cm3, equal to forests or waterfalls, and helpful for spontaneous recovery on
the human body.
Negative oxygen ion can reduce PM 2.5, optimize room air, and play an important
part in improving human body immunity.
2. Magnet therapy function
Place 8 natural energy magnets in the calf airbags.
By the national infrared and industrial electric products quality supervision and
inspection center verification, the surface of the magnetic intensity is 73mT,
according with the best protection strength of national standard 40-110mT .
Magnet therapy can lower cholesterol, eliminate free radical accumulation in
the body, enhance human immunity, and other functions.
3. 3D Digital Audio
With 3D digital audio equipment on each side of the upper armrest and the ability to connect with
cell phone music to play through, you can enjoy perfect fusion of music and
massage while relaxing.
4. LED colorful light
LED Colorful light on armrest: with colorful light on each side, red, green, blue,
blue-green, purple, yellow, and white changed automatically
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
Standard functions
Negative oxygen
ion function
Magnet
Therapy function
3D Digital Audio LED colorful light
WARNING
With safety switch in the power source box,
if any heavy weights are on the box cover, the
backrest lay down function will be stopped,
avoiding accident crush injuries when the
backrest is down.

LCD
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
LCD manual controller controls the massage chair
NOTE: This is for reference only.

POWER INPUT FUSE ON/OFF TOUCH SCREEN
CONTROLLER JACK
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
Switch the main power supply on
Diagram of plug in
Diagram of the switch position of power supply
To Start a Massage
Buttons Description On Display
Shoulder
adjust
High shoulder position
Suitable shoulder position
Low shoulder position
Shoulder position
adjustment (Upper button)
Shoulder position
adjustment (lower button)
Press to adjust the massage heads higher.
Press to adjust the massage heads lower.
Press the red power button to start the massage, the massage chair will
automatically recline down.
Press certain auto massage button; the massage hands proceed with an auto detection
of your shoulder and body scan. Then the calf rest roller begins to work at the same time.
(Choose the auto program of rapid massage to start the massage program
immediately to save half the time). If you made no choice
of the auto massage program after 20 minutes, the massage chair will
automatically switch off.
Upon completion of scan, a beeping sound will begin emitting from the controller
and the massage heads will gently roll on your shoulder region to demonstrate
where the chair has sensed the position of your shoulders. During this period, if
you would like to further adjust the detected shoulder region, you can do so by
depressing the up or down shoulder position buttons seen below; it has 11 grades.
If you have not made any adjustments to the shoulder position or selected a
manual massage mode during the time after scanning, the chair will automatically
start the fine massage program for you.

F0 Auto
F1 Auto
F2 Auto
F3 Auto
F5 Auto
F6 Auto
F7 Auto
F8 Auto
A1~A3
A1~A3
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
Choose massage methods
Emory massage: When it is on shoulder position detection, you can use the M1 or M2
memory button to start massage. There is no need to wait until the detection is finished, it will go back
to the stored massage models to massage.
PROGRAM MEMORY
Characterization of automatic massage
Buttons On Display
DEMO
COMFORT
ACHE
RELIEVE
FATIGUE
RECOVERY
FULL AIR
WAIST
STRETCH
SYNCHRONOUS
MUSIC
RELAX
SELECT
OK
Fast experience all the massage function
Relax muscles and bones
Improves body fatigue state, recovers body activity
Depth massage on acupressure point, relax ache area
Waist, buttocks, arms, legs air bag work at same time,
relaxing the whole body.
When the calf air bag works and squeezes the calf part, the
backrest lies down and the calf rest pulls down to stretch the
waist part, then returns to the original position and repeats the
above actions, relieving waist fatigue and bounces back.
Music synchronization massage
Promote blood circulation
APP program auto calling
Description
Buttons On Display
Description
APP Automatic function selection: 3 auto modes
Confirm selection: If the current APP mode is invalid,
press the confirm button. The horn remind invalid

H0
H4
H1
H2
H3
3D
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
SHOULDER GRASP
KNEAD
TAP
KNEAD&TAP
SHIATSU
BACK
STRETCH
SPEED
WIDTH
Upper body manual operation, lower body manual operation
Upper body manual operation
Buttons On Display
Description
LOWER ADJUST
UPPER ADJUST
Shoulder grasp: auto turn to shoulder grasp massage,
speed and intensity adjustable
Kneading: speed and intensity adjustable
Tapping: subdivide into two massage modes, speed,
width, intensity adjustable
Kneading & tapping: speed and intensity adjustable
Shiatsu: subdivide into two massage modes, speed,
width, intensity adjustable
3D subdivide into four massage modes, speed,
intensity adjustable
Speed: 5 grades adjustable
Width: 5 grades adjustable
Fixed position massage
Back and forth massage on partial position
Back and forth massage on upper body
Back and forth massage on upper back
Back and forth massage on lower back
Under fixed or partial position massage
mode, massag e hands can m ove downward
Above fixed or partial position massage
mode, massag e hands can m ove downward
Massage hand
Move downward
Massage hand
Move upward
Massage position
adjustment (under
fixed and partial
position massage
mode, it is
adjustable)

Massage Time Ajustment
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
HEATER
SOLE ROLLER
LOWER BODY
INTENSITY
ART HRO SIS
TRA CTIO N
AR M AIR
PR ES SU RE
Air compression massage functions
Buttons On Display
Description
Lower body air compression function (total 3 modes:
lower body, back and waist, calf).
Lower body, back and waist, calves air compression
intensity adjustable, 3 grades adjustable.
Under l ower bo dy air c ompres sion mo de or ca lf air
compre ssion m odes, s witch o n/off c alf rest stretch function
Arm air compression massage on/off and intensity
adjustment; 3 grades adjustable.
Other functions
Buttons On Display
Description
Upper body
intensity (weaken)
Uppe r bod y
intensity (strengthen )
Back massage intensity weakened: massage hands
move to any position, can weaken the current intensity
Back massage intensity strengthened: massage hands
move to any position, can strength the current intensity
Foot roller switch on/off and speed adjustment, 3 grades
adjustable.
Back far infrared heating therapy, feel warm after 3
minutes.
Buttons On Display
Description
TIME
The default time for massage is 20 minutes, max workout
time is 40 minutes. Press the time button to add in 5
minute increments. You can set the time range
anywhere from 5 minutes to 40 minutes.
Buttons On Display
Description
Negative oxygen ion generator Controller button is in the upper arm
Negative
oxygen
ion function
Speed
Negative oxygen ion function on & off
2 grades available

Press power button during massage to stop all massage functions immediately or
when one setting massage program finishes. The backrest and footrest won't return to
their original position, and the remote controller display SA & Memory
will twinkle.
A. Press M1 or M2 button within 10 seconds to store the massage mode.
B. Or press the power button within 10 seconds. The massage hands, backrest and
footrest will return to their original position automatically.
C. Or if you wait for 10 seconds, the massage hands return to their original position.
POWER INPUT FUSE ON/OFF TOUCH SCREEN
CONTROLLER JACK
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
The angle of backrest and calf rest
Buttons Description
Auto lay down mode: with the 3 auto lay down mode, when you press the
button, it turns into one mode, followed by cycle.
Calf rest lifting button: press this button and the calf rest lifts slowly, then stops
when you release it.
Calf rest decline button: press this button and the calf rest declines slowly, then stops
when you release it.
Backrest lifting button: press this button and the backrest lifts slowly, then stops
when you release it.
Backrest decline button: press this button and the backrest declines slowly, then stop
when you release it.
Shut off power and finish massage
Turn off power
Figure (Cut off the power of the machine)
Diagram of the switch position of power supply Method; turn off power

Application program interface
1
2
3
4
5
6
7
8
9
10
11
Function keys
Massage status information display area
Upper body intensity adjustment
Massage button
Long press for 2 seconds to exit program
Minimize program
Status-bar
Service
Operation/pause key
Function setting function
Information prompt line
1
2
3
4
5
6
7
8
9
10
11
Number Number
Description Description
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
iPhone or Android tablet system operate massage chair
Preparation before operation
1) Installation program download and install
Installation program supplied by agent or download from the network provided by agent.

Diagram of plug in
Make sure the massage chair power switch is off, connect the power cord with the
massage chair, plug it into the good ground connection socket, turn the power switch
on, and the massage chair into startup states
Turn on the chair power switch.
Open the applicant menu in the tablet main screen, choose setting to open the
setting interface.
To operate the Bluetooth function, choose the Bluetooth setting, and then click and check attachment
equipment. When you find the Fihonest icon, click it to match the tablet Bluetooth with
the massage chair Bluetooth (matching code: 0000). When matched successfully, click
the Fihonest again to connect the tablet computer Bluetooth with massage chair Bluetooth.
When connected successfully, the application program can be used to operate the massage chair.
After the Bluetooth paired succeed, if it cannot connect well with the Bluetooth of
the massage chair, please try to cancel the Bluetooth pairing, turn off the power of
the massage chair, and restart it; then reconnect as above.
The Bluetooth shows connection succeeded, but the application program cannot
control the massage chair well, or the information tips showed the Bluetooth connection
failed, it shows abnormal in Bluetooth module, you should exit the APP and connect
the Bluetooth module again, or turn off the power of the massage chair, and restart it,
then reconnect as above.
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
USB connect the tablet and computer, install the program in the tablet through the
software tools (such Peasecod, 360 mobile phone assistant). After it is installed
successfully, the program icon will be shown in the tablet application program. If you have any
questions, please consult the tablet supplier when installing the program.
Install successfully, an (application
program) icon appears
2) Blue tooth link
3) The Bluetooth module: abnormal problems and solutions
Switch on the machine
POWER INPUT FUSE ON/OFF TOUCH SCREEN
CONTROLLER JACK
Diagram of the switch position of power supply

Shoulder position and massage
points detection interface
Shoulder position adjust interface
Shoulder position
adjust button Function description
High shoulder position
Suitable shoulder position
Low shoulder position
While automatically detecting shoulder positions and acupressure points, please wait until the detection
is finished.
It sounds like di-di-di...... after finishing the detection and then goes into the shoulder position adjust
interface. Now, you can adjust the shoulder position by pressing up or down button; it has
11 grades available. If you have not made any adjustments to the shoulder position or
selected a manual massage mode within 10 seconds after scanning, the chair will
automatically start the fine massage program for you.
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
Massage function control operation
1.To start a massage
On pad screen, unfold the APP listing and click to “ “ start up the massage chair
control program.
First go into startup interface after you start up the program. After 5 seconds into the massage
information interface,
click the power on/off on the display interface to start the massage function. The massage
chair will lie down automatically.
Startup interface In standby mode massage
information display interface
2.Shoulder position adjustment
Press to adjust the massage
heads higher
Press to adjust the massage
heads lower

TM
Medical Breakthrough 9
Method of Usage
Pause/start
Function description
PAUSE
Strength: 5
grades adjustable
Running state interface Suspended state interface
In the massage information interface, when the massage chair is in a running state, press
the running /pausing button. All the massage function will stop at this point, and go into a pausing
state. In the pausing state, press the running /pausing button; the massage function will
continue running as paused before. All the massage functions will turn off
automatically if the pausing time goes over 10 minutes.
In running state, you can adjust the massage hands' intensity on the back of the upper
body by clicking the intensity adjust icon in the massage information interface; 5 grades
available.
Instruction manual
3.Massage function running and pausing
RUNNING
Press this button and the massage function will continue to run as it was
paused before.
Press this button to pause all the massage functions.
4. Upper body massage intensity
INTENSITY PAUSING

5.Auto massage
COMFORT
Button function description
RELAX
ACHE
RELIEVE
FULL AIR
PRESSURE
WASIT
STRETCH
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
FATIGUE
RECOVERY
Auto massage function selecting interface
Relax muscles and bones
Promote blood circulation
Depth massage on acupressure point, relax ache area
Neck and shoulder, waist, buttocks, arms, legs air bag work at same
time, relax the whole body
Improve body fatigue state, recover body activity
When the calf rest air bag works and squeezes the calf part, the backrest lies
down and the calf rest pulls down to stretch the waist part, then returns to the
original position and repeats the above actions. Meantime the seat air bag
and massage hands work together.
Back to running state information interface
Click the “ “ popup massage function selecting menu, and choose what you need.
Click the “ “ auto function selecting interface, and then click auto icon and choose auto
massage mode. In the auto massage state, the speed and width are non adjustable.

6. Manual massage
1) - Manual massage methods, speed, width
WIDTH
SPEED
Auto massage function
selecting-technique interface
Width: 5 grades adjustable
(in flapping and shiatsu massage state)
Speed : 5 grades adjustable
3D MASSAGE
KNEAD
FLAP
SHIATSU
SHOULDER GRASP
KNEAD AND FLAP
Click into manual massage function selecting interface, select manual
massage methods, back stretch mode, speed, width function. In flapping, 3D,
shiatsu, stop state, the width of massage hands is adjustable. Except the stop state,
the speed is adjustable in any other massage methods.
In the interface of manual function selecting, click into the massage
technique selection, speed, width adjustment interface, and then click the corresponding
technique icon, speed icon, and width icon. Choose the personalized massage function.
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
18
Technique
buttons Description
Shoulder grasp: auto turn to shoulder grasp massage, speed and
intensity adjustable
Kneading: speed and intensity adjustable
Tapping: subdivide into two massage modes, speed,
width, intensity adjustable
Kneading & tapping: speed and intensity adjustable
Shiatsu: subdivide into two massage modes, speed,
width, intensity adjustable
3D subdivide into four massage modes, speed,
intensity adjustable
Return to the running state information interface

In manual function selecting interface, click into stretch mode interface,
click the corresponding stretch mode icon and choose your personalized massage function.
2) Manual massage-stretch mode
Manual massage
function select-stretch mode
Note
Function description
Stretch Mode
Whol e bac k
Uppe r back
Lowe r back
Partia l
Fixed point
Massage up and down on the whole back
Massage up and down on the upper back
Massage up and down on the lower back
Back partial massage up and down on a small area
Massage on fixed point
Click into the air compression massage function selecting interface, click
the corresponding air compression massage function icon. It includes the lower body air
compression massage (lower body, waist, buttocks) and the arms air compression
massage.
TM
Medical Breakthrough 9
Method of Usage
Instruction manual
19
At the shoulder grasping mode, stretching
mode selection is invalid.
7.Air compression massage
