Medify Air MA-14 User manual

Medify Air
Model: MA-14
Technical Data:
•Voltage: 120 V AC 60Hz
•Power Rating: 26 W
•Noise level: 55 dB(A)
•Room size: up to 200 sq. ft.
•Unit dimension: 12.20”H x 8.26”W x 8.26”D
•Unit weight: 5.3 lbs.
READ AND FOLLOW THESE INSTRUCTIONS.
Use unit according to instructions provided in the manual.
Keep manual for future reference.
Medify Air
579 Route 22 West
North Plainfield, NJ 07060
[phone]
[e-mail]
www.medifyair.com

1. Safety Precautions.................................................................3
2. Product Information………………………………………………………..…4
3. Before Use…………………………………………………………………….…..6
Placement of Air Purifier……………………………………………………6
Install Filter Set………………………………………………………………….6
4. Filter Purification…………………………………………………………….…8
5. How to Use………………………………………………………………………..9
Power ON/OFF…………………………….…………………………………….9
Control Fan Speed………………………………………………..……………9
Sleep Mode………………………………………………..……………………..9
Standby Mode………………………………………………..…………………9
Turn Off Filter Replacement ………………………………..……………9
6. Maintenance and Cleaning……………………………………………….10
Clean the Air Purifier……………..………………………………………..10
Change Filter……………………………..…………………………………….10
Filter Replacement Suggestions………………………………….……10
7. Warranty………………………………………………………………………….11
Warranty and Service………………………………………………………11
Order Filters…………………………………………………………………….11
User Manual
CONTENTS
User Manual
12

User Manual
1. Safety Precautions
User Manual
To avoid damage, pay attention and follow these safety
precautions.
If the power chord or unit is broken, or if the unit is out of
order, contract customer support immediately.
WARNING
Do not touch power plug
with wet hands.
This is a 110v unit. Only use this
with a 100v power supply for
use in North America. Do NOT
use with a 220v power supply
or you will destroy the unit and
render the warranty void.
Turn off the power before
cleaning machine.
34
Do not take apart or modify
unit without authorization.
1. WARNING -UNPLUG OR DISCONNECT AIR PURIFIER FROM THE POWER SUPPLY BEFORE). IF
THE PLUG DOES NOTSERVICING
2. WARNING -THIS APPLIANCE HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN OTHER FIT
FULLY IN THE OUTLET REVERSE THE PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED
ELECTRICIAN. DO NOT ATTEMPT TO DEFECT THIS SAFETY FEATURE.
READ AND SAVE THESE INSTRUCTIONS.
2. Product Information

User Manual User Manual
Control Panel
56
Fan speed buttons: Levels 1, 2, 3, Sleep
ON/OFF light button & Filter Change Indicator.
This button will flash when filter needs to be
changed.
Power ON/OFF
3. Before Use
Do not obstruct air intake or clean
air outlet.
To ensure sufficient air
circulation, make sure there is a
20 inch or 50 cm distance
between air inlet and wall or
nearby furniture.
This will ensure enough
ventilation and high efficiency.
Placement of Air Purifier
Install Filter Set
All filters are combined into a one-piece housing for maximum
effectiveness. Remove and replace filter according to instructions.
1. Place the machine in a dry
location on a flat surface.
2. Rotate the base clockwise.

User Manual User Manual
78
4. Reattach base at the bottom of
the unit (with filters inside). Rotate
counter-clockwise to secure base.
3. Rotate base CLOCKWISE to remove filter cover in order to
change filters. Remove old filter and replace with only
GENUINE MEDIFY REPLACEMENT FILTERS.
To remove base, turn clockwise
as shown in Figure A.
To secure base, turn counter-
clockwise as shown in Figure B.
Attention
Please remove all packaging on
the filters before use.
Do not use the air purifier
without filters.
Helpful Hint
Please be careful when
installing the back cover.
Watch your hands.
4. Filter Purification
1. Pre-Filter 2. HEPA H13 Filter
Removes larger particles
including hair, fibers, dander,
and others.
Removes 99.97% of particles
down to 0.3 microns as well as
PM2.5 particles such as, smoke,
pollen, dust mites and others.
Pre-Filter HEPA H13 Medical Grade Filter

User Manual User Manual
5. How to Use
Standby Mode
Power ON/OFF
Insert the plug into a
power source. Unit lights
will turn on. After one
second, air purifier is in
standby mode.
910
Control Fan Speed
Press button once.
POWER indicator will
turn on. After three
seconds, the unit will
turn onto Speed 1. The
blue light will turn on.
Press button to select speed
from the following options: 1, 2,
3, S.
Speed 1 is slow
Speed 2 is medium
Speed 3 is fast
Speed “S” is sleep mode
Turn Off Filter Replacement Light
Press and hold the button until all
lights are off. The icon will appear
with partial light. Press again and
hold until all lights turn on. Filter
replacement light should be off.
Sleep Mode
Press button for sleep
mode. After 5 seconds, all
lights will turn off and only
S button will appear with
partial lighting. Press any
button to quit SLEEP mode.
Pull out power plug before cleaning the unit. Do not immerse
machine in water or any other liquid. Do not use abrasive,
corrosive or flammable products to clean any parts of the
unit. Filters cannot be washed.
6. Maintenance and Cleaning
Clean the air purifier regularly.
1. Use soft and dry clothes to remove
the dust from the air purifier.
2. Use soft and dry clothes to clean
the outlet and inlet of the air
purifier.
Clean the Air Purifier Change Filter
The unit will remind user when
filter needs to be replaced.
For steps to replace the filters,
see pages 7-8.
Filter Replacement Suggestions
Filters should be replaced
every 2000 hours of use.
The filter indicator light will
let you know when you have
reached that time.

User Manual User Manual
11 12
7. Warranty
Warranty and Service
If you have any additional questions, please contact customer service.
All names and trademarks are property of Medify Air. Our company
reserves the right to change the product at any time, without prior
notice, and the company has no obligation to adjust products supplied
earlier.
Please refer to detailed warranty terms on the following page.
To register for the lifetime warranty, please visit our website and
register online at:
www.medifyair.com
Medify guarantees your Medify Air Purifier to be free of defects in
material or workmanship for a lifetime period, provided you have
completed and returned your warranty registration to Medify Air
within the first 30 days of purchase, and that the filters are replaced
with original and genuine Medify Air replacement filters at least once
every four (4) months or after 2,000 hours of use. Within the first 30
days, Medify Air will replace the defective unit at no charge to you
and reimburse you for any shipping charges. After 30 days, Medify
Air’s obligation and liability under this Lifetime Warranty is dependent
on your use of our genuine filters, purchased on our website or from
our authorized resellers, which can be found on our website.
Our Lifetime Warranty remains in effect as long as:
1. You submit your warranty registration to Medify Air within 30
days of purchase.
2. You change filters with genuine and original Medify Air
replacement filters at least once every four (4) months or after
2,000 hours of use (whichever comes first).
3. You use a proper power supply based on voltage: 120-120 V.
4. There is no evidence of tampering, mishandling, neglect,
accidental damage, modification, and/or repair done to the
Medify Air Purifier by anyone other than authorized Medify Air
service personnel.
5. Your air purifier is operated in accordance with the provided
instructions.
This Lifetime Warranty is provided by:
Medify Air, 8 The Green, Dover, DE 19901.
Lifetime Warranty
Order Filters
You can order genuine Medify
replacement filters at:
www.medifyair.com
