Medion Tevion 82937 User manual

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 1
Introduction 1
Congratulations on choosing to buy a Tevion® product. By doing so you now have
the assurance and peace of mind that comes with purchasing a product made by
one of Europe’s leading manufacturers.
All products brought to you by Tevion® are manufactured to the highest
standards of performance and safety, and, as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 3 Year Warranty.
Please fill in and return the Warranty Card to the address provided.
We hope you will enjoy using your purchase for many years to come.
General Information 2
Read these instructions carefully under all circumstance and follow all the
instructions listed. You will guarantee the reliable operation and a long life
expectancy of your wireless headphones in this way. Always keep these
instructions at hand, close to your wireless headphones. In the event that
you transfer ownership of this wireless headphone, please provide these
instructions to the new owner.
Purpose of use
This 863MHz stereo wireless headphone system offers you advances in wireless
transmission technology so that you can listen to ultra stereo sound from your
audio components up to 100 meters away. The transmitter is compatible with any
audio sources, such as DVD players, CD players, i-pods, MP3 players, TV sets, VCRs,
Hi-Fi systems or radios.
This device is only suitable for using in dry, internal rooms.
The device is not subjected to dripping or sprayed water and that no objects filled
with liquids are placed on the device, e.g. vases.
This device is intended for personal use only. It not intended for commercial use
in a heavy industry environment. Use under extreme environmental conditions
can result in damage to your device.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 2
Included in the box
Check that nothing is missing from the packaging and inform us of any missing
parts within 14 days of purchase. The delivery of the wireless headphone system
you have purchased includes:
RF receiver headphones
RF transmitter
AC/DC adaptor output DC 6 V, 300 mA
RCA audio cable (3,5 mm)
2 rechargeable NiMH batteries type HR03/AAA
Adaptor plug (from 3.5 mm to 6.3 mm)
Documentation
Overview 3
Transmitter
1 RED led: signal
indicator /
GREEN led:
charge indicator
2Channel selector
3
R - AUDIO IN –L :
Connect the RCA audio
cable to the audio
output of any audio
source (TV, HiFi system,
VCR, radio cassette
player etc.)
4
DC IN 6V input:
Connect the adaptor
cable to the power-
supply
DC IN 6V

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 3
Headphones
1 ON/OFF : switch the power on or
off
2Power indicator: lights if the
headphones are switched on
3Volume knob: you can regulate
the volume of your headphones
4Auto Scan indicator: lights if the
signal is strong enough
5Auto Scan button: press this
button to get the fine scanned
channel
6Battery compartment cover
7Clasp to open the battery
compartment

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 4
Safety instruction 4
Safety
Do not allow children to play unattended on electrical equipment. Children may
not always correctly recognize danger.
Keep the packing materials, such as foil away from children. The danger of
suffocation could arise in the case of misuse.
Do not insert any objects through the slots and openings into the inside of the
device (electrical shock, short-circuit and the danger of fire)!
Please proceed as outlined in the service centre section:
– if the AC cable overheats or is damaged
– if liquid has gotten into the device
– if the device does not work properly
– if the device is dropped or the housing damaged
Point of use
In the first hours of operation, new devices may emit a typical, unavoidable but
completely harmless smell, which will decline increasingly in the course of time.
We recommend you to ventilate the room regularly, in order to counteract the
formation of the smell.
Keep your headphones and all units connected to it away from moisture and
avoid dust, heat and direct sunlight. Failure to observe these instructions can lead
to malfunctions or damage to the device.
Do not operate your device in the open air, because external influences, such as
rain, snow, etc. could damage the device.
Do not subject the device to drops or splashes of water and do not place any
vessels filled with water, such as vases, on the device. Water penetrating the
device can impair its electrical safety.
Do not place any open sources of fire (candles or similar objects) on the device.
Repair
Leave all repairs of your device to authorized and qualified personnel only.
Should a repair be necessary, please contact one of our authorized service centre.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 5
Intended Environment
Provide an interval of at least one meter from high-frequency and magnetic
sources of interference (television sets, loudspeakers, mobile telephones, etc.) in
order to avoid malfunctions.
Disconnect the power plug from the power socket during storms or if the device
is not being used for a long time.
Power Supply
Please pay attention: Parts of the device are still live, even if
the mains switch is switched off. Pull the mains plug out of
the socket, to interrupt the power supply to your device
completely.
Operate your RF transmitter mains (AC/DC adaptor) only on sockets with
230 V ~ 50 Hz. If you have doubts about the power supply in the location where
the device is installed, consult your energy supplier.
Only use the power adaptor supplied with the device. Never attempt to connect
other power supplies with the device, this may result in damage or fire.
The power socket must be in the vicinity of your device and within reach of the
power cables.
If you use an extension cable, please ensure that it complies with the safety
requirements. If necessary consult your electrical equipment supplier.
You should lay the cables in a manner that no one can trip or step on them.
To avoid damage of cable do not place any objects or furniture on the cable.
Batteries and Proper Treatment
Batteries may contain combustible materials. By misuse, this may cause battery
leakage, heat, explosion or ignition, bringing about injury or damage to the
device.
Please observe strictly the following:
Keep children away from batteries. If by any chance, the batteries are swallowed,
consult a doctor immediately.
Never use another type of battery or non-rechargeable batteries to replace the
supplied rechargeable (HR03/AAA) batteries.
Do not charge batteries (except rechargeable batteries).
Do not forcibly discharge batteries.
Do not short-circuit batteries.
Do not heat or dispose off in fire.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 6
Do not disassemble or deform batteries. Your hands and fingers may be injured,
or the liquid of the battery may get into your eyes or adhere to your skin. If this
happens, rinse with a large quantity of water immediately and consult a doctor.
Do not expose batteries to strong impact by dropping or throwing them.
Do not reverse the positive (+) and negative (-) terminals to avoid short-circuit.
Do not mix used and new or different types of batteries together.
Remove promptly the used batteries from the device.
Remove the batteries from your device if it is not to be used for a longer period.
The device could be damaged by leaking batteries.
When the headphones are not in use, switch
OFF the headphones to avoid
damaging the batteries.
Clean the battery and device contacts, if necessary, before inserting batteries.
Replace all batteries with new batteries of the same type at the same time.
Information about the Regulatory Compliance according
to R&TTE
The company declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC. Complete
declarations of conformity are available under www.medion.com/conformity.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 7
Setting Up 5
Read the Safety Information Chapter under all circumstances before
bringing the device into operation.
Unpacking
Open the box very carefully to prevent the equipment from being damaged.
Damage can occur if a knife with a long blade is used to open the box.
There are various small parts in the packaging (batteries, screws, etc.). Keep these
out of the reach of children. There is a risk of swallowing the parts.
Please keep the packaging material well and use it exclusively to transport the
headphones.
Connecting the transmitter
Insert the plug on the supplied AC/DC adaptor into the connecting jack on the
device and insert the other end into an easily accessible 230 V ~ 50 Hz power
socket.
Connect the red and white plug of the RCA audio cable to the red and white jack
of the transmitter.
Connect the black plug (3.5 mm) with the audio output of the source.
Use the adaptor plug if the audio output needs a 6.3 mm plug.
The red Auto On indicator led will light up as soon as you have connected both
the AC/DC adaptor to the mains outlet and the audio cable to a signal source.
If the signal indicator led remains off, switch on the audio source and increase its
output level until the red indicator light comes on.
Putting the batteries into the headphone
The batteries must be fully charged before first use. An initial
24 hour charge is required to guarantee an acceptable service
life for the rechargeable batteries. Always ensure that the
headphones are switched to the position OFF while the
batteries are charging.
Remove the small cover on the battery compartment on left side of the receiver
headphone.
Install two AAA sized, rechargeable NiMH batteries (type HR03) according to the
correct polarity (marked in the battery compartment).
Close the battery compartment.
Switch off the receiver headphones and place it into the transmitter to charge the
batteries for 24 hours before the initial use.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 8
Using the headphones 6
Using this appliance at full volume for extended periods of time
may cause damage to the hearing capacity of the listener.
In the first instance set the volume of the audio device to a value at
the lowest end of the scale before you put on the headphones. Then
select a comfortable volume. Excessive volume can damage your
hearing.
Switch on
Turn on the audio source (TV set or any audio devices) which the transmitter has
connected.
Switch on the headphones.
Place the headphones on your head and adjust the volume to obtain the desired
sound level.
If you cannot find the best reception frequency, press the "Auto Scan" button on
the headphones to get the fine scanned channel.
You should then be able to move around freely from one room to another
without any interference. If interference does occur (interruptions in the
signal), press the "Auto Scan" button once to find a better reception channel.
A For better stereo reception, stay approximately seven meters away from the
transmitter when you press the "Auto Scan" button.
B If it is impossible to find a satisfactory frequency, change the channel setting
on your transmitter, then press the "Auto Scan" button on the headphones to
find the corresponding channel.
To protect the transmitter and to save power, the transmitter will automatically
switch off after approximately four minutes if there is no audio signal, or the
signal that it receives from the audio source is too weak for proper reception. If
the signal returns to an acceptable level, then the transmitter will automatically
switch back on.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 9
Charging the batteries
Switch OFF the receiver headphone.
To recharge the headphone batteries, place the headphones on the transmitter,
taking care to ensure that the charge contacts touch the transmitter's charge pins
and the green charging indicator is
ON .
The charge process starts automatically and the green indicator light comes
ON .
Be sure to charge new batteries for 24 hours before using them for the first time
in the headphones. The green indicator light will be on continuously during
battery charging.
Troubleshooting 7
Many times, problems have simple causes. We would like to give you some tips to
solve some common problems. Should these tips not help, please call us!
T
he
headphones
has no
function
No battery charge: Make sure that the battery
touching the charging contact has the coating
removed.
Ensure that the AC/DC adaptor is pushed fully into the power
outlet and that its cable is properly connected to the DC IN 6V
connector on the transmitter.
T
he
headphones
output level
is set too
low.
Adjust the volume to a suitable level.
Use the headphones volume control to increase the sound
level.
The headphones battery charge level may be too low. Recharge
the batteries or replace them with fully charged batteries.
No sound. Ensure that your TV set, Hi-Fi system or audio component is
switched on and set to a channel that broadcasts an audio
signal or is in playback mode.
T
he
reception is
bad or
distorted.
The headphones may be too far away from the transmitter.
Move closer to it.
The audio signal input level is too low. Increase the volume
from the audio source of Hi-Fi, CD, or TV, etc.
If distortion appears, press the “Auto Scan” button again. Use
the channel selector to change the transmitter's transmission
frequency. Then you will need to adjust the tuning control by
press the “Auto Scan” button on the headphones.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 10
Do you require additional Support?
If the suggestions in the above section have not solved your problem, please
contact the helpline. We will try and help you over the telephone. However,
before you contact your helpline, please have the following information at hand:
What external devices have been connected?
What messages appear on your display?
During which operating step has the problem arisen?
When a PC has been connected to the device:
– What is the system configuration?
– Which software were you using when the problem arose?
What steps have you already undertaken to solve the problem?
If you have already been given a customer number, please keep this available.
Maintenance 8
The lifespan of the device can be extended by the following means:
Before cleaning, always remove the power adaptor plug and all connecting
cables.
Do not use any solvents, corrosive or gaseous cleaning agents. Clean the device
with a soft, lint-free cloth. Ensure that no water droplets remain on the screen.
Water can cause permanent discoloration.
Please keep the packaging material well and use it exclusively to transport the
device.
There are no user-serviceable or user-cleanable parts inside the device.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 11
Recycling 9
Packaging
Your device is packaged to protect it against damage during
transportation. The packaging is manufactured from materials that can
be sent to a specialist recycling facility and disposed of in an
environmentally-friendly way.
Appliance
At the end of its life, the appliance must not be disposed of in
household rubbish. Enquire about the options for environmentally-
friendly disposal.
Batteries
Do not dispose of used batteries in the household rubbish! They must
be deposited at a collection point for used batteries.

Helpline No. UK
/
North Ireland 0871 37 61 020 Rep. Ireland 1-800-992 508
Web Support www.medion.co.uk
Model Number: 82937 12
