Mega Filter Max Series User manual

Your “Filter Max” Filter is a high performance corrosion-
proof filter that has superior flow characteristics that is with
the ease of operation. Everything is made simple from
installation, operation to the maintenance of the filter. Your
“Filter Max” filter will be your pool filtration partner that
provides clear water with the least maintenance hassle and
care.
operation will depends on how dirty your filter is. Check the
sight glass to see when the water becomes clear. It is
recommended that the backwash should be at least 2 minutes
long.
Once the backwash operation had been completed, the filter
should go through the process of “Rinse” and then back to
“Filter”. To perform the different operations, position the
handle on the control valve as indicated.
INSTALLATION
Installation had been made simple, the only tools needed is a
screwdriver and pipe sealant for plastic.
The filter should be installed as close to the pool as possible,
but keep a distance of at least 5 feet (1.5m). Locate the Filter
on rigid, level surface, preferably in a dry, shaded, and well-
ventilated area. Prior to installation give consideration to
the following: Position of suction, return, and waste
connections. Access for backwashing operation and
servicing; protection from sun, rain, splashing, etc;
Drainage of filter room; Ventilation and protection of the
motor.
1/ Place the empty tank in position.
2/ Fill the tank with water to the level that covers the laterals
(crepinas), or about 1/3 of the tank height is recommended.
This will avoid damages to the laterals (crepinas) by the
force of the sand when pouring into the filter.
Model MFV17, the Multiport Control Valve had been pre-
assembled. Remove the Multiport Control Valve from the
tank by unfastening the screw from the Clamp. Place the
Sand Fill Cover over the tank opening to prevent the sand
from getting into the standpipe.
Model MFV20, MFV24, 7A 7
MFV31, MFV35, the Sand Fill Cover had been pre-
assembled.
MFV2 , MFV2 , MFV31A,
WARNING B E F O R E INSTALLATION BE
S U R E T O R E A D A L L
INSTRUCTIONS AND WARNINGS
CAREFULLY. KEEP THIS USER MANUAL FOR
FUTURE REFERENCE.
HOW IT WORKS
The Filter uses special sand to remove dirt particles from
pool water. Filter sand is loaded into the filter tank to act as
the filtration media. The pool water which contains dirt
particles is pumped through your piping system to the filter
via the filter control valve. As pool water passes through the
filter, dirt particles will be caught by the sand bed and
filtered out. The cleaned pool water is returned from the
bottom of the Filter Tank, through the control valve and
back to the pool through your piping system. The entire
process is continuous and automatic. It is this process that
provides the filtration and circulation of water in your pool.
With the filtration process, dirt will accumulate and
becomes saturated in the filter tank. Pressure in the tank will
increase and the resistance of water flow will occur. This
means it is time to clean (backwash) your filter. Another
indication to know when to clean (backwash) the filter is by
checking the pressure gauge reading. Backwash operation
should be performed when the pressure increases by 10psi
above the pressure when it was clean. Typically a clean
filter will run at 10 to 15psi, so take note of the pressure
gauge reading when the filter was installed. When the
pressure reaches approximately 20 to 25psi or 50% increase
from the clean reading, proceed to the Backwash operation.
WARNING: turn off the pump before switching the control
valve handle.
To perform the Backwash operation, position the handle on
the control valve to “Backwash”, the water flow is
automatically reversed through the filter so the water is
directed from the bottom of the tank, up through the sand,
flushing the trapped dirt and debris out of the waste line.
The duration of the backwash
1-4
FILTER SMAX ERIES
MFV27A MFV31A MFV27
MFV31 MFV35
Add water to cover
laterals and add sand.
MFV17 MFV20 MFV24
1.Sand fill cover.
2. Place
on tank
opening.
3. Add water
to cover
laterals and
add sand.
MODEL: MFV17, MFV20, MFV24, MFV27A, MFV27,
MFV31A,MFV31, MFV35
MEFI13031601
E
N
G
L
I
S
H

3/ Pour the recommended amount of sand into the tank,
making sure that the centre-pipe remains centred and
vertical.
4/ Level the surface of the sand upon completion.
5/ Remove the Sand Fill Cover.
6/ Carefully remove all sand particles from the valve
mounting surface.
7/ Place the O-ring into the groove on the tank.
8/ Lower the Multiport Control Valve carefully into position
so that its underside engages with the centre-pipe. Rotate
the valve until the inlet is approximately in line with the
pump.
9/ Place the clamp set around the tank and the valve. Secure
using the screw provided.
10/ Firmly tap with a rubber mallet outside of the clamps as
you tighten the screw.
11/ Tighten the screw until the Multiport Control Valve is
properly assembled to create a water tight seal. Do not over
tighten.
START-UP PROCEDURE
1/ Be sure the correct amount of filter sand media is in the
tank and all connections have been made and are secure.
2/ Turn the Control Valve handle to the “Backwash”
position. Press the handle downward before turning.
3/ Start the pump according to pump instruction manual (be
sure all suction and return lines are open).
4/ Once water flow is steady out the waste line, run the pump
for at least 2 minutes. The initial backwashing of the filter is
recommended to remove any impurities or fine sand
particles in the sand media.
5/ Turn the pump off and set the control valve to RINSE
position. Start pump and operate until water in sight glass is
clear about ½ to 1 minute. Turn pump off, set valve to
FILTER position and restart pump. Your filter is now
operating in the normal filter mode, filtering particles and
dirt from the pool water.
6/ Take note of the initial pressure gauge reading for future
reference. Variation may occur from pool to pool.
7/ Adjust pool suction and return valves to achieve desired
flow. Check system and filter for water leaks and tighten
connections, bolts, nuts as required.
NOTE: During the initial clean-up of the pool water, it
may be necessary to backwash frequently due to the
unusually heavy initial dirt load in the water.
IMPORTANT: To prevent unnecessary strain on piping
system and control valve, always turn off the pump before
changing the operation of the control valve. To prevent
damage to the pump and filter and for proper operation of
the system, clean pump strainer (basket) and skimmer
basket(s) regularly.
MULTIPORT CONTROL VALVE FUNCTIONS:-
FILTER gives downward flow through the filter bed. This
position can also be used for vacuuming.
BACKWASH gives upward flow through the filter bed that
removes the dirt from the sand and carries it to the waste.
WASTE is for pumping water from the pool. It allows the
flow from the pump to bypass the filter and go directly to the
waste. You can also use this position to vacuum heavy
concentration of debris.
RECIRCULATE bypasses the filter to circulate water
through the pool system.
RINSE gives a downward flow that settles the filter bed
after backwashing and carries any remaining loose dirt to
the waste.
CLOSED prevents only backflow of water from pool during
pump maintenance.
To WINTERISE, set the control valve handle in the middle
between RINSE and FILTER. This will allow air to leave or
enter the tank to help priming and draining. Only to be used
when the pump is off.
VACUUMING THE POOL
Light Soil: set the control valve to FILTER position.
Heavy Soil: set the control valve to WASTE position.
12/ Install the pressure gauge into the threaded opening on
the Multiport Control Valve.
13/ Install the union sets and the backwash union set.
14/ Connect pump to the control valve opening marked
“PUMP”.
15/ Make return to pool pipe connection to control valve
opening marked “RETURN”.
16/ Connect the waste water pipe to the control valve
opening marked “WASTE”.
17/ To prevent water leakage, be sure all pipe connections
are tight.
18/ Prior to starting the filtration process by turning on the
pump, we highly recommend that you read through the
pump instruction manual to ensure proper installation and to
avoid the risk of electric shock.
FIGURE3.-Clamp Installation
tap with a rubber
mallet and tighten the
screws.
TYPICAL INSTALLATION
Sand
Nozzle
Inlet
(From pump)
Outlet
(To pool)
Drain
Waste
pipe
Pressure Gauge
E
N
G
L
I
S
H
2-4

D
B
A
C
E
WINTERRISING
Backwash the filter for at least thirty minutes before closing
down the pool for winterising. This will clean the filter bed
thoroughly.
1/ Drain the filter tank by removing the drain cap at the base
of the filter tank. Leave the cap off during winter.
2/ Set the control valve handle between the RINSE and
FILTER. This will lift the handle and help with the draining
process by allowing air to enter into the tank.
3/ Unscrew the pressure gauge from the control valve and
store the gauge indoor.
4/ Drain and winterise pump according to pump
instructions.
5/ Repairs should be made during the off-season when the
best service is available, do not leave them until the next
season.
TROUBLE SHOOTING
SAND ENTERING THE POOL
Sand too small; Flow too high; Sand bed calcified; Broken
Laterals; Loose centre-pipe; Too much sand; Control Valve
not engaged; Air accumulation in filter.
SAND OUT OF BACKWASH HOSE
Flow too high; Too much sand in tank.
INADEQUATE FILTERING
Dirt build up; improper sand; Sand bed is too low; Algae in
filter; Excessive dirt in pool; Calcified sand bed; Heavy
swimmer load; Flow rate too high or too low; Backwashing
cycle too short; Backwash line too small.
SHORT FILTER CYCLE
Dirty filter; Improper sand; Sand bed is low; Algae in filter;
Excessive dirt in pool; Calcified sand bed; heavy swimmer
load; Flow rate too high or too low; Backwashing cycle too
short; Channels low; Backwash adapter in wrong location;
Channels in sand.
FILTER LEAKS
Tank cracked; Drain plug not tight; Valve/Tank O'ring
damaged.
CONTROL VALVE LEAKS
Handle not properly engaged; Valve/Tank O'ring damaged;
Valve cover O'ring damaged. Pressure gauge O'ring
damaged.
ABNORMAL LOSS OF POOL WATER
Leak inside Control Valve; Leakage from pool or piping.
HIGH PRESSURE FILTER
Dirty filter; Calcified sand bed; Return lines too small.
LOW PRESSURE IN FILTER
Control Valve incorrectly set; Pump running too slow
(plugged or clogged); Air leakage into pump suction.
NOTE: If the recommendation in this manual do not solve
your particular problem(s), please contact your local dealer
for service.
POOL CHEMISTRY GUIDELINES
SUGGESTED POOL CHEMISTRY LEVELS ACTION REQUIRED TO CORRECT POOL CHEMISTRY
PH 7.2 to 7.6
TOTAL ALKALIN ITY 100 to 130 ppm
CHLORINE (UNSTABILIZED) 0.3 to 1.0 ppm
CHLORINE (STABILIZED) 1.0 to 3.0 ppm
CHLOR！NE STAB！LIZER 40 to 70 ppm
(Cyanuric Acid)
TO RAISE
Add Soda Ash
Add Sodium Bicarbonate
Add Chlorine Chemical
Add Chlorine Chemical
Add Stabilizer
TO LOWER
Add Muriatic Acid or Sodium Bisulphate
Add Muriatic Acid
No action-chlorine will naturally dissipate
No action-chlorine will naturally dissipate
Dilution-partially drain&refill pool with water
that has not been treated with Cyanuric Acid.
SPECIFICATIONS
A(mm)
B(mm)
Turnover Capacity (In Gallons) - 10 Hour
Turnover Capacity (In Gallons) - 8 Hour
3
Max Flow Rate (m /h)
Max Flow Rate (LPM)
Effective Filtration Area (Sq Ft)
Turnover Capacity (In Gallons) - 12 Hour
C(mm)
D(mm)
E(mm)
MFV27A
All Sand Required (kg)
0.14
125
7.5
15840
19800
23760
40
816
425
695
625
195
0.20
175
10.5
22176
27720
33264
70
889
500
772
712
225
0.28
238
14.3
30202
33752
45302
125
980
600
860
800
280
0.36
325
19.5
41184
51480
61776
185
1081
675
963
903
300
0.47
373
22.4
47309
59136
70963
320
1126
775
1008
948
370
88012526CODE 88012527 88012528 88012529 88012531
MFV24MFV20MFV17 MFV31A MFV31
0.39
325
20.3
42874
53592
64310
185
1133
675
976
910
300
0.47
373
24.7
52166
65208
78250
320
1178
775
1021
955
370
0.61
515
30.9
65261
81576
97871
430
1296
875
1139
1073
440
88012530 88012532 88012533
MFV27 MFV35
E
N
G
L
I
S
H
3-4

PARTS FOR FILTER MAX FILTER
Laterals for MFV27 MFV31 MFV35: , ,
Key NO. Part
Number Product Description QTY Key NO. Part Number Product Description QTY
1
88281505 MPV07 6-Way 1.5" Clamp Type Multiport Valve for
MFV17 MFV20 MFV24 MFV27A MFV31A Filter Max 112 01331029 MFV35 Filter Tank 1
88280306 MPV08 6-Way 2.0" Clamp Type Multiport Valve for
MFV27 MFV31 MFV35 Filter Max 1
13
89012507 Lateral Assembly with Center Pipe for MFV17 1
2
89280102 1.5" Union Set (3 Pieces) With O-Ring for MPV07
Valve 389012508 Lateral Assembly with Center Pipe for MFV20 1
89280103 2.0" Union Set (3 Pieces) With O-Ring for MPV08
Valve 3 89012509 Lateral Assembly with Center Pipe for MFV24 1
3
06021013 Plastic Pressure Gauge With O-Ring (40psi) 189012510 Lateral Assembly with Center Pipe for MFV27A 1
01111048 Connector for Pressure Gauge/Stopper 1 89012513 Lateral Assembly with Center Pipe for MFV27 1
4 89012512 Clamp Kit 189012511 Lateral Assembly with Center Pipe for MFV31A 1
5 01271021 Clamp Lock (left) 1 89012514 Lateral Assembly with Center Pipe for MFV31 1
6 01271022 Clamp Lock (right) 189012515 Lateral Assembly with Center Pipe for MFV35 1
7 03021035 M6 Nut 1
14
01172007 Laterals (115mm) for MFV17 8
8 01111101 Star-Shaped Nut 101172008 Laterals (126mm) for MFV20 MFV24 MFV27A
MFV31A 8
9 03011166 M6×110mm Screws 101172010 Laterals (185mm) for MFV27 MFV31 MFV35 4
10 03018124 Pin 101172007 Laterals (115mm) for MFV27 MFV31 MFV35 4
11 02010007 O-Ring 115 89010107 Water Drain Set 1
12
01331024 MFV17 Filter Tank 1
16
01111059 Filter Base for MFV17 MFV20 1
01331025 MFV20 Filter Tank 101111062 Filter Base for MFV24 MFV27A MFV27 1
01331026 MFV24 Filter Tank 101331003 Filter Base for MFV31A MFV31 MFV35 1
01331027 MFV27A MFV27 Filter Tank 117 89012516 Laterals bracket for MFV27 MFV31 MFV35 4
01331028 MFV31A MFV31 Filter Tank 1
E
N
G
L
I
S
H
4-4
