MegaLite Baby Color VW User manual

USER MANUAL
Table of Contents
Safety Information…………………………………………………..…3
Specifications…………………………………………………………..4
Main Power Connection…………………………………………….. 5
DMX-512 Connection……………………………………………...... 5
Main Control Menu.........................................................................6
DMX Profile.................................................................................... 8
Rigging the Fixture……………………………...………………….….9
Cleaning & Maintenance.................................................................9
Parts List.........................................................................................9

Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
4. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured
6. Maximum surface operating temperature 80º.
Protection Against Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. Do not expose unit to rain or moisture.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
3

Technical Information
4
4037– Baby Color VW
Mechanical Specifications
Fixture In ATA Road Case
Size: 8.25” x 4” x 7.25
Weight: 5lb
Size: 10.25” x 9.5” x 6.25”
Weight: 6lb
Electrical Specifications
DMX 512 Protocol
DMX Modes: Mode 1 3 Channels Amber, Warm White, Cool White
Mode 2 4 Channels Dimmer, Amber, Warm White, Cool White
Mode 3 6 Channels Dimmer, Amber, Warm White, Cool White, CTO, Strobe
Control Options: Audio Trigger, Master Slave
Control & Programming
DMX Connectors: 3 pin XLR connectors in and out
Thermal: Maximum ambient temperature 104°
Maximum surface temperature 140°
Fastening System: Double Mounting Yoke
Display: Digital
Power connection: Power Con in & out
LED Quantity: 7LED Angle: 20°
Diffusion Beam Angel: 25°
Amber: 7Power Input Voltage: 110V-240 50/60 Hz
Warm White: 7
Cool White:7Ballast: Electronic auto switching
Power Consumption Watts: 29
Amps: .42
LED Watts: 5
LED Lifetime: 60 to 100 thousand hours
Part Numbers
4.25”
7.25”
8.25”
4.8”

5
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 220V automatically
3. This unit must be earthed. (electronically grounded)
4. Replace fuse only with the specified type and rating.
The occupation of the connection-cable is as follows:
DMX-512 Connection
This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 240V from 50Hz to
The fixture is equipped with 3 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only use a
shielded twisted pair cable designed for RS-485 and 3 pin XLR plugs and connectors in order to connect the controller
with the fixture or the fixture with another.
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a
120 Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it
in to the last fixture on the signal run. Pre-manufactured terminator plugs are availa-
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
L
L
220V
L
L
110V
Connec-
220V
Connec-
N
L
12
3
2
3
1
DMX—input DMX—output
1. Shield
2. Signal (-)
3. Signal (+)
