MegaLite Mass-LED-WW User manual

USER MANUAL
Table of Contents
Safety Information…………………………………………………………..………………….….3
Specifications………………………………………………………………………………….…...4
Main Power Connection……………………………………………………………………….….5
DMX-512 Connection…………………………………………………………………...………...5
Main Control Menu...............................................................................................................6
DMX Profile..........................................................................................................................7
Rigging the Fixture………………………………………………………………………………...8
Cleaning & Maintenance......................................................................................................8
Parts List..............................................................................................................................8

Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
4. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured
6. Maximum surface operating temperature 113º.
Protection Against Electrical Shock
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. This unit is IP 22 rated (do not expose unit to rain or moisture )
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
3

4
4421-MASS LED WW
Mechanical Specifications
Fixture Packaging
Size: 9” x 6.25” x 7.5”
Weight: 3.75lb
Size: 10” x 8.25” x 11.5”
Weight: 4.5lb
Electrical Specifications
Protocol: DMX 512
DMX Modes: 3 Mode Operation
Mode 3 Channel Dimmer
Mode 4 Channel Dimmer, Strobe
Mode 7 Channel Dimmer, Strobe, Macro, Dimming Speed
Control Options: Display preset setting
Control & Programming
DMX Connectors: 5 pin XLR Connetion
Power connection: Nema 5-15 (cable mounted)
Thermal: Maximum ambient temperature 105°
Maximum surface temperature 113°
Fastening System: Single Yoke
Display: LED Display
Lens Angles: 60º reflector,
35º lens (included)
LED Quantity: 1 COB LED Warm White
LED Watts: 100W
LED Color Temp: 3000-3200K
LED Lifetime: 40 to 80 thousand hours average
Refresh Rate: 45000 Hz
Power Input Voltage: 110V-240 50/60 Hz
Ballast: Electronic auto switching
Power Consumption: Watts: 75
Amps: 1.2
Part Numbers
9”
Technical Information
6.25”
7.5”

5
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 240V automatically
3. This unit must be earthed. (electronically grounded)
The occupation of the connection-cable is as follows:
This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz
The fixture is equipped with 5 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only use a
shielded twisted pair cable designed for RS-485 and 5 pin XLR plugs and connectors in order to connect the controller
with the fixture or the fixture with another.
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120 Ohm re-
sistor between the (-) and the (+) signal into a 5 pin XLR plug and plug it in to the last fixture on
the signal run. Pre-manufactured terminator plugs are available for
purchase from your Mega-Lite dealer (P-DMX-T).
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
DMX-512 Connection
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
220V
L
L
LN
Main Power Connection
DMX—Input DMX—Output
1. Shield
2. Signal (-)
3. Signal (+)
4. N/A
5. N/A
5
3
4
2
11
2
3
4
5

Display Menu
6
Menu Up Down Enter
CONTROL BOARD
The control board on the fixture base is your interface to access and
control all the functions on the unit. Its digital display gives you a code
view of the options and functions. The following will explain each func-
tion and its options.
Press Menu to access the menu options.
Fade
This function allows you to select speed for dimmer fading the fixture. Press Enter use the up/down keys to select de-
sired fade speed (15 options). Press Enter to confirm the settings.
Flash
Dimming Speed
Press Enter to select the desired dimming speed when used with a DMX controller. Use the up/down keys to select from
0 to 4. 0 speed will be the fastest 4 will be the slowest. Press Enter to confirm.
DMX Address
Press Enter to select the DMX start address channel. Use the up/down keys to select the desired start address press
Enter to confirm. ( DMX address must match the DMX start channel on the controller)
Set Color Menu
Press Enter to set Dimmer via display control. . Use the up/down keys to select the desired dimmer intensity you would
like to adjust. Press Enter to confirm (255 dimmer settings)
This function allows you to select a preprogrammed strobe sequences. Press Enter use the up/down keys to select de-
sired strobe program (4 options). Press Enter to set the desired sped use the up/down keys (15 options). Press Enter
to confirm the settings.
Channel Mode
Press Enter to set DMX operational Channel Mode. . Use the up/down keys to select the desired channel operation
mode. Press Enter to confirm. (there is 3 options)

7
DMX Profile
MASS LED WW 1CH Mode
DMX Channel Function Description Value Init Value
1Dimmer LED intensity 0-255 255
MASS LED WW 2CH Mode
DMX Channel Function Description Value Init Value
1Dimmer Dimmer 0-255 255
No Function 0-1
2Strobe Strobe (slow to fast) 2-85 0
Pulse (slow to fast) 86-170
Random Strobe (slow to fast) 171-255
MASS LED WW 4CH Mode
DMX Channel Function Description Value Init value
1Dimmer Dimmer Off to Full 0-255 255
No Function 0-1
2Strobe Strobe (slow to fast) 2-85 0
Pulse (slow to fast) 86-170
Random Strobe (slow to fast) 171-255
No Function 0-1
3Macro Fade All (slow to fast) 2-85 0
Sound Fade (slow to fast) 86-170
Sound Snap (slow to fast) 171-255
Dim Speed 0 0-50
Dim Speed 1 51-100
4Dimming Dim Speed 2 101-150 0
Speed Dim Speed 3 151-200
Dim Speed 4 201-255

8
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installa-
tions and electronics checked by an expert every year.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any
safety problems have to be removed.
Note: There is no serviceable parts inside the device. Maintenance and service operations are to be carried out
by authorized dealers.
Replacing the fuse: Only replace the fuse with the same type and rating. (Line Fuse is located inside the fixture)
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by author-
ized dealers or trained professional only.
Should you have further questions , please contact your dealer.
Parts List
4421-DRI LED Driver card
4420-PS Power Supply
4421-DIS Display
4420-KN Knob Set
4421-LED Replacement LED
4420-FP Frontal Plastic
4420-LEN35 35 Degree Lens
Cleaning and Maintenance
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injures if you have doubts concerning the safety do not install.
3. Unit is to be 24inches away from flammable materials (decoration material)
4. Use high quality installation equipment to hang unit.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi-
ence including but not limited to calculating working loads, material being used and periodic safety inspections. If you
lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the fixture has
got to be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be
checked at least one time a year by a skilled person.
Rigging the fixture
4420-BD Barn Door

Mega-Lite
18668 Highway 16N
Helotes, TX 78023
Ph 210-684-2600 Fax [phone]
www.mega-lite.com / [e-mail]
Warranty Information
Warranty Conditions
-Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty.
-LED’s or Lamps are not guaranteed to match in color temperature or output.
-It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor.
If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
-Goods returned under warranty must follow the proper authorization procedure and must be accompanied by a copy of
the original invoice and Return Authorization Number given by MSI.
-Goods repaired under warranty will be returned to the owner with the freight prepaid by MSI via the most economical
means of shipment.
-Repair or replacement as provided for under this warranty is the exclusive remedy of the consumer. MEGA SYSTEMS
INC. makes no warranties, express or implied, with respect to any product, and Mega Systems specifically disclaims any
warranty of merchantability or fitness for a particular purpose. Mega Systems shall not be liable for any indirect, inci-
dental or consequential damage, including lost profit, sustained or incurred in connection with any product or caused by
product defect or the partial or total failure of any product regardless of the form of action, weather in contract, tort
(including negligence), strict liability or otherwise, and weather or not such damage was foreseen or unforeseen.
- Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This
warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
