MegaLite Halo 5R User manual

USER MANUAL
Table of Contents
Safety Information……………………………………………………………………………………………. 3
Specifications……………………………………………………………………………………………………..4
Features……………………………………………………………………………………………………………...5
Main Power Connection…………………………………………………………………………………..6
DMX-512 Connection…………………………………………………………………...……………......6
Main Control Menu…………………………………………………………………………………………...7
DMX Profile......................................................................................................................... 8
Cleaning & Maintenance.............................................................................................10
Parts List............................................................................................................................10

Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
4. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured away from unit movement.
6. Maximum surface operating temperature 104º.
Protection Against Fire
1. Disconnect power before lamp replacement or servicing.
2. For connection to main power supply proceed to page 6.
3. This unit must be earthed. (electronically grounded)
4. Do not expose unit to rain or moisture.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit risk of electrical shock.
3

4
Specifications
Part Numbers
Fixture
1200-Halo 5r
Mechanical Specifications
Lamp: Phillips 5R lamp
LED lamp: 16 RGB Series 3in1 LED’s
Pan: 480°
Tilt: 280°
Rotating Gobo: 1 Rotating Gobo wheel 7 Gobos +open
Gobo flow effect
Gobo roto bounce effect
Bi-directional gobo rotation
Color Wheel: Color Wheel with 7 colors + open
Rainbow flow effect
Iris: Adjustable Iris
Prism: 8 face rotating Prism
Focus: Mechanical
LED Control: LED control of 4 sections on 32 Channel Mode
DMX Connectors: 3 pin XLR connector in and out
Power Connection: Neutrik Power Conn in and out
Fastening System: 2 Quick release mounts
Center Beam Angle: 12°
LED Beam Angle: 45° (optional 25°)
Power: Auto switching 100ac to 240ac 50-60 Hz
Power Supply: Electronic
Protocol: DMX 512
DMX Channels: Mode 1 15 Channels
Mode 2 19 Channels
Mode 3 29 Channels
23.5”
13”
15.5”
4.5”
3.86”
7.38”
19”

5
Color
Gobo’s
1: Open
2: Red
3: Green
4: Yellow
5: Blue
6: Magenta
7: Orange
8: Light Blue
1: Open
2: Gobo 1
3: Gobo 2
4: Gobo 3
5: Gobo 4
6: Gobo 5
7: Gobo 6
8: Gobo 7
Note; Gobo’s are not replaceable
Rotating Gobo Wheel
Prism
1-8 Face Rotating Prism
LED’s
Zone 1
Zone 2
Zone 3
Zone 4
In 29 Channel Mode you have control over 4 zone’s of the LED ring

6
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit must be earthed. (electronically grounded)
3. Replace fuse only with the specified type and rating.
The occupation of the connection-cable is as follows:
12
3
1
3
2
DMX-512 Connection
This device is equipped with a auto switching power supply that will allow you to work from 100V-240V 50/60Hz
The fixture is equipped with 3 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only use a shielded
twisted pair cable designed for RS-485 and 3 pin XLR plugs and connectors in order to connect the controller with the fixture or
the fixture with another.
DMX—input DMX—output
1. Shield
2. Signal (-)
3. Signal (+)
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120
Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it in to the
last fixture on the signal run. Pre-manufactured terminator plugs are available for
purchase from your Mega-Lite dealer (HOS-DMXT).
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
L
L
220V
L
L
110V
Connection
220V
Connection
N
L

ENTER
MODE
7
Main Control Menu
The control board on the fixture base is your interface to access and control
all the functions on the unit. Its digital display gives you a code view of the
options and functions. The following will explain each function and its options. 5718 Kenwick St San Antonio. TX 78238
866-460-MEGA www.mega-lite.com
Set DMX
Address
Set Run
AUTO
Set Run
Sound
Set Pan
Reverse
Set Tilt
Reverse
System
Reset
Set DMX
Address Press Enter to confirm
15
Channel
19
Channel
29
Channel Use the up/down keys to select the required DMX Mode, Press Enter to
confirm
Address
001
Press Mode continuously to select and Enter to confirm
Use the up/down keys to select the required DMX start channel. Press Enter to confirm
Press Enter to confirm
AUTO
(P0)
AUTO
(P1)
AUTO
(P2)
AUTO
(P8) Use the up/down keys to select the required Auto Run program. Press Enter to confirm
Set Run
AUTO
AUTO
(P3)
AUTO
(P4)
AUTO
(P5)
AUTO
(P6)
AUTO
(P7)
Press Enter to confirm
Sound
(P0)
Sound
(P1)
Sound
(P2)
Sound
(P8) Use the up/down keys to select the required Sound sensor to reflect the Auto programs. Press Enter to con-
firm
Set Run
Sound
Sound
(P3)
Sound
(P4)
Sound
(P5)
Sound
(P6)
Sound
(P7)

Set Pan
Reverse Press Enter to confirm
Pan
(No)
Pan
(Yes) Use the up/down keys to select the Pan movements reversed. Press Enter to confirm
Set Tilt
Reverse Press Enter to confirm
Tilt
(No)
Tilt
(Yes) Use the up/down keys to select the Tilt movements reversed. Press Enter to confirm
System
Reset Press Enter to confirm
Note: Reset function will not re-strike the lamp.
8

9
Halo 5R 15 Channel Mode
DMX Channel Function Description Value
1 Pan Pan 0-255
2 Pan Fine Pan Fine 0-255
3 Tilt Tilt 0-255
4 Tilt Fine Tilt fine 0-255
Fast 0-84
5 Pan/Tilt Speed Mid 85-170
Slow 171-255
No Function 0-249
6 Control Reset 250-254
No Function 255
7 Dimmer 5R Lamp 0% to 100% 0-255
Close 0-31
Strobe (slow to fast) 32-95
8 5R lamp Shutter/ Open 96-127
Strobe Pulse strobe (slow to fast) 128-158
Open 159-191
Random Strobe (slow to fast) 192-223
Open 0-15
Red 16-31
Green 32-47
Yellow 48-63
Blue 64-79
9 Colors Magenta 80-95
Orange 96-111
Light Blue 112-127
Forward and Backward Rainrow Effect(slow to fast) 128-255
Open 0-15
Gobo 1 16-31
Gobo 2 32-47
Gobo 3 48-63
10 Gobo Gobo 4 64-79
Gobo 5 80-95
Gobo 6 96-111
Gobo 7 112-127
Gobo Wheel Rotation Clockwise (slow to fast) 128-191
Gobo Wheel Rotation Counter Clockwise (slow to fast) 192-255
No Function 0-15
Clockwise rotation (slow to fast) 1-85
11 Gobo Rotation Counter Clockwise rotation (slow to fast) 86-171
Gobo Bounce (back and forth) 172-255
12 Iris Iris (open to close) 0-191
Iris Pulse (slow to fast) 192-252
DMX Profile

10
13 Focus Focus from Near to far 0-255
14 Prism No Function 0-63
Prism 64-255
No Function 0-15
15 Prism Rotate Prism Rota Clockwise (Slow to Fast) 16-136
Prism Rota Counter Clockwise (Fast to Slow) 137-255
Halo 5R 19 Channel Mode
DMX Channel Function Description Value
1 Pan Pan 0-255
2 Pan Fine Pan Fine 0-255
3 Tilt Tilt 0-255
4 Tilt Fine Tilt fine 0-255
5 Pan/Tilt Speed From fast to slow 0-255
No Function 0-249
6 Control Reset 250-254
No Function 255
7 Dimmer 5R Lamp Dimmer 0% to 100% 0-255
Close 0-31
Strobe (slow to fast) 32-95
8
5R lamp Shut-
ter/ Open 96-127
Strobe Pulse strobe (slow to fast) 128-158
Open 159-191
Random Strobe (slow to fast) 192-223
Open 224-255
Open 0-15
Red 16-31
Green 32-47
Yellow 48-63
Blue 64-79
9 Colors Magenta 80-95
Orange 96-111
Light Blue 112-127
Forward and Backward Rainrow Effect(slow to fast) 128-255
Open 0-15
Gobo 1 16-31
Gobo 2 32-47
Gobo 3 48-63
10 Gobo Gobo 4 64-79
Gobo 5 80-95
Gobo 6 96-111
Gobo 7 112-127
Gobo Wheel Rotation Clockwise (slow to fast) 128-191
Gobo Wheel Rotation Counter Clockwise (slow to fast) 192-255

No Function 0-15
Clockwise rotation (slow to fast) 16-136
11 Gobo Rotation Counter Clockwise rotation (slow to fast) 137-225
Gobo Bounce (back and forth) 172-255
12 Iris Iris (open to close) 0-191
Iris Pulse (slow to fast) 192-252
13 Focus Focus from Near to far 0-255
14 Prism No Function 0-63
Prism 64-255
No Function 0-15
15 Prism Rotate Prism Rota Clockwise (Slow to Fast) 16-136
Prism Rota Counter Clockwise (Fast to Slow) 137-255
15 Red Red LED Dimmer (full ring) 0-255
16 Green Green LED Dimmer (full ring) 0-255
17 Blue Blue LED Dimmer (full ring) 0-255
No Function 0
Color Fade (slow to fast) 1-19
Color Step Chase (slow to fast) 20-39
Red Ring Chase (slow to fast) 40-59
Green Ring Chase (slow to fast) 60-79
18 Macros Blue Ring Chase (slow to fast) 80-99
Random Color Fade each different (slow to fast) 100-119
Random Color Step each different (slow to fast) 120-139
Red Pulse (slow to fast) 140-169
Green Pulse (slow to fast) 170-199
Blue Pulse (slow to fast) 200-229
White Pulse (slow to fast) 230-255
19 LED Strobe Strobe (slow to fast) 0-255
Halo 5R 29 Channel Mode
DMX Channel Function Description Value
1 Pan Pan 0-255
2 Pan Fine Pan Fine 0-255
3 Tilt Tilt 0-255
4 Tilt Fine Tilt fine 0-255
5 Pan/Tilt Speed From fast to slow 0-255
No Function 0-249
6 Control Reset 250-254
No Function 255
7 Dimmer 5R Lamp Dimmer 0% to 100% 0-255
Close 0-31
Strobe (slow to fast) 32-95
8 5R lamp Shutter/ Open 96-127
Strobe Pulse strobe (slow to fast) 128-158
Open 159-191
Random Strobe (slow to fast) 192-223
Open 224-255
11

Open 0-15
Red 16-31
Green 32-47
Yellow 48-63
9 Colors Blue 64-79
Magenta 80-95
Orange 96-111
Light Blue 112-127
Forward and Backward Rainbow Effect (slow to fast) 128-255
Open 0-15
Gobo 1 16-31
Gobo 2 32-47
Gobo 3 48-63
10 Gobo Gobo 4 64-79
Gobo 5 80-95
Gobo 6 96-111
Gobo 7 112-127
Gobo Wheel Rotation Clockwise (slow to fast) 128-191
Gobo Wheel Rotation Counter Clockwise (slow to fast) 192-255
No Function 0-15
11 Gobo Rotation Clockwise rotation (slow to fast) 16-136
Counter Clockwise rotation (slow to fast) 137-255
12 Iris Iris (open to close) 0-191
Iris Pulse (slow to fast) 192-252
13 Focus Focus from near to far 0-255
14 Prism No Function 0-63
Prism 64-255
No Function 0-10
15 Prism Rotate Prism rotation Clockwise (Slow to Fast) 11-130
Prism rotation Counter Clockwise (Slow to Fast) 131-255
No Function 0
Color Fade (slow to fast) 1-19
Color Step Chase (slow to fast) 20-39
Red Ring Chase (slow to fast) 40-59
Green Ring Chase (slow to fast) 60-79
16 Macros Blue Ring Chase (slow to fast) 80-99
Random Color Fade each different (slow to fast) 100-119
Random Color Step each different (slow to fast) 120-139
Red Pulse (slow to fast) 140-169
Green Pulse (slow to fast) 170-199
Blue Pulse (slow to fast) 200-229
White Pulse (slow to fast) 230-255
17 LED Strobe Strobe (slow to fast) 0-255
18 Red 1 Red 1 Dimmer 0-255
19 Green 1 Green 1 Dimmer 0-255
20 Blue 1 Blue 1 Dimmer 0-255
21 Red 2 Red 2 Dimmer 0-255
22 Green 2 Green 2 Dimmer 0-255
23 Blue 2 Blue 2 Dimmer 0-255
24 Red 3 Red 3 Dimmer 0-255
25 Green 3 Green 3 Dimmer 0-255
26 Blue 3 Blue 3 Dimmer 0-255
27 Red 4 Red 4 Dimmer 0-255
28 Green 4 Green 4 Dimmer 0-255
29 Blue 4 Blue 4 Dimmer 0-255
12

Cleaning and maintenance
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron-
ics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) Mechanically moved parts like axles and other must not show any traces of wearing and must not rotate with unbalances.
4) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments. Further
instructions depending on the installation spot and usage have to be adhered by a skilled installer and any safety problems
have to be removed.
Disconnect from mains before starting maintenance operation!
Caution Danger to life!
We recommend a frequent cleaning of the device. Please use a moist, lint free cloth. Never use alcohol or solvents!
1) The objective lens will require periodic cleaning on usage and environment. Environment with foggers will require more peri-
odic cleaning as fog fluid tends to build up residues, reducing the light output.
2) The cooling-fans should be cleaned monthly. DO NOT blow high pressure air into fans as incorrect rotation can damage the
fans operation.
3) The gobos, dichroic color filters and internal lenses may be cleaned with soft brush using soapy water.
4) The interior of the fixture should be cleaned using a vacuum.
5) We recommend proper lubrication of the motor wheel. The quantity of the oil must not be excessive in order to avoid oil run
outs when motor wheel rotates
Note: There is no serviceable parts inside the device except for the fuse. Maintenance and service operations are to be carried
out by authorized dealers.
Replacing the fuse: Only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized dealers only
In order to avoid hazards.
Should you have further questions , please contact your dealer.
13
Parts List
Item # Description
1200-PSL Lamp Power Supply
1200-PS Unit Power Supply
1200-IG Lamp Ignitor
1200-PCBL LED PCB
1200-PCBM Main PCB
1200-PCBD Driver PCB
1200-PCBDIS Display PCB
1200-PCBDMX DMX PCB
1200-FAN80 80mm fan 12V Brushless
1200-FAN60 60mm fan 12V Brushless
1200-FAN54 54mm fan 12V Squirl Cage Brushless
1200-BEZF Front Bezel
1200-BEZH Head Bezel
1200-H Handle
1200-QR Quick release clamps (pair)
1200-PCBLED LED 3in1 4 unit PCB (include 4 LED's)
1200-LED LED 3in1 TX RGB single LED
1200-SENFC Focus Sensor
1200-SENPT Pan Tilt Sensor
1200-SENRO Sensor Gobo Rotate
1200-MOTFO Motor Focus
1200-MOTGO Motor Gobo
1200-MOTRO Gobo Rotate Motor
1200-MOTCO Color Wheel Motor
L-5R Phillips platinum 5R Lamp

Mega-Lite
5718 Kenwick St
San Antonio, TX 78238
Ph 210-684-2600 Fax [phone]
www.mega-lite.com / [e-mail]
Warranty Information
Limited Warranty
Unless otherwise stated, your product is covered by a one year parts and labor limited warranty. Dichroic filters and glass gobos are not guaranteed
against breakage or scratches to coating. It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and dealer
or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
Returning an Item Under Warranty for Repair
It is necessary to obtain a Return Material Authorization (RMA) number from your dealer or point of purchase BEFORE any units are returned for
repair. The manufacturer will make the final determination as to whether or not the unit is covered by warranty. Lamps are covered by the lamp
manufacturer’s warranty.
Any Product unit or parts returned to MEGA Systems Inc. must be packaged in a suitable manner to ensure the protection of such Product unit or
parts, and such package shall be clearly and prominently marked to indicate that the package contains returned Product units or parts and with an
RMA number. Accompany all returned Product units or parts with a written explanation of the alleged problem or malfunction. Ship returned Prod-
uct units or parts to: 5711 Kenwick St. San Antonio TX 78254 USA.
Note: Freight Damage Claims are invalid for fixtures shipped in non-factory boxes and packing materials.
Freight
All shipping will be paid by the purchaser. Items under warranty shall have return shipping paid by the manufacturer only in the Continental United
States. Under no circumstances will freight collect shipments be accepted. Prepaid shipping does not include rush expediting such as air freight. Air
freight can be sent customer collect in the Continental United States.
REPAIR OR REPLACEMENT AS PROVIDED FOR UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
MEGA SYSTEMS INC. MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO ANY PRODUCT, AND MEGA SYS-
TEMS SPECIFICALLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. MEGA
SYSTEMS SHALL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGE, INCLUDING LOST PROF-
ITS, SUSTAINED OR INCURRED IN CONNECTION WITH ANY PRODUCT OR CAUSED BY PRODUCT DEFECTS OR THE PARTIAL
OR TOTAL FAILURE OF ANY PRODUCT REGARDLESS OF THE FORM OF ACTION, WHETHER IN CONTRACT, TORT (INCLUDING
NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, AND WHETHER OR NOT SUCH DAMAGE WAS FORESEEN OR UNFORESEEN.
Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This warranty gives you specific
legal rights, and you may also have other rights which vary from state to state.
