Megger DCM340 User manual

Off / On
Auto Power Off
30min
AC V / DC V
Auto Power Off disable :
Press buttons (except Hold button) than
switch the rotary knob to power on the
Meter.
Symbols as marked on the
Meter and Instruction card
Risk of electric shock
See instruction card
DC measurement
Equipment protected by double or
reinforced insulation
Battery
Earth
AC measurement
Conforms to EU directives
Resistance
Continuity
Caution
If the meter is used in the vicinity of
equipment which generates electromag-
netic interference, the display may
become unstable or the measurements
show may be subject to large errors.
User Guide
DCM340 Clampmeter
Warning
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . .
Safety sheet
. . . . . . . . .
. . . . . . . . . .
. . . . . . . . . .
. . . . . . . .
. . . . . . . . . Read First
Safety Information
To ensure safe operation and service
of the Meter, follow these instructions.
Failure to observe warnings can result
in severe injury or death.
-Avoid working alone so assistance can
be rendered.
- To enhance safety, test leads should be
disconnected from instrument when not
in use.
- Do not use test leads or the Clamp
Meter if they look damaged.
- Do not use the Meter if the Clamp
Meter is not operating properly or if it
is wet.
- Use the Clamp Meter only as specified
in the Instruction card or the protection
provided by the Clamp Meter might be
impaired.
- Special precautions are necessary
when operating in situations where
exposed live parts at dangerous
voltages may be encountered. Personal
protective equipment (not supplied with
this instrument) should be used.
- The test leads sould be disconnected
from the instrument when making a
current measurement.
- Use caution with voltages above 30 V
ac rms, or 60 V dc. These voltages
pose a shock hazard.
www. .com [e-mail]1.800.561.8187

ACA / DCA
I
I
I
I
590A
Hz
Zero
ACA50Hz
0A
Min / Max Hold
Battery Replacement
Peak Hold
Back Light
Back light Automatic off after 60
seconds.
oREL: Meter save the displayed
offset value after one press of the
ZERO button. The LCD is display-
ing the relative value.
pREL (flashing): A second press of
the ZERO button saves the offset
value, with the present value then
displayed.
nNormal : Press and hold ZERO for
≧2 sec to return to normal opera-
tion and cancel the offset value.
Low battery :
“” is displayed or displays
“” a flash when press
button.
Data Hold
I + (-I) = 0
oMAX: Meter is saving the maxi-
mum and minimum value. Maxi-
mum value is displayed.
pMIN: Meter is saving the maxi
mum and minimum value. Mini-
mum value is displayed.
qMAX MIN (flashing): Meter is
saving the maximum and mini-
mum values. Present value is
displayed.
nNormal : Press and hold MIN
MAX to return to normal operation.
oPMAX: Meter is saving the peak
maximum and minimum value.
Peak maximum value is displayed.
pPMIN: Meter is saving the peak
maximum and minimum value.
Peak minimum value is displayed.
qCAL : Press and hold PEAK but-
ton≧3 sec to calibrate the
Meter itself for accurate meas-
urement.
nNormal : Press and hold PEAK
button to return to normal opera-
tion.
CAT.Ⅲ.600V
with respect to
earth for the jaw.
Tactile barrier for
Hand Guard.
Do not hold the
meter in front of
the Tactile Barrier.
√
X
X
www. .com [e-mail]1.800.561.8187

Specifications
1-1 General Specifications
LCD display digits :
3 3/4 digit large scale LCD readout.
Display count : 4000 counts.
Measuring rate : 1.5 times / sec.
Overrange display :
“OL” is displayed for “Ω” functions,
shows the real value for “A” and “V”
function.
Automatic power off time :
Approximately 30 minutes after
power on.
Low battery indicator :
is displayed. Replace the battery
when the indicator appears in the
display.
Power requirement :
9V PP3 / 6LR61 battery.
Rechargeable batteries are not
suitable for use with this instrument.
1-2 Environmental Conditions
Indoor Use.
Calibration :
One year calibration cycle.
Operating temperature :
0°C ~ 30°C (≦80% RH)
30°C ~ 40°C (≦75% RH)
40°C ~ 50°C (≦45% RH)
Storage temperature :
-20 to +60°C, 0 to 80% RH (batteries
not fitted).
Overvoltage category :
IEC 61010-1 600V CAT.Ⅲ.
CAT.Ⅲequipment is designed to
protect against the transients in the
equipment in fixed installations,
such as distribution panels, feeders
and short branch circuits and light-
ing systems in large buildings.
Operating altitude : 2000m (6562 ft)
Conductor Size : 35mm diameter.
Pollution degree : 2
EMC : EN 61326-1
Function Range Accuracy
V0~400.0Vrms
400~600Vrms ±(1.0%+ 5 dgt)
50Hz ~ 500Hz
V0~400.0 V
400~600 V ±(0.7% + 2 dgt)
Overload protection : 600V rms
Input impedance : 1MΩ// less
than 100pF.
AC Conversion Type :
AC Conversion are average sensing
rms indication calibrated to the rms
value of a sine wave input.
Resistance & Continuity
Function Range Accuracy
Ω 400.0Ω±(1% + 3 dgt)
Overload protection : 600V rms
Max. open circuit voltage : 3V
Continuity check : Internal sounds
activates if the resistance of the
circuit under test is less than 30Ω
approximately.
AC Current
*1 : Over 80% of full scale add ±1.6%
Overload protection : 600A rms
AC Conversion Type and additional
accuracy is same as AC Voltage.
Position Error : ±1% of reading.
Frequency : Hz
Range Resolution Accuracy
20~400Hz 1Hz ±(0.1% + 2 dgt)
Min/Max Hold : add ±15 dgt to
accuracy for ACA / DCA.
* Automatically switch to the low
resolution range at Peak Hold
and MIN MAX Hold.
Function Range Accuracy
A
(50~60Hz) 0~400.0A ±(1.5%+ 5 dgt) *1
400~600A ±(2.0%+ 7 dgt)
A
(61~400Hz) 0~400.0A ±(2.0%+ 5 dgt) *1
400~600A ±(2.5%+ 7 dgt)
DC Current
Function Range Accuracy
A0~400.0A ±(1.2%+ 5 dgt)
400~600A ±(1.9%+ 7 dgt)
Overload protection : 600A rms
Position Error : ±1% of reading.
Addition error according to rema-
nence : 1% max. of current crest.
Auto Power Off (APO)
The meter will automatically shut itself
off after approximately 30 minutes
after power on.
Maintenance
Do not attempt to repair this Meter.
It contains no user-serviceable
parts. Repair or serving should only
be performed by qualified personal.
Cleaning
Periodically wipe the case with a
dry cloth and detergent do not use
abrasives or solvents.
Shock vibration :
Sinusoidal vibration per MIL-T-
28800E (5 ~ 55 Hz, 3g maximum).
Drop Protection : 1.2m drop to
hardwood on concrete floor.
1-3 Electrical Specifications
Accuracy is ±(% reading + number
of digits) at 23°C ±5°C < 80%RH.
Temperature coefficient :
0.2 x (Specified accuracy) / °C,
< 18°C, > 28°C .
Voltage
Overload protection : 600A rms.
Sensitivity : 3A rms for ACA (A)
(>400Hz Unspecified)
Peak Hold : ±(3% + 15dgt)
*>600Vpeak Unspecified.
*>600Apeak Unspecified.
