Members Mark CG2310601-MM-00 Quick reference guide

1 of 32 20191202-Ver.1.0
PELLET GRILL
Model number: CG2310601-MM-00
ASSEMBLY & OPERATING INSTRUCTIONS
For Outdoor Use Only
Please read this entire manual before installation and use of this pellet
fuel-burning appliance.
Follow all warnings and instructions when using the appliance.
Failure to follow these instructions could result in property damage, bodily
injury or even death.
Contact local building or fire officials about restrictions and installation
inspection requirements in your area.
Save these instructions.
Should you encounter any problem,
CALL US FIRST.
Do not return product to the store.
WE CAN HELP.
For assistance, contact customer service at [email protected]
or at 1-888-837-1380, Mon to Fri, 8:00am –5:00pm Pacific Standard time

2 of 32 20191202-Ver.1.0
WARNINGS
SAFETY LABELS
DANGER: Indicates an imminent hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
DANGER
1. Hazardous voltage is present which can shock, burn or cause death.
Disconnect the power cord before servicing the grill unless otherwise
noted in the owner’s manual.
2. Never use or store flammable liquids near the grill.
3. Never use gasoline or lighter fluid to manually light your grill. Use only
alcohol gel for this procedure and according to the instructions in the
owner’s manual.
DANGER
A MAJOR CAUSE OF FIRES IS FAILURE TO
MAINTAIN REQUIRED CLEARANCES 60 INCHES
TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST
IMPORTANCE THAT THIS PRODUCT BE
INSTALLED ONLY IN ACCORDANCE WITH THESE
INSTRUCTIONS.
PROP 65 WARNING
WARNING: This product can expose you to chemicals including soot, which is known to
the State of California to cause cancer, and carbon monoxide, which is known to the State of
California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.

3 of 32 20191202-Ver.1.0
WARNING
Important Safety Instructions
When using electrical appliances, basic safety precautions should always be followed, including
the following:
READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE APPLIANCE.
This grill is for outdoor use only. Do not use it in any enclosed area.
Use this appliance only on a level, stable surface to prevent tipping.
Do not store or use combustible materials or liquids near this appliance.
Maintain a long safe distance between your grill and any combustible.
Do not move your grill while operating or while it is hot until the grill is completely cold.
If a grease fire occurs, turn “off” and leave lid closed until the fire extinguished. Do not
unplug the power cord. Do not throw water on it.
Do not try to smother the fire.
Clean and maintain your grill after each time use.
Use Only Wood Pellet Fuel Specified By The Manufacturer. Do Not Use Pellet Fuel
Labeled As Having Additives.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar
liquids to start or ’freshen up’ a fire in this appliance. Keep all such liquids well away from
the appliance when in use.
Seal and put the pellets in a dry place for storage when appliance is not in use.
Remove pots and pans while the operating appliance is unattended, to reduce the risk of
fire.
Do not use accessories not specified for use with this appliance.
Only Dia 6 mm Pellets can be used.
Do not use your grill on rainy days.
Do not touch any part of your grill directly while it is hot. Serious bodily injury could result.
We suggest that use heat-resistant gloves when operating this grill.
We suggest that you should warp Grease Drip Tray up with heavy-duty aluminum foil
before using because it is easy to clean.
For convenient and safe assembly, use at least two people to assemble the grill.
Make sure the power cord is disconnected before performing any service or maintenance.
Always keep the Pellet Hopper dry, the wood pellets will expand greatly, break apart and
even jam the feed system if the pellets get wet or exposed to high humidity.
Never use heating fuel pellets in the grill, due to potential hazardous contaminants and
additives that may be present.
Use your grill OUTDOORS in a well ventilated space away from dwellings or other
buildings to prevent dangers associated with gas accumulation and toxic vapors. The grill
should be situated at least 60 inches (152.4 cm) from buildings. Not adhering to these
clearances will prevent proper ventilation and may increase the risk of a fire and/or
property damage, which could also result in personal injury.

4 of 32 20191202-Ver.1.0
Maintain a minimum clearance of 60 inches
(152.4 cm) between all sides of grill, deck
railings, walls or other combustible material.
DO NOT use grill under any overhead
combustible construction.
To protect against electric shock, wear
protective gloves such as oven mitts at all
times when using appliance. Do not immerse
cord, plugs or temperature controller in water
or other liquid.
Do NOT expose the appliance to rain or
water at any time.
Keep children and pets away from the
appliance at all times. Do NOT allow children to use this appliance.
Do NOT plug in the appliance until fully assembled and ready for use.
Unplug the appliance from outlet when not in use or before cleaning. Allow appliance to
cool down before putting on or taking off parts, and before cleaning.
The appliance MUST be on the ground. Do NOT locate it on tables or counters. Do NOT
move it across uneven surfaces.
Use only approved and grounded electrical outlet.
Keep a fire extinguisher accessible while using the appliance.
Do NOT use fuel, such as charcoal briquettes or heat pellets for in this appliance.
Be careful when removing food from the appliance. All surfaces are HOT and may cause
burns.
Do NOT allow anyone to conduct activities around the appliance during or following its use
until the unit has cooled.
Do NOT use appliance when under the influence of alcohol, prescription or
non-prescription drugs.
Do NOT use this appliance as a heater.
Remove the label on the lid before first use.
Maintain a minimum clearance of
60 inches from combustible material.

5 of 32 20191202-Ver.1.0
WARNING
When using electrical appliances, basic safety precautions should always be followed, including
the following:
Electrical Rating: 120 Volts / 60 Hz / 250W, Phase 1.
Must be electrically grounded in accordance with local codes or, in the absence of local
codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code,
Part I, CSA C22.1 when install this appliance.
Keep any electrical supply cord and the fuel supply hose away from any heated surfaces.
To protect against electric shock, do not immerse cord or plugs in water or other liquid.
Unplug from the outlet when not in use and before cleaning. Allow to cool before putting
on or taking off parts.
Do not let the cord hang over the edge of a table or touch hot surfaces.
Never remove the grounding plug or use with an adapter of 2 prongs.
Use only extension cords with a 3-prong grounding plug, rated for the power of the
equipment, and approved for outdoor use with a W-A marking.
WARNING
Follow these guidelines to prevent this colorless, odorless gas from poisoning you,
your family or others.
Know the symptoms of carbon monoxide poisoning: headache, dizziness, weakness,
nausea, vomiting, sleepiness, and confusion. Carbon monoxide reduces the blood's ability
to carry oxygen. Low blood oxygen levels can result in loss of consciousness and death.
See a doctor if you or others develop cold or flu-like symptoms while cooking or in the
vicinity of this appliance. Carbon monoxide poisoning, which can easily be mistaken for a
cold or flu, is often detected too late.
Alcohol consumption and drug use increase the effects of carbon monoxide poisoning.
Carbon monoxide is especially toxic to mother and child during pregnancy, infants, the elderly,
smokers, and people with blood or circulatory system problems, such as anemia, or heat
disease.
WARNING
Contact local building or fire officials about restrictions and installation
inspection requirements in your area.

6 of 32 20191202-Ver.1.0
WARNING
Creosote - Formation and need for removal. When wood pellets are burned slowly, they
produce tar and other organic vapors that combine with expelled moisture to form
creosote. The creosote vapors condense in a relatively cool oven flue and exhaust hood
of a slow burning fire. As a result, creosote residue accumulates on the flue lining and
exhaust hood. When ignited, this creosote makes an extremely hot fire.
The grease duct should be inspected at least twice a year to determine when grease
and/or creosote buildup has occurred.
When grease or creosote has accumulated, it should be removed to reduce risk of fire.
Disposal of ashes - Ashes should be placed in a metal container with a tight-fitting lid. The
closed container of ashes should be placed on a non-combustible floor or on the ground,
well away from all combustible materials, pending final disposal. When the ashes are
disposed by burial in soil or otherwise locally dispersed, they should be retained in the
closed container until all cinders have thoroughly cooled.
SAVE THESE INSTRUCTIONS.

7 of 32 20191202-Ver.1.0
PRODUCT DIAGRAM

8 of 32 20191202-Ver.1.0
COMPONENT LIST
1. Warming Rack
2. Cooking Grate
3. Lid Handle Heat Shield
Qty: 1pc
Qty: 3pcs
Qty: 1pc
4. Lid Handle
5. Side Handle Tray
6. Flame Tamer
Qty: 1pc
Qty: 1pc
Qty: 1pc
7. Meat Probe
8. Grease Drip Tray
9. Grill Body Assembly
Qty: 2pcs
Qty: 1pc
Qty: 1pc
10. Smoke Stack Assembly
11. Side Handle
12. Hook
Qty: 1pc
Qty: 1pc
Qty: 3pcs

9 of 32 20191202-Ver.1.0
13. Grease Bucket
14. Grease Drain Assembly
15. Front Shelf Left Bracket
Qty: 1pc
Qty: 1pc
Qty: 1pc
16. Front Shelf Right Bracket
17. Front Shelf
18. Cart Bottom Panel
Qty: 1pc
Qty: 1pc
Qty: 1pc
19. Left Rear Leg
20. Left Front Leg
21. Wheel Axle
Qty: 1pc
Qty: 1pc
Qty: 1pc
22. Cart Front Panel
23. Right Rear Leg
24. Right Front Leg
Qty: 1pc
Qty: 1pc
Qty: 1pc
25. Locking Caster
26. Wheel
Qty: 2pcs
Qty: 2pcs

10 of 32 20191202-Ver.1.0
HARDWARE LIST
Item No.
Item name
Diagram
Qty
A
M6x12mm Bolt
39
B
M6 Nut
11
C
M6x20mm Bolt
2
D
Wheel Sleeve
2
E
M10 Locking Nut
2
F
M10 Washer
2
G
Heat Insulating Washer
4
H
M6x14mm Bolt
4
I
M6x15 Nut
2
