Mercia Garden Products 01DTSHAX0406SDFW-V1 Instruction manual

**Protim Aquatan T5 (621)**
Your building has been dip treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct
application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.
Measure
under the
head
Measure
overall
length
Screws & Nails Bolts To identify the
xings required
for each step use a
measuring tape.
01DTSHAX0406SDFW-V1
DIP TREATED SHIPLAP APEX 4X6 SINGLE DOOR FIXED WINDOWS
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All buildings should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips screw-
driver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for maintenance,
annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree causing
damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be
helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine
and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to prevent
the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof treat-
ment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm above
the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
For ease of assembly, you
will need a tape measure to
check dimensions of
components.
REGISTER FOR YOUR
ANTI-ROT
GUARANTEE TODAY
PLEASE SCAN HERE:
P 1
Please retain product label and instructions for future reference
General Instructions

P 2
01DTSHAX0406SDFW-V1
Please retain product label and instructions for future reference
4x6 Shed
Overall Dimensions:
Width = 1972mm
Depth = 1299mm
Height = 2039mm
Base Dimensions:
Width: 1860mm
Depth: 1190mm
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
7
Ridge Bar - 28x28x1137mm QTY 1
FS2828-1137mm
8
Door Block - 27x44x160mm QTY 1
F2744-160mm
9
Cover Strip - 40x12x1570mm QTY 4
S1240-1570mm
10
Fascia - 12X80x1045mm QTY 4
S1280-1045mm
11
Greenhouse Roof Frame - 44x27x1574mm QTY 2
F2744-G-1594mm (Angled) - Used only when attaching greenhouse to shed (See Step 17).
12
Greenhouse Roof Block - 44x27x410mm QTY 1
F2744-G-450mm (Angled) - Used only when attaching greenhouse to shed (See Step 19).
13
T-Hinge QTY 3
PI-07-0021
14
“L” Bracket QTY 2
PI-07-0012
15
Pad Bolt
PI-07-0035
**For greenhouse contents please see
instructions before beginning assembly.**
16
Shed Diamond Finial
QTY 2
Shed diamond Finial
17
Felt
PI-01-0013
50mm Screws x 52
30mm Screws x 59
20mm Screws x 8
Felt Tacks x 100
60mm Screws x 8
8x6 Greenhouse with
shed
Overall Dimensions:
Width = 1972mm
Depth = 2447mm
Height = 2039mm
Base Dimensions:
Width: 1860mm
Depth: 2397mm
10x6 Greenhouse with
shed
Overall Dimensions:
Width = 1972mm
Depth = 3030mm
Height = 2039mm
Base Dimensions:
Width: 1860mm
Depth: 2980mm
12x6 Greenhouse with
shed
Overall Dimensions:
Width = 2042mm
Depth = 3665mm
Height = 2039mm
Base Dimensions:
Width: 1860mm
Depth: 3590mm
56
Floor QTY 1
AI-S21MBF1190X1860-V1
Roof QTY 2
AI-S11MBOHAR1075X1217-V1
1 2 34
Door QTY 1
AI-S21FBMBZBD544X1660-V1
Door Gable QTY 1
AI-01S11SHASD2FW1808X1970-V1
Plain Side QTY 2
AI-S11SHPP1193X1571-V1
Plain Gable QTY 1
AI-01S11SHAGP1808X1970-V1
Nail Bag
There may be extra screws present in the nail bag
18
Turn Button QTY 2
PI-07-0034
70mm Screws x 7

P 3
Please retain product label and instructions for future reference
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips screw-
driver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for maintenance,
annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree causing
damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be
helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine
and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to prevent
the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof treat-
ment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm above
the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
Place the door (No. 4) into the
door gable (No. 1) aperture,
making sure there is an equal
amount of space either side
of the door.
Once in place secure the door
to the door gable using 3x
T-hinges (No. 13) securing
each hinge into position with
7x30mm screws.
21x30mm screws.
Pre drill
hole
30mm
screw
Place the oor (No. 5) onto a
rm and level surface.
Ensure your base has suitable
drainage and is free from
areas where standing water
can collect.
Place the plain gable (No.3) and one
of the plain panels (No.2) on to the
oor and x the corners together
using 3x50mm screws.
Do not secure the building to the
oor until the roof is secured in place.
*Ensure the plain gable is tted on
the inside of the plain panel. Screw
through the plain gable framing
into the framing of the plain panel.
3x50mm screws
Pre drill
hole
50mm
screw
Step 1
Parts Needed- No.1 QTY 1
- No.4 QTY 1
- No.13 QTY 3
Step 2
Parts Needed- No.5 QTY 1
Step 3
Parts Needed- No.2 QTY 1
- No.3 QTY 1
1
4
13
5
2
3
a
a
a
a

P 4
Please retain product label and instructions for future reference
Step 4
Parts Needed- No.1 QTY 1
- No.2 QTY 1
2
1
714
714
14
Step 5
Parts Needed- No.7 QTY 1
- No.14 QTY 2
Step 6
Parts Needed- No.6 QTY 2
Pre drill
hole
50mm
screw
Place the Door gable (No.1) and one of
the plain panels (No.2) on to the oor
and x the corners together using
3x50mm screws.
Do not secure the building to the oor
until the roof is secured in place.
*Ensure the Door gable is tted on the
inside of the plain panel. Screw
through the Door gable framing into
the framing of the plain panel.
9x50mm screws
a
Fix the Corner Braces (No. 14) to
either end of the ridge bar (No. 7)
using 2x20mm screws per bracket.
*Ensure the corner bracesare
ush with each end of the ridge
bar.
Once in place position the ridge bar
between the gables, securing into
position using 2x30mm screws per
side.
8x20mm Screws
Pre drill
hole
20mm
screw
a
a
a
a
a
a
a
a
60mm
screw
Pre drill
hole
Place the Roof Panels (No. 6) on top of
the building making sure the framing in
the roof panels sits rmly within the
Gable Panels (No. 1 & 3) and on top of
the Ridge Bar (No. 7).
**Make sure that you have got the
roof panels the correct way round
with the recess at the top of the apex
as shown in the diagram.**
**The edges of the roof panels must
be ush with the outer cladding of the
Gable Panels (No. 1 & 3).**
From the top, x directly through the
roof panels (No. 6) and into the ridge bar
(No. 7) below using 4x60mm screws per
Roof Panel.
It is essential that the ridge bar (No. 7)
and roof panel (No. 6) framing pull
together when xed with 60mm screws.
You may require another person pushing
the ridge bar (No. 7) up
from below to achieve this.
**HINT - Follow the nailing line of the
framing on the roof panel so that you
are more likely to x into the ridge bar
below. **
8x60mm Screws
6
6

P 5
Please retain product label and instructions for future reference
Place the plain gable (No.3) and one
of the plain panels (No.2) on to the
oor and x the corners together
using 3x50mm screws.
Do not secure the building to the
oor until the roof is secured in place.
*Ensure the plain gable is tted on
the inside of the plain panel. Screw
through the plain gable framing
into the framing of the plain panel.
3x50mm screws
Once the roof has been xed into
place secure the building to the oor
using 18x50mm screws.
*Ensure to screw through the panel
framing into the oor bearers
below.
18x50mm screws
b
Pre drill
hole
50mm
screw
b
b
b
bb
b
b
b
Step 8
Place a cover strip (No. 9)
at each corner of the
building & x into position
using 3x30mm screws per
strip.
Fix the Door block (No.8) to the inside
of the door, ensuring its ush to
the door framing, secure using
2x30mm screws through the
door boards and into the door
block (No.8)
14x30mm Screws
Pre drill
hole
30mm
screw
9
Step 9
Parts Needed- No.9 QTY 4
- No.8 QTY 1
9
9
9
8
Fix the roof to the panels on each
side using 16x50mm screws. ensure
to go through the roof and into the
panel framing below
16x50mm screws
Step 7
Pre drill
hole
50mm
screw

P 6
Please retain product label and instructions for future reference
HANDLE
WITH CARE
12
3
4
Felt
tacks
Cut the felt (No.17) into three strips
of 1320mm and lay onto the as shown
in the illustration.
*Ensure there is approximatley
50mm of overhanging felt around
the building.
Fix the felt into place using felt tacks
at 100mm intervals.
100x Felt Tacks
17
Step 10
Parts Needed- No.17 QTY 1
Step 12
Parts Needed- No.10 QTY 4
- No.16 QTY 2
*If you have purchased a Greenhouse,
avoid this step move onto Step 13*
Fix the Fascias (No.10) onto the
front and back of the building
using 3x30mm screws per Fascia
Fix the She diamond nials (No.16)
onto the cover trims using 2x30mm
screws per nial, ensuring to go
through the fascias and into the
roof
16x30mm Screws
Pre drill
hole
30mm
screw
18
15
10
10
16
10
10
16
Step 11
Parts Needed- No.15 QTY 1
- No.18 QTY 2
Pre drill
hole
30mm
screw
Screw the Pad Bolt (No.15) on
to the door (No.4) and the
retainer to the door gable (No.1)
using 10x30mm screws. Make
sure that you screw into the
framing behind.
Fix the Turn Button (No. 18) onto
the Door Gable (No. 1) using
1x30mm screw for each one.
*These turn buttons help to
keep your doors straight
during high and low levels of
moisture content in the air.*
12x30mm Screws.
12
3

P 7
Please retain product label and instructions for future reference
It is ESSENTIAL that you apply wood treat-
ment immediately after the building has
been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back
**Please note: For greenhouse contents
please see instructions before beginning assembly.
Not every panel from the greenhouse will be used**

Please retain product label and instructions for future reference
Lay the base frames onto the base
as shown in the illustration.
*Ensure your framing is square
and is placed against the front
of the shed.
Secure the base frames together
at each corner using 8x70mm
screws - See greenhouse nail
bag.
8x70mm Screws
Pre drill
hole
70mm
screw
**Please note: This product can be installed with the shed
door either inside the building (internal) or outside (external).
Before beginning assembling, decide which conguration best
suits your needs and read through both sets of
instructions carefully.**
Instructions: Internal shed door option.
Window panel sizes:
4x6 Greenhouse = 1193mm
(8x6 Greenhouse with shed)
6x6 Greenhouse = 1776mm
(10x6 Greenhouse with shed)
8x6 Greenhouse = 1193mm
(12x6 Greenhouse with shed)
6x6 Greenhouse
(10x6 Greenhouse with shed)
8x6 Greenhouse
(12x6 Greenhouse with shed)
4x6 Greenhouse *Shown
(8x6 Greenhouse with shed)
Place the two small window panel
onto the base frame against the shed
and x into position using 50mm screws.
Ensure to screw through the window
panels into the framing underneath
-See greenhouse nail bag.
See greenhouse instructions
for installing glazing and for
screw quantities.
Pre drill
hole
50mm
screw
a
aa
a
a
aa
a
a
a
a
a
a
a
P 8
Step 12
Step 13
a

P 7
Please retain product label and instructions for future reference
Place the Door side panels onto the
base frame against the shed and x
into position using 50mm screws.
Ensure to screw through the window
panels into the framing underneath
-See greenhouse nail bag.
See greenhouse instructions
for installing glazing and for
screw quantities.
Pre drill
hole
50mm
screw
a
a
a
a
a
a
a
Attach the door gable top
to the front of the building as
shown in the illustration using
50mm screws - See greenhouse
nail bag.
See greenhouse instructions
for installing glazing and for
screw quantities.
50mm
screw
30mm
16mm
Roof sizes:
4x6 Greenhouse = 1217mm
(8x6 Greenhouse with shed)
6x6 Greenhouse = 1800mm
(10x6 Greenhouse with shed)
8x6 Greenhouse = 2385mm
(12x6 Greenhouse with shed)
6x6 Greenhouse
(10x6 Greenhouse with shed)
8x6 Greenhouse
(12x6 Greenhouse with shed)
4x6 Greenhouse *Shown
(8x6 Greenhouse with shed)
Place the window into the Roof
and secure with the Buttery
Hing into position using 6x16mm
screws and 6x30mm screws as
shown in the illustration
-See greenhouse nail bag.
See greenhouse instructions
for installing glazing and for
screw quantities.
Pre drill
hole
16mm
screw
30mm
screw
Pre drill
hole
a
a
a
Step 14
Step 15
Step 16
P 9

Please retain product label and instructions for future reference
P 8
P 7
Fix the casement stay to the
window using 20mm screws
as shown in the ilustration.
once in position secure the
pins to the roof framing with
20mm screws, ensuring the
stay and pins align and lock
the window - See greenhouse
nail bag.
See greenhouse instructions
for installing glazing and for
screw quantities.
Pre drill
hole
20mm
screw
Place the greenhouse roof frame(s)
against each window panel and
secure in place using 3x50mm screws
per frame, ensuring to screw
into each panel.
6x50mm Screws
Pre drill
hole
50mm
screw
Using the roof’s as a guide, mark the
position for the roof block at the top
of the shed door gable.
Once marked secure the block to the
gable using 1x70mm screw, making
sure to secure through the block into
the central upright on the door gable.
1x70mm Screws
Pre drill
hole
70mm
screw
Step 17
Step 18
Step 19
P 10
