**Protim Aquatan T5 (621)**
Your building has been dip treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct
application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.
Measure
under the
head
Measure
overall
length
Screws & Nails Bolts To identify the
xings required
for each step use a
measuring tape.
05DTOVPN0305DD-V1
DIP TREATED OVERLAP PENT 3X5 DOUBLE DOOR STORAGE
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All buildings should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips screw-
driver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for maintenance,
annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree causing
damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be
helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine
and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to prevent
the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof treat-
ment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm above
the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
For ease of assembly, you
will need a tape measure to
check dimensions of
components.
P 1
Please retain product label and instructions for future reference
General Instructions

P 2
05DTOVPN0305DD-V1
Overall Dimensions:
Width = 1429mm
Depth = 955mm
Height = 1419mm
Base Dimensions:
Width = 1395mm
Depth = 910mm
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Please retain product label and instructions for future reference
8
Door Strip - 7 x 45 x 1264mm QTY 2
S745-1264MM
9
Large Fascia - 7 x 60 x 1429mm QTY 1
S760-1429MM
10
Small Fascia - 7 x 60 x 945mm QTY 2
S760-945MM
12
13
Turn Button QTY 2
PI-07-0034
Hasp & Staple QTY 1
PI-07-0207
14
Felt
PI-01-0025
15
1
Front Panel QTY 1
AI-R11OVPPBSF1425X142-V1
Left Gable QTY 1
AI-05R11OVPGL915X1390-V1
2
Right Gable QTY 1
AI-05R11OVPGR915X1390-V1
3
Plain Panel QTY 1
AI-R11OVPP1425X1246-V1
4
Floor QTY 1
AI-R11OSBF1395X910-V1
5
Roof QTY 1
PI-03-0083
67
Door QTY 2
AIR11FBMBZBD665X1260-V1
11
Door Block - 28x28x140mm QTY 1
FS2828140MM
T-Hinge QTY 4
PI070021
50mm Screw x17
Felt Tacks x48
30mm Screw x63
Nail Bag
There may be extra screws present in the nail bag

P 3
Please retain product label and instructions for future reference
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
5
Place the oor (No.5) onto a rm and
level base.
Ensure the base has suitable drainage
& is free from areas where standing
water can collect.
Step 1
Parts Needed - No. 5 Qty 1
IMPORTANT: Pre-drill before xing screws.
Place the plain panel (No.4) and the right
gable (No.3) onto the oor and secure
at the corner with 3x50mm screws.
Do not secure the building to the
oor until the roof is tted.
3x50mm Screws
Pre drill
hole
50mm
screw
a
a
a
a
4
3
Step 2
Parts Needed - No. 4 Qty 1
- No. 3 Qty 1
IMPORTANT: Pre-drill before xing screws.
a
Place the left gable (No.2) onto the oor
and secure at the corner with
3x50mm screws.
Do not secure the building to the
oor until the roof is tted.
3x50mm Screws
Pre drill
hole
50mm
screw
a
a
2
a
a
IMPORTANT: Pre-drill before xing screws.
Step 3
Parts Needed - No. 2 Qty 1

P 4
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips screw-
driver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for maintenance,
annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree causing
damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can be
helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm sunshine
and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to prevent
the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof treat-
ment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm above
the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
Please retain product label and instructions for future reference
Fix the front panel (No.1) inbetween the gables,
securing into place with 4x50mm screws
from the inside of the building.
*Ensure to align the framing with the edge
of each gable.
4x50mm Screws
Pre drill
hole
50mm
screw
1
IMPORTANT: Pre-drill before xing screws.
Step 4
Parts Needed - No. 1 Qty 1
8
8
Attach the door strips (No.8) to either side of the
building using 3x30mm screws per strip.
*Ensure the strip sits fush to edge of the
framing and there is NO overhang inside
the building.
6x30mm Screws
Pre drill
hole
30mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 5
Parts Needed - No. 8 Qty 2
Parts Needed- No.12 QTY 4
No.7 QTY 2
Fix the T Hinges (No.12) onto the
doors (No.7) as shown. Ensure that
the screws go through the cladding
and into the framing behind.
16x30mm screws
30mm
screw
Pre drill
hole
Step 6
12
12
12
7
7
12
IMPORTANT: Pre-drill before xing screws.
Step 7
7
7
12
Fix the Doors (No.7) to the Door strips
(No.8) with 30mm screws ensuring
the screws are located into the framing.
Leave a 2mm gap in between the
doors and the building.
Pre drill to avoid splitting
12x30mm Screws
30mm
screw
Pre drill
hole

P 5
6
Place the roof sheet (No.6) on top of the building
and x into place with 10x30mm screws.
10x30mm Screws
Pre drill
hole
30mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 8
Parts Needed - No. 6 Qty 1
Once the roof is xed attach the
building to the oor with 50 mm
screws. Fix the panels onto the
oor using 50mm screws in
alignment with the oor joists.
7x 50mm Screws
Pre drill
hole
50mm
screw
b
b
IMPORTANT: Pre-drill before xing screws.
Step 9
Please retain product label and instructions for future reference
HANDLE
WITH CARE
12
3
4
Felt
tacks
Measure and cut the felt (No.15) to 1515mm
and lay onto the roof.
*Ensure there is approximately 50mm of
overhang around the building.
Fix the felt down using 48x felt tacks at 100mm
intervals.
48x Felt Tacks
Felt size: 1530mm
15
Step 10
Parts Needed - No. 15 Qty 1

P 6
Please retain product label and instructions for future reference
9
10
10
Pre drill
hole
30mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 11
Parts Needed - No. 10 Qty 2
- No. 9 Qty 1
Attach the large (No.9) and
small (No.10) fascias to the front
and sides of the building, xing
into place using 9x30mm screws.
9x30mm Screws
Step 12
30mm
screw
Pre drill
hole
Parts Needed- No.11QTY 3
Attach a Door Block (No. 11) to the
top of the secondary door (No.7)
using 2x30mm screws, in the posi-
tions illustrated. Screw through the
door cladding into the blocks.
2x30mm Screws
11
IMPORTANT: Pre-drill before xing screws.
Pre drill
hole
a
b
Step 13
Parts Needed - No. 13 Qty 2
- No. 14 Qty 1
Fix the turn button (No. 13) to
the left hand door block ensuring the
turn button catches the Front Panel
(No. 1) to secure the door use
1x30mm screw.
Fit the hasp and staple (No.14)
on to the doors centrally with 7x30mm
screws, making sure to screw into the
door framing.
8x30mm Screws
30mm
screw
14
b
13
a
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.

P 7




















































2





1












3
4














P 8



















¡




1




2























¡



