Mercia Garden Products Rose Instruction manual

02RSE0505-V2-PEFC
Rose Playhouse
In all instances for assistance with your product, please contact customer care on :
01636 880514 or [e-mail]
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE THE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed in the parts list provided.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a
Phillips screwdriver, Flathead screwdriver, Stanley knife, Wood saw, Step ladder, Hammer, Spirit level and
a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
- Ensure you have enough time to build the product to ensure the building is water tight.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration
of heavy or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may
also occur during excessive dry spells due natural processes. Unfortunately, these processes cannot be
avoided but can be helped. It is suggested that the outdoor building is sprayed with water during
extended periods of hot weather and sheltered as much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to prevent discolouration
whilst in stock. To validate your guarantee and ensure longevity of the product, it is ESSENTIAL the
building is treated with a suitable preservative in accordance with the manufacturers recommendations.
Care must be taken to ensure the product is placed on a suitable base.
We recommended using a suitable protection for your playhouse. As the product is destined for use by
children, a water based treatment that is EN71 tested for children is ESSENTIAL.
We also recommend treating the building prior to construction.
POSITIONING YOUR PLAYHOUSE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual treatment.
We recommend a minimum space of 2m around a playhouse, away from any structure or obstructions
such as fences, garages, houses, overhanging branches, washing lines or electrical wires.
It is recommended that the position of the Playhouse, Slide and Swing is not in direct sunlight.
Activity toys such as swings and slides for towers shall not be installed over concrete, asphalt or
any hard surface.
BUILDING A BASE
Ensure the base is level and is built on rm ground, to prevent distortion, checking with a spirit level.
Refer to diagrams for the base dimensions. The base should be slightly smaller than the external
measurement of the building, i.e. The cladding should overlap the base, creating a run o for water. It is
also recommended that the oor be at least 25mm above the surrounding ground level to avoid
ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
- Wooden base.
CAUTION
Wood is a natural product and can change post manufacture. So despite every eort being
made to ensure the material used are cut and machined to a clean and smooth nish, care
must be taken when handling the product and preparing for use by your child.
Any areas of concern, in the play areas, can be rubbed over with sandpaper to achieve a
smoother nish. Alternatively, call the customer service department who will be happy to
arrange replacement panels/parts.
WARNING
•ONLY SUITABLE FOR DOMESTIC USE.
• TO BE USED UNDER DIRECT SUPERVISION OF AN ADULT.
•THIS PRODUCT SHOULD NOT BE MODIFIED IN ANY WAY. ANY MODIFICATIONS SHOULD BE
DETERMINED BY THE MANUFACTURER AND CARRIED OUT ACCORDING TO THE INSTRUCTIONS.
• DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY COMPONENT PARTS PRIOR TO ASSEMBLY.
•MAX AGE OF 14 YEARS.
• THIS TOY IS FOR OUTDOOR USE ONLY.
• USE A WATER BASED TREATMENT THAT IS EN71 TESTED
!
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens products
independently tested to EN71, we cannot accept responsibility for your safety whilst erecting this product.
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All buildings should be erected by
atleast two adults.
DO NOT ALLOW
CHILDREN TO ASSIST.
To prevent damage during
assembly, you MUST pilot
drill all screw holes and
ensure all screw heads are
countersunk.
For ease of assembly, you will
need a tape measure to check
dimensions of components.
**Protim Aquatan T
Your building has been treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct application of
Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl sulphosuccinat and
alcohols: 2, 4, 6-trichlorophenol.
WARNING: Only for domestic use
Not suitable for children under 36 months due to
small parts and danger of falling from heights.
To be used under direct supervision of an adult
www.merciagardenproducts.co.uk P1
2mm Drill bit
12mm CSK

02RSE0505-V2
Overall Dimensions:
Width = 1504mm
Height =1275mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Door Gable
AI-02RSE0505-V2DG
50kg per user
DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY COM-
PONENT PARTS PRIOR TO ASSEMBLY. www.merciagardenproducts.co.uk P2
2
134
578
69
Plain Gable
AI-02RSE0505-V2DG
Right Window Side
AI-02RSE0505-V2RWS
Left Window Side
AI-02RSE0505-V2LWS
Door
AI-02RSE0505-V2D
Floor Sheet
OSB8 1470mm-1210mm
Roof Sheet
OSB8-1544x796mm
QTY x2
Window Styrene
STY2-405x394mm
QTY x3
Window Cross
PI-04-0013
QTY x3
10
12
Ridge Bar - 28x28x1220mm FS2828-1220mm
Eaves Frame - 28x28x1544mm FS2828-1544X796mm QTY x2
Floor Joist - 28x28x1210mm FS2828-1210mm QTY x5
Fascia - 40x12x790mm S1240-790mm QTY x4
11
13
15
Cover Trims- 40x12x1119mm S1240-1119mm QTY x2
14
Fascia Block - 28x28x400mm FS2828-440mm (2x9 DEG CUTS FINISHED 400mm)
Door Flower
Wooden Door
Handle
Hinge QTY 2
Finial QTY 2
Felt
16 17 18
Beading Block
QTY 12
19 20 21
1!
Look for the symbols and follow the safety guidlines below.
Ensure screw heads
are subush and
sand down any
splinters created.
Ensure the screws are
xed squarely and do
not protrude.
12mm gap
surrounding the
door.
2! 3!
50kg

Please retain product label and instructions for future reference
Please retain product label and instructions for future reference
DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY
COMPONENT PARTS PRIOR TO ASSEMBLY. www.merciagardenproducts.co.uk P3
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
30mm Screw x66
50mm Screw x28
60mm Screw x2
40mm Screw x34
Felt Tacks x60
10mm Screw x4
30mm Black Screw x 16
Nail Bag

17
15
12
6
Please retain product label and instructions for future reference
Step 3
Parts needed - &
Lay the oor joists (No.12)
under the oor sheet (No.6)
with an even space between
each one. Position the joists
ush on one side of the oor
sheet and mark the centers of
joists onto either end . Fix using
4x30mm screws per joist.
Repeat the screws positions along
each line
Place the oor (No.6) on your
rm and level base, ensure base
has suitable drainage free from
areas where standing water can
collect. (See front page on base
requirements).
20 x 30mm Screws
Please retain product label and instructions for future reference
DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY
COMPONENT PARTS PRIOR TO ASSEMBLY. www.merciagardenproducts.co.uk P4
Step 1
Remove transportation blocks from
the bottom of each panel before
beginning assembly. Each Panel
should have two blocks.
Step 2
Parts needed - & &
Lay the door gable (No.1) face up on a
at surface, place the door within the
door aperture. Position the door (No.5)
so that you have an equal 12mm gap at
either side and at the top of the door.
Once you are happy the door is in the
correct position place a hinge (No.17) at
the top and bottom of the door, ensur-
ing the screws will go into the framing
(in cases where you have been supplied
three hinges use the third in the middle
of the door) and using 30mm black
screws x the hinge to the door and the
door gable. Ensure to pre-drill the holes
rst.
30mm Black Screw x 14
17
30mm
screw
1
5
30mm
screw
b
a
6
12
12mm
12mm
1! 2!
Pre drill
hole
3!
1! 2!
Pre drill
hole
1! 2!
a
b

Please retain product label and instructions for future reference
Please retain product label and instructions for future reference
DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY
COMPONENT PARTS PRIOR TO ASSEMBLY. www.merciagardenproducts.co.uk P5
Step 4
Parts needed - &
Attach the Plain Gable(No.2) to
the Left Window Side (No.4)
together with 3x50mm screws as
shown in the diagram.
DO NOT SECURE THE BUILDING
TO THE FLOOR UNTIL AFTER
THE ROOF HAS BEEN FITTED.
Position the panels so there are
equal gaps between the oor
and cladding.
3x50mm screws
50mm
screw
4
2
3
Step 5
Parts needed - &
Attach the Door gable (No.1) to the
Right Window Side (No.3) from the
inside (same as the previous step)
with 3x50mm screws per corner.
DO NOT SECURE THE BUILDING TO
THE FLOOR UNTIL AFTER THE ROOF
HAS BEEN FITTED.
Position the panels so there are
equal gaps between the oor
and cladding.
9 x 50mm screws
50mm
screw
1
1
3
Step 6
Parts needed - & &
Place the Ridge Bar (No.10) in
between the front and back
panels (No.1 & 2). Ensure the
framing sits ontop of the central
upright on both gables (see
illustration). Secure in place with a
screw through the gable into the
ridge bar.
2x30mm screws
30mm
screw
10
1 102
1
7
40mm
screw
30mm
screw
Step 7
Parts needed - &
Fix a eaves frame (No.11) to
each roof sheet (No.7) using
5x30mm screws per eave.
Position the roof sheets on
the building ensuring the
roof sheet sits ush with the
building at the back and x
using 10x40mm screws per
sheet.
10x30mm screws
20x40mm screws
711
1! 2!
Pre drill
hole
1! 2!
Pre drill
hole
1! 2!
Pre drill
hole
1! 2!
Pre drill
hole
2
4
6
2
11
7

P 6
Please retain product label and instructions for future reference
DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY
COMPONENT PARTS PRIOR TO ASSEMBLY.
Please retain product label and instructions for future reference
Step 8
Parts needed -
Fix the panels to the oor (No.6)
using 50mm screws as shown in
the illustration.
Fix the panels to the oor with
3x50mm screws per panel as in
the diagram.
14x50mm screws
50mm
screw
Step 9
Parts needed - &
Fit the fascia block (No.13) to
the front of the building using
4x30mm screws, make sure it is
ush with the outside edge of
each roof sheet (No.7).
4x30mm screws
30mm
screw
137
Step 10
Parts needed -
At the back of the building, x the
two cover trims (No.14) to either
end of the side panels. Use
3x30mm screws per trim.
6x30mm screws
30mm
screw 14
14
Step 11
Parts needed - &
Cut the felt (No.21) into 3 sheets
at 1644mm and lay onto the roof
(No.7) as shown in the diagram
ensuring there is a 50mm
overhang around the sides.
Fix using felt tacks at 100mm
intervals.
60 x Felt Tacks
Felt
tacks
1! 2!
21
7
14
6
7
13
7
21
1! 2!
Pre drill
hole
1! 2!
Pre drill
hole
1! 2!
Pre drill
hole
21

P 7
Please retain product label and instructions for future reference
DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY
COMPONENT PARTS PRIOR TO ASSEMBLY.
Step 12
Parts needed - &
Fix the fascias (No.13) and
nials (No.16) using 40mm
screws. Pre drill holes to
avoid splitting. Ensure to
the trap the felt between
the fascia and building.
12x40mm screws
40mm
screw
13
13
13 16
13
16
16
13
20
8
9
Step 13
Parts needed - &
Place the styrene (No.8) in each
window aperture ensure you
remove the lm from both
sides of the styrene before
tting, then place the window
cross (No.9) over the top of the
styrene.
To x the styrene and window
cross in place x a beading
block (No. 20) centrally to the
framing above, below, to the
left and right of the window
with 30mm screws.
24x30mm screws
9
8
30mm
screw
1! 2!
Pre drill
hole
1! 2!
Pre drill
hole

AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back
P 8
Please retain product label and instructions for future reference
DO NOT ALLOW YOUR CHILD TO PLAY WITH ANY
COMPONENT PARTS PRIOR TO ASSEMBLY.
Step 14
Parts needed - & &
Place the wooden door handle (No.18)
on the outside of door (No.5) and use a
60mm screw from the inside to secure.
Pre drill hole rst to avoid splitting.
Sandwich the door styrene between the
door cut out and door ower (No.19),
then x using 3 x 10mm screws. Ensure
the glazing covers the cut out and the
screws do not crack the glazing.
Apply Clear Silicone Sealant (not
supplied) around the outside of the
windows.
3x10mm screws
1x60mm screw
10mm
screw
60mm
screw
It is ESSENTIAL that you apply wood treat-
ment immediately after the building has
been assembled.
SILICONE
SEALANT
1918
5
19
5
1! 2!
Pre drill
hole
18
Playhouse Maintenance:
It is recommended that the following checks and maintenance are carried out at the begin-
ning of each season as well as at regular intervals during the usage season.
- Check all nuts /bolts/ screws for tightness and tighten when required.
- Check for movement / opening of wood giving rise to protrusion of nail heads and tips.
- Check hinges.
- Replace defective parts in accordance with the manufacturers instructions.
- Check any crossbeams, suspensions and anchors.
- If a swing is included; check the swing seat, chains and ropes.
IF THESE CHECKS ARE NOT CARRIED OUT THE ACTIVITY TOY COULD BECOME A HAZARD
