Mercia Garden Products 01DTPRMSHPN0804SDOW-V1 User manual







 

 




                 



             







  



2mm Drill bit
x2 


































           






















                



 

















































ANY QUESTIONS?
Scan the QR code to
contact us via our customer
portal.
PLEASE SCAN HERE:


 

8
Some steps within this set of instructions come with an added video guide for your
convenience. These can be accessed via the QR code and used to aid you in constructing that
step. See below for how to use.
You can also nd all the videos on our youtube channel:
https://www.youtube.com/@merciagardenproducts8716/videos
ACCESSING VIDEO GUIDES...
1.Find the QR code within the instruction step...
2. Open camera app...
3. Scan QR code...
4. Watch the video...
On your personal smart device (phone, tablet etc), open your camera app or QR code scanner
app.
To scan the QR code, hold the camera over the QR code so that it can be seen on the screen.
Once the QR code has been registered, follow the prompts on your device to open the video.
(This will vary depending on your device.)
Please note: Ensure to use the back camera of your smart device as this will scan the QR code more
accurately.

The video guide will now be displayed on your smart device.
Parts Needed- No. QTY 1
No. QTY 1
No. QTY 1
Step..... 
Within the instruction step, there will be an icon in the top right that has a QR code in. This
is where the video can be accessed from.
Please note: not every step has a video guide.
Disclaimer: The garden building constructed in the video guides may be
constructed dierently to your building. Please ensure to read your instructions
carefully to avoid error.
ACCESSING VIDEO GUIDES...

 

Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Overall Dimensions:
Width = 2550mm
Depth = 1322mm
Height = 2130mm
Base Dimensions:
Width = 2442mm
Depth = 1174mm
See back of instructions
for 8x8 Combi shed and
greenhouse assembly 1 2 34
567 8
9
Gable Top Left QTY 1
AI-S21SHPGTL1180X304-V1
Plain Panel QTY 3
AI-S21SHPPTF1180X1801-V1
Panel Top QTY 2
AI-S21SHPP1180X251-V1
Window Panel QTY 2
AI-01S21SH1LFW1180X1801-V1
Door Panel QTY 1
AI-01S21SHSD1180X1801-V1
Gable Top Right QTY 1
AI-S21SHPGTR1180X304-V1
Roof Panel QTY 2
AI-S21MBPR1263X1322-V1
Floor Panel QTY 2
AI-R11MBF1221X1175-V1
Building Content:
Door QTY 1
AI-S21FBMBZBD743X1683-V1
10
Window QTY 2
AI-FW1000X540-V1
Assembly options:
This building is modular. The side panels are all interchangeable and can be
positioned in a variety of congurations, some of which are shown below.
Decide which assembly works best before beginning construction.
Assemblies shown throughout the instructions are for illustrative purposes.
Door on the right, both
windows on the front.
Door on the left, both
windows on the front.
Door on the front, one
window on the front, one
window on the side.
Green Label
Blue Label

 

11
12
13
Large Cover Trim - 12x55x2025mm QTY 3
S1255-2025MM
Small Cover Trim - 12x55x1793mm QTY 3
S1255-1793MM
Large Fascia - 12x55x1340mm QTY 2
S1255-1340MM
Small Fascia - 12x55x1263mm QTY 4
S1255-1263MM
14
17
Felt
PI-01-0015
Pad bolt QTY 1
PI-07-0035
18
19
T Hinge QTY 3
PI-07-0021
20
Turn Button QTY 2
PI-07-0034
22
21
Butt Hinge QTY 4
PI-07-0066
Casement Stay QTY 2
PI-07-0007
Floor Block - 28x28x400mm QTY 3
F2828-400MM
15
Window Strip - 12x56x1038mm QTY 2
S1256-1038mm
16
Nail Bag
There may be extra screws present in the nail bag
30mm Screw x 84
50mm Screw x 61
70mm Screw x 28
40mm Screw x 24
Felt Tacks x 100
20mm Screw x 6
16mm Screw x 12
Pre Assembly
Before assembling remove the transportation blocks from the bottom of each panel.
Take care removing the blocks as to not damage the panels. Tap with a at headed
screwdriver and hammer.
Dispose of the blocks once removed.
PLEASE SCAN HERE:

 

Step 1
Parts needed - No. 3 QTY 1
No. 9 QTY 1
No. 19 QTY 3
Locate the Door (No.9) into the Door Panel (No.3)
ensuring there is equal spacing on each side.
Locate the T-Hinges (No.19) onto the door (No.9)
and Door Panel (No.3), ensuring to line them up
with the door blocks on the back of the door.
Please note: Ensure to x your hinges in accordance
with what side you want the door to open on.
Secure in place using 7x30mm screws per
T-hinge.
21x30mm screws.
Pre drill
hole
30mm
screw
3
19
9
19
19
19
Opens from the Left Opens from the Right
**PLEASE NOTE** Before tting the hinges,
ensure the door is in the correct position
depending on which side you want the door to
open. See external illustrations below which
show the doors internal framing.
IMPORTANT: Pre-drill before xing screws.
PLEASE SCAN HERE:
Step 2
Parts needed - No. 4 QTY 1
No. 15 QTY 3
Place the Floors (No. 4) on a rm and level
base, ensure base has suitable drainage free
from areas where standing water can collect.
(See front page on base requirements).
Locate three Floor Blocks (No.15) between
the bearers of one Floor panel (No.4). Ensure
the blocks are spaced centrally between the
bearers and the end of the panel, as shown.
Fix in place using 2x30mm screws per block,
screwing through the Floor into the blocks,
as shown.
6x30mm screws.
4
15
15
15
Pre drill
hole
30mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 3
Parts needed - No. 4 QTY 1
Locate the second Floor (No.4) up against
the rst, ensuring they are level and ush.
Secure the oors together by screwing
through the second oor (No.4) into the
Floor blocks (No.15) below.
6x30mm screws.
Pre drill
hole
30mm
screw
4
4
IMPORTANT: Pre-drill before xing screws.

 

IMPORTANT: Pre-drill before xing screws.
Step 4
Parts needed - No. 1 QTY 1 (or QTY 2)
No. 2 QTY 1 (or QTY 2)
(Or No.3 QTY 1)
50mm
screw
Pre drill
hole
a
** Please note: The side panels are all
interchangeable and can be positioned in a
variety of congurations, Decide which
works best before assembly. Assemblies
shown are for illustrative purposes.
Place the Plain Panel (No.1) and the Window
Panel (No.2), or panels of your choice,onto
the oor. Fix the panels together at the
corner using 3x50mm Screws
Do not secure the building to the oor
until the roof has been tted.
Position the panels so there is equal
spacing between the oor and cladding on
all sides.
3x50mm screws.
1
2a
a
a
50mm
screw
Pre drill
hole
Step 5
Parts needed - No. 1 QTY 1 (or QTY 2)
No. 2 QTY 1 (or QTY 2)
(Or No.3 QTY 1)
Place the Plain Panel (No.1) and the
Window Panel (No.2), or panels of your
choice,onto the oor. Fix the panels
together using 3x50mm Screws
Do not secure the building to the oor
until the roof has been tted.
Position the panels so there is equal
spacing between the oor and cladding
on all sides.
6x50mm screws.
2a
a
a
1
a
IMPORTANT: Pre-drill before xing screws.
50mm
screw
Pre drill
hole
Step 6
Parts needed - No. 1 QTY 1
No. 3 QTY 1
(Or No.2 QTY 1)
Place the Plain Panel (No.1) and the
assembled Door Panel (No.3), or panels
of your choice,onto the oor, Fix the
panels together using 3x50mm Screws.
Do not secure the building to the
oor until the roof has been tted.
Position the panels so there is equal
spacing between the oor and
cladding on all sides.
9x50mm screws.
3
1a
a
a
a
a
a
a
a
a
a
IMPORTANT: Pre-drill before xing screws.

 

50mm
screw
Pre drill
hole
Step 7
Parts needed - No. 6 QTY 1
No. 7 QTY 1
Place the Gable Top Left (No. 6)
and Gable Top Right (No. 7) on
top of the end panels (No.1&3),
as shown.
Ensure the cladding on the
bottom of the Gables slots into
the cladding on the top of the
panels below.
Secure into position using
4x50mm screws per Gable top,
ensure to stagger screws to avoid
collision.
8x50mm screws.
7
6
7
IMPORTANT: Pre-drill before xing screws.
50mm
screw
Pre drill
hole
Step 8
Parts needed - No. 8 QTY 2
Locate the two Panel Tops (No.8) next to each
other as shown, ensuring they are ush and
level.
Secure the panels together using 3x50mm
screws in an alternating pattern.
3x50mm Screws
88
IMPORTANT: Pre-drill before xing screws.
50mm
screw
Pre drill
hole
Step 9
Parts needed - No. 8 QTY 2
Place the assembled Panel Top (No.8) on
top of the Plain Panels (No.1) on the side
of the building as shown.
Ensure the cladding on the bottom of
the Panel tops slots into the cladding on
the top of the panels below.
Secure into position using 4x50mm
screws per Panel Top, ensure to stagger
screws to avoid collision.
8x50mm screws.
8
8
8
IMPORTANT: Pre-drill before xing screws.

 

50mm
screw
Pre drill
hole
Step 10
Parts needed - No. 5 QTY 2
Locate the Roof Panels (No.5) on top of
the building, ensuring that the roof
overhang is at the top side of the
building, as shown.
Internally, secure the Roof Panels
together using 6x50mm screws in an
alternating pattern
6x50mm Screws
5
5
5
5
5
Internally
IMPORTANT: Pre-drill before xing screws. Step 11
Fix the Roofs (No.5) to the top of the
building, ensuring the side edges are
ush with the building and the roof is
overhanging at the back.
Using 18x70mm screws, x the Roofs
(No.5) around the edge and along the
framing, ensuring the screws go through
to the panel framing below.
18x70mm Screws
5
5
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
Step 12
Once the Roof has been secured to the
building, x the building to the oor.
Secure by screwing through the panel
framing into the oor bearers below using
3x50mm screws per panel.
18x50mm Screws
b
b
b
b
b
b
b
b
b
b
30mm
screw
Pre drill
hole

 

Step 13
Parts needed - No.10 QTY 2
No.16 QTY 2
No.21 QTY 4
16
Opening Window
Fixed Window
Pre drill
hole
16mm
screw
30mm
screw
Place the Window Strip (No.16) 11mm
above the window opening and x in
place with 3x30mm screws per strip.
6x30mm Screws
Opening Window
If you would like the window (No.10)
to be opening use the butt hinges
(No.21) to attach the window to the
Window Strip.
Fix the hinges to the Window Strip
using 30mm screws and 16mm to t
the hinges to the window frame.
12x16mm Screws
12x30mm Screws
Fixed Window
If you would like the window (No.10)
to be xed instead of opening, secure
the window to the panel using
4x30mm screws per window.
8x30mm Screws
Repeat chosen process for both
windows.
b
a
c
a
b
10
21
21
c
21
30mm
Screws
16mm
screws
IMPORTANT: Pre-drill before xing screws.
Felt
tacks
Step 14
Parts needed - No. 17 QTY 1
Cut the felt (No.17) into two sheets
measuring:
2646mm (L) x 1000mm (W).
Place the felt onto the roof, ensuring the
two sheets overlap by 100mm and there
is at least 50mm overhang on each side.
Fix onto the roof using felt tacks at
100mm intervals.
100 x Felt Tacks
17
100mm
1
2
HANDLE
WITH CARE
1 2
3
4
