Metabo HPT C 3612DRA Troubleshooting guide

Model
Modèle
Modelo C3612DRA
(LED Light Equipment)
(Équipement de la DEL
d'éclairage)
(Equipo de iluminación LED)
Cordless Slide Compound Miter Saw
Scie à coupe d’onglet radiale sans fil
Sierra ingletadora deslizante inalámbrica
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury!
This manual contains important information about product safety. Please read and understand
this manual BEFORE operating the power tool. Please keep this manual available for other
users and owners before they use the power tool. This manual should be stored in safe place.
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de cet outil motorisé peut entraîner la mort
ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce produit.
Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil motorisé. Garder ce
mode d’emploi à la disponibilité des autres utilisateurs et propriétaires avant qu’ils utilisent
l’outil motorisé. Ce mode d’emploi doit être conservé dans un endroit sûr.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede resultar
en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual para
que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este manual debe
ser guardado en un lugar seguro.
2023/08/31 19:12:24Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
2
IMPORTANT SAFETY INSTRUCTIONS
Read and understand all of the safety precautions, warnings and operating instructions in the Instruction Manual before
operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic safety
rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation before it occurs,
and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual and in the sections which
contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by WARNINGS on the power
tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by metaboHPT.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in minor or moderate injury, or
may cause machine damage.
NOTE emphasizes essential information.
MEANINGS OF SYMBOLS
Symbols
The following show symbols used for the machine. Be sure that you understand their meaning before use.
WARNING
To reduce the risk of injury, user must read
instruction manual.
WARNING
Always wear eye protection.
CAUTION
Do not stare at operating lamp. WARNING Always wear hearing protection.
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
3
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes, radiators,
ranges and refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool.
Keep cord away from heat, oil, sharp edges
or moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as a dust mask, non-
skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair and clothing
away from moving parts.
Loose clothes, jewellery or long hair can be
caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities,
ensure these are connected and properly
used.
Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent
use of tools allow you to become
complacent and ignore tool safety principles.
A careless action can cause severe injury within
a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or remove the battery pack, if
detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of
untrained users.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
4
e) Maintain power tools and accessories.
Check for misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power toolʼs
operation.
If damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed.
Use of the power tool for operations different
from those intended could result in a hazardous
situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by
the manufacturer.
A charger that is suitable for one type of battery
pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk
of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small
metal objects, that can make a connection
from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help.
Liquid ejected from the battery may cause
irritation or burns.
e) Do not use a battery pack or tool that is
damaged or modified.
Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire,
explosion or risk of injury.
f) Do not expose a battery pack or tool to fire
or excessive temperature.
Exposure to fire or temperature above 265°F may
cause explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the
instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified
repair person using only identical
replacement parts.
This will ensure that the safety of the power tool
is maintained.
b) Never service damaged battery packs.
Service of battery packs should only be
performed by the manufacturer or authorized
service providers.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach
of children and infirm persons.
SAFETY INSTRUCTIONS FOR MITER
SAWS
1. Miter saws are intended to cut wood or wood-like
products, they cannot be used with abrasive cut-
off wheels for cutting ferrous material such as
bars, rods, studs, etc.
Abrasive dust causes moving parts such as the lower
guard to jam. Sparks from abrasive cutting will burn
the lower guard, the kerf insert and other plastic parts.
2. Use clamps to support the workpiece whenever
possible. If supporting the workpiece by hand,
you must always keep your hand at least 100mm
from either side of the saw blade. Do not use this
saw to cut pieces that are too small to be
securely clamped or held by hand.
If your hand is placed too close to the saw blade,
there is an increased risk of injury from blade contact.
3. The workpiece must be stationary and clamped
or held against both the fence and the table. Do
not feed the workpiece into the blade or cut
"freehand" in any way.
Unrestrained or moving workpieces could be thrown
at high speeds, causing injury.
4. Push the saw through the workpiece. Do not pull
the saw through the workpiece. To make a cut,
raise the saw head and pull it out over the
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
5
workpiece without cutting, start the motor, press
the saw head down and push the saw through
the workpiece.
Cutting on the pull stroke is likely to cause the saw
blade to climb on top of the workpiece and violently
throw the blade assembly towards the operator.
5. Never cross your hand over the intended line of
cutting either in front or behind the saw blade.
Supporting the workpiece “cross handed” i.e. holding
the workpiece to the right of the saw blade with your
left hand or vice versa is very dangerous.
6. Do not reach behind the fence with either hand
closer than 100mm from either side of the saw
blade, to remove wood scraps, or for any other
reason while the blade is spinning.
The proximity of the spinning saw blade to your hand
may not be obvious and you may be seriously injured.
7. Inspect your workpiece before cutting. If the
workpiece is bowed or warped, clamp it with the
outside bowed face toward the fence. Always
make certain that there is no gap between the
workpiece, fence and table along the line of the
cut.
Bent or warped workpieces can twist or shift and may
cause binding on tile spinning saw blade while
cutting. There should be no nails or foreign objects in
the workpiece.
8. Do not use the saw until the table is clear of all
tools, wood scraps, etc., except for the
workpiece.
Small debris or loose pieces of wood or other objects
that contact the revolving blade can be thrown with
high speed.
9. Cut only one workpiece at a time.
Stacked multiple workpieces cannot be adequately
clamped or braced and may bind on the blade or shift
during cutting.
10. Ensure the miter saw is mounted or placed on a
level, firm work surface before use.
A level and firm work surface reduces the risk of the
miter saw becoming unstable.
11. Plan your work. Every time you change the bevel
or miter angle setting, make sure the adjustable
fence is set correctly to support the workpiece
and will not interfere with the blade or the
guarding system.
Without turning the tool “ON” and with no workpiece
on the table, move the saw blade through a complete
simulated cut to assure there will be no interference
or danger of cutting the fence.
12. Provide adequate support such as table
extensions, saw horses, etc. for a workpiece that
is wider or longer than the table top.
Workpieces longer or wider than the miter saw table
can tip if not securely supported. If the cut-off piece or
workpiece tips, it can lift the lower guard or be thrown
by the spinning blade.
13. Do not use another person as a substitute for a
table extension or as additional support.
Unstable support for the workpiece can cause the
blade to bind or the workpiece to shift during the
cutting operation pulling you and the helper into the
spinning blade.
14. The cut-off piece must not be jammed or pressed
by any means against the spinning saw blade.
If confined, i.e. using length stops, the cut-off piece
could get wedged against the blade and thrown
violently.
15. Always use a clamp or a fixture designed to
properly support round material such as rods or
tubing.
Rods have a tendency to roll while being cut, causing
the blade to "bite" and pull the work with your hand
into the blade.
16. Let the blade reach full speed before contacting
the workpiece.
This will reduce the risk of the workpiece being
thrown.
17. If the workpiece or blade becomes jammed, turn
the miter saw off. Wait for all moving parts to
stop and disconnect the plug from the power
source and/or remove the battery pack. Then
work to free the jammed material.
Continued sawing with a jammed workpiece could
cause lass of control or damage to the miter saw.
18. After finishing the cut, release the switch, hold
the saw head down and wait for the blade to stop
before removing the cut-off piece.
Reaching with your hand near the coasting blade is
dangerous.
19. Hold the handle firmly when making an
incomplete cut or when releasing the switch
before the saw head is completely in the down
position.
The braking action of the saw may cause the saw
head to be suddenly pulled downward, causing a risk
of injury.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
6
SPECIFIC SAFETY RULES FOR USE OF
THIS POWER TOOL
WARNING
The following specific operating instructions
must be observed when using this POWER TOOL
in order to avoid injury:
DO’s
ALWAYS OBSERVE THE FOLLOWING RULES TO
ASSURE SAFE USE OF THIS TOOL:
1. Review this Manual and familiarize yourself with the
safety rules and operating instructions for this
POWER TOOL before attempting to use it.
2. Remove all packing materials attached or connected
to the tool before attempting to operate it.
3. Always confirm that the POWER TOOL is clean
before using it.
4. Always wear snug-fitting clothing, non-skid footwear
(preferably with steel toes) and eye protection when
operating the POWER TOOL.
5. Always handle the POWER TOOL carefully. If the
POWER TOOL falls or strikes against a hard object, it
might become deformed or cracked or sustain other
damage.
6. Always cease operating the saw at once, if you notice
any abnormality whatsoever.
7. Always confirm that all components are mounted
properly and securely before using the tool.
8. When replacing the saw blade, always confirm that
the rpm rating of the new blade is correct for use on
this tool.
9. Always shut off the power and wait for the saw blade
to completely stop rotating before doing any
maintenance or adjustments.
10. During slide cutting, always push the saw blade away
from the operator.
11. Always clamp or otherwise secure the workpiece to
the fence; otherwise the workpiece might be thrust
form the table and cause bodily harm.
12. During miter or bevel cutting, always wait for the
rotation of the blade to stop completely before lifting
the saw blade.
13. Always make a trial run first before attempting any
new use of the saw.
14. Always handle the saw blade with care when
dismounting and mounting it.
15. Always confirm that the workpiece is free of nails or
other foreign objects before beginning a cut.
16. Always keep your hands out of the path of the saw
blade.
17. Always confirm that the lower guard is in the proper
place before using the saw.
18. Always confirm that the lower guard does not obstruct
the sliding motion of the saw before attempting slide
cutting.
19. Inspect the tool power cords periodically.
20. Always confirm that the proper lengths and types of
extension cords are being utilized, if necessary,
before starting the tool.
21. Always confirm that the motor air vents are fully open
before using the tool.
22. Always wait until the motor has reached full speed
before starting a cut.
23. Always keep the handles dry, clean and free of oil and
grease. Hold the tool firmly when in use.
24. Always use outboard stands to provide support for
long workpieces that overhang the table of the slide
compound miter saw.
25. Always operate the tool after ensuring the workpiece
is fixed properly with a vise assembly.
26. The operating instructions provided with the tool shall
direct the user to secure the tool to supporting
structure if, during normal operation, there is a
tendency for the tool to tip over, slide, or walk on the
supporting surface.
27. Ensure before each cut that the machine is stable.
28. If the saw blade should become jammed, switch the
machine off and hold the workpiece until the saw
blade comes to a complete stop. To prevent
kickback, the workpiece may not be moved until after
the machine has come to a complete stop.
Correct the cause for the jamming of the saw blade
before restarting the machine.
29. Use only saw blades that are marked with a maximum
permitted speed equal or higher than the no-load
speed marked on the POWER TOOL.
30. Use only a saw blade diameter in accordance with the
markings on the POWER TOOL.
31. Replace the table insert when worn.
DON’Ts
NEVER VIOLATE THE FOLLOWING RULES TO
ASSURE SAFE USE OF THIS TOOL:
1. Never operate the POWER TOOL unless you fully
understand the operating instructions contained in
this Manual.
2. Never leave the POWER TOOL unattended without
first removing the battery from the main body.
3. Never operate the POWER TOOL when you are tired,
after you have taken any medications, or have
consumed any alcoholic beverages.
4. Never use the POWER TOOL for applications not
specified in the instruction manual.
5. Never operate the tool while wearing loose clothing, a
necktie or jewelry, or while your hair is uncovered, to
protect against getting caught in the moving
machinery.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
7
6. Never reach around the saw blade.
7. Never touch any moving parts, including the blade,
while the saw is in use.
8. Never remove any safety devices or blade guards;
use of the tool without them would be hazardous.
9. Never lock the lower guard; always confirm that it
slides smoothly before using the tool.
10. Never attempt to move a plugged-in or battery-in
POWER TOOL while your finger is on the starting
switch.
11. Never use the POWER TOOL if the starting switch
does not turn on and off properly.
12. Never use the POWER TOOL if the plastic housing or
the handle is cracked or deformed.
13. Never use the POWER TOOL near flammable liquids
or gases because sparking can cause an explosion.
14. Never clean plastic components with solvents
because the plastic may dissolve.
15. Never operate the saw unless all the blade guards are
in place.
16. Never raise the saw blade from the workpiece until it
has first come to a complete stop.
17. When slide cutting, never pull the handle toward the
operator, since this could cause the saw blade to kick
up from the workpiece. Always push the handle away
from the operator in a single, smooth motion.
18. Never place your limbs inside of the line next to
warning sign “ ” while the tool is being operated.
This may cause hazardous conditions.
19. Never use abrasive type blades on this saw.
20. Never expose to rain or use in damp locations.
21. Never cut ferrous metals or masonry.
22. Do not replace the LED light with a different type.
23. Do not stand in a line with the saw blade In front of the
machine. Always stand aside of the saw blade. This
protects your body against possible kickback. Keep
hands, fingers and arms away from the rotating saw
blade.
24. Do not cross your arms when operating the tool arm.
25. When the saw head is in the down position, never
release the hand that is gripping the handle.
Doing so could snap the saw head up, forcing the tool
to fall and possibly cause injury.
WARNING
FOR YOUR OWN SAFETY READ THIS INSTRUCTION
MANUAL BEFORE OPERATING THE CORDLESS
SLIDE COMPOUND MITER SAW
1. Make sure to securely hold the tool during operation.
Failure to do so can result in accidents or injuries.
(Fig. 1)
Fig. 1
2. Always wear eye protection when using the slide
compound miter saw.
3. Always keep hands out of the path of the saw blade.
4. Never operate the saw without the guards in place.
5. Never perform any freehand operation with the slide
compound miter saw.
6. Never reach around the saw blade.
7. Always turn off tool and wait for saw blade to stop
before moving workpiece or changing settings.
8. Always disconnect the battery before changing blade
or servicing.
9. Saw blade diameter is 12" (305mm).
10. No load speed is 4,000 /min (Auto Switch mode) /
3,200 /min (High Torque mode).
11. To reduce the risk of injury, return carriage to the full
rear position after each crosscut operation.
12. Do not use the product if the tool or the battery
terminals (battery mount) are deformed.
Installing the battery could cause a short circuit that
could result in smoke emission or ignition.
13. Keep the tool’s terminals (battery mount) free of swarf
and dust.
○ Prior to use, make sure that swarf and dust have not
collected in the area of the terminals.
○ During use, try to avoid swarf or dust on the tool from
falling on the battery.
○ When suspending operation or after use, do not leave
the tool in an area where it may be exposed to falling
swarf or dust.
Doing so could cause a short circuit that could result
in smoke emission or ignition.
14. Always use the tool and battery at temperatures
between 23°F (-5°C) and 104°F (40°C).
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
8
15. Definitions for symbols used on this tool
V.......................................................................... volts
A ................................................................... amperes
Hz ....................................................................... hertz
W.......................................................................... watt
or DC ................................................ direct current
or AC...................................... alternating current
n0
......................................................... no load speed
---/min............. revolutions or reciprocation per minute
min ................................................................. minutes
REPLACEMENT PARTS
When servicing use only identical replacement parts.
Repairs should be conducted only by a metaboHPT
authorized service center.
IMPORTANT SAFETY INSTRUCTIONS FOR
CHARGER OR ADAPTER
The term “charger or adapter” in the safety instructions
refers to your battery charger or AC/DC adapter.
WARNING
Death or serious bodily injury could result from
improper or unsafe use of charger or adapter. To
avoid these risks, follow these basic safety
instructions:
READ ALL INSTRUCTIONS
1. This manual contains important safety and operating
instructions for battery charger Model UC18YSL3 or
AC/DC adapter Model ET36A.
2. Before using charger or adapter, read all instructions
and cautionary markings on (1) charger or adapter,
(2) battery, and (3) product using battery.
3. When charging the battery with a battery charger,
reduce the risk of injury by charging metaboHPT
rechargeable battery multi volt type series and
BSL18series. Other type of batteries may burst
causing personal injury and damage.
4. Do not expose charger or adapter to rain or snow.
5. Use of an attachment not recommended or sold by
the charger or adapter manufacturer may result in a
risk of fire, electric shock, or injury to persons.
6. To reduce risk of damage to electric plug and cord,
pull by plug when disconnecting charger or adapter.
7. Make sure cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage or stress.
8. An extension cord should not be used unless
absolutely necessary. Use of improper extension cord
could result in a risk of fire and electric shock.
If extension cord must be used make sure:
a. That blades of extension cord are the same
number, size, and shape as those of plug on
charger or adapter:
b. That extension cord is properly wired and in good
electrical condition; and
c. That wire size is large enough for AC ampere
rating of charger or adapter as specified in
Table1.
Table 1: RECOMMENDED MINIMUM AWG SIZE FOR
EXTENSION CORDS FOR CHARGER OR ADAPTER
AC Input Rating
Amperes *1AWG Size of Cord
Equal to
or
greater
than
but less
than
Length of Cord, Feet (Meter)
25
(7.5) 50 (15) 100 (30) 150 (45)
0
2
3
2
3
4
18
18
18
18
18
18
18
16
16
16
14
14
*1 If the input rating of a charger or adapter is given in
watts rather than in amperes, the corresponding
ampere rating is to be determined by dividing the
wattage rating by the voltage rating–for example:
1,250 watts
125 volts =10 amperes
9. Do not operate charger or adapter with damaged cord
or plug-replace them immediately.
10. Do not operate charger or adapter if it has received a
sharp blow, been dropped, or otherwise damaged in
any way; take it to a qualified serviceman.
11. Do not disassemble charger or adapter; take it to a
qualified serviceman when service or repair is
required. Incorrect reassembly may result in a risk of
electric shock or fire.
12. To reduce risk of electric shock, unplug charger or
adapter from receptacle before attempting any
maintenance or cleaning. Removing the battery will
not reduce this risk.
13. This AC/DC adapter is for use only with specific tools,
including C3612DRA. The adapter might be suitable
for use with other metaboHPT battery operated tools.
It is necessary to confirm suitability by referencing the
instruction manual of the specific tool or by consulting
our web site https://www.metabo-hpt.com/. Failure to
confirm suitability before using the adapter with
specific tools could result in fire hazard.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
9
IMPORTANT SAFETY INSTRUCTIONS FOR
USE OF THE BATTERY AND CHARGER OR
ADAPTER
You must charge the battery before you can use the
power tool. Before using the model UC18YSL3 battery
charger, be sure to read all instructions and cautionary
statements on it, the battery and in this manual.
WARNING
USE ONLY metaboHPT BATTERIES. OTHER
MODELS OF BATTERIES MAY BURST AND
CAUSE INJURY!
Follow these instructions to avoid the risk of injury:
WARNING
Improper use of the battery or battery charger
can lead to serious injury. To avoid these
injuries:
1. NEVER disassemble the battery or AC/DC adapter.
2. NEVER incinerate the battery or AC/DC adapter,
even if it is damaged or is completely worn out. The
battery can explode in a fire.
3. NEVER short-circuit the battery or AC/DC adapter.
4. NEVER insert any objects into the charger or
adapter’s air vents. Electric shock or damage to the
charger or adapter may result.
5. NEVER use outdoors. Keep the battery or AC/DC
adapter away from direct sunlight and use only where
there is low humidity and good ventilation.
6. NEVER charge when the temperature is below 14°F
(-10°C) or above 104°F (40°C). (UC18YSL3)
NEVER use when the temperature is below 14°F
(-10°C) or above 104°F (40°C). (ET36A)
7. NEVER connect two charger or adapter together.
8. NEVER insert foreign objects into the hole for the
battery or the charger or adapter.
9. NEVER use a booster transformer.
10. NEVER use DC power.
11. NEVER store the battery or charger or adapter in
places where the temperature may reach or exceed
104°F (40°C) such as inside metal box or car.
12. NEVER expose the battery or charger or adapter to
rain or wet conditions.
13. ALWAYS operate charger or adapter on standard
household electrical power (120 volts). Using the
charger or adapter on any other voltage may overheat
and damage the charger.
14. ALWAYS wait at least 15 minutes between charges
to avoid overheating the charger. (UC18YSL3)
15. ALWAYS disconnect the power cord from its
receptacle when the charger or adapter is not in use.
[The information below applies only to ET36A]
16. Do not use the product if the tool or the AC/DC
adapter terminals (AC/DC adapter mount) are
deformed. Installing the AC/DC adapter could cause
a short circuit that could result in smoke emission or
ignition.
17. Keep the tool’s terminals (AC/DC adapter mount) free
of swarf and dust.
○ Prior to use, make sure that swarf and dust have not
collected in the area of the terminals.
○ During use, try to avoid swarf or dust on the tool from
falling on the AC/DC adapter.
○ When suspending operation or after use, do not leave
the tool in an area where it may be exposed to falling
swarf or dust.
Doing so could cause a short circuit that could result
in smoke emission or ignition.
18. The product is intended for Use in Pollution Degree 2
or PD2 environments. Operate only in areas of non-
conductive pollution. A temporary conductivity
caused by condensation is normally expected.
19. This is a precision machine so do not drop or expose
to impact.
20. Do not use this product near a pacemaker or other
similar implanted device, which may be affected by a
magnetic field produced by this product.
21. The adapter, power supply box and the inside of the
DC cord generates a boosted high voltage of 380V
so please be careful of the following.
○ Do not disassemble the product.
○ Do not drop or expose to impact.
In the event the product is damaged from strong
impact, do not use the product.
○ Do not use the product in areas exposed to rain,
snow, iron powder or wet condition.
○ Do not touch the product with wet hands.
○ Do not spill or pour liquid onto the product.
○ Do not pull the cord with excessive force.
○ Use the product in a well-ordered work environment.
CAUTION
1. When the mesh of the vent is plugged by objects
such as wood shavings, try to keep the objects out
when you clear the mesh.
(If not properly maintained, the temperature protective
feature could shut the product off )
2. When the temperature protective feature frequently
cuts the power off , do not overload the machine with
continued work, but let the machine rest for a little
before continuing operation.
3. The machine does get hot. However, this does not
indicate an abnormality.
Keep the electricity running and operate the internal
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
10
fan to cool the machine before carrying it elsewhere.
When carrying the product, the case may be hot so
please be careful.
4. During use, do not pull the cord to move the Box.
Doing so may result in damage.
5. Do not use more that a single cord reel of 30 meters.
Doing so may result in damage.
6. During use, if the machine stops running after the
Box’s LED lamp blinks, confirm the power supply
environment.
7. Do not drag the cord when using or carrying the
machine.
Doing so may tear the cord insulation or break the
cord which could result in electric shock.
8. Do not stretch the cord out any more than required.
When using tools such as gardening clippers or
circular saws, always make sure of the power cord’s
position to avoid cutting the cord during operation.
9. To use the AC/DC adapter after it shuts down due to
high temperature, disconnect the box’s power plug,
wait for the LED lamp to go out and then reconnect
the box’s power plug.
If the machine cuts off even after sufficiently cooling it
off with the built-in fan, discontinue use as there may
be a problem with the machine.
10. Do not use this product near a radio. Doing so could
cause noise from the radio, making it difficult to listen
to a broadcast.
11. This is a power source for multi volt products. Do not
use with 18 V products or chargers. Doing so could
result in damage.
12. Overload behavior may differ when compared with
BSL36B18 battery use.
With the battery where the LED should blink on the
main unit, the LED on the AC/DC adapter may blink
instead.
PRECAUTIONS FOR AC/DC ADAPTER
The adapter equips with the protection function to stop the
output. In the cases of 1 to 2 described below, when using
this product, even if you are pulling the switch, the motor
may stop. This is not the trouble but the result of
protection function.
1. If the tool is overloaded, output may stop. In this case,
release the switch of tool and eliminate causes of
overloading.
2. If the adapter is overheated under overload work,
output may stop. In situations like this, discontinue
use of the adapter and detach it from the tool. Allow
the adapter to cool in a location such as a shaded
area with good air circulation.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with
the protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may
stop. This is not the trouble but the result of protection
function.
1. When the battery power remaining runs out, the motor
stops.
In such case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes
of overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and
caution.
WARNING
In order to prevent any battery leakage, heat
generation, smoke emission, explosion and ignition
beforehand, please be sure to heed the following
precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○ During work make sure that swarf and dust do not fall
on the battery.
○ Make sure that any swarf and dust falling on the
power tool during work do not collect on the battery.
○ Do not store an unused battery in a location exposed
to swarf and dust.
○ Before storing a battery, remove any swarf and dust
that may adhere to it and do not store it together with
metal parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject
the battery to severe physical shock.
3. Do not use an apparently damaged or deformed
battery.
4. Do not use the battery for a purpose other than those
specified.
5. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately
stop further recharging.
6. Do not put or subject the battery to high temperatures
or high pressure such as into a microwave oven,
dryer, or high pressure container.
7. Keep away from fire immediately when leakage or
foul odor are detected.
8. Do not use in a location where strong static electricity
generates.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
11
9. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears
abnormal during use, recharging or storage,
immediately remove it from the equipment or battery
charger, and stop use.
10. Do not immerse the battery or allow any fluids to flow
inside. Conductive liquid ingress, such as water, can
cause damage resulting in fire or explosion. Store
your battery in a cool, dry place, away from
combustible and flammable items. Corrosive gas
atmospheres must be avoided.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return it to
your supplier or vendor.
WARNING
If an electrically conductive foreign object enters the
terminals of the lithium ion battery, a short-circuit may
occur resulting in the risk of fire. Please observe the
following matters when storing the battery.
● Do not place electrically conductive cuttings,
nails, steel wire, copper wire or other wire in the
storage case.
● Either install the battery in the power tool or
store by securely pressing into the battery cover
until the ventilation holes are concealed to
prevent short-circuits (See Fig. 5).
REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe
the following precautions.
WARNING
Notify the transporting company that a package
contains a lithium-ion battery, inform the
company of its power output and follow the
instructions of the transportation company when
arranging transport.
● Lithium-ion batteries that exceed a power output
of 100Wh are considered to be in the freight
classification of Dangerous Goods and will
require special application procedures.
● For transportation abroad, you must comply with
international law and the rules and regulations of
the destination country.
Wh
Power Output
2 to 3 digit number
Fig. 2
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO OTHER USERS
AND
OWNERS OF THIS TOOL!
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
12
FUNCTIONAL DESCRIPTION
NOTE
The information contained in this Instruction Manual is designed to assist you in the safe operation and maintenance
of the power tool.
NEVER operate, or attempt any maintenance on the tool unless you have first read and understood all safety
instructions contained in this manual.
Some illustrations in this Instruction Manual may show details or attachments that differ from those on your own
power tool.
NAME OF PARTS
1.Cordless Slide Compound Miter Saw (C3612DRA)
Motor
Dust bag
Holder (A)
Hinge
Indicator
(For bevel scale)
Set pin (A)
Sub fence (B)
Fence (B)
Base
Motor head
Lock-off button
6mm machine screw
Gear case
Handle
LED light
Saw blade
Rotation direction
Lower guard
Sub fence (A)
Fence (A)
Table insert
5 mm machine screw
Turntable
Side holder
4mm screw
Positive stop lever
Detent lever
Miter lock handle
Bevel lock handle
Miter scale
Left hex.
10mm socket bolt
Locking pin
Indicator (For miter scale)
Vise assembly
Battery
LED light switch
Mode selector switch
Mode selector lamp
Switch panel
Fig.3
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
13
LED light
Trigger switch
Spindle lock
Positive stop lever
Miter lock handle
Detent lever
Base
Miter scale
Side holder
6mm machine screw
Holder
Indicator
(For bevel scale)
Holder (A)
Slide securing knob
Carry handle
Battery
Nameplate
Fig.4
2.Battery 3.Battery Charger
Display panel
Ventilation holes Battery cover
Terminals
Latch
Cord
Nameplate Guide rail
Ventilation holes
Charge indicator
lamp
<BSL36B18>
Fig.5
<UC18YSL3>
Fig.6
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
14
4.AC/DC Adapter (Optional accessories... sold separately)
AC cord
Box
Error lamp
Cord armor
Cord armor
Power lamp
Ventilation holes
Error lamp
Adapter
Latch
Terminals
DC cord
Cord armor
Plug
<ET36A>
Fig.7
SPECIFICATIONS
1.Cordless Slide Compound Miter Saw
Model C 3612DRA
Motor DC brushless motor
LED light Yes
Applicable saw blade Outside Dia. 12" (305mm),
Hole Dia. 1" (25.4mm),
No load speed 4,000/min (Auto Switch mode) / 3,200/min (High Torque
mode)
Miter sawing range Left 0°–45° Right 0°–57°
Bevel sawing range Left 0°–45° Right 0°–45°
Compound sawing range Left (Bevel) 0°–45° Left (Miter) 0°–45°, Right (Miter) 0°–45°
Right (Bevel) 0°–45° Right (Miter) 0°–45°, Left (Miter) 0°–45°
Power supply Type*1Li-ion battery Model BSL36B18
AC/DC adapter Model ET36A (sold separately)
Voltage 36V
Net weight 56.4lbs. (25.6kg) (BSL36B18 attached)
*1 Existing batteries (BSL3660/3626/3620, BSL18 and BSL14 series, etc.) cannot be used with this tool.
If using the AC/DC adapter, please read and understand its manual before operating the power tool.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
15
Table 2: Max. sawing dimension
Head Turntable Max. sawing dimension
Max. height Max. width With aux. board
Miter 0
04-3/16" (107 mm) 12-1/4" (312 mm) -
*4-11/16" (120 mm) 10-3/16" (260 mm) 1" (25 mm)
Left 45°
or
Right 45°
4-3/16" (107 mm) 8-5/8" (220 mm) -
*4-11/16" (120 mm) 7-1/16" (180 mm) 1" (25 mm)
Right 57° 4-3/16" (107 mm) 6-11/16" (170 mm) -
* 4-3/4" (120 mm) 5-1/8" (130 mm) 1" (25 mm)
Bevel
Left 45° 0 2-3/4" (70 mm) 12-1/4" (312 mm) -
*2-15/16" (75 mm) 10-3/16" (260 mm) 1" (25 mm)
Right 45° 0 1-3/4" (45 mm) 12-1/4" (312 mm) -
*1-15/16" (50 mm) 10-3/16" (260 mm) 1" (25 mm)
Compound
Left 45°
Left 45° 2-3/4" (70 mm) 8-5/8" (220 mm) -
*2-15/16" (75 mm) 7-1/16" (180 mm) 1" (25 mm)
Right 45° 2-3/4" (70 mm) 8-5/8" (220 mm) -
*2-15/16" (75 mm) 7-1/16" (180 mm) 1" (25 mm)
Right 45°
Left 45° 1-3/4" (45 mm) 8-5/8" (220 mm) -
*1-15/16" (50 mm) 7-1/16" (180 mm) 1" (25 mm)
Right 45° 1-3/4" (45 mm) 8-5/8" (220 mm) -
*1-15/16" (50 mm) 7-1/16" (180 mm) 1" (25 mm)
When cutting the workpiece which has the dimension of "*" there might be some possibility of the lower end of the
circular saw to touch with the workpiece, even if the motor head is located at the lower limit position. Pay attention when
cutting the workpiece. For further details, refer to "PRACTICAL APPLICATIONS" on page28. Mount the auxiliary board
on the fence surface Refer to "5. Cutting large workpieces" on page30 (Fig.35).
2.Battery Charger
Model UC18YSL3
Input power source Single phase: AC 120 V 60 Hz
Charging time
(At a temperature of 68°F (20°C)) BSL36B18: Approx. 52min
Charging voltage DC 14.4–18V
Charging current DC 8.0A
Weight 1.3 lbs. (0.6 kg)
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
16
NOTE
The charging time may vary according to temperature and power source voltage.
3.AC/DC Adapter
Model ET36A
Input power source Single phase: AC 120 V 60 Hz
Output voltage 36V
Operating temperature range 14°F (-10°C)–104°F (40°C)
Weight Adapter : 1.8 lbs. (0.8 kg)
Box : 2.6 lbs. (1.2 kg)
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
17
ASSEMBLY AND OPERATION
APPLICATIONS
○ Cutting various types of wood.
○ Cutting aluminum sash.
REMOVAL AND INSTRUCTION METHOD
OF BATTERY OR AC/DC ADAPTER
○ How to install the battery or AC/DC adapter.
Align the battery or AC/DC adapter with the groove in
tool handle and slip it into place.
Always insert it all the way until it locks in place with a
little click, If not, it may accidentally fall out of the tool,
causing injury to you or someone around you (Fig.8).
○ How to remove the battery or AC/DC adapter.
Withdraw battery or AC/DC adapter from the tool
handle while pressing the latch (2pcs) of the battery
or AC/DC adapter (Fig.8).
Latch
Battery
Pull out
Insert
Push
Fig. 8
CHARGING METHOD
NOTE
Before plugging into the receptacle, make sure the
following points.
○ The power source voltage is stated on the nameplate.
○ The cord is not damaged.
WARNING
Do not charge at voltage higher than indicated
on the nameplate.
If charged at voltage higher than indicated on the
nameplate, the charger will burn out.
<UC18YSL3>
1. Connect the charger’s power cord to a receptacle.
When the power cord is connected, the charge
indicator lamp will blink in red. (See Table 3)
WARNING
Do not use the electrical cord if damaged. Have it
repaired immediately.
2. Insert the battery to the battery charger.
Insert the battery into the battery charger as shown in
Fig. 9.
Charge
indicator lamp
Battery
Guide rail
Fig. 9
3. Charging
When inserting a battery in the charger, charging will
commence and the charge indicator lamp will blink in
blue.
When the battery becomes fully recharged, the
charge indicator lamp will light up in green. (See
Table3)
(1) Charge indicator lamp indication
The indications of the charge indicator lamp will be as
shown in Table3, according to the condition of the
battery charger or the battery.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
18
Table 3:Indications of the charge indicator lamp
ON/OFF at 0.5 sec. intervals
(RED) Before charging *1
Lights for 0.5 sec. at intervals
of 1 sec. (BLUE) Charged at less than
50%
Lights for 1 sec. at intervals of
0.5 sec. (BLUE) Charged at less than
80%
Lights continuously (BLUE) Charged at more than
80%
Lights continuously
(Continuous buzzer sound:
about 6 sec.) (GREEN) Charging complete
ON/OFF at 0.3 sec. intervals
(RED) Overheat standby *2
ON/OFF at 0.1 sec. intervals
(Intermittent buzzer sound;
about 2 sec.) (PURPLE) Charging impossible *3
NOTE
*1 If the red lamp continues to blink even after the
charger has been attached, check to confirm that the
battery has been fully inserted.
*2 Battery overheated. Unable to charge.
Although charging will start once the battery has
cooled down even when left in situ, the best practice
is to remove the battery and allow it to cool down in a
shaded, well-ventilated location before charging.
*3 Malfunction in the battery or the charger
– Fully insert the battery.
– Check to confirm that no foreign matter is stuck
to the battery mount or terminals. If there are no
foreign objects, it is probable that the battery or
charger is malfunctioning. Take it to your
authorized Service Center.
○ When the battery charger has been continuosly used,
the battery charger will be heated, thus constituting
the cause of the failures. Once the charging has been
completed, give 5minutes rest until the next charging.
(2) Regarding the temperature of the rechargeable
battery.
Table 4
Rechargeable
batteries Temperatures at which the battery can be recharged
BSL36B18 32°F–122°F
(0°C–50°C)
(3) Regarding recharging time (At 68°F (20°C))
Table 5:Charging time
Battery Charger: UC18YSL3
BSL36B18 Approx. 52 min
NOTE
○ The recharging time may vary according to the
ambient temperature.
○ If charging takes a long time
– Charging will take longer at extremely low
ambient temperatures. Charge the battery in a
warm location (such as indoors).
– Do not block the air vent. Otherwise the interior
will overheat, reducing the charger’s
performance.
– If the cooling fan is not operating, contact a
metaboHPT Authorized Service Center for
repairs.
4. Disconnect battery charger from the receptacle.
CAUTION
Do not pull the plug out of the receptacle by
pulling on the cord.
Make sure to grasp the plug when removing from
receptacle to avoid damaging cord.
5. Remove the battery from the battery charger.
Supporting the battery charger with hand, pull out the
battery from the battery charger.
NOTE
Be sure to pull out the battery from the battery charger
after use, and then keep it.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries and
batteries that have not been used for an extended period
is not activated, the electric discharge might be low when
using them the first and second time. This is a temporary
phenomenon, and normal time required for recharging will
be restored by recharging the batteries 2–3 times.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
19
How to make the batteries perform longer
(1) Recharge the batteries before they become
completely exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery. If
you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate,
and the battery life will be shortened. Leave the
battery and recharge it after it has cooled for a while.
HOW TO RECHARGE USB DEVICE
When an unexpected problem occurs, the data in a USB
device connected to this product may be corrupted or lost.
Always make sure to back up any data contained in the
USB device prior to use with this product.
Please be aware that our company accepts absolutely no
responsibility for any data stored in a USB device that is
corrupted or lost, nor for any damage that may occur to a
connected device.
WARNING
● Prior to use, check the connecting USB cable for
any defect or damage.
Using a defective or damaged USB cable can
cause smoke emission or ignition.
● When the product is not being used, cover the
USB port with the rubber cover.
Buildup of dust etc. in the USB port can cause
smoke emission or ignition.
NOTE
○ The time required for charging will be longer when a
USB device and battery are being simultaneously
charged.
○ There may be an occasional pause during USB
recharging.
○ When a USB device is not being charged, turn the
USB power switch OFF and remove the USB device
from the charger.
Failure to do so may not only reduce the battery life of
a USB device, but may also result in unexpected
accidents.
○ It may not be possible to charge some USB devices,
depending on the type of device.
(1) Select a charging method
Depending on the charge method selected, either the
battery is inserted into the charger or the power cord
is plugged into an outlet.
○ Charging a USB device by battery
○ Charging a USB device from a electrical outlet
○ Charging a USB device and battery from a electrical
outlet
a b c
Fig. 10
(2) Turn the USB power switch ON
When you turn the USB power switch ON, the USB
power indicator lamp will light up.
Rubber cover
USB cable
USB port
USB power
indicator lamp
USB power switch
Fig. 11
(3) Connect the USB cable.
Pull back the rubber cover and firmly plug in a
commercially available USB cable (appropriate to the
device being charged) into the USB port.
○ When the power cord is not plugged into an outlet
and the battery runs out of power, power output will
stop and the USB power indicator lamp will shut off.
○ When the USB power indicator lamp goes out,
change the battery or plug the power cord into an
electrical outlet.
(4) When charging is completed
○ The USB power indicator lamp will not go out when a
USB device has been completely charged.
To verify charge status, check the USB device.
○ Turn the USB power switch OFF and unplug the
power cord from the electrical outlet.
○ Remove the battery from the charger and place the
rubber cover over the USB port.
<USB device charging stops midway>
○ Charging stops for approximately five seconds to
allow the power supply to be detected under the
following conditions: if the battery charger power plug
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA

English
20
is plugged in while charging a USB device from the
battery, or if a rechargeable battery is inserted while
charging a USB device from the battery charger.
○ USB charging stops for five seconds so that checking
can be performed once the rechargeable battery has
been fully charged.
○ If the rechargeable battery level is extremely low,
charging the rechargeable battery takes priority, and
USB charging is temporarily stopped. USB charging
automatically resumes once the battery level has
reached a preset level.
PREPARATION BEFORE OPERATION
WARNING
Pull out battery before carrying out any
adjustment, servicing or maintenance.
When finished with a job, pull out the battery.
1. Power switch
Ensure that the switch is in the OFF position. If the
battery installed to power tool while the switch is in
the ON position, the power tool will start operating
immediately, which could cause a serious accident.
2. Remove all packing materials attached or connected
to the tool before attempting to operate it.
3. Installation
Attach the power tool to a level, horizontal work bench
in accordance with Fig. 12.
Select 5/16" (8mm) diameter bolts suitable in length
for the thickness of the work bench. Bolt length
should be at least 1-9/16" (40mm) plus the thickness
of the work bench.
For example, use 2-9/16" (65mm) or larger bolts for a
1" (25mm) thick work bench.
11/32" (9mm)
4 holes
10-1/16" (255.5mm)
12-7/8"
(327mm)
11-1/18"
(282mm)
Miter lock handle side
Base
1" (25mm) thick bench
5/16" (8mm) bolt
5/16" (8 mm) nut
Work bench
Fig. 12
The holder attached to the rear of the base helps stabilize
the power tool.
Holder adjustment:
Loosen the 6mm bolt with the 10mm box wrench.
Adjust the holder until its bottom surface contacts the work
bench surface.
After adjustment, firmly tighten the 6mm bolt.
6 mm Bolt
Move
Adjust the holder until its bottom surface
contacts the work bench surface.
Holder
Fig. 13
4. Releasing the locking pin
When the power tool is prepared for shipping, its main
parts are secured by a locking pin.
Press the handle slightly down and pull out the
locking pin to disengag the cutting head.
During transport, lock the locking pin into the gear
case.
2023/08/31 19:12:25Stylesheet: NA Version: 2023.7.18
C3612DRA_C99749361_309_NA
