Metabo HPT CR 18DB Troubleshooting guide

Designed for operating in USA & Canada only.
When this product is used in areas other than the USA & Canada,
we cannot guarantee the product quality and performance.
Model
Modèle
Modelo CR 18DB
Cordless Reciprocating Saw
Scie alternative sans fil
Sierra sable inalámbrica
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury!
This manual contains important information about product safety. Please read and understand
this manual BEFORE operating the power tool. Please keep this manual available for other
users and owners before they use the power tool. This manual should be stored in safe place.
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de cet outil motorisé peut entraîner la mort
ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce produit.
Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil motorisé. Garder ce
mode d’emploi à la disponibilité des autres utilisateurs et propriétaires avant qu’ils utilisent
l’outil motorisé. Ce mode d’emploi doit être conservé dans un endroit sûr.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede resultar
en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual para
que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este manual debe
ser guardado en un lugar seguro.
000BookCR18DBNA.indb1000BookCR18DBNA.indb1 2022/03/2410:13:372022/03/2410:13:37

2
English
IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in the Instruction Manual before
operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic safety
rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation before it occurs,
and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual and in the sections which
contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by WARNINGS on the power
tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by metabo HPT.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in minor or moderate injury, or
may cause machine damage.
NOTE emphasizes essential information.
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings, instructions, illustrations and specifications provided with this power tool.
Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges
and refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool.
Keep cord away from heat, oil, sharp edges
or moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
000BookCR18DBNA.indb2000BookCR18DBNA.indb2 2022/03/2410:13:382022/03/2410:13:38

3
English
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as a dust mask, non-
skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.
Loose clothes, jewellery or long hair can be
caught in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used.
Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent
use of tools allow you to become complacent
and ignore tool safety principles.
A careless action can cause severe injury within a
fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed.
Use of the power tool for operations different
from those intended could result in a hazardous
situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by
the manufacturer.
A charger that is suitable for one type of battery
pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk
of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small
metal objects, that can make a connection
from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help.
Liquid ejected from the battery may cause
irritation or burns.
e) Do not use a battery pack or tool that is
damaged or modified.
Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire,
explosion or risk of injury.
000BookCR18DBNA.indb3000BookCR18DBNA.indb3 2022/03/2410:13:392022/03/2410:13:39

4
English
f) Do not expose a battery pack or tool to fire or
excessive temperature.
Exposure to fire or temperature above 265 °F may
cause explosion.
g) Follow all charging instructions and do
not charge the battery pack or tool outside
the temperature range specified in the
instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
6) Service
a)Have your power tool serviced by a
qualified repair person using only identical
replacement parts.
This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs.
Service of battery packs should only be
performed by the manufacturer or authorized
service providers.
– WARNING –
To reduce the risk of injury, user must read
instruction manual.
SPECIFIC SAFETY RULES
1. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring.
Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live”and could
give the operator an electric shock.
2. Use clamps or another practical way to secure
and support the workpiece to a stable platform.
Holding the workpiece by hand or against your body
leaves it unstable and may lead to loss of control.
3. ALWAYS wear ear protectors when using the tool
for extended periods.
Prolonged exposure to high intensity
noise can cause hearing loss.
4. NEVER touch moving parts.
NEVER place your hands, fingers or other body parts
near the tool’s moving parts.
5. NEVER operate without all guards in place.
NEVER operate this tool without all guards or safety
features in place and in proper working order. If
maintenance or servicing requires the removal of a
guard or safety feature, be sure to replace the guard
or safety feature before resuming operation of the
tool.
6. Use right tool.
Don’t force small tool or attachment to do the job of a
heavy-duty tool.
Don’t use tool for purpose not intended —for
example— don’t use circular saw for cutting tree
limbs or logs.
7. NEVER use a power tool for applications other
than those specified.
NEVER use a power tool for applications other than
those specified in the Instruction Manual.
8. Handle tool correctly.
Do not drop or throw the tool.
9. Keep all screws, bolts and covers tightly in
place.
Keep all screws, bolts, and plates tightly mounted.
Check their condition periodically.
10. Do not use power tools if the plastic housing or
handle is cracked.
Cracks in the tool’s housing or handle can lead to
electric shock. Such tools should not be used until
repaired.
11. Blades and accessories must be securely
mounted to the tool.
Prevent potential injuries to yourself or others.
Blades, cutting implements and accessories which
have been mounted to the tool should be secure and
tight.
12. Handle the blades very carefully.
13. Check the blade carefully for cracks or damage
before operation. Replace cracked or damaged
blade immediately.
14. Avoid cutting nails. Inspect for and remove all
nails from the workpiece before operation.
15. Always hold the body handle and front cover of
the power tool firmly. Otherwise the counterforce
produced may result in inaccurate and even
dangerous operation. (Fig. 19)
16. Keep motor air vent clean.
The tool’s motor air vent must be kept clean so that
air can freely flow at all times. Check for dust build-up
frequently.
17. NEVER use a tool which is defective or operating
abnormally.
If the tool appears to be operating unusually, making
strange noises, or otherwise appears defective, stop
using it immediately and arrange for repairs by a
metabo HPT authorized service center.
18. NEVER leave tool running unattended. Turn
power off.
Don’t leave tool until it comes to a complete stop.
19. Carefully handle power tools.
Should a power tool be dropped or struck against
hard materials inadvertently, it may be deformed,
cracked, or damaged.
20. Do not wipe plastic parts with solvent.
Solvents such as gasoline, thinner benzine, carbon
tetrachloride, and alcohol may damage and crack
plastic parts. Do not wipe them with such solvents.
Wipe plastic parts with a soft cloth lightly dampened
with soapy water and dry thoroughly.
000BookCR18DBNA.indb4000BookCR18DBNA.indb4 2022/03/2410:13:392022/03/2410:13:39

5
English
21. ALWAYS wear eye protection that meets the
requirement of the latest revision of ANSI
Standard Z87.1.
22. ALWAYS wear a mask or respirator to protect yourself
from dust or potentially harmful particles generated
during operation.
23. ALWAYS firmly grip the handle while operating.
24. ALWAYS be careful with buried object such as an
underground wiring.
Touching these active wiring or electric cable with
this tool, you may receive an electric shock.
Confirm if there are any buried object such as electric
cable within the wall, floor or ceiling where you are
going to operate here after.
25. Definitions for symbols used on this tool
V ..................volts
---.................direct current
no................no load speed
---/min..........revolutions or reciprocation per minute
26. Do not touch the blade immediately after
operation: it may be extremely hot and could
burn your skin.
27. During use, do not touch the metal portion of the tool.
28. Because the cordless power tool operates by battery
power, be aware of the fact that it can begin to operate
at any time.
29. When working at elevated locations, clear the area
of all other people and be aware of conditions below
you.
30. Do not use the product if the tool or the battery
terminals (battery mount) are deformed.
Installing the battery could cause a short circuit that
could result in smoke emission or ignition.
31. Keep the tool’s terminals (battery mount) free of swarf
and dust.
○ Prior to use, make sure that swarf and dust have not
collected in the area of the terminals.
○ During use, try to avoid swarf or dust on the tool from
falling on the battery.
○ When suspending operation or after use, do not leave
the tool in an area where it may be exposed to falling
swarf or dust.
Doing so could cause a short circuit that could result
in smoke emission or ignition.
32. Always use the tool and battery at temperatures
between 23°F (-5°C) and 104°F (40°C).
IMPORTANT SAFETY INSTRUCTIONS
FOR BATTERY CHARGER
WARNING
Death or serious bodily injury could result from
improper or unsafe use of battery chargers.
To avoid these risks, follow these basic safety
instructions:
READ ALL INSTRUCTIONS
1. This manual contains important safety and operating
instructions for battery charger Model UC18YFSL.
2. Before using battery charger, read all instructions
and cautionary markings on (1) battery charger, (2)
battery, and (3) product using battery.
3. To reduce risk of injury, charge metabo HPT
rechargeable batteries. Other type of batteries may
burst causing personal injury and damage.
4. Use of an attachment not recommended or sold by
the battery charger manufacturer may result in a risk
of fire, electric shock, or injury to persons.
5. To reduce risk of damage to electric plug and cord,
pull by plug when disconnecting battery charger.
6. Make sure cord is located so that it will not be stepped
on, tripped over, or otherwise subjected to damage or
stress.
7. An extension cord should not be used unless
absolutely necessary. Use of improper extension
cord could result in a risk of fire and electric shock.
If extension cord must be used make sure:
a. That blades of extension cord are the same
number, size, and shape as those of plug on
battery charger:
b. That extension cord is properly wired and in good
electrical condition; and
c. That wire size is large enough for AC ampere
rating of battery charger as specified in Table 1.
Table 1
RECOMMENDED MINIMUM AWG SIZE FOR
EXTENSION CORDS FOR BATTERY CHARGERS
AC Input Rating Amperes* AWG Size of Cord
Equal to or
greater than but less than Length of Cord, Feet (Meter)
25 (7.5) 50 (15) 100 (30) 150 (45)
0 2 18 18 18 16
2 3 18 18 16 14
3 4 18 18 16 14
000BookCR18DBNA.indb5000BookCR18DBNA.indb5 2022/03/2410:13:392022/03/2410:13:39

6
English
* If the input rating of a battery charger is given in watts
rather than in amperes, the corresponding ampere
rating is to be determined by dividing the wattage
rating by the voltage rating–for example:
1,250 watts = 10 amperes
125 volts
8. Do not operate battery charger with damaged cord or
plug-replace them immediately.
9. Do not operate battery charger if it has received a
sharp blow, been dropped, or otherwise damaged in
any way; take it to a qualified serviceman.
10. Do not disassemble battery charger; take it to a
qualified serviceman when service or repair is
required. Incorrect reassembly may result in a risk of
electric shock or fire.
11. To reduce risk of electric shock, unplug charger from
receptacle before attempting any maintenance or
cleaning. Removing the battery will not reduce this
risk.
IMPORTANT SAFETY INSTRUCTIONS
FOR USE OF THE BATTERY AND
BATTERY CHARGER
You must charge the battery before you can use the power
tool. Before using the model UC18YFSL battery charger,
be sure to read all instructions and cautionary statements
on it, the battery and in this manual.
REMEMBER: USE ONLY metabo HPT BATTERIES.
OTHER TYPES OF BATTERIES MAY BURST AND
CAUSE INJURY!
Follow these instructions to avoid the risk of injury:
WARNING: Improper use of the battery
or battery charger can lead to
serious injury. To avoid these
injuries:
1. NEVER disassemble the battery.
2. NEVER incinerate the battery, even if it is damaged
or is completely worn out. The battery can explode in
a fire.
3. NEVER short-circuit the battery.
4. NEVER insert any objects into the battery charger’s
air vents. Electric shock or damage to the battery
charger may result.
5. NEVER charge outdoors. Keep the battery away
from direct sunlight and use only where there is low
humidity and good ventilation.
6. NEVER charge when the temperature is below 32°F
(0°C) or above 104°F (40°C).
7. NEVER connect two battery chargers together.
8. NEVER insert foreign objects into the hole for the
battery or the battery charger.
9. NEVER use a booster transformer when charging.
10. NEVER use DC power to charge.
11. NEVER store the battery or battery charger in places
where the temperature may reach or exceed 104°F
(40°C) such as inside metal box or car.
12. NEVER expose the battery or battery charger to rain
or wet conditions.
13. ALWAYS operate charger on standard household
electrical power (120 volts). Using the charger on any
other voltage may overheat and damage the charger.
14. ALWAYS wait at least 15 minutes between charges to
avoid overheating the charger.
15. ALWAYS disconnect the power cord from its
receptacle when the charger is not in use.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with
the protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may stop.
This is not the trouble but the result of protection function.
1. When the battery power remaining runs out, the
motor stops.
In such case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes
of overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and
caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand,
please be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○ During work make sure that swarf and dust do not fall
on the battery.
○ Make sure that any swarf and dust falling on the
power tool during work do not collect on the battery.
○ Do not store an unused battery in a location exposed
to swarf and dust.
○ Before storing a battery, remove any swarf and dust
that may adhere to it and do not store it together with
metal parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject
the battery to severe physical shock.
3. Do not use an apparently damaged or deformed
battery.
4. Do not use the battery for a purpose other than those
specified.
5. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately
stop further recharging.
000BookCR18DBNA.indb6000BookCR18DBNA.indb6 2022/03/2410:13:392022/03/2410:13:39

7
English
6. Do not put or subject the battery to high temperatures
or high pressure such as into a microwave oven,
dryer, or high pressure container.
7. Keep away from fire immediately when leakage or
foul odor are detected.
8. Do not use in a location where strong static electricity
generates.
9. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears
abnormal during use, recharging or storage,
immediately remove it from the equipment or battery
charger, and stop use.
10. Do not immerse the battery or allow any fluids to flow
inside. Conductive liquid ingress, such as water,
can cause damage resulting in fire or explosion.
Store your battery in a cool, dry place, away from
combustible and flammable items. Corrosive gas
atmospheres must be avoided.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return it to
your supplier or vendor.
WARNING
If an electrically conductive foreign object enters the
terminals of the lithium ion battery, a short-circuit may
occur resulting in the risk of fire. Please observe the
following matters when storing the battery.
○ Do not place electrically conductive cuttings,
nails, steel wire, copper wire or other wire in the
storage case.
○ Either install the battery in the power tool or
store by securely pressing into the battery
cover until the ventilation holes are concealed to
prevent short-circuits (See Fig. 3).
REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe
the following precautions.
WARNING
Notify the transporting company that a package
contains a lithium-ion battery, inform the company
of its power output and follow the instructions of the
transportation company when arranging transport.
● Lithium-ion batteries that exceed a power output
of 100 Wh are considered to be in the freight
classification of Dangerous Goods and will
require special application procedures.
● For transportation abroad, you must comply with
international law and the rules and regulations
of the destination country.
Wh
Power Output
2 to 3 digit number
Fig. 1
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO OTHER USERS
AND
OWNERS OF THIS TOOL!
000BookCR18DBNA.indb7000BookCR18DBNA.indb7 2022/03/2410:13:392022/03/2410:13:39

8
English
FUNCTIONAL DESCRIPTION
NOTE
The information contained in this Instruction Manual is designed to assist you in the safe operation and maintenance
of the power tool.
NEVER operate, or attempt any maintenance on the tool unless you have first read and understood all safety
instructions contained in this manual.
Some illustrations in this Instruction Manual may show details or attachments that differ from those on your own
power tool.
NAME OF PARTS
1. Cordless Reciprocating Saw (CR18DB)
Lock-offbutton
Trigger switch
LED light
Blade
Base
Change lever
Blade holder
Motor
Nameplate
Housing
Hexagonal bar
wrench
Front cover
Handle
Battery
Fig. 2
000BookCR18DBNA.indb8000BookCR18DBNA.indb8 2022/03/2410:13:392022/03/2410:13:39

9
English
2. Battery
(optional accessories…sold separately) 3. Battery Charger (optional accessories…sold separately)
Ventilation holes
Latch
Terminals
Battery cover
Battery Nameplate
Pilot lamp
Guide rail
Cord
Ventilation holes
<BSL1830C>
Fig. 3
<UC18YFSL>
Fig. 4
SPECIFICATIONS
1. Cordless Reciprocating Saw
Model CR18DB
Motor DC motor
Capacity
Mild Steel Pipe: O.D. 5" (130 mm)
Vinyl Choride Pipe: O.D. 5" (130 mm)
Wood: 4-23/32" (120 mm)
Mild Steel Plate: 3/4" (19 mm)
No-load speed 0–3,000 /min
Stroke 1-1/8" (29 mm)
Battery Type Li-ion battery Model BSL1830C
Voltage DC 18V
Weight 7.4 lbs. (3.4 kg) (BSL1830C attached)
2. Battery Charger
Model UC18YFSL
Input power source Single phase: AC 120 V 60 Hz
Charging time
(At a temperature of 68°F (20°C)) BSL1830C: Approx. 45 min
Charging voltage DC 14.4–18 V
Charging current DC 3.5 A
Weight 1.1 lbs. (0.5 kg)
NOTE: The charging time may vary according to temperature and power source voltage.
000BookCR18DBNA.indb9000BookCR18DBNA.indb9 2022/03/2410:13:392022/03/2410:13:39

10
English
ASSEMBLY AND OPERATION
APPLICATIONS
○
Cutting metal and stainless steel pipe.
○ Cutting various lumber.
○ Cutting mild steel, aluminum and copper plate.
○ Cutting synthetic resins, such as phenol resin and
vinyl chloride.
REMOVAL AND INSTALLATION METHOD
OF BATTERY
○
How to remove the battery.
Withdraw battery from the tool handle while pressing
the latch (2 pcs) of the battery (Fig. 5).
○ How to install the battery.
Align the battery with the groove in tool handle and
slip it into place.
Always insert it all the way until it locks in place with a
little click, If not, it may accidentally fall out of the tool,
causing injury to you or someone around you (Fig. 5).

Latch
Lock-offbutton
Battery
Pull out
Insert
Push
Fig. 5
CHARGING METHOD
NOTE
Before plugging into the receptacle, make sure the
following points.
○ The power source voltage is stated on the nameplate.
○ The cord is not damaged.
WARNING
Do not charge at voltage higher than indicated
on the nameplate.
If charged at voltage higher than indicated on
the nameplate, the charger will burn out.
1. Connect the charger’s power cord to a receptacle.
When the power cord is connected, the charge
indicator lamp will blink in red. (At 1-second intervals)
WARNING
Do not use the electrical cord
if damaged. Have it repaired
immediately.
2. Insert the battery to the battery charger.
Firmly Insert the battery into the battery charger as
shown in Fig. 6.
Battery
Guide rail
Pilot lamp
Fig. 6
3. Charging
When inserting a battery in the charger, the pilot lamp
will light up continuously in red.
When the battery becomes fully recharged, the pilot
lamp will blink in red. (At 1- second intervals.) (See
Table 2)
(1) Lamp indication
The indications of the pilot lamp will be as shown
in Table 2, according to the condition of the battery
charger or the battery.
000BookCR18DBNA.indb10000BookCR18DBNA.indb10 2022/03/2410:13:402022/03/2410:13:40

11
English
Table 2
Indications of the pilot lamp
Pilot lamp
(red)
Before
charging Blinks Lights for 0.5 seconds. Does not light for
0.5 seconds. (offfor 0.5 seconds) Plugged into power source
While
charging Lights Lights continuously
Charging
complete Blinks Lights for 0.5 seconds. Does not light for
0.5 seconds. (offfor 0.5 seconds)
Overheat
standby Blinks Lights for 1 second. Does not light for
0.5 seconds. (offfor 0.5 seconds)
Battery overheated.
Unable to charge.
(Charging will commence
when battery cools)
Charging
impossible Flickers Lights for 0.1 seconds. Does not light for
0.1 seconds. (offfor 0.1 seconds) Malfunction in the battery or
the charger
(2) Regarding the temperature of the rechargeable
battery.
The temperatures for rechargeable batteries are
as shown in the Table 3, and batteries that have
become hot should be cooled for a while before being
recharged.
Table 3
Rechargeable
batteries Temperatures at which the battery can be recharged
BSL1830C 32°F–122°F
(0°C–50°C)
(3) Regarding recharging time (At 68°F (20°C))
Table 4 Charging time
Charger
Battery UC18YFSL
BSL1830C Approx. 45 min
NOTE
The recharging time may vary according to the
ambient temperature.
4. Disconnect battery charger from the receptacle.
CAUTION
Do not pull the plug out of the receptacle by
pulling on the cord.
Make sure to grasp the plug when removing from
receptacle to avoid damaging cord.
5. Remove the battery from the battery charger.
Supporting the battery charger with hand, pull out the
battery from the battery charger.
NOTE
Be sure to pull out the battery from the battery
charger after use, and then keep it.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries
and batteries that have not been used for an extended
period is not activated, the electric discharge might
be low when using them the first and second time.
This is a temporary phenomenon, and normal time
required for recharging will be restored by recharging
the batteries 2–3 times.
How to make the batteries perform longer
(1) Recharge the batteries before they become
completely exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery.
If you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate,
and the battery life will be shortened. Leave the
battery and recharge it after it has cooled for a while.
000BookCR18DBNA.indb11000BookCR18DBNA.indb11 2022/03/2410:13:452022/03/2410:13:45

12
English
(3) When you release your hand from the blade holder,
the blade is fixed in place.
Blade
Blade holder
Slit of blade holder
Fig. 7
You can mount this blade either in the upward or
downward direction. (Fig. 8)
Blade mounted in
upward direction
Slit of blade holder
Fig. 8
(4) Pull the back of the saw blade two or three times by
hand and check that the blade is securely mounted.
(Fig. 9)
Blade
Fig. 9
CAUTION
When pulling the saw blade, be absolutely sure
to pull it from the back. Pulling other parts of the
blade will result in an injury.
CAUTION
● When the battery charger has been continuously
used, the battery charger will be heated, thus
constituting the cause of the failures. Once the
charging has been completed, give 15 minutes
rest until the next charging.
● If the battery is charged while it is heated
because it has been left for a long time in a
location subject to direct sunlight or because
the battery has just been used, the pilot lamp of
the charger lights for 1 second, does not light for
0.5 seconds (offfor 0.5 seconds).
The battery will not be recharged. In such a
case, let the battery cool before charging.
● When the pilot lamp flickers (at 0.2-second
intervals), check for and take out any foreign
objects in the charger’s battery connector. If
there are no foreign objects, it is probable that
the battery or charger is malfunctioning. Take it
to your authorized Service Center.
BEFORE USE
WARNING
In the following situations, press in the lock-off
button to the Lock side (right side).
○ When stopping or ending work
○ When attaching or removing the blade
○ When adjusting the position of the base
○ When removing or attaching the battery
○ When selecting the stroke mode
For how to use the lock-offbutton, see “(1) Lock-off
button” in “1. Switch operation” on page 14.
PRIOR TO OPERATION
WARNING
To avoid serious accident, ensure the switch is
in the OFF position, and pull out the battery.
1. Check the work area environment
Check the work area to make sure that it is clear of
debris and clutter.
Clear the area of unnecessary personnel. Ensure that
lighting and ventilation is adequate.
2. Power switch
Ensure that the switch is in the OFF position.
3. Mounting the blade
This unit employs a detachable mechanism that
enables mounting and removal of saw blades without
the use of a wrench or other tools.
(1) Pivot the blade holder to open the blade clamp.
(2) Insert the saw blade all the way into the slit of the
blade holder with the blade holder pivoting.
000BookCR18DBNA.indb12000BookCR18DBNA.indb12 2022/03/2410:13:452022/03/2410:13:45

13
English
5. Adjusting the base (Fig. 12)
To maximize blade life, the base slides in or out
to allow the stroke length to be adjusted for better
efficiency.
(1) Remove the hexagonal bar wrench from its storage
spot, and use it to loosen the 2 base stopper screws
at the bottom of the front cover.
(2) Adjust the attachment position of the base.
(3) Firmly tighten the 2 base stopper screws that were
loosened.
Base
Hexagonal bar wrench
Base stopper screws
(2 locations)
Fig. 12
WARNING
To avoid injury and damage, do not operate the
saw without the base in place. The blade holder
may strike against the workpiece and damage
the reciprocating mechanism.
6. Check battery insertion
WARNING
If the battery is inserted while the power switch
is in the ON position, the power tool will start
operating immediately, inviting serious accident.
CAUTION
Until the battery locks in place with a little click,
if not, it may accidentally fall out of the tool
causing injury to you or someone around you.
HOUSING THE HEXAGONAL BAR WRENCH
Insert all the way
Hexagonal bar wrench
Fig. 13
4. Dismounting the blade
CAUTION
Never touch the saw blade immediately after use.
The metal is hot and can easily burn your skin.
(1) After pivoting the blade holder, point the blade
downward. The blade should fall out on its own. If the
blade fails to fall out, pull it out by hand.
WHEN THE BLADE IS BROKEN
Even when the saw blade is broken and remains inside
the slit of the blade holder, it should fall out when
the blade holder is pivoted and the blade is pointed
downward. If the blade fails to fall out on its own, take it
out by using the procedures described below.
(1) If a part of the broken saw blade is sticking out of the
slit of the blade holder, pull out the protruding part
and take the blade out.
(2) If the broken saw blade is hidden inside the slit, hook
the broken blade using a tip of another saw blade and
take it out. (Fig. 10)
Another blade
Slit of the blade holder
Fig. 10
MAINTENANCE AND INSPECTION OF SAW BLADE
MOUNT
(1) After use, blow away sawdust, earth, sand, moisture,
etc., with air or brush them away with a brush, etc., to
ensure that the blade mount can function smoothly.
NOTE
Continued use of the tool without cleaning the
area where the saw blade is attached can result in
sawdust and chip buildup which may adversely affect
the movement of the blade holder. Should this be the
case, pivot the blade holder and clean around the
blade holder by wiping or blowing away the buildup.
CAUTION
Do not use any saw blade with a worn-out blade
hole. Otherwise, the saw blade can come off,
resulting in personal injury. (Fig. 11)
Blade hole
Blade
Fig. 11
000BookCR18DBNA.indb13000BookCR18DBNA.indb13 2022/03/2410:13:452022/03/2410:13:45

14
English
OPERATION
WARNING
● Never touch the moving parts.
● Do not remove the front cover (refer to Fig. 2).
Be sure to hold the body from the top of the front
cover.
CAUTION
● Be careful not to let sawdust, earth, moisture,
etc., enter the inside of the machine through the
plunger section during operation. If sawdust
and the like accumulate in the plunger section,
always clean it before use.
● During use, press the base against the material
while cutting.
Vibration can damage the saw blade if the base
is not pressed firmly against the workpiece.
Furthermore, a tip of the saw blade can
sometimes contact the inner wall of the pipe,
damaging the saw blade.
● Select a saw blade of the most appropriate
length. Ideally, the length protruding from the
base of the saw blade after subtracting the stroke
should be larger than the material (Fig. 14).
Stroke
Fig. 14
Stroke
If you cut a large pipe, large block of wood, etc.,
that exceeds the cutting capacity of a blade;
there is a risk that the blade may contact with
the inner wall of the pipe, wood, etc., resulting in
damage. (Fig. 15)
Stroke
Stroke
Fig. 15
● To extend the lifetime, the lithium-ion battery
equips with the protection function to stop the
output. Therefore, if the tool is overloaded, the
motor may stop. However, this is not the trouble
but the result of protection function. In this case,
release the switch of tool and eliminate the
causes of overloading.
● Don’t remove the tool from workpiece during a
cut while the saw blade is moving.
NOTE
Take care not to lock the motor. If the motor is locked,
immediately turn the power off. If the motor is locked
for a while, the motor or battery may be burnt.
1. Switch operation
(1) Lock-offbutton
The tool is equipped with a lock-offbutton. To start
the tool, press the lock-offbutton and then squeeze
the trigger switch. (Fig. 16)
Lock-offbutton
Lock-offbutton
Push
Lock
Unlock
Push
Trigger switch
Fig. 16
CAUTION
Do not fix and secure the lock-offbutton.
Besides, keep your finger offthe trigger switch
when the tool is being carried around. Otherwise,
the trigger switch can be inadvertently turned
ON, resulting in unexpected accidents.
000BookCR18DBNA.indb14000BookCR18DBNA.indb14 2022/03/2410:13:462022/03/2410:13:46

15
English
(2) Trigger switch (Fig. 17)
This tool is equipped with a variable speed controlled
trigger switch. The tool can be turned “ON” or
“OFF” by squeezing or releasing the trigger. The
blade plunger stroke rate can be adjusted from the
minimum to maximum nameplate stroke rate by
the pressure you apply to the trigger. Apply more
pressure to increase the speed and release pressure
to decrease speed.
Trigger switch
Fig. 17
2. Stroke Mode
This power tool features a straight mode in which the
blade moves back and forth, and an orbital mode in
which the blade moves back and forth while moving
up and down.
For soft materials such as wood, orbital mode
ensures smooth cutting operation while improving the
discharge of sawdust and the interlock with materials.
Use the change lever to select the ideal mode for the
task at hand. (Fig. 18)
The ideal mode depends on factors such as the
hardness of the material to be cut and the level of
finish required. Use Table 5 as a guideline when
making your choice.
Table 5
Stroke Mode Straight mode Orbital mode
Trajectory of Motion Back and forth action Back and forth action + up and down action
Hardness of Material Hard material Soft material
Cutting Speed Slow Fast
Level of Finish Smooth Rough
NOTE
○ To select the stroke mode, operate the change lever when the product is completely stopped.
○ Select Straight Mode if you wish to cut soft materials neatly.
○ Occasionally clean the change lever as its movement may be adversely affected if dirt or dust collects on the
change lever.
Change Lever
(Straight Mode) Change Lever
(Orbital Mode)
Fig. 18
000BookCR18DBNA.indb15000BookCR18DBNA.indb15 2022/03/2410:13:472022/03/2410:13:47

16
English
3. Cutting operation
<Cutting metallic materials>
CAUTION
● Press the base firmly against the workpiece.
● Never apply any unreasonable force to the saw
blade when cutting. Doing so can easily break
the blade.
● The motor can be locked sometimes, depending
on the combination of the material to be cut and
the blade. Whenever the motor gets locked,
switch it offimmediately.
● Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Reciprocating saw create
sparks which may ignite the dust or fumes.
(1) Fasten a workpiece firmly before operation. (Fig. 19)
Fig. 19
(2) When cutting metallic materials, use proper machine
oil (turbine oil, etc.). When not using liquid machine
oil, apply grease over the workpiece.
CAUTION
The service life of the saw blade will be drastically
shortened if you don’t use machine oil.
<Cutting lumber>
When cutting lumber, make sure that the workpiece is
fastened firmly before beginning. (Fig. 20)
Fig. 20
CAUTION
Never apply any unreasonable force to the saw
blade when cutting. Also remember to press the
base against the lumber firmly.
<Sawing curved lines>
We recommend that you use the BIMETAL blade
mentioned in Page 21 for the saw blade since it is
tough and hardly breaks.
CAUTION
Delay the feed speed when cutting the material
into small circular arcs. An unreasonably fast
feed may break the blade.
<Plunge cutting>
With this tool, you can perform plunge cutting on
plywood panels and thin board materials. You can
carry out plunge cutting quite easily with the saw
blade installed in reverse as illustrated in Fig. 22, 23,
24.
NOTE
If the base is set to the position closest to the tool
body, it becomes easier to make starter holes.
Base stopper screws
(2 locations)
Hexagonal bar
wrench
Base
Fig. 21
Use the saw blade that is as short and thick as
possible. We recommend for this purpose that
you use BI-METAL Blade 725362 mentioned in
Page 21.
Be sure to use caution during the cutting operation
and observe the following procedures.
(1) Press the lower part of the base against the material.
Pull the trigger switch while keeping the tip of the saw
blade apart from the material. (Fig. 22)
(2) Raise the handle slowly and cut in with the saw blade
little by little. (Fig. 23)
(3) Hold the body firmly until the saw blade completely
cuts into the material. (Fig. 24)
000BookCR18DBNA.indb16000BookCR18DBNA.indb16 2022/03/2410:13:472022/03/2410:13:47

17
English
Fig. 24
Fig. 22
Fig. 23
CAUTION
● Avoid plunge cutting for metallic materials. This
can easily damage the blade.
● Never pull the Trigger switch while the tip of the
saw blade is pressed against the material. If you
do so, the blade can easily be damaged when it
collides with the material.
● Make absolutely sure that you cut slowly
while holding the body firmly. If you apply any
unreasonable force to the saw blade during
the cutting operation, the blade can easily be
damaged.
4. How to use the LED light (Fig. 25)
The LED light will light the area at the tip of the tool
when the trigger switch is drawn.
The LED light goes out after releasing the trigger
switch.
LED Light Trigger switch
Fig. 25
CAUTION
● Do not expose directly your eye to the light by
looking into the light.
If your eye is continuously exposed to the light,
your eye will be hurt.
● Wipe offany dirt or grime attached to the lens of
the LED light with a soft cloth, being careful not
to scratch the lens.
Scratches on the lens of the LED light can result
in decreased brightness.
5. LED light warning signals (Fig. 26)
This product features functions that are designed
to protect the tool itself as well as the battery. While
the switch is pulled, if any of the safeguard functions
activate during operation, the LED light will blink as
described in Table 6. When any of the safeguard
functions are triggered, immediately remove your
finger from the switch and follow the instructions
described under corrective action.
Fig. 26
Table 6
Safeguard
Function LED Light Display Corrective Action
Overburden
Protection
On 0.1 second/
off0.1 second Remove the
cause of the
overburdening.
Temperature
Protection
On 0.5 second/
off0.5 second Allow the tool
and battery to
thoroughly cool.
OPERATIONAL CAUTIONS
Resting the unit after continuous work
(1) The power tool is equipped with a temperature
protection circuit to protect the motor.
Continuous work may cause the temperature of the
unit to rise, activating the temperature protection
circuit and automatically stopping operation.
If this happens, allow the power tool to cool before
resuming use.
(2) After use for continuous works, rest the unit for
15 minutes or so when replacing the battery. The
temperature of the motor, switch, etc., will rise if
the work is started again immediately after battery
replacement, eventually resulting in burnout.
000BookCR18DBNA.indb17000BookCR18DBNA.indb17 2022/03/2410:13:482022/03/2410:13:48

18
English
MAINTENANCE AND INSPECTION
WARNING
Be sure to turn offthe switch and pull out the battery before doing any inspection or maintenance.
1. Inspecting the blade
Continued use of a dull or damaged blade will
result in reduced cutting efficiency and may cause
overloading of the motor. Replace the blade with a
new one as soon as excessive abrasion is noted.
CAUTION
If a dull saw blade is used, reactive force is
increased during cutting operation. Avoid the
use of the dull saw blade without repair.
2. Check the Screws
Loose screws are dangerous. Regularly inspect them
and make sure they are tight.
CAUTION
Using this power tool with loosened screws is
extremely dangerous.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the
power tool. Exercise due care to ensure the winding
does not become damaged and/or wet with oil or
water.
4. Check for Dust
Dust may be removed with a soft cloth or a cloth
dampened with soapy water.
Do not use bleach, chlorine, gasoline or thinner, for
they may damage the plastics.
5. Inspection of terminals (tool and battery)
Check to make sure that swarf and dust have not
collected on the terminals.
On occasion check prior, during and after operation.
CAUTION
Remove any swarf or dust which may have collected
on the terminals.
Failure to do so may result in malfunction.
6. Lubrication
The bearings in this tool have been sufficiently
lubricated with quality lubricating oil, taking into
account the expected life of this tool under normal
operating conditions. As a result, no further
lubrication is necessary.
7. Disposal of the exhausted battery
WARNING
Do not dispose of the exhausted battery. The
battery must explode if it is incinerated. The
battery is recyclable. At the end of it’s useful
life, under various state and local laws, it may
be illegal to dispose of this battery into the
municipal waste stream. Check with your local
solid waste officials for details in your area for
recycling options or proper disposal.
8. Storage
Storing in a place below 104°F (40°C) and out of the
reach of children.
NOTE
Storing lithium-ion batteries
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries
with a low charge may result in performance
deterioration, significantly reducing battery usage
time or rendering the batteries incapable of holding a
charge.
However, significantly reduced battery usage time
may be recovered by repeatedly charging and using
the batteries two to five times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries
dead and purchase new batteries.
9. Service and repairs
All quality power tools will eventually require servicing
or replacement of parts because of wear from normal
use. To assure that only authorized replacement
parts will be used, all service and repairs must
be performed by a metabo HPT AUTHORIZED
SERVICE CENTER, ONLY.
CAUTION
In the operation and maintenance of power tools,
the safety regulations and standards prescribed
in each country must be observed.
000BookCR18DBNA.indb18000BookCR18DBNA.indb18 2022/03/2410:13:482022/03/2410:13:48

19
English
Important notice on the batteries for the
metabo HPT cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used
with batteries other than these designated by us, or
when the battery is disassembled and modified (such
as disassembly and replacement of cells or other
internal parts).
TROUBLESHOOTING GUIDE
WARNING
● To avoid injury from an accidental start, turn the switch OFF and remove the plug from the power source
or remove the battery from the main body before making any adjustments.
● All electrical or mechanical repairs should be done only by qualified service technicians. Contact
metabo HPT Authorized Service Center.
Problem Possible Cause Possible Solution
Tool doesn’t run No remaining battery power Charge the battery.
Tool suddenly stopped Tool was overburdened Get rid of the problem causing the
overburden.
During operation, lighten the applied
pressure.
Battery or tool overheated Allow the tool and battery to thoroughly
cool.
The trigger switch was held down for 5
minutes or more. This is not a malfunction. The motor was automatically stopped to
prevent failure of the tool.
Saw blade
-can’t be attached
-fall off
The shape of the attachment portion
doesn’t match Use the appropriate blade
The blade’s attachment hole is worn Replace with a new blade.
Switch can’t be pulled Lock-offbutton is pushed in Release the Lock-offbutton.
An abnormal high-pitched
noise occurs when the
trigger switch is pulled.
The trigger switch is being pulled only
slightly. This is not a malfunction. It does not occur if the trigger switch is
pulled more fully.
Blade wears out too quickly. Proper machine oil not used when cutting
metallic materials Use machine oil (turbine oil, etc.)
Too much applied pressure during
operation During operation, lighten the applied pressure.
Unable to properly cut. Blade is inappropriate for the quality and
thickness of the material to be cut Use the proper blade
Blade is too short for the length of the
material to be cut
Blade is worn, degraded or damaged Replace with a new blade.
Battery cannot be installed Attempting to install a battery other than
that specified for the tool. Please install batteries that are multi volt or BSL18xx series.
000BookCR18DBNA.indb19000BookCR18DBNA.indb19 2022/03/2410:13:482022/03/2410:13:48

20
English
ACCESSORIES
WARNING
ALWAYS use Only authorized metabo HPT replacement parts and accessories. NEVER use replacement
parts or accessories which are not intended for use with this tool. Contact metabo HPT if you are not
sure whether it is safe to use a particular replacement part or accessory with your tool.
The use of any other attachment or accessory can be dangerous and could cause injury or mechanical
damage.
NOTE: Accessories are subject to change without any obligation on the part of the metabo HPT.
STANDARD ACCESSORIES
CR18DB
(NN)
1 Blade ...................................................................................................... 1
Battery, battery charger, plastic case and battery cover are not contained.
OPTIONAL ACCESSORIES
1. Battery (BSL1830C)
2. Battery charger (UC18YFSL)
3. Battery cover (Code No. 329897)
000BookCR18DBNA.indb20000BookCR18DBNA.indb20 2022/03/2410:13:482022/03/2410:13:48
