Metabo BS 200 Manual

54 |
Safe eye protection
The large protective guards provide
effective protection against flying sparks.
Fatigue-free working
The workpiece supports can be adjusted
without tools, allowing you to work
accurately and comfortably.
Long service life
Grinding wheels of 200 mm diameter
last 50% longer than grinding wheels
of 175 mm diameter; grinding wheels
with a diameter of 250 last even
145 % longer.
ESSENTIAL FOR EVERY WORKSHOP.
Good tools are worth their weight in gold and should
always be in perfect working order. For example, rust
needs to be removed, chisels need to be sharpened,
HSS bits re-ground. Whether you want to clean, grind,
deburr or polish: Metabo has the right grinding
machine for every task.
Large eye shield
for optimum protection
from flying sparks.
e.g. BS 200
Powerful induction
motor
for low-noise, mainte-
nance-free operation.
Rotor shaft mounted on
ball bearings
for long service life
of the machine
Fully closed protective
cover.
450 mm adjustable
grinding arm.
Workpiece support plates can be
readjusted without tools.
GRINDING MACHINES

| 55
DS 175 D
DS 150 W
DS 125 W DS 175 W
BENCH GRINDERS
Special advantages
For single phase alternating
current

For three phase current 
Comparative device characteristics
Grinding wheels
(Øx thickness x bore)
125 x 20 x 20 mm 150 x 20 x 20 mm 175 x 25 x 20 mm 175 x 25 x 20 mm
Maximum speed 2.950 /min 2.950 /min 2.950 /min 2.950 /min
Bore with distance sleeve (Ø) 12 mm 13 mm 17 mm 17 mm
Rated input power 200 W 330 W 450 W 570 W
Tilting movement 0,6 Nm 0,7 Nm 1,6 Nm 1,4 Nm
Dimensions L x W x H 265 x 180 x 185 mm 325 x 190 x 200 mm 395 x 220 x 250 mm 395 x 220 x 250 mm
Base plate 137 x 147 mm 137 x 147 mm 147 x 187 mm 147 x 187 mm
Weight 5,5 kg 7,5 kg 12,5 kg 12,5 kg
Standard equipment Normal corundum
grinding wheels 36 P and
60 N, spark protection
guards, workpiece
support plates
Normal corundum
grinding wheels 36 P and
60 N, spark protection
guards, workpiece
support plates
Normal corundum
grinding wheels 36 P and
60 N, spark protection
guards, workpiece
support plates
Normal corundum
grinding wheels 36 P and
60 N, spark protection
guards, workpiece
support plates
Type DS 125 W DS 150 W DS 175 W DS 175 D
Order no. 0300012540 0300015034 0300017533 0300017541
COMMON FEATURES

For sanding/grinding, sharpening, deburring and removing rust
on steel and metal, kitchen appliances, tools and garden tools

Quiet, maintenance-free induction motor

Large spark protection guards for optimum eye protection
Bench Grinder
DS 125 W
Bench Grinder
DS 150 W
Bench Grinder
DS 175 W
Bench Grinder
DS 175 D
ANGLE GRINDERSMETAL PROCESORSHAMMERSIMPACT DRILLSDRILLSSCREWDRIVERS
WOOD SANDING
MACHINES
ROUTERS
AND PLANERS

56 |
DS 200/25 DDS 200/25 W
BENCH GRINDERS
Special advantages
For single phase
alternating current

For three phase current 
Comparative device
characteristics
Grinding wheels
(Øx thickness x bore)
200 x 25 x 20 mm 200 x 25 x 20 mm
Maximum speed 2.950 /min 2.950 /min
Bore with distance sleeve (Ø) 17 mm 17 mm
Rated input power 580 W 740 W
Tilting movement 1,9 Nm 2 Nm
Dimensions L x W x H 420 x 255 x
265 mm
420 x 255 x
265 mm
Base plate 147 x 187 mm 147 x 187 mm
Weight 16 kg 16 kg
Standard equipment Normal corundum
grinding wheels
36 P and 60 N,
spark protection
guards, workpiece
support plates
Normal corundum
grinding wheels
36 P and 60 N,
spark protection
guards, workpiece
support plates
Type DS 200/25 W DS 200/25 D
Order no. 0300020003 0300020011
COMMON FEATURES

For sanding/grinding, sharpening, deburring and removing rust
on steel and metal, kitchen appliances, tools and garden tools

Quiet, maintenance-free induction motor

Large spark protection guards for optimum eye protection
Bench Grinder
DS 200/25 W
Bench Grinder
DS 200/25 D Sander/Grinder stands
Order no.
Sander/Grinder stands
For all blue bench grinders,
belt sanders, and wet
or dry sanding/grinding
machines
Made of robust sheet
steel with water container
Height: 805 mm
0900051204
Sander/Grinder bracket
Order no.
Sander/Grinder bracket
For all blue bench grinders,
belt sanders, and wet or dry
sanding/grinding machines
Made of robust sheet steel
(wall mounting)
0900051212

| 57
TNS 150 W TNS 175 W BS 200 W BS 200 D
GRINDING MACHINES
Comparative device
characteristics
Grinding wheels
(Øx thickness x bore)
150 / 200 x 20 /
40 x 20 / 20 mm
175 / 200 x 25 /
40 x 20 / 20 mm
Maximum speed 2.750/126 /min 2.750/126 /min
Bore with distance
sleeve (Ø)
13/12 mm 17/12 mm
Rated input power 330 W 450 W
Tilting movement 0,7 Nm 1,6 Nm
Dimensions L x W x H 420 x 255 x
260 mm
490 x 260 x
285 mm
Base plate 137 x 147 mm 147 x 187 mm
Weight 8 kg 14 kg
Standard equipment Normal corundum
grinding wheels
60 N and wet
grinding disc,
workpiece
support plates,
spark protection
guards
Normal corundum
grinding wheels
60 N and wet
grinding disc,
workpiece
support plates,
spark protection
guards
Type TNS 150 W TNS 175 W
Order no. 0000415014 0000517526
COMMON FEATURES

For single phase alternating current

For sanding/grinding, sharpening, deburring and
removing rust on steel and metal, kitchen appliances,
tools and garden tools

Quiet, maintenance-free induction motor

Large spark protection guards for optimum eye protection

Corrosion-proof water bath container

Slow running, fine grained wet grinding disc and
quick running dry grinding disc
Dry-wet Grinder
TNS 150 W
Dry-wet Grinder
TNS 175 W
Special advantages
For single phase
alternating current

For three phase
current

Comparative device
characteristics
Grinding wheels
(Øx thickness x bore)
200 x 25 x 20 mm 200 x 25 x 20 mm
Maximum speed 2.650 /min 2.950 /min
Bore with distance
sleeve (Ø)
17 mm 17 mm
Rated input power 580 W 740 W
Tilting movement 1,9 Nm 2 Nm
Belt length 450 mm 450 mm
Sanding belt 1.020 x 50 mm 1.020 x 50 mm
Dimensions L x W x H 420 x 255 x
265 mm
420 x 255 x
265 mm
Base plate 147 x 187 mm 147 x 187 mm
Weight 16 kg 16 kg
Standard equipment Normal corund-
um grinding
wheels 60 N and
fabric grinding
belt K 60, work-
piece support
plates, spark pro-
tection guards
Normal corund-
um grinding
wheels 60 N and
fabric grinding
belt K 60, work-
piece support
plates, spark pro-
tection guards
Type BS 200 W BS 200 D
Order no. 0000320005 0000320013
COMMON FEATURES

For sanding/grinding, sharpening, deburring and
removing rust on steel and metal, kitchen appliances,
tools and garden tools

Quiet, maintenance-free induction motor

Large spark protection guards for optimum
eye protection

For finishing wood and metal workpieces

The belt sanding attachment can be operated
in horizontal and vertical positions
Belt Sander
BS 200 W
Belt Sander
BS 200 D
ANGLE GRINDERSMETAL PROCESORSHAMMERSIMPACT DRILLSDRILLSSCREWDRIVERS
WOOD SANDING
MACHINES
ROUTERS
AND PLANERS

58 |
ACCESSORIES FOR GRINDING MACHINES
FOR DOUBLE GRINDERS
Grinding wheels, coarse
Suitable for: Pre-grinding,
Screwdriver, Chisel, Splitting
tools, Unhardened metals
Diameter
x thickness
x bore
mm
Grit and
grade
Suitable for Order no.
120 x 20 x 20 36 P DS 125 W 0900025181
150 x 20 x 20 36 P DS 150 W 0900025262
175 x 25 x 20 36 P DS 175 W / DS 175 D 0900025408
200 x 25 x 20 36 P DS 200/25 W /
DS 200/25 D
0900025513
Grinding wheels, fine
Suitable for: Finishing,
Screwdriver, Chisel, Firmer
chisel, Turning chisel,
Carving knife, Splitting tools,
Unhardened metals
Diameter
x thickness
x bore
mm
Grit and
grade
Suitable for Order no.
120 x 20 x 12 60 N DS 125 W 0900025254
120 x 20 x 20 60 N DS 125 W 0900025190
150 x 20 x 20 60 N DS 150 W 0900025270
175 x 25 x 20 60 N DS 175 W / DS 175 D 0900025416
200 x 25 x 20 60 N DS 200/25 W /
DS 200/25 D
0900025521
Widia grinding wheels
Suitable for: Finishing, Hard metals, Grey cast iron, Copper,
Aluminium, Glass, Ceramic
Diameter
x thickness
x bore
mm
Grit and
grade
Suitable for Order no.
120 x 20 x 20 80 J DS 125 W 0900025203
150 x 20 x 20 80 M DS 150 W 0900025289
175 x 25 x 20 80 J DS 175 W / DS 175 D 0900025424
200 x 25 x 20 80 J DS 200/25 W /
DS 200/25 D
0900025556
FOR DRY-WET GRINDERS
Wet grinding wheels
Suitable for: Finishing, Blade,
Firmer chisel, Turning chisel,
Carving knife, Splitting tools,
Shears, Unhardened metals
Diameter x thickness x bore
mm
Order no.
150 x 30 x 20 0900025386
200 x 40 x 20 0900025653
FOR BELT GRINDING MACHINES
Sanding belts
Dimensions
mm
Grit Packing unit Order no.
50 x 650 P 60 3 0900025718
50 x 650 P 100 3 0900025726
50 x 650 P 150 3 0900025734
50 x 650 P 220 3 0900025742
50 x 650 P 400 3 0900025769
50 x 1.020 P 40 3 0900025777
50 x 1.020 P 60 3 0900025688
50 x 1.020 P 80 3 0900025696
50 x 1.020 P 100 3 0900025785
50 x 1.020 P 120 3 0900025700
50 x 1.020 P 180 3 0900025807
50 x 1.020 P 240 3 0900025823
50 x 1.020 P 400 3 0900025840
Dressing stick
Order no.
Dressing stick 100 x 25 x 13 mm
For the dressing of grinding wheels:
blunt grinding abrasives
are removed
0900025858
Which grinding wheel is suitable for which application?
Grinding wheel, coarse Grinding wheel, fine Tungsten
grinding wheel
Wet grinding wheel
(natural stone, ceramics)
Rough sanding 
Finishing 
Screwdriver 
Chisel 
Knife blade 
Firmer chisel 
Turning chisel 
Carving knife 
Splitting tool  
Shears 
Unhardened metals  
Hard metals 
Grey cast iron 
Copper 
Aluminium 
Glass 
Ceramics 

| 59
Ds W 5175 Ds W 9200
BENCH GRINDERS
Special advantages
Grinding wheel diameter 200 mm:
50 % higher tool life compared
to a grinding wheel with 175 mm Ø

Comparative device characteristics
Grinding wheels (Øx thickness x bore) 175 x 25 x 32 mm 200 x 25 x 32 mm
Maximum speed 2.840 /min 3.000 /min
Rated input power 500 W 500 W
Output power 370 W 370 W
Tilting movement 1,8 Nm 3,6 Nm
Extraction nozzle, internal Ø 41 mm 41 mm
Work bench model:
Weight 15 kg 16 kg
Stand model:
Height to centre of grinding shaft 1.010 mm 1.025 mm
Weight 34 kg 35 kg
Standard equipment Normal corundum grinding wheels 36 P
and 80 M, spark protection guards,
workpiece support plate
Normal corundum grinding wheels 36 P
and 80 M, spark protection guards,
workpiece support plate
Type Ds W 5175 Ds W 9200
Order no. 6.05175 6.09200
COMMON FEATURES

For single phase alternating current

Quiet, high quality maintenance-free induction motor

Emergency stop switch for optimum safety of the user

Sturdy machine for sophisticated sharpening,
grinding and deburring tasks

Rotor shaft mounted on ball bearing for long service
life of the machine

Adjustable workpiece supports without tools

Protective covers closed on the sides with extraction nozzle

Large spark protection guards for optimum eye protection
500 Watt
Bench Grinder
Ds W 5175
500 Watt
Bench Grinder
Ds W 9200
– bench model
– floor model 6.05175 + 6.23866 6.09200 + 6.23866
ANGLE GRINDERSMETAL PROCESORSHAMMERSIMPACT DRILLSDRILLSSCREWDRIVERS
WOOD SANDING
MACHINES
ROUTERS
AND PLANERS

60 |
Ds D 6175 Ds D 9201 Ds D 9250
BENCH GRINDERS
Special advantages
Sturdy machine for sophisticated
sharpening, grinding and
deburring tasks

Sturdy machine for industrial use 
Grinding wheel diameter
200 mm: 50 % higher tool life
compared to a grinding wheel
with 175 mm Ø

Grinding wheel diameter
250 mm: 145 % higher tool life
compared to a grinding wheel
with 175 mm Ø

Comparative device characteristics
Grinding wheels
(Øx thickness x bore)
175 x 25 x 32 mm 200 x 25 x 32 mm 250 x 40 x 51 mm
Maximum speed 2.840 /min 3.000 /min 1.500 /min
Rated input power 550 W 550 W 900 W
Output power 400 W 400 W 620 W
Tilting movement 3,6 Nm 7,2 Nm 8 Nm
Extraction nozzle, internal Ø 41 mm 41 mm 35 mm
Work bench model:
Weight 15 kg 16 kg 33 kg
Stand model:
Height to centre of grinding shaft 1.010 mm 1.025 mm 1.025 mm
Weight 34 kg 35 kg 52 kg
Standard equipment Normal corundum grinding
wheels 36 P and 80 M,
spark protection guards,
workpiece support plate
Normal corundum grinding
wheels 36 P and 80 M,
spark protection guards,
workpiece support plate
Normal corundum grinding
wheels 36 P and 80 M,
spark protection guards,
workpiece support plate
Type Ds D 6175 Ds D 9201 Ds D 9250
Order no. 6.06175 6.09201 6.09250
COMMON FEATURES

For three phase current

Quiet, maintenance-free induction motor

Rotor shaft mounted on ball bearing for long service
life of the machine

Adjustable workpiece supports without tools

Protective covers closed on the sides with extraction nozzle

Large spark protection guards for optimum eye protection
550 Watt
Bench Grinder
Ds D 6175
550 Watt
Bench Grinder
Ds D 9201
900 Watt
Bench Grinder
Ds D 9250
– bench model
– floor model 6.06175 + 6.23866 6.09201 + 6.23866 6.09250 + 6.23866

| 61
ACCESSORIES FOR BENCH GRINDERS
Grinding wheels, aluminium oxide
For sanding/grinding tool steel
Diameter
x thickness
x bore
mm
Grit and
grade
Suitable for Order
no.
150 x 20 x 20 36 P Ds W 3150 6.30632
150 x 20 x 20 80 M Ds W 3150 6.30633
150 x 20 x 32 36 P Ds 7202 6.30777
150 x 20 x 32 80 M Ds 7202, Ds 7203 6.30778
175 x 20 x 32 36 P Ds 7204 6.30780
175 x 20 x 32 80 M Ds 7204 6.30781
175 x 25 x 32 36 P Ds W 5175 / Ds D 6175 6.30657
175 x 25 x 32 60 N Ds W 5175 / Ds D 6175 6.30656
200 x 25 x 32 36 P Ds W 9200 / Ds D 9201 6.30647
200 x 25 x 32 60 N Ds W 9200 / Ds D 9201 6.30646
200 x 25 x 32 36 P Ds 7211, Ds W 9200 /
Ds D 9201
6.30784
200 x 25 x 32 60 N Ds 7211, Ds W 9200 /
Ds D 9201
6.30785
200 x 32 x 32 36 P Ds W 9200 / Ds D 9201 6.30634
200 x 32 x 32 60 N Ds W 9200 / Ds D 9201 6.30635
250 x 32 x 32 24 Q Ds 7226 6.30788
250 x 32 x 32 60 N Ds 7226 6.30789
250 x 40 x 51 36 P Ds D 9250 6.30636
250 x 40 x 51 60 N Ds D 9250 6.30637
Pink aluminium oxide grinding wheels
For sanding/grinding HPHSS tools
Diameter
x thickness
x bore
mm
Grit and
grade
Suitable for Order
no.
150 x 20 x 20 80 J Ds W 3150 6.30638
Silicon carbide grinding wheels
For sanding/grinding carbide tools
Diameter
x thickness
x bore
mm
Grit and
grade
Suitable for Order
no.
150 x 20 x 20 46 K Ds W 3150 6.30755
150 x 20 x 20 80 J Ds W 3150 6.30756
Accessories
Order
no.
Stand for bench grinders
For bench grinders from 175 mm
grinding wheel diameter
Height: 820 mm
Weight: 19 kg
6.23866
Order
no.
Wall panel for double grinders 6.23863
ANGLE GRINDERSMETAL PROCESORSHAMMERSIMPACT DRILLSDRILLSSCREWDRIVERS
WOOD SANDING
MACHINES
ROUTERS
AND PLANERS
