MetaLife Reformer Tower Technical Document

Equipment Manual
REFORMER TOWER
Review January 10, 2020

2
THIS MANUAL CONTAINS ESSENTIAL INFORMATION FOR THE USE OF YOUR EQUIPMENT.
PLEASE READ IT CAREFULLY BEFORE STARTING INSTALLATION AND OPERATION. PRESERVE
AND KEEP IT FOR FUTURE CONSULTATIONS.
Equipment manual
REFORMER TOWER
Throughout this manual, this symbol on the left will indicate extremely
important information that must be read, understood and strictly followed.

3
TABLE OF CONTENTS
Product presentation............................................................4
Technical specifications ........................................................ 5
Packaging content................................................................. 6
Installation manual ............................................................... 8
Components.......................................................................... 8
Preparation for assembly.................................................... 10
Detailed assembly...............................................................11
User manual........................................................................13
Preparing the Reformer for use with the Tower.................13
Uses and settings ................................................................14
Maintenance and safety .....................................................17
Warranty Term....................................................................20

4
PRODUCT PRESENTATION
The equipment has a structure built in carbon steel and eyebolts for fitting stainless
steel springs. It also has 21 eyes for adjusting the springs and three points for
height adjustment of the Support Bar.
The Reformer Tower comprises two pieces of equipment traditionally used in
Pilates classes: the classic Reformer and the Wall Unit. According to Letícia Toledo,
technical coordinator at Pilates StudioFit, the novelty focuses mainly on the body's
natural movements, obtaining significant benefits in a regular practice.

5
TECHNICAL SPECIFICATIONS
A
DIMENSION
REFORMER
TOWER
HIGH REFORMER
TOWER
A
1.96m
2.18m
B
0.82m
0.82m
25 KG
Note: The weight of the
equipment may change due to
the density variation of the raw
material used in its
manufacture.
B
