MetaSystem BLE42 Operating manual

L’utilizzo della mobile APP per l’arming del prodotto esclude temporaneamente la ricezione della
Card B9.5 , per ripristinare la ricezione automatica premere il tasto della Card B9.5 in prossimità
del modulo BLE42.
Nuovo Modulo
Blocco Avviamento Bluetooth
Manuale Uso e Installazione
IT
Il nuovo modulo BLE42 ha la possibilità di essere abbinato ad una SmartPhone App le cui funzionalità sono descritte all’in-
terno del manuale disponibile Online e scaricabile dal menu della App stessa. Per una corretta gestione del prodotto
tramite App suggeriamo di incollare qui l’etichetta bianca autoadesiva che sigilla la confezione della centrale anti-
furto. Conservare queste indicazioni in un luogo sicuro, saranno utili per aggiornamenti di prodotto e accessori opzionali.
Suggeriamo di scrivere in questo spazio la Password personalizza-
ta per l’abbinamento allo SmartPhone da utilizzare nel caso si voglia
abbinare al prodotto un ulteriore SmartPhone. Password:
5040351901
AVVERTENZE DI SICUREZZA
I simboli grafici posti sull’apparecchiatura indicano di attenersi alle specifiche informazioni con-
tenute in questo manuale. Essi indicano il pericolo che i materiali interni al prodotto possono
causare e sono utilizzati per salvaguardare la salute di ogni utilizzatore.
ATTENZIONE! PERICOLO D’ESPLOSIONE SE LA BATTERIA E’ SOSTITUITA CON ALTRA DI TIPO ERRATO.
SMALTIRE LE BATTERIE USATE SEGUENDO LE SPECIFICHE ISTRUZIONI DEDICATE PER LO SMALTIMENTO.
Non ingerire la batteria, pericolo di ustione chimica.
Questo prodotto contiene una batteria con elemento a moneta/bottone. Se la batteria con elemento a moneta/bot-
tone viene ingerita, può provocare gravi ustioni interne in sole 2 ore e portare
alla morte.
Tenere le batterie nuove e usate fuori dalla portata dei bambini. Se il comparto batterie non si chiude saldamente,
sospendere l’uso del prodotto e tenerlo fuori dalla portata dei bambini. In caso di sospetta ingestione delle batterie
rivolgersi immediatamente a un medico.

1. CARATTERISTICHE TECNICHE
Alimentazione: ......................................................................................................................................12Vdc/24Vdc
Dimensioni:.........................................................................................................................................70x52x22mm
Assorbimento:.................................................................................................................<5mAmp(aquadroOFF)
Frequenza radio (Bluetooth Low Energy): ................................................2,402 Ghz ÷ 2,480 GHz (<10mW)
Corrente max a 12V del blocco avviamento (C/NC): .........................................................................25 Amp
Corrente max a 24V del blocco avviamento (C/NC): .........................................................................10 Amp
Temperature di funzionamento: .......................................................................................................-30°C /+85°C
2. INGRESSI/USCITE
Alimentazione principale (+30 / GND)
Ingresso segnale positivo sottochiave (+15)
Ingresso/uscita per Pulsante/Led di Override
Uscite OUT1/OUT2/OUT3 programmabili: Attive a GND corrente max 500mA
ATTENZIONE: la CARD B9.5 presente all’interno della
confezione non è attiva, per attivarla è necessario
premere 5 volte il tasto. Per associare ulteriori card
è necessario utilizzare il programmatore PRG007V3
ed il cavo programmazione 2010337600.
Per la selezione delle varie funzioni di prodotto utilizzare
esclusivamente il
programmatore PRG007 V3
.
L’aggiornamento software del
programmatore PRG007
V3
e le informazioni relative alle funzioni programmabili
sono disponibili ON LINE sul sito www.metasystem.it
nell’AREA TECNICA/AREA VEICOLI.
CAVO PROGRAMMAZIONE BLE42
MetaSystem code: 2010337600
PROGRAMMATORE PRG007 V3
MetaSystem code: ABS15090
3. SET-UP PRODOTTO
CARD
B9.5
BLE42
Fig. 1
OUT1
OUT2
OUT3
NERO
PULSANTE/LED
ROSSO
RELE’ INTERNO PER
BLOCCO AVVIAMENTO
ARANCIONE
USCITE
PROGRAMMABILI
POSITIVO
BATTERIA (+30)
MASSA
POSITIVO
SOTTOCHIAVE
SET-UP DI FABBRICA
Out 1 = Set-Up Uscita Codicata
Out 2 = Set-Up Dipendente da Card
Out 3 = Set-Up Uscita Clacson
Paragrafo 3
ATTIVAZIONE CARD
4. SCHEMA GENERALE
BLE42 Immobilizer
SN: 123456789012345678
MAC: B12345678901
Pin Code: 23456
PUK Code: 123456
Code: A6015941
MAC
ADDRESS
PIN CODE
DI FABBRICA
2

5. DESCRIZIONE DEL MODULO BLE42
Il modulo BLE42 è stato studiato per l’applicazione all’interno dell’abitacolo e blocca automaticamente l’avviamento del
veicolo una volta spento il quadro strumenti se non è presente la propria Card B9.5.
Il modulo include al suo interno un relè di blocco avviamento (C-NC) che si attiva solo in caso che all’accensione del qua-
dro strumenti non sia stata riconosciuta la propria Card B9.5.
Oltre al relè interno di blocco avviamento sono disponibili 3 uscite programmabili che consentono di eseguire le seguenti
funzionalità:
1. Comandare dei relè esterni codificati (Set-Up Uscita Codificata).
2. Attivare un relè esterno per effettuare un blocco avviamento in funzione della assenza della Card B9.5 (Set-Up
Dipendente da Card).
3. Comandare un avvisatore acustico (Set-Up Uscita Clacson).
4. Pilotare il pulsante Hazard per attivare gli indicatori di direzione (Set-Up Pulsante Hazard).
All’interno dei paragrafi che seguono verranno descritte le varie tipologie di funzionamento dandone i dettagli.
6. FUNZIONALITA’ DEL MODULO BLE42
ATTIVAZIONE DELLA PROTEZIONE ALL’AVVIAMENTO
Allo spegnimento del quadro strumenti il modulo BLE42 entra in modalità di pre-attivazione, il LED si accende fisso; la
completa attivazione del sistema avviene solamente dopo 50 secondi di mancanza di comunicazione con il dispositivo di
sblocco (Card B9.5) ed è indicata da un lampeggio lento del LED (1 flash ogni 5 sec).
Nota: Se prima della completa attivazione si accende il quadro strumenti il modulo si disinserisce e il LED si spegne.
RILEVAMENTO DEL PROPRIO DISPOSITIVO DI SBLOCCO CON QUADRO STRUMENTI SPENTO
Con il quadro strumenti spento la presenza del proprio dispositivo di sblocco (Card B9.5) è sempre indicato dal LED che
si accende fisso, in questa condizione il blocco avviamento è pronta ad essere sbloccato grazie all’attivazione del quadro
strumenti.
DISATTIVAZIONE DELLA PROTEZIONE ALL’AVVIAMENTO
Alla accensione del quadro strumenti il modulo BLE42 si disinserisce in presenza del proprio dispositivo di sblocco (Card
B9.5) e il LED si spegne. In caso il dispositivo di sblocco (Card B9.5) sia stato smarrito o abbia la batteria scarica è possibile
disattivare il modulo BLE42 tramite l’introduzione di un codice di sicurezza Override, il PIN CODE di fabbrica è riportato
sull’adesivo consegnato con il prodotto (Fig.1) ed è personalizzabile con il programmatore PRG007.
7. INDICAZIONI DEL LED DI STATO DEL MODULO BLE42
Il LED di stato consente di avere alcune indicazioni del sistema e nella tabella seguente vengono elencati i significati:
LED CON LAMPEGGIO RAPIDO
(1 flash ogni 1 sec) Fase di allarme per tentativo di
avviamento a prodotto inserito
LED CON LAMPEGGIO LENTO
(1 flash ogni 5 sec) Protezione all’avviamento attiva e QUADRO OFF
LED ACCESO FISSO QUADRO OFF e sistema abilitato al disinseri-
mento
LED SPENTO Protezione all’avviamento
disattiva e QUADRO ON
LED ESEGUE 2 LAMPEGGI RAVVICINATI Indicazione di batteria Card B9.5 in esauri-
mento e QUADRO ON
LED ACCESO FISSO PER 5 SEC.
ALL’ATTIVAZIONE QUADRO Funzione SERVICE MODE abilitata
3

Fig.2
INSTALLARE
UN RELE’
SUPPLEMENTARE
CLACSON
COMANDO
ORIGINALE
CLACSON
OUT (1/2/3)
BLE42
Fig.3b
INSTALLARE
UN RELE’
SUPPLEMENTARE
DA 25A
MOTORINO
DI
AVVIAMENTO
BLOCCO CHIAVE
AVVIAMENTO
TAGLIARE FILO
ORIGINALE
OUT (1/2/3)
BLE42
RELE’
CODIFICATO BLOCCO
AVVIAMENTO
STANDARD
BLE42
OUT (1/2/3)
C
NC
C
NC
BLU
MARRONE
MARRONE
VERDE
VERDE
ROSSO
NERO
Fig.4
INSTALLARE UN RELE’
SUPPLEMENTARE
SE CLACSON SOTTOCHIAVE
CLACSON
COMANDO
ORIGINALE
CLACSON
RELE’
CLACSON
D’ORIGINE
OUT (1/2/3)
BLE42
Fig.5
Fig.6
NEGATIVE PULSE
COMMAND
NO COMMAND
25 SEC.
1 SEC.
1 SEC.
PILOTAGGIO
CLACSON
PILOTAGGIO
CLACSON
PILOTAGGIO
PULSANTE HAZARD
Fig.3a
BLE42
BLOCCO CONSENSO
ALL’AVVIAMENTO
LINEA CONSENSO
ALL’AVVIAMENTO
+30/F POSITIVO FISSO CON
FUNZIONE SLEEP MODE
OUT (1/2/3)
Set-Up Uscita Codificata Set-Up
Dipendente da Card
Set-Up Uscita Clacson
Set-Up Pulsante Hazard
Set-Up
Dipendente da Card
Set-Up Uscita Clacson
RELÉ 1
RELÉ 2
8. FUNZIONALITA’ USCITE PROGRAMMABILI DEL MODULO BLE42
Il modulo BLE42 ha 3 uscite programmabili utilizzabili per vari scopi, nei paragrafi che seguono sono illustrate le varie
opzioni possibili.
1. In caso sia stata selezionata l’uscita codificata nel momento in cui il modulo passa in condizione di completa attiva-
zione i relè esterni vengono armati e aprono i loro contatti ripristinandoli solo alla successiva ricezione del comando
di sblocco ricevuto dal modulo BLE42 (Fig.2).
2. In caso sia stata selezionata l’uscita in conseguenza della presenza della Card B9.5 l’uscita verrà sempre attivata in
assenza della Card ed è quindi possibile utilizzare un relè esterno standard per impedire, con modulo BLE42 inserito,
l’avviamento ad ogni attivazione del quadro strumenti o del +30 con funzione SLEEP (Fig.3a/3b).
3. In caso l’uscita sia stata selezionata come pilotaggio clacson questa produrrà un ciclo di ON/OFF di 25 secondi se
viene acceso il quadro strumenti con modulo BLE42 inserito; il ciclo di segnalazione clacson inizierà 10 secondi dopo
aver attivato il quadro strumenti e si concluderà solo al termine dei 25 sec anche in caso il quadro strumenti venga
spento durante il ciclo. Nel caso il quadro strumenti rimanga acceso per un tempo superiore ai 25 sec verranno ripetu-
ti cicli di ON/OFF di pilotaggio del clacson per un massimo di 10 e intervallati tra loro da una pausa di 5 sec. (Fig.4/5).
4. In caso l’uscita sia stata selezionata come pilotaggio pulsante Hazard questa produrrà un ciclo di ON/OFF degli indi-
catori di direzione della durata di 25 secondi se viene acceso il quadro strumenti con modulo BLE42 inserito; il ciclo
di segnalazione clacson inizierà 10 secondi dopo aver attivato il quadro strumenti e il tipo di segnale di pilotaggio è
quello illustrato in Fig.6.
4

9. RELE’ INTERNO DI AVVIAMENTO BLOCCO
Per il blocco avviamento è disponibile un relè interno al modulo BLE42 i cui contatti C e NC sono accessibili dall’esterno
tramite la connessione ai 2 Faston da 6,3 mm (Fig.7/8). La logica di attivazione del relè interno di blocco avviamento
prevede che i contatti del relè vengano aperti nel caso di accensione del quadro strumenti con modulo BLE42 inserito.
Fig.7 Fig.8
INIEZIONE
ELETTRONICA
POMPA
BENZINA
C
INSTALLARE UN RELE’
SUPPLEMENTARE
DA 30A
MOTORINO
DI
AVVIAMENTO
BLE42 BLE42
NC
C
NC
TAGLIARE FILO
ORIGINALE
TAGLIARE FILO
ORIGINALE
10.1 SISTEMA DI DISATTIVAZIONE D’EMERGENZA CON CODICE OVERRIDE
Nel caso si smarrisca la CARD o questa abbia la batteria scarica è possibile disattivare il modulo BLE42 tramite l’introdu-
zione di un codice di sblocco Override (Pin Code). Tramite il programmatore PRG007 è possibile selezionare se utilizzare
un codice a 3 o 5 cifre, le modalità di introduzione del codice sono descritte nel paragrafo che segue e nel caso di codice
a 3 cifre (Set-Up di fabbrica) il disinserimento avverrà dopo l’introduzione della 3 cifra. NB: Il prodotto disattivato tramite
Override rimane disattivo fino a che non lo si riattiva volontariamente.
Con quadro
strumenti OFF
tenere premuto
il pulsante
per 10 sec.
fino
all’accensione
del LED
poi rilasciare
il pulsante
e procedere
con la conferma
delle cifre.
10.2 RIATTIVAZIONE DELLA PROTEZIONE ALL’AVVIAMENTO
Per riattivare il sistema eseguire le seguenti operazioni:
• Con quadro strumenti OFF tenere premuto il pulsante per 3 sec fino alla accensione fissa del LED poi rilasciare il pulsante.
• Al rilascio del pulsante il LED lampeggia veloce quindi premere nuovamente il pulsante entro 3 sec. per confermare la
riattivazione.
• Il lampeggio lento del LED confermerà il ripristino della protezione all’avviamento.
11. PROGRAMMAZIONI DEL MODULO BLE42
Tramite il programmatore PRG007 è possibile eseguire una serie di Set-Up del modulo BLE42, di seguito riportiamo le
principali opzioni disponibili:
• Eseguire il Set-Up delle 3 uscite programmabili.
• Variare la portata radio del modulo per limitare l’area di ricezione dei dispositivi Bluetooth.
• Personalizzare il codice Override e scegliere se lo si vuole a 5 cifre o 3 cifre
• Aggiungere nuove Card (fino al massimo di 5) o Rimuovere le Card smarrite o non funzionanti.
• Variare il funzionamento della CARD da ID-TAG (riconoscimento automatico) a telecomando (trasmette solo alla pres-
sione del tasto).
5

The use of the mobile APP to product arming temporarily excludes the reception of the B9.5
Card, to restore automatic reception, press the B9.5 Card button near the BLE42 Device to
disarm it.
New
Bluetooth Immobilizer Module
User and Installation Manual
EN
The new BLE42 Device has possibility to be paired with a Smart Phone App whose functions are described in the manual
available Online and downloadable from the App menu. For a correct management of the product through the App we
suggest to apply here the white self-adhesive label that seals the alarm control unit package. Keep these indications
in a safe place, they will be useful for product updates and optional accessories.
We suggest to write in this space the customized Password used
to pair the SmartPhone in order to use it if you have to pair another
SmartPhone to the same product. Password:
SAFETY WARNINGS
The graphic symbols placed on the equipment indicate that the specific information in this
manual must be observed. The symbols are used to safeguard the health of users against the
danger that the materials inside the product may cause.
WARNING! DANGER OF EXPLOSION IF BATTERY IS REPLACED WITH A DIFFERENT OR UNSUITABLE TYPE.
USED BATTERIES MUST BE DISPOSED OF IN ACCORDANCE WITH THE DESIGNATED DISPOSAL
INSTRUCTIONS.
Do not swallow the battery: danger of chemical burns. This product contains a coin/button cell battery.
Swallowing coin/button cell batteries can cause severe internal burns and lead to death within 2 hours.
Keep new and used batteries out of the reach of children. Stop the use of the product and keep it out of the reach of
children if the battery compartment does not close completely. Seek immediate medical attention if battery ingestion
is suspected.
6

1. TECHNICAL SPECIFICATIONS
Power supply: ....................................................................................................................12Vdc/24Vdc
Dimensions: ..............................................................................................................70 x 52 x 22 mm
Consumption: ..................................................................< 5 mAmp (with instrument panel OFF)
Radio frequency (Bluetooth Low Energy): .........................2,402 Ghz ÷ 2,480 GHz (<10mW)
Max immobilizer current at 12V (C/NC): ..............................................................................25 Amp
Max immobilizer current at 24V (C/NC): ................................................................................10 Amp
Operating temperature: ..................................................................................................-30°C /+85°C
2. INPUTS/OUTPUTS
Main Power supply (+30 / GND)
Ignition Key positive input signal (+15)
Input/output for Override LED/Push button
Programmable outputs OUT1/OUT2/OUT3: Active to GND with max load 500mA
ATTENTION: the ID-TAG CARD B9.5 supplied in the
package is not active. To activate the card press
it’s button 5 times. To pair additional cards, use
the PRG007 programmer V3 and the programming
cable 2010337600.
Use only the PRG007 Programmer V3 to select the
various functions of the product.
Software updates for the PRG007 Programmer V3 and
information about the programmable functions are
available ONLINE in the TECH AREA/VEHICLES AREA of the
www.metasystem.it website.
PROGRAMMING WIRING FOR BLE42
MetaSystem code: 2010337600
PRG007 PROGRAMMER V3
MetaSystem code: ABS15090
3. PRODUCT SET-UP
Fig. 1
4. GENERAL DIAGRAM
Paragraph 3
ID-TAG CARD ACTIVATION
FACTORY SET-UP
Out 1 = Coded output Set-Up
Out 2 = Card depending Set-up
Out 3 = Horn output
BLE42
OUT1
OUT2
OUT3
BLACK
BUTTON/LED
RED
INTERNAL RELAY FOR
STARTER IMMOBILIZER
ORANGE
PROGRAMMABLE
OUTPUTS
POSITIVE
BATTERY (+30)
GROUND
KEY IGNITION
(+15)
BLE42 Immobilizer
SN: 123456789012345678
MAC: B12345678901
Pin Code: 23456
PUK Code: 123456
Code: A6015941
MAC
ADDRESS
FACTORY
PIN CODE
B9.5
CARD
7

FAST FLASHING LED
(1 flash every 1 sec) Attempt of engine starting with armed
system and IGNITION KEY ON
sLOW FLASHING LED
(1 flash every 5 sec) System armed and instrument
IGNITION KEY OFF
LED ON System ready to be disarmed
by turning on the ignition key
5. DESCRIPTION OF THE BLE42 IMMOBILIZER MODULE
The BLE42 module was designed for use inside the passenger compartment and executes an automatic ignition immo-
bilization after turning off the instrument panel if the ID-TAG Card B9.5 is not present.
The module includes an internal immobilizer relay (C-NC) that’s activates only if turning on the instrument panel and it
not recognize its ID-TAG Card B9.5.
In addition of the internal relay are available 3 programmable outputs that allow to execute these following features:
1. Driving a coded external relays (Coded output Set-up).
2. Driving an external relay to perform a starter immobilization depending from absence of its ID-TAG Card B9.5
(Card depending Set-up).
3. Drive the clacson (Horn output Set-up).
4. Drive the Hazard push button to activate the turning indicators (Hazard button Set-up).
Included in the paragraphs of this manual are described a different options to use the module and some details
useful to use it.
6. BLE42 IMMOBILIZER MODULE OPERATIONS
ACTIVATION OF STARTER IMMOBILIZER
After turning OFF the instrument panel the BLE42 module goes in pre-arming status, the LED goes ON; complete arming
happen only 50 sec after complete absence of its ID-TAG Card B9.5 in the module receiving area and the complete
arming status is shows by a slow flashing LED (1 flash every 5 sec).
Note: Turning On the instrument during the pre-arming status the BLE42 module disarms and the LED goes Off.
PRESENCE OF ID-TAG CARD B9.5 IN THE MODULE RECEIVING AREA AND IGNITION KEY OFF
When the vehicle ignition Key is OFF the presence of the unlock device (ID-TAG Card B9.5) it’s always indicated by the
LED ON fix, in this condition the immobilizer it’s ready to be completely unlocked turning ON the vehicle ignition Key.
DEACTIVATION OF STARTER IMMOBILIZER
After turning ON the instrument panel the BLE42 module disarms if its ID-TAG Card B9.5 it is present and the LED goes
Off. If the ID-TAG Card B9.5 was lost or in case of flat battery it is possible disarm the BLE42 module introducing the
Override PIN CODE, on the sticker supplied with product you can find the factory PIN CODE (see Fig.1) and it is customi-
zable by PRG007 programmer.
LED OFF System disarmed
and IGNITION KEY ON
lED EMIT 2 CLOSE FLASHES Warning of id-tag card
low battery and IGNITION KEY ON
lED ON FOR FIRST 5 SEC. TURNING
IGNITION KEY ON SERVICE MODE enabled
7. BLE42 MODULE LED STATUS
The status LED permit to have indications about the protection system and in the following table are present the mea-
nings of flashes indications:
8

Fig.2
INSTALL AN
ADDITIONAL
RELAY
HORN
ORIGINAL
HORN
CONTROL
OUT (1/2/3)
BLE42
Fig.3b
INSTALL AN
ADDITIONAL
25A RELAY
STARTER
MOTOR
IGNITION
KEY BLOCK
CUT ORIGINAL WIRE
OUT (1/2/3)
BLE42
CODED
RELAY STANDARD
STARTER
IMMOBILIZER
BLE42
OUT (1/2/3)
C
NC
C
NC
BLUE
BROWN
BROWN
GREEN
GREEN
RED
BLACK
Fig.4
INSTALL ADDITIONAL
RELAY IF HORN
IS POWERED BY
IGNITION-ON
HORN
ORIGINAL
HORN
CONTROL
ORIGINAL
HORN
RELAY
OUT (1/2/3)
BLE42
Fig.5
Fig.6
NEGATIVE PULSE
COMMAND
NO COMMAND
25 SEC.
1 SEC.
1 SEC.
CLACSON
PILOTING
CLACSON
PILOTING
HAZARD BUTTON
PILOTING
Fig.3a
BLE42
STARTER AUTHORIZATION
LOCKING
STARTER
AUTHORIZATION LINE
+30/F
POSITIVE WITH A SLEEP
MODE FUNCTION
OUT (1/2/3)
Coded output Set-Up Card depending Set-Up
Horn output Set-Up
Hazard button Set-Up
Card depending
Set-Up
Horn output Set-Up
RELAY 1
RELAY 2
8. FUNCTIONS OF PROGRAMMABLE OUTPUTS OF BLE42 MODULE
The BLE42 Module has three programmable outputs able to provide different functions, below the list of the possible
options:
1. If it has been selected coded output when the BLE42 Module has a complete arming the external coded relays
actives opening their contacts, the contacts will be restored only after received the coded unlock command coming
from the BLE42 Module (Fig.2).
2. If it has been selected the output depending from the ID-TAG Card B9.5 presence, with BLE42 Module activated
this output will be activate every time the ID-TAG Card B9.5 will be out of its transmission range. With this output
it is possible pilot an external relay avoiding the car starting when the ignition key is ON or the +30 “sleep” passes to
active (Fig.3a/3b).
3. If it has been selected as a horn output when BLE42 Module is armed this output will be activate a 25 sec ON/OFF
cycle every time ignition key will turn ON ; the alarm cycle will start 10 sec after turning on the ignition key, turning
off the ignition key during the alarm cycle it doesn’t stop and will be completed. If the ignition key stay ON more of 25
sec the alarm cycles will be repeated for max 10 times with a 5 sec pause between the cycles (Fig.4/5).
4. If it has been selected as a Hazard button output when BLE42 Module is armed this output will be activate a 25 sec of
turning indicators cycle when ignition key will turn ON; the turning indicators activation will start 10 sec after turning
on the ignition key and the activation signal it is shown in Fig.6.
9

9. INTERNAL RELAY IMMOBILIZER
To make the starter immobilization it’s available an internal relay into the module BLE42 and its C - NC contacts are loca-
ted on the module panel to be connected with a couple of 6,3 mm Faston (Fig. 7/8). The activation logic for the internal
relay give a contacts status change every time the instrument panel is turned on when the BLE42 Module is armed.
Fig.7 Fig.8
PETROL
PUMP
ELECTRONIC
INJECTION
C
INSTALL AN
ADDITIONAL
30A RELAY
STARTER
MOTOR
BLE42 BLE42
NC
C
NC
CUT ORIGINAL WIRE CUT ORIGINAL WIRE
10.1 EMERGENCY DISARMING BY OVERRIDE CODE
If the ID-TAG Card B9.5 was lost or in case of flat battery it is possible disarm the BLE42 module introducing the Override
PIN CODE. By the PRG007 programmer it is possible select if use a complete PIN CODE (5 digits) or short PIN CODE
(3 digits), in the following paragraph is described how to introduce the override code and if short PIN CODE has been
selected (factory set-up) the disarm will be after introduced the third digit. Note: when the BLE42 module has been disar-
med by the Override code the system stay disarmed until the voluntary reactivation.
10.2 REACTIVATION OF THE IMMOBILISER PROTECTION
To reactivate the system follow the steps below:
• With ignition key OFF press hold the LED/Button for 3 sec until the LED will be ON, releases the button
• After released button the LED flash quickly, press again the button within 3 sec to confirm the reactivation.
• The LED will flash slowly to indicate the immobilizer protection reactivation.
11. SET-UP OF THE BLE42 MODULE
Using the programming tool PRG007 it’s possible perform some set-up of the BLE42 module, below the list of the main
set-up options:
• Possibility to Set-Up the 3 programmable outputs.
• Possibility to adjust the BLE42 module radio sensitivity range to set the receiving distance between module and its ID-TAG
Card B9.5.
• Customization of the Override code and selecting from use 5 digit or 3 digits code.
• Pairing the new bluetooth CARDs (max 5 cards) or removing the lost or not working CARDs.
• Changing the CARD Behavior from standard mode ID-TAG (automatic recognizing) as a remote control
(the CARD emit only one time pressing the button).
With ignition
key OFF
press hold
the LED/Button
for 10 sec
until the LED
will be ON,
releases
the button
and start with
the PIN CODE
digits
inserting.
10

11

SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, Meta System S.p.A. declares that Engine Starter Cut O Module type BLE42 and ID-TAG Type B9.5 are in
compliance with Radio Equipment Directive 2014/53/EU.
Frequency Bands in which the radio equipment operates: 2402.0 MHz – 2480.0 MHz <10mW e.i.r.p.
Certicate Holder’s Address: Meta System S.p.A. - Via Galimberti 5, 42124 Reggio Emilia (Italy)
The full text of the EU Declaration of Conformity is available at the following internet address:
https://docs.metasystem.it/
Table of contents
Languages:
Other MetaSystem Control Unit manuals
Popular Control Unit manuals by other brands

STIEBEL ELTRON
STIEBEL ELTRON FEB Operation and installation manual

Farfisa
Farfisa Alba Series manual

Task Force Tips
Task Force Tips VORTEX 2 ER Instructions for installation, safe operation and maintenance

ZIEHL-ABEGG
ZIEHL-ABEGG AM-MODBUS operating instructions

Exodraft
Exodraft EFC16 instructions

Still
Still Easy Control Original instructions
