MetaSystem T.2 User manual

T.2 INSTALLATION MANUAL EN
5040331600
KIT COMPOSITION
INSTALLATION
Power Supply: ..................................................................................12Vdc (9V-14V)
Working temperature: ..........................................................from -30°C to +80°C
IP: .....................................................................................................................................40
Application classication: ...........................................passenger compartment
TECHNICAL SPECIFICATIONS
WARNINGS
• ALL INSTALLATION OPERATIONS MUST BE CARRIED OUT WITH THE MOTOR OFF.
• Before starting installation, detect the OBD port location referring to the use and maintenance manual of the
vehicle.
• If the OBD connector should be used for other purpose, such as maintenance, remove T2 and, after tempora-
ry operation, reconnect the T2 to OBD connector.
• Strictly comply with operations indicated in this manual.
• Installation sta are not authorised to remove warranty seals and/or access the inside of the product.
• The device must be connected to OBD port on board to the vehicle, provided with protectec power supply
by means a 5 A fuse maxiumum activation current.
• The manufacturer assumes no responsibility for damages caused to property and/or people, caused
by the incorrect installation of the product.
TELEMATIC CONTROL UNIT
1
2c2b
OBD PORT
By using user manual of the vehicle nd
the OBD connector on your car.
Typically OBD plug can be located:
• near the breaks unit
• near the fuse box
• under the dashboard
• in the middle console
Plug the connector into the vehi-
cle’s OBD.
Lock the Secondary Lock to se-
cure the device.
2a
Check that the device is fully
connected and does not unlock.

Hereby, Meta System S.p.A., declares that this T.2 is in compliance with the essential requirements and other rele-
vant provisions of Directive R&TTE (1999/5).
The declaration of conformity may be consulted at http://docs.metasystem.it
APPROVAL
REMOVING THE PRODUCT
3b
The instructions in this manual do not refer to specic vehicle models but apply to all vehicles in general. Any
information provided by Meta System regarding a type (model) of vehicle is to be considered purely indicative.
Installation, positioning, product securing and electrical connections, and possibly the removal, must be carried
out in a workmanlike manner on each motor vehicle. The installer is obliged to and bears responsibility for ca-
refully verifying the individual vehicle model on which operations are carried out. Failure to comply with that
stipulated above can render the warranty of the device null and void.
STANDARDS APPLICABLE TO THE VEHICLE
3a
Unlock the Secondary Lock to release the device. Remove the device.
Model: T2 with FCC ID.: P3OT2OBDBT
This device complies with Part 15 of the FCC rules subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept all interference received, including interference that may cause undesired
operation.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
For Canada only IC: 4429A - T2OBD
LEGENDA
: Identication number of identify body.
: Direct current of power supply.
: Conformity mark to European certication.
