Metcal 910-MSG User manual

OK International Inc. • 10800 Valley View Street • Cypress, CA 90630 • USA
Phone: [phone] • Fax: [phone] • www.metcal.com
MANUAL SYRINGE GUN
DESCRIPTION:
The manual syringe gun is a light weight
barrel applicator and provides excellent
control for low to medium viscosity fluids.
Available in 10, 30 and 55cc, the manual
syringe gun is simple to setup and easy to
use.
SIZE SYRINGE
PART NUMBER
10 cc
910-MSG
30 cc
930-MSG
55 cc
955-MSG
INTENDED USE:
The manual Syringe Gun is used for professional application of different adhesives. Other use
than this has not been evaluated and may lead to an unsafe condition.
Use of this manual gun in ways other than those described in this instruction sheet may result in
injury to persons or damage to property.
SAFETY INFORMATION:
WARNING
Always read and follow the instruction of the safety Data Sheet (SDS) of the used adhesive.
Failure to follow may result in personal injury.
Figure 1

OK International Inc. • 10800 Valley View Street • Cypress, CA 90630 • USA
Phone: [phone] • Fax: [phone] • www.metcal.com
SETUP INSTRUCTIONS: (Refer to Figure 2)
1. Press the lock button (#2) and insert the push rod (#3) to the gun body; make sure the
push rod is pushed all the way back
2. Insert the syringe barrel assembly (#1) into the gun assembly and turn clockwise to lock
3. Install the dispense tip to the syringe barrel outlet
4. Squeeze the trigger (#4) to start dispensing
5. Press the lock button and pull the push rod back to remove the syringe barrel assembly
PARTS LISTS:
Gun Assembly
Item #
Replacement Component
Description
910-MSG
1
71000ROD
Push Rod, 10 cc
2
910-WW
Piston, 10 cc
3
910-N
Barrel, 10 cc
4
900-ORTC
Tip Cap
930-MSG
1
73000ROD
Push Rod, 30 cc
2
930-WW
Piston, 30 cc
3
930-N
Barrel, 30 cc
4
900-ORTC
Tip Cap
955-MSG
1
75500ROD-C
Push Rod, 55 cc
2
930-WW
Piston, 30 cc
3
955-N
Barrel, 30 cc
4
900-ORTC
Tip Cap
Figure 2
7000-2230_F
23
4
1
Figure 3
