Metra Electronics 99-8270HG User manual

Metra. The World’s Best Kits.®MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 12/11/19 INST99-8270HG
INSTALLATION INSTRUCTIONS
99-8270HG
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DIN radio provision
• ISO DDIN radio provision †
• Pioneer modular DDIN radio
provision †
• Painted high gloss black to
match the factory finish
KIT COMPONENTS
• A) ISO DIN radio trim panel • B) ISO DDIN radio trim panel • C) Trim panel housing • D) Trim panel housing clip brackets • E) Radio brackets
• F) Pioneer adapter brackets • G) Panel clips (qty. 2) • H) Phillips screws (qty. 8)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 10mm socket wrench
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly
–ISO DIN radio provision .......................................3
–ISO DDIN radio provision .....................................4
–Pioneer modular DDIN radio provision .............5
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: 70-1765
Antenna Adapter: 40-LX11
Steering wheel control interface: ASWC-1
12v-to-6v camera step-down: AX-CAM6V
A B C D E F
G
Toyota Corolla 2020-Up, Corolla Hatchback 2019-Up
H
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
† This kit can only be used with an ISO DDIN radio
with an “L” shaped chassis design, with the radio
chassis at the bottom of the screen. As of this
writing, only the Alpine INE-W967HD (discontinued,
replaced by INE-W977HD), iLX-107, and iLX-207 have
this design. Also, The Pioneer modular radios,
DMH-C2550NEX and DMH-C2500NEX, can be used
with the adapter brackets provided.

1.800.221.0932
|
MetraOnline.com
2
1. Unclip and remove the radio trim panel.
(Figure A)
2. Unclip, unplug, and remove the climate
control panel. (Figure B)
3. Unclip, unplug, and remove the center
a/c vent and hazard switch assembly.
(Figure C)
(Figure B) (Figure D)
(Figure A) (Figure C)
DASH DISASSEMBLY
4. Remove (4) 10mm screws securing the
bottom of the radio. Two screws will be
clearly visible, but two will be hidden,
facing upward. Unclip and slide the radio
out, then unplug and remove. (Figure D)
Continue to Kit Assembly

REV. 12/11/2019 INST99-8270HG 3
ISO DIN radio provision
1. Remove the metal DIN sleeve and trim
ring from the aftermarket radio.
2. Secure the radio brackets to the radio
using screws supplied with the radio.
Note the location of the bracket on the
radio and the screw slots to be used.
(Figures A,B)
3. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio. Metra recommends using
the proper mating adapter from Metra
and/or Axxess. Test the radio for proper
operation.
4. Slide the radio assembly into the dash,
then secure using the factory screws.
5. Attach the ISO DIN radio trim panel to
the trim panel housing, then secure
using (4) Phillips screws provided
(Figure C)
6. Secure the trim panel housing clip
brackets to the trim panel/housing
assembly using (4) Phillips screws
provided. (Figure D)
7. Attach (2) panel clips provided onto the
trim panel/housing assembly.
8. Clip the trim panel/housing assembly to
the dash.
9. Reassemble the dash in reverse
order of disassembly to complete the
installation.
KIT ASSEMBLY
(Figure B)
(Figure C)
(Figure D)
(Figure A)

1.800.221.0932
|
MetraOnline.com
4
ISO DDIN radio provision
1. Secure the radio brackets to the radio
using screws supplied with the radio.
Note the location of the bracket on the
radio and the screw slots to be used.
(Figures A,B)
2. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio. Metra recommends using
the proper mating adapter from Metra
and/or Axxess. Test the radio for proper
operation.
3. Slide the radio assembly into the dash,
then secure using the factory screws.
4. Attach the ISO DDIN radio trim panel
to the trim panel housing, then secure
using (4) Phillips screws provided
(Figure C)
5. Secure the trim panel housing clip
brackets to the trim panel/housing
assembly using (4) Phillips screws
provided. (Figure D)
6. Attach (2) panel clips provided onto the
trim panel/housing assembly.
7. Clip the trim panel/housing assembly to
the dash.
8. Reassemble the dash in reverse
order of disassembly to complete the
installation.
(Figure A)
(Figure C)
(Figure B)
KIT ASSEMBLY
(Figure B)

REV. 12/11/2019 INST99-8270HG 5
Pioneer Modular DDIN radio provision
Note: For steps 1 and 2, reference the
installation manual provided with the radio
for which hardware to use. The display
screen and radio chassis use two different
types of screws.
1. Secure the Pioneer adapter brackets
to the radio chassis using (4) screws
supplied with the radio. (Figure A)
2. Secure the radio display to the Pioneer
adapter brackets using (4) screws
supplied with the radio. (Figure B)
Note: Use the screw slots in the adapter
bracket indicated in the inset.
3. Connect the radio display to the
radio chassis.
Continued on the next page
(Figure A)
(Figure B)
(Figure B)
KIT ASSEMBLY

1.800.221.0932
|
MetraOnline.com
6
4. Secure the radio brackets to the radio
chassis using screws supplied with the
radio. Note the location of the bracket
on the radio and the screw slots to be
used. (Figures C,D)
5. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio. Metra recommends using
the proper mating adapter from Metra
and/or Axxess. Test the radio for proper
operation.
6. Slide the radio assembly into the dash,
then secure using the factory screws.
(Figure C)
(Figure D)
(Figure E)
(Figure F)
7. Attach the ISO DDIN radio trim panel
to the trim panel housing, then secure
using (4) Phillips screws provided
(Figure E)
8. Secure the trim panel housing clip
brackets to the trim panel housing
using (4) Phillips screws provided.
(Figure F)
9. Attach (2) panel clips provided onto the
trim panel/housing assembly.
10. Clip the trim panel/housing assembly to
the dash.
11. Reassemble the dash in reverse
order of disassembly to complete the
installation.

REV. 12/11/2019 INST99-8270HG 7

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
Metra. The World’s Best Kits.®MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 12/11/19 INST99-8270HG
INSTALLATION INSTRUCTIONS
99-8270HG
If you are having difficulties with the installation
of this product, contact our Tech Support line
either by phone at 386-257-1186 ext. 8300, or
email at [e-mail].
Before doing so, look over the instruction booklet
a second time and ensure that the installation
was performed exactly as the instruction booklet
is stated. Have the vehicle apart and ready to
perform troubleshooting steps before contacting
Metra/Axxess Tech Support.
