Meyer Path Pro User manual

Item Part No. Qty. Description
08913 1 Polaris RZR Mounting Carton
1 13476 1 • RZR Mounting Plate
2 13477 1 • RZR Mounting Plate Support
08348 • Polaris RZR Hardware Bag
3 20066 2 •• Bolt H 3/8-16 x 1-3/4” Gr. 5
4 20095 4 •• Bolt H 1/2-13 x 1-1/2” Gr. 5
5 20305 2 •• Locknut 3/8-16
6 20307 4 •• Locknut 1/2-13
7 20353 2 •• Flatwasher 3/8”
8 20355 4 •• Flatwasher 1/2”
Form 1-1064
April 2012
Parts List
Meyer Path ProTM Moldboard
Model PP-50”, PP-60” & PP-72”
08913 Polaris RZR Universal Mounting Instruction
Parts indented are included in the assembly under which they are indented.
Meyer Products LLC reserves the right, under its continuing product improvement program, to change construction or design
details, specifications and prices without notice or without inncurring any obligation.
1
2
3
4
5
6
78
4
6
8
13464
13243

POLARIS RZR MOUNT ASSEMBLY INSTRUCTIONS
A. If equipped, remove the bottom skid plate from RTV and retain.
B. Drop in Bolts 3/8-16 x 1-3/4 (3) and Bolts 1/2-13 x 1-1/2 (4) thru top of the RZR frame as shown on picture
below. Attach RZR mounting plate (1) to RZR using 3/8 flatwasher (7) and 3/8-16 Locknuts (5) onto bolt
(3). Use1/2 flatwashers (8) and 1/2-13 Locknut (6) onto bolt (4). Leave loose, do not tighten at this time.
C. Slide in plate support (2) with Bolts 1/2-13 x 1-1/2 (4) on top of RZR frame thru holes marked “A” on
picture below. The RZR frame will be sandwiched between RZR mounting plate (1) and plate support (2).
Attach 1/2 flatwashers (8) and 1/2-13 Locknut (6) onto bolt (4).
D. Tighten all bolts to proper torque using torque chart below.
E. See owners manual for plow assembly and attachment to the RZR.
Bolt Nut Size Gr. Gr. Gr.
2 5 8
1/4 -20 4 - 5
5/16 -18 9 - 11
3/8-16 17- 20 26-29
7/16 - 14 42 - 46 60 - 66
1/2 -13 64 - 72 90 - 100
5/8-11 127-141 179-198
TORQUE CHART FOOT
3
4
A
4
A
3
© 2012 Printed in the U.S.A.
Meyer Products LLC
18513 Euclid Ave. • Cleveland, Ohio 44112-1084
Phone [phone] (Area Code 216)
www.meyerproducts.com• email [email protected]
