Meyer RL30-30 Owner's manual

6990633 (1-13) Printed in U.S.A. © Bobcat Company 2013
RELOADER
Model RL30-30
PB-RL30-21
Owner / Operator’s Manual
Patent
Pending
8 / 2020 Starting 2021 Model Year

Meyer Manufacturing Corporation - 2 -
1.0 IMPORTANT INFORMATION
The reloader serial number plate is located behind the front left upright.
Please enter the model, serial number and additional information in the space provided for future reference.
Always use your serial number when requesting information or when ordering parts.
HOW TO READ YOUR SERIAL NUMBER
Meyer Manufacturing Corporation
674 W. Business Cty Rd A
Dorchester, WI 54425
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.meyermfg.com
Model No.
Reloader Serial No.
Date of Purchase
Dealership
Dealership Phone No.
Reloader
Serial Number
Model Year / Reloader / Sequence Of Build
RL 201
21
RELOADER
EXAMPLE: 21RL201

1-800-325-9103
PB-RL30-21 Check List - 3 - www.meyermfg.com
2.0 PRE-DELIVERY & DELIVERY CHECK LIST
This Pre-Delivery & Delivery Check List must be gone through by the Selling Party and the Customer to validate the
Owner’s Registration Form.
Meyer Manufacturing Corporation
Phone: [phone] • Toll-Free: 1-800-325-9103 • P.O. Box 405 • Dorchester, WI 54425
Reloader Check List
All shields and guards are in place and securely
fastened.
All bolts and other fasteners are secure and tight.
All mechanisms operate trouble free.
All grease fittings have been lubricated, gear
boxes filled to proper levels, and all roller chains
are oiled. See “Lubrication” section of this
manual.
Main Apron Chains are at proper tension. See
“Adjustments” section in this manual.
All decals are in place and legible.
All stop/tail/turn lights work properly.
No hydraulic leaks.
Both emergency stops work properly in both
manual and remote modes.
PRE-DELIVERY CHECK LIST
After the new Meyer Reloader has been completely
set-up, check to be certain it is in correct running order
before delivering it to the customer.
The following is a list of points to inspect:
Check off each item as you have made the proper
adjustments and found the item operating
satisfactorily. Any adjustments made, MUST be
according to specifications defined in this manual.
DELIVERY CHECK LIST
The following check list is an important reminder of
valuable information that MUST be passed on to the
customer at the time the unit is delivered.
Check off each item as you explain it to the
customer.
Explain to the customer that pre-delivery check
list was fully completed.
Give customer the Owner & Operator’s Manual.
Instruct to read and completely understand its
contents BEFORE attempting to operate the
Reloader.
Explain and review with customer the new Meyer
Reloader manufacturer’s warranty.
Show the customer where to find the serial
number on the implement.
Explain and review with the customer “Safety
Precautions” section of this manual.
Explain and review with customer the proper
“Start-up and Operating Procedures” sections of
this manual.
Demonstrate the start-up & shutdown controls,
proper hydraulic hose storage and tip holder used
to keep system clean from contaminants.
Explain that regular lubrication and proper
adjustments are required for continued proper
operation and long life of the Reloader. Review
with the customer the “Lubrication” and
“Adjustments” sections of this manual.
Explain the importance of apron chain tension,
and the need to watch and tighten during the
break in period.
Fully complete this “PRE-DELIVERY &
DELIVERY CHECK LIST” with the customer.

Meyer Manufacturing Corporation - 4 - PB-RL30-21 Check List
Meyer Manufacturing Corporation
674 W. Business Cty Rd A
Dorchester, WI 54425
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.meyermfg.com
FARM EQUIPMENT BUYERS TRUST THE NAME MEYER!

1-800-325-9103
PB-RL30-21 - 5 - www.meyermfg.com
3.0 INTRODUCTION
Congratulations on your purchase of a new Meyer farm equipment product. Undoubtedly you have given
much consideration to your purchase and we’re proud that you have selected Meyer. Pride in craftsmanship,
engineering and customer service have made Meyer products the finest in the farm equipment industry today.
There is no substitute for quality. That is why thousands of people like you have purchased Meyer farm
equipment. They felt it was the best equipment to serve their farming needs, now and in years to come. We
ask that you follow our policy of “safety first”, and we strongly suggest that you read through the “Owner /
Operator’s Manual” before operating your Meyer farm equipment. Meyer Manufacturing Corporation wants
to thank you for not compromising quality. We are determined to offer excellence in customer service as well
as provide you with the very best value for your dollar.
Sincerely,
All Employees of
MEYER MANUFACTURING CORPORATION
The Model RL30-30 may be referred to as reloader, unloader, or transfer box in this manual.
Manufacturer’s Statement: Meyer Manufacturing Corporation reserves the right to make improvements in design, or
changes in specifications at any time, without incurring any obligation to owners of units previously sold. This supersedes
all previous published instructions.
IMPORTANT: You are urged to study this manual and follow the instructions carefully. Your efforts will be
repaid in better operation and service as well as a savings in time and repair expense. Failure to read this
manual and understand the machine could lead to serious injury. If you do not understand instructions in
this manual, contact either your dealer or Meyer Manufacturing Corp. in Dorchester, WI.
WARRANTY: At the front of this manual is an “Owner's Registration Form”. Be sure your dealer has
completed this form and promptly forwarded a copy to Meyer Manufacturing to validate the manufacturer’s
warranty. The product model and serial number are recorded on this form and on the inside of the front
cover for proper identification of your Meyer Reloader by your dealer and the manufacturer when ordering
repair parts. The serial number is riveted on behind the front upright on the left-hand side.
REPAIR PARTS: At the back of this manual is the repair parts section. All replacement parts are to be
obtained from or ordered through your Meyer dealership. When ordering repair parts, refer to the parts
section and give complete information including quantity, correct part number, detailed description and
even model and serial numbers of the reloader which needs repair parts.

Meyer Manufacturing Corporation - 6 - PB-RL30-21
FEATURES
DESCRIPTION RL30-30
Clad-Tuff Fiberglass Woven Side Panels STD
Solid Poly Floor - High Molecular STD
Hydraulic Drive STD
Rear Transport Lights - LED STD

1-800-325-9103
PB-RL30-21 - 7 - www.meyermfg.com
TABLE OF CONTENTS
1.0 IMPORTANT INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.0 PRE-DELIVERY & DELIVERY CHECK LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.0 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.0 MANUFACTURER’S WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.0 SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.1 SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.2 SAFETY SIGNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
5.3 SHUTOFF & LOCKOUT POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.3.1 Shutoff & Lockout Power Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.0 PRE-OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.1 STATIC INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.2 PTO DRIVELINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
6.3 SET UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.4 OPERATIONAL CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.4.1 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
6.4.1.1 Emergency Stops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.4.1.2 Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.4.1.3 Guide Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.4.2 Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
6.4.3 Shut-Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
6.5 TEAR DOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.6 HYDRAULIC HOOK-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.7 TRANSPORTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
6.7.1 Hitching To Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.7.2 Safety Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
6.7.3 Tractor Towing Size Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.7.4 Unhooking The Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.0 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.1 LOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2 UNLOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8.0 MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.1 LUBRICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.1.1 Daily Lubrication (every 8-10 hours of operation) . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.1.2 Weekly Lubrication (every 56-70 hours of operation) . . . . . . . . . . . . . . . . . . . . . . 36
8.1.3 Monthly Lubrication (every 224-280 hours of operation) . . . . . . . . . . . . . . . . . . . . 36

Meyer Manufacturing Corporation - 8 - PB-RL30-21
8.1.4 Annual Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.1.5 Gearbox Oil Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
8.2 ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
8.2.1 Adjust Apron Chain Tension (Daily Every 8-10 Hours) . . . . . . . . . . . . . . . . . . . . .40
8.2.2 Adjust Wheel Bearing Preload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
8.2.3 Wheels and Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
8.3 STORING THE RELOADER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
8.4 RETURNING THE RELOADER TO SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
9.0 PARTS REPAIR AND REPLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
9.1 REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
10.0 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
MAINTENANCE RECORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

1-800-325-9103
PB-RL30-21 - 9 - www.meyermfg.com
4.0 MANUFACTURER’S WARRANTY
MEYER RELOADER
01/2019
I. The “Owner's Registration Form” must be completed in full and promptly returned to Meyer Mfg. Corp. for this
warranty to become both valid and effective. All warranties on new Meyer Reloaders shall apply only to the original
retail customer from an authorized Meyer Mfg. Corp. dealership.
II. This warranty shall not apply to any Meyer Reloader which has been subjected to misuse, negligence, alteration,
accident, incorrect operating procedures, has been used for an application not designed for or pre-authorized by
Meyer in writing, has had the serial numbers altered, or which shall have been repaired with parts other than those
obtained through Meyer Mfg. Corp. Meyer is not responsible for the following: Depreciation or damage caused by
normal wear, lack of reasonable and proper maintenance, failure to follow the operator’s manual recommendations
or normal maintenance parts and service. Meyer is not responsible for rental of replacement equipment during
warranty repairs, damage to a power unit (including but not limited to a truck or tractor), loss of earnings due to
equipment down time, or damage to equipment while in transit to or from the factory or dealer.
III. Meyer Mfg. Corp. warrants new Meyer Reloader to be free from defects in material and workmanship under
recommended use and maintenance service, as stated in the “Owner / Operator’s Manual”, as follows:
IV. Repairs eligible for labor warranty must be made by Meyer Mfg. Corp. or an authorized Meyer dealership. The original
retail customer is responsible for the transportation of the reloader to the dealership for warranty service or for any
service call expenses.
V. Except as stated above, Meyer Mfg. Corp. shall not be liable for injuries or damages of any kind or nature, direct,
consequential, or contingent, to persons or property. This warranty does not extend to loss of crop or for any other
reasons.
VI. No person is authorized to give any warranties or to assume any other obligation on Meyer Mfg. Corp.’s behalf unless
made or assumed in writing by Meyer Mfg. Corp. This warranty is the sole and exclusive warranty which is applicable
in connection with the manufacture and sale of this product and Meyer Mfg. Corp's responsibility is limited accordingly.
VII. Tires, optional scales and tarps fall under the original manufacturer’s warranty.
A. Meyer Mfg. Corp. will repair or replace F.O.B. Dorchester, WI, as Meyer Mfg. Corp. elects, any part of a
new Meyer forage box which is defective in material or workmanship:
i. Without charge for either parts or labor during the first (1) year from purchase date to the
original retail customer.

Meyer Manufacturing Corporation - 10 - PB-RL30-21
