Mi Electric Scooter Pro User Manual

This version is for private use only and should not be distributed.
Thank you for purchasing Mi Electric Scooter Pro. It is a sports and recreational vehicle with style.
1. Package Contents
3. Assembly and Set-Up
2. Product Overview
Contents
2
3
4
5
6
7
12
13
18
18
17
5. Quick Setup
6. How To Ride
7. Safety Reminder
9. Daily Care and Maintenance
11. Trademark and Legal Statement
10. Specifications
12. Certifications
8. Folding and Carrying
5
4. Charge Your Scooter
1

This version is for private use only and should not be distributed.
1. Package Contents
Assembled Electric Scooter
Carefully check the package contents, if anything is missing or damaged, please contact the local customer service for
support.
Accessories
Extension Nozzle
Charging Adapter
Screw × 5
T-shape Allen Key
Quick Start GuideMaintenance Card
User Manual Warranty NoticeLegal Statement
Legal Statementof Mi Electric Scooter Pro 01
Déclaration juridique concernant la MiElectricScooterPro 09
Rechtliche Hinweise zum Mi ElektrorollerPro 17
Note legali di Mi Electric Scooter Pro 27
Declaración legal del Mi Electric ScooterPro 35
Mi 전동킥보드 프로 법적 고지문 45
Юридическая информация об Электрическом
самокате MiPro 53
ﺔﻴﺋﺎﺑﺮﻬﻜﻟا وﺮﺑ Mi ﺮﺗﻮﻜﺴﻟ ﻲﻧﻮﻧﺎﻘﻟا نﺎﻴﺒﻟا 53
WARRANTYNOTICE
As a Xiaomi consumer,you benefit under certain conditions from additional warranties. Xiaomi
offers specific consumer warranty benefits which a re in addition to, and not instead of, any
legal warranties provided by yourn ational consumer law. The duration and conditions related
to the legal warranties are provi ded by respective local l aws. For m ore information about the
consumer warranty benefits, please refer to Xiaomi's official website hps://www.mi.com/en/
service/warranty/. Except as prohibited by laws or otherwise promised by Xiaomi, the aer-
sales services shall be limited to the country or region of the original purchase. Under the
consumer warranty,to the fullest extent permied by law, Xiaomi will, at its discretion, repair,
replace or refundyour product. Normal wear and tear, force majeure, abuse or damagecaused
bythe user's negligence or fault are not warranted.The contact person forthe aer-sale service
may be any person in Xiaomi's authorizedservice network, Xiaomi's authorized distributors or
the final vendor who sold the productsto you. If in doubt please contact the relevant person as
Xiaomi mayidentify.
The presentwarranties do not apply in Hong Kong and Taiwan.
Products which were not duly imported and/or were not duly manufactured by Xiaomi and/or
were not duly acquired from Xiaomi or a Xiaomi’sofficial seller are not covered by the present
warranties.As per applicable law you may benefit from warranties from the non-official retailer
who sold the product. Therefore, Xiaomi invites you to contact the re tailer from whom you
purchasedthe product.
Maintenance Card 01
Carte d’entretien 03
Wartungskarte 05
Scheda di manutenzione 07
Tarjetade mantenimiento 09
유지보수 카드 11
Карта техническогообслуживания 13
نﺎﻤﻀﻟا ﺔﻗﺎﻄﺑ 15
Quick Start Guide 01
Guide de démarrage rapide 03
Kurzanleitung 05
Guida rapida 07
Manual de inicio rápido 09
퀵스타트 가이드 11
Краткое руководство 13
ﻊﻳﺮﺴﻟا ﻞﻴﻐﺸﺘﻟا ﻞﻴﻟد 15
Mi Electric Scooter Pro User Manual
2

This version is for private use only and should not be distributed.
2. Product Overview
Baery
Compartment
Disc Brake
Brake Light
Buckle
Scooter Bell Lever
Control Panel & Power Buon
Accelerator
Mudguard
Quick Release Lever
Kickstand
Folding Mechanism
Front Fork
Stem
Wheel Motor
Charging Port
Headlight
Handlebar
Brake Lever
Control Panel & Power Buon
Speedometer: Display the current speed of the scooter, as well as to display error codes.
Modes: Three riding modes available. "ECO" for Energy Saving mode (top speed approx. 15 km/h, smooth throle, suitable for
beginners), "D" for Standard mode (top speed approx. 20 km/h) and "S" for Sport mode (top speed approx. 25 km/h,
powerful, only recommended for skilled riders).
Bluetooth: The icon indicates that the scooter has been successfully connected to the mobile device.
Error: The wrench icon indicates that the scooter has detected an error.
Baery Level: The baery power is indicated by 5 bars, each representing approximately 20 % of a full baery.
Power Buon: Press the buon to turn the scooter on, and press and hold the buon for 3 seconds to turn the scooter off.
When the scooter is on, press the buon to turn the headlight on/off, and double press to switch between modes.
Scooter Bell
3

This version is for private use only and should not be distributed.
3. Assembly and Set-Up
3. Tighten the screws onto both sides of the
stem with the T-shaped Allen key.
4. Aer the assembly, press the power
buon to check if it's working properly.
2. Install the handlebar onto the stem.
1. Fold the handlebar stem up, fasten it, and
put down the kickstand.
4

This version is for private use only and should not be distributed.
4. Charge Your Scooter
Li up the
rubber flap.
Plug the charging
adapter into the
charging port.
When charging is
completed, put
back the rubber
flap.
5. Quick Setup
Control your device and interact it with other smart home devices in Mi Home app.
1. Install Mi Home app
Scan the QR code or go to the app store to download and install Mi Home app.
2. Add a device
Open Mi Home app, tap "+" on the upper right, and then follow prompts to add your device.
Note: The version of Mi Home app might have been updated, please follow the instructions based on
the current app version.
5

This version is for private use only and should not be distributed.
3. When the scooter starts to
coast, put both feet on the
deck and press the accelerator
Note: The accelerator initiates
once the coasting speed
exceeds 5 km/h.
5. Tilt your body to the steering
direction as you turn, and
slowly turn the handlebar.
4. Release the accelerator and
the kinetic energy recovery
system (KERS) initiates
automatically to brake slowly;
squeeze the brake lever for a
sudden brake.
2. Step on the deck with one
foot, and slowly kicks off
the other on the ground.
6. How To Ride
Wear a helmet and knee pads to
prevent injuries in case you fall
while learning to ride the scooter.
1. Turn on the scooter, and
check the power indicator.
6

This version is for private use only and should not be distributed.
Do not accelerate when going downhill, and brake in time
to slow down. When encountering a steep incline, you need
to step off the scooter and push, do not risk riding up.
Avoid hiing your head on
door frames, elevators, and
other overhead obstacles.
Keep your speed between 5-10 km/h when riding over
speed bumps, elevator door sills, bumpy roads or other
uneven surfaces. Slightly bend your knees to absorb the
impact of said surfaces.
7. Safety Reminder Watch out for safety risks.
Do not ride in the rain.
7

This version is for private use only and should not be distributed.
Do not press the accelerator when you're
walking alongside the scooter.
Do not hang bags or other heavy
stuff on the handlebar.
Do not ride on one foot.
Always steer clear of obstacles.
8

This version is for private use only and should not be distributed.
Do not try dangerous actions.
Do not abruptly change the steering
direction at high speed.
Do not ride in traffic lanes or
residential areas where vehicles and
pedestrians are both allowed.
Do not ride through any water
deeper than 2 cm.
Do not ride with anyone else,
including children.
9

This version is for private use only and should not be distributed.
Do not let go of the handlebar
while riding.
Do not try riding up or down stairs, nor try
jumping over obstacles.
Do not touch the disc brake.
Do not keep your feet on the rear
mudguard.
10

This version is for private use only and should not be distributed.
Safety Instructions
• This electric scooter is a leisure device. However, when entering a public area, it is considered a
vehicle subject to possible risks. For your own safety, please follow the instructions in the manual as
well as local traffic laws and regulations.
• At the same time, you should understand that risks cannot be entirely avoided as others may violate
traffic regulations and drive incautiously, and you're exposed to road accidents just as when you're
walking or biking. The higher the speed the longer the stopping distance. On a smooth surface, the
scooter may slip, lose balance, and even result in a fall. Be cautious when riding, don't speed and
keep a safe distance from other road users, especially when riding in unfamiliar areas.
• Respect pedestrians' Right of Way. Try not to startle them while driving, especially children. When
you ride from behind pedestrians, ring your bell to give them a heads-up and slow your scooter down
to pass from their le (applicable to countries where vehicles drive on the right). When you ride
across pedestrians, keep to the right at a low speed. When you drive across pedestrians, keep the
lowest speed or geing off the vehicle.
• Closely follow the safety instructions in the manual especially in China and countries that lack
relevant laws and regulations regarding electric scooters. Xiaomi Communication Co., Ltd. shall not
be liable for any financial losses, physical injuries, accidents, legal disputes and other interest
conflicts resulted from actions that violate user instructions.
• Do not lend your scooter to whoever does not know the operations. And when you do lend it to your
friends, please take the responsibility to ensure he/she knows the operations and wears the safety
gear.
• Check the scooter before every use. When you note loosen parts, low baery alerts, flat tires,
excessive wear, strange sounds, malfunctions and other abnormal conditions, stop riding
immediately and call for professional support.
11

This version is for private use only and should not be distributed.
8. Folding and Carrying
The scooter needs to be turned off
before folding. Hold the handlebar
stem, turn it counterclockwise to
open the safety hook and open the
quick release lever.
Folding Open
Carrying
Hold the handlebar stem with either one hand or both hands.
Align the bell and the buckle
and hook them.
When opening, disengage the
bell lever from the buckle on the
mudguard. Fold the handlebar
stem up, close the quick release
lever and turn the handlebar
stem clockwise to close the
safety hook.
Safety Hook
12

This version is for private use only and should not be distributed.
9. Daily Care and Maintenance
Cleaning and Storage
If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains won't scrub off,
put on some toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth. If
you see scratches on plastic parts, use sandpaper or other abrasive materials to polish them.
Notes: do not clean the scooter with alcohol, gasoline, kerosene or other corrosive and volatile
chemical solvents to prevent dire damage. Do not wash the scooter with a high-pressure water spray.
During cleaning, make sure that the scooter's turned off, the charging cable is unplugged, and the
rubber flap is closed as water leakage may result in electric shock or other major problems.
When the scooter's not in use, keep it indoors where it is dry and cool. Do not put it outdoors for long
time. Excessive sunlight, overheating and overcooling accelerate tire aging and compromise the
scooter and the baery pack's lifespan.
Tire Maintenance
Regularly check the tire pressure (at least every 2-3 months), the recommended tire pressure is 50 psi.
Riding with an incorrect tire pressure reduces tire life and safety.
Baery Maintenance
1. Do not use baery packs of other models or brands, as there may be a safety risk.
2. Do not disassemble, squeeze or puncture the product. Do not touch its baery contacts. Do not
disassemble or poke the outer casing. Do not place the product into water, fire nor expose it to
temperatures above 50°C (including heat sources such as stoves, heatings, etc.). Avoid metal objects
from touching the baery contacts, since this may result into short circuits, physical injury or even
death.
3. Any water geing into the baery may cause damage to the internal circuit, risk of fire or even
explode. If there is any suspicion of water geing into the baery, immediately stop using the baery
and return it to the Aer Sales service for inspection.
4. Only use the original charging adapter to avoid potential damage or fire.
5. Improper disposal of used baeries can seriously pollute the environment. Observe local regulations
when disposing of this baery pack. Do not discard this baery pack at will, to protect the natural
environment.
6. Fully charge aer every use, in order to extend its baery life.
Do not place the baery in an environment where the ambient temperature is higher than 50°C or
lower than -20°C (e.g., do not leave the scooter or the baery pack in a car under direct sunlight for an
extended time). Do not throw the baery pack into fire as it may lead to baery failure, baery
overheating, and even another fire. If the scooter is expected to be le idle for more than 30 days,
please fully charge the baery and place it in a dry and cool place. Keep in mind to recharge it every
60 days to protect the baery from potential damage which is beyond limited warranty.
Always charge before exhausting the baery to prolong the baery's lifespan. The baery pack
performs beer at normal temperature, and poor when it is below 0°C. For instance, when it is below
-20°C, the riding range is only half or less at normal state. When the temperature rises, the riding range
restores. For detailed information, please refer to Mi Home App.
Note: fully charged Mi Electric Scooter Pro will last for 120-180 days. The built-in intelligent chip will
keep a log of its charging and discharging records. The damage caused by prolonged no charge is
irreversible and is beyond limited warranty. Once the damage is done, the baery cannot be recharged
(non-professionals are forbidden to dismantle the baery pack, as it may cause electric shock, short
circuit or even major safety accidents).
13

This version is for private use only and should not be distributed.
Cleaning and Storage
If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains won't scrub off,
put on some toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth. If
you see scratches on plastic parts, use sandpaper or other abrasive materials to polish them.
Notes: do not clean the scooter with alcohol, gasoline, kerosene or other corrosive and volatile
chemical solvents to prevent dire damage. Do not wash the scooter with a high-pressure water spray.
During cleaning, make sure that the scooter's turned off, the charging cable is unplugged, and the
rubber flap is closed as water leakage may result in electric shock or other major problems.
When the scooter's not in use, keep it indoors where it is dry and cool. Do not put it outdoors for long
time. Excessive sunlight, overheating and overcooling accelerate tire aging and compromise the
scooter and the baery pack's lifespan.
Tire Maintenance
Regularly check the tire pressure (at least every 2-3 months), the recommended tire pressure is 50 psi.
Riding with an incorrect tire pressure reduces tire life and safety.
Baery Maintenance
1. Do not use baery packs of other models or brands, as there may be a safety risk.
2. Do not disassemble, squeeze or puncture the product. Do not touch its baery contacts. Do not
disassemble or poke the outer casing. Do not place the product into water, fire nor expose it to
temperatures above 50°C (including heat sources such as stoves, heatings, etc.). Avoid metal objects
from touching the baery contacts, since this may result into short circuits, physical injury or even
death.
3. Any water geing into the baery may cause damage to the internal circuit, risk of fire or even
explode. If there is any suspicion of water geing into the baery, immediately stop using the baery
and return it to the Aer Sales service for inspection.
4. Only use the original charging adapter to avoid potential damage or fire.
5. Improper disposal of used baeries can seriously pollute the environment. Observe local regulations
when disposing of this baery pack. Do not discard this baery pack at will, to protect the natural
environment.
6. Fully charge aer every use, in order to extend its baery life.
Do not place the baery in an environment where the ambient temperature is higher than 50°C or
lower than -20°C (e.g., do not leave the scooter or the baery pack in a car under direct sunlight for an
extended time). Do not throw the baery pack into fire as it may lead to baery failure, baery
overheating, and even another fire. If the scooter is expected to be le idle for more than 30 days,
please fully charge the baery and place it in a dry and cool place. Keep in mind to recharge it every
60 days to protect the baery from potential damage which is beyond limited warranty.
Always charge before exhausting the baery to prolong the baery's lifespan. The baery pack
performs beer at normal temperature, and poor when it is below 0°C. For instance, when it is below
-20°C, the riding range is only half or less at normal state. When the temperature rises, the riding range
restores. For detailed information, please refer to Mi Home App.
Note: fully charged Mi Electric Scooter Pro will last for 120-180 days. The built-in intelligent chip will
keep a log of its charging and discharging records. The damage caused by prolonged no charge is
irreversible and is beyond limited warranty. Once the damage is done, the baery cannot be recharged
(non-professionals are forbidden to dismantle the baery pack, as it may cause electric shock, short
circuit or even major safety accidents).
14

This version is for private use only and should not be distributed.
Adjusting the disc brake
Unscrew the valve cap.
Tire Valve Stem
If the brake is too tight, use the 4 mm Allen
key to loosen the screw on the caliper. Then
slightly adjust the brake line (decrease the
exposed length), and tighten the screw again.
Brake Cable
If the brake is too loose, loosen the screw
on the caliper. Then slightly adjust the brake
line (increase the exposed length), and
tighten the screw again.
Valve Cap
Connect the extension nozzle
to the tire valve stem.
Connect the pump to
inflate the tire.
15

This version is for private use only and should not be distributed.
Adjust the handlebar
Long-term use of the scooter may result in loose screws, causing the handlebar stem to get unstable. If
you notice the handlebar stem gets shaky when riding, follow the steps below.
Tools:
I: 8-10 mm wrench
II: 4 mm Allen key
Note: These tools are to be prepared by the user.
Steps:
1. When in the folded state (see page 12), use tool I to loosen "c" (clockwise).
2. Use tool I to loosen "b" (clockwise).
3. Use tool II to adjust "a" (clockwise) to the appropriate position, and use tool I to tighten "b"
(counterclockwise).
4. Fold the handlebar stem up, close the quick release lever and turn the handlebar stem clockwise to
close the safety hook.
5. Shake the handlebar stem to see if the problem has been resolved.
If not, repeat step 2 and 3.
If it has, continue to step 6.
6. Return to the scooter to the folded state and use tool I to tighten "c" (counterclockwise).
* Step 6 is mandatory.
a. Inner Hex Nut
b. Hex Stud
c. Hex Nut
16

This version is for private use only and should not be distributed.
Mi Electric Scooter Pro
DDHBC02NEB
113×43×118
113×43×49
Approx. 14.2
100
16–50
120–200
Approx. 25
Approx. 45
Approx. 20
Cement, asphalt and dirt roads, with benches of less
than 1 cm or crevices narrower than 3 cm.
-10~+40
-20~+45
IP54
Approx. 8
37 V
42 V
474
Unusual temperature/short circuit/under voltage/over
current/dual overcharge/dual over-discharge protections
300
600
71
100–240 ~
42 V
1.7
8.5 inch front
50 psi
2.4000-2.4835GHz
100
Name
Model
Vehicle: L × W × H (cm)[1]
Aer Folding: L × W × H (cm)
Vehicle Net Weight (kg)
Load Range (kg)
Age
Body Length (cm)
Max. Speed (km/h)
General Range (km)[2]
Max. Climbing Angle (%)
Suitable Surfaces
Operating Temperature (°C)
Storage Temperature (°C)
Ip Rating
Charging Time (h)
Rated Voltage (VDC)
Max. Input Voltage (VDC)
Rated Capacity (Wh)
Intelligent Baery
Management System
Rated Power (W)
Max. Power (W)
Output Power (W)
Input Voltage (V)
Output Voltage (V)
Output Current (A)
Rear Wheel
Recommended Tire Pressure
Frequency Band (s)
Max. RF Power (mW)
10. Specifications
[1] Vehicle height: from the ground to the top of the scooter.
[2] General range: measured when there is no wind and at 25°C, the scooter's fully charged to ride at a constant speed of 15 km/h on a flat
surface with a load of 75 kg.
Product
Dimensions
Net Weight
Assembled
Electric Scooter
Baery Pack
Wheel Motor
Charging Adapter
Tire
Bluetooth
Riding
17

This version is for private use only and should not be distributed.
is the trademark of Xiaomi Inc. All rights reserved. Ninebot is a registered trademark of Ninebot
(Tianjin) Technology Co., Ltd., all other trademarks and trade names are those of their respective
owners.
This manual is produced and copyrighted by Ninebot (Beijing) Technology Co., Ltd. No entity nor
individual may use, duplicate, modify, copy, spread any part of this manual, or bundle or sell with other
products without the wrien consent of Ninebot (Beijing) Technology Co., Ltd.
All the described functions and instructions were up to date at the time of printing this manual.
However, the actual product may vary due to improved functions and design.
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Ninebot (Changzhou) Tech Co., Ltd.
Address: 16F-17F, Block A, Building 3, No.18, Changwu Mid Rd, Wujin Dist., Changzhou, Jiangsu, China.
11. Trademark and Legal Statement
European Union Compliance Statement
Baery recycling information for the European Union
Baeries or packaging for baeries are labeled in accordance with European Directive 2006/66/EC
concerning baeries and accumulators and waste baeries and accumulators. The Directive
determines the framework for the return and recycling of used baeries and accumulators as applicable
throughout the European Union. This label is applied to various baeries to indicate that the baery is
not to be thrown away, but rather reclaimed upon end of life per this Directive.
In accordance with the European Directive 2006/66/EC, baeries and accumulators are labeled to
indicate that they are to be collected separately and recycled at end of life. The label on the baery may
also include a chemical symbol for the metal concerned in the baery (Pb for lead, Hg for mercury, and
Cd for cadmium). Users of baeries and accumulators must not dispose of baeries and accumulators
as unsorted municipal waste, but use the collection framework available to customers for the return,
recycling, and treatment of baeries and accumulators. Customer participation is important to
minimize any potential effects of baeries and accumulators on the environment and human health due
to the potential presence of hazardous substances.
Before placing electrical and electronic equipment (EEE) in the waste collection stream or in waste
collection facilities, the end user of equipment containing baeries and/or accumulators must remove
those baeries and accumulators for separate collection.
12. Certifications
18

This version is for private use only and should not be distributed.
Waste Electrical and Electronic Equipment (WEEE) Directive
"All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive
2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect
human health and the environment by handing over your waste equipment to a designated collection
point for the recycling of waste electrical and electronic equipment, appointed by the government or
local authorities. Correct disposal and recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local authorities for more information
about the location as well as terms and conditions of such collection points".
Restriction of Hazardous Substances Directive (RoHS)
This Ninebot (Changzhou) Tech Co., Ltd. product, with included parts (cables, cords, and so on) meets the
requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous substances in
electrical and electronic equipment ( “RoHS recast” or “RoHS 2” ).
Radio and Telecommunications Terminal Equipment Directive
Segway Europe B.V.
EU Contact Address for regulatory topics only: Hogehilweg 8, 1101CC, Amsterdam, The Netherlands
This device meets the EU requirements on the limitation of exposure of the general public to
electromagnetic fields by way of health protection.
Hereby, [Ninebot (Changzhou) Tech Co., Ltd,] declares that the radio equipment type [DDHBC02NEB] is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the
following internet address:hp://www.mi.com/global/service/support/declaration.html.
19
