Microlife CARDIO+ User manual

Instruction Manual
For accurate blood pressure measurement
Blood Pressure Monitor
MICROLIFE®CARDIO+

1
Dear Customer,
We thank you for purchasing the Microlife®Cardio+, the blood pressure
monitor that allows you to easily and accurately measure your blood
pressure.
The Microlife Cardio+ Blood Pressure Monitor is a reliable medical
device designed for use with your iPhone, iPad, or iPod touch. This
simple-to-use, accurate monitor comes highly recommended for
blood pressure monitoring at home. Developed in collaboration with
physicians, the Microlife Cardio+ has been clinically tested to ensure
the highest accuracy of its measurements.*
Read through these instructions carefully to understand this product’s
functions and safety information. We want you to be happy with your
Microlife product.
If you have any inquiries, contact Microlife’s customer support center.
Your retailer or pharmacy can provide you with the contact information
of the Microlife dealer in your country. Or visit www.microlife.com for
more information about our products.
Stay healthy!
MicrolifeAG
* This device uses the same measuring technology as the award winning
«BP 3BTO-A» model tested according to the British Hypertension Society
(BHS) protocol.

EN
2
Table of Contents
Product Overview
The Microlife Cardio+ Blood Pressure Monitor andApplication.......... 3
What is included................................................................................ 4
Before Using the Microlife Cardio+ for the First Time
Charging the Microlife Cardio+ Blood Pressure Monitor .................... 5
Downloading the Microlife Cardio+App from theApp Store ............... 5
Creating a User Prole ...................................................................... 5
Setting a Blood Pressure Target ........................................................ 6
Taking Measurements with the Microlife Cardio+
Before Taking a Measurement........................................................... 6
Taking a Measurement...................................................................... 7
During Measurement ........................................................................ 7
Completed Measurement.................................................................. 8
Interpreting the Measurement Results
WHO Indicator .................................................................................. 8
PulseArrhythmia Detection (PAD) Indicator ...................................... 8
Managing the Measurement Data
Saving, Deleting, Viewing, or Sharing Data ..................................... 10
Managing a User Prole
Creating, Selecting, or Deleting a User Prole ..................................11
Appendix
Battery Power Indicators ..................................................................11
Error Messages............................................................................... 12
Facts about Blood Pressure and Self-Measurement........................ 13
Safety and Protection...................................................................... 13
Device care/Cleaning of the Cuff ..................................................... 14
Accuracy Test/Guarantee................................................................ 14
Technical Specications.................................................................. 15
Guarantee Card............................................................................. 20

3
Product Overview
1 5 7 8
2
1) Connection Slot on iPhone/iPad/iPod touch
2) Microlife Cardio+ Dock
3) On/Off Button
Cancel Button (during measurement)
4) Microlife Cardio+ Plug
5) Preformed Cuff
6) Air Hose
7) Micro USB Port
8) Air Hose Socket
3 4 6
Microlife Cardio+ Blood Pressure Monitor and
Application

EN
4
9) Measurement
10) Report
11) Settings
12) Users
9 10 11 12
What is included:
• Microlife Cardio+ Dock x 1
• Preformed Cuff, Size M–L (22–42 cm) x 1
• USB Cable for Charging Battery x 1
• Carrying Case x 1
• Instruction Manual x 1
• Quick Start Guide x 1
Read the instructions carefully before using this device.
Type BF applied part.

5
Charging the Microlife Cardio+ Blood Pressure
Monitor
• Connect the dock to an iOS-device USB power adapter using the
supplied USB cable. Connect to a power outlet and charge the dock
for 2 hours.
• During the charging process, the « » button lights up in yellow.
When the battery is completely charged, the « » button lights up
briey in blue, and then the unit automatically switches off.
While Charging
Start button lights up
in yellow
When Charged
Start button lights up briey in
blue and the unit switches off
• The battery status of the blood pressure monitor is displayed at the
bottom of the Microlife Cardio+ app screen.
• While charging the Microlife Cardio+ Blood Pressure Monitor, you
can also charge your iOS device.
Charging the Microlife Cardio+ Blood Pressure Monitor directly
through a computer USB port is not recommended.
Downloading the Microlife Cardio+ App from the
App Store
Go to the App Store and search for «Microlife Cardio+». Once this app
has been downloaded, the icon will appear on your iOS device.
☞To download the app, you need an Apple ID with an email address
and password, as well as an active Internet connection. While the
Microlife Cardio+ app is free to download, you may be subject to
charges from your Internet provider for using the Internet to do so.
Creating a User Prole (optional)
If more than one person will use the monitor, create a user prole to
ensure that each user’s data is stored separately. Open , and go to
«User» to create a prole.
Before Using the Microlife Cardio+ for the First Time

EN
6
Setting a Blood Pressure Target (optional)
If targeted measurement values have been recommended by a
doctor, set a blood pressure target to give a realistic reading based
on these recommendations. Open , and go to «Settings». Set and
save the «Systolic» and «Diastolic» targets.
After completing these steps, you are ready to take a blood pressure
measurement.
Note: Conrm that the time and date on your iOS device are correct.
Taking Measurements with the
Microlife Cardio+
Before Taking a Measurement
• Avoid any activity, eating, or smoking immediately before taking a
measurement.
• Sit down and relax for at least 5 minutes before taking a
measurement.
Relax 5 mins
• Always take measurements on the same arm (normally the left).
• Remove close-tting clothing from the upper arm. To avoid
constriction, your shirt sleeve should not be rolled up; it will not
interfere with the cuff if it is laid at.
• Fit the cuff closely, but not too tightly. Make sure that the cuff is
2 cm (0.75 inches) above your elbow, with the tube on the inside of
your arm.
2 cm (0.75 inches)
• Support your arm so that it is relaxed. Ensure that the cuff is at the
same height as your heart.

7
Taking a Measurement
• Open the «Microlife Cardio+» app automatically by plugging the iOS
device to the monitor dock.Alternatively, click on the app displayed
on the iOS device screen.
• Select the measurement mode: ONE measurement (single), or MAM
measurement (triple).
• Press «Start» to begin.
• Press «Stop» to cancel anytime during the measurement (e.g., if
you feel uncomfortable because of the pressure from cuff). You can
cancel the measurement through theApple device interface or the
blood pressure monitor itself.
☞What Is MAM Measurement?
MAM stands for «Microlife Average Mode». It is a Microlife proprietary
patented technology that takes and analyzes your blood pressure in
3 successive measurements, automatically. Since blood pressure
constantly uctuates, a result determined with MAM is more reliable
than a result obtained from a single measurement. This type of
measurement is also recommended by doctors in most of the medical
guidelines for hypertension management.
During Measurement
• The cuff will pump up automatically. Do not move or talk, and do not
tense your arm muscles. Breathe normally.
• When the correct pressure is reached, the pumping stops and the
pressure decreases gradually.
• The heart symbol ashes in the display every time a heartbeat is
detected.
• If you choose MAM measurement, 3 measurements are taken in
succession, with 15-second intervals between each one.Afourth
measurement will be taken if any of the results are unclear.
☞During the measurement process, if you receive a phone call or
detach the iOS device from the dock, the cuff will automatically deate
and stop the whole measurement process.

EN
8
Completed Measurement
• After the results are shown, the measurement is complete.
• Your systolic and diastolic blood pressure and your pulse are
displayed in the results.
• Remove the cuff and save the measurement results.
Interpreting the Measurement
Results
WHO Indicator
The color of the «WHO» icon indicates the results of your measurement.
To check the evaluation of the measurement, press the «WHO» icon.
The higher value is used in this evaluation, even if the other value
is normal.
Example: 150/85 mmHg indicates «Blood pressure too high».
120/98 mmHg indicates «Blood pressure too high».
Pulse Arrhythmia Detection (PAD) Indicator
The « PAD » symbol indicates that certain pulse irregularities were
detected during the measurement:
• If the result deviates from your normal blood pressure, repeat the
measurement.
• If this symbol appears on a regular basis (e.g., several times a week
when measurements are taken daily), we advise you to inform your
doctor and show the following explanation.
☞Early Detection of Pulse Arrhythmia
This device is an oscillometric blood pressure monitor that also
analyzes pulse rate during measurement. Although it does not replace
a cardiac examination, this device has been clinically tested and can
detect pulse irregularities at an early stage.
The «PAD »symbol is displayed if pulse irregularities have been
detected. If this symbol appears frequently, we recommend that the
patient seek medical advice.

9
Classication of Adult’s Blood Pressure Values in Accordance with the World Health Organization (WHO) in 2003.
Range Systolic (mmHg) Diastolic (mmHg) Recommendation
Blood pressure too low 100 60 Consult your doctor
1Blood pressure optimum 100–120 60–80 Self-check
2Blood pressure normal 120–130 80–85 Self-check
3Blood pressure slightly high 130–140 85–90 Consult your doctor
4Blood pressure too high 140–160 90–100 Seek medical advice
5Blood pressure far too high 160–180 100–110 Seek medical advice
6Blood pressure dangerously high 180 110 Urgently seek medical advice

EN
10
Managing the Measurement Data
Saving Data
• Press «Save» to store the measurement results, including
measurement mode, date, and time. If you do not wish to keep a
measurement, press «Cancel».
• To store measurement results from other blood pressure devices, go
to «Manual Input».
☞ The amount of data saved depends on the memory capacity of your
iOS device.Awarning message will appear when the memory is full.
Delete old data to save new data.
Deleting Data
• Delete Individual Data: Go to «Report» and press «Edit».
• Delete All Data: Go to «Settings» and press «Reset Data».
Viewing Data
Go to «Report» to view data.
• Viewing Individual Data: Swipe the screen vertically to see data
taken in the same month. To view data taken in different months,
swipe the screen horizontally.
• Viewing Data in a Line Graph: Turn the iOS device horizontally. To
view data in a specic timeline, choose the intended period of view.
• Viewing Data in a Bar Chart*: Turn the iOS device and swipe the
screen horizontally. To view data in a specic timeline, choose the
intended period of view.
1D – One day
1W – One week
1M – One month
3M – Three months
1Y – One year
All – All measurements stored
Sharing Data
Go to «Report» and press « » to share data*.
*Data is shared via email in CSV format. To use this function, an email
account must be set up in your iOS device and an Internet connection
is needed.

11
Creating a User Prole
Creating a prole for an individual user ensures that each individual's
data is stored separately. Go to «User» and choose «+» to create a
new user. Up to 10 proles can be created.
Selecting a User Prole
Go to «User», select the user listed, and proceed to take a
measurement.
Deleting a User Prole
Go to «User», click «Edit», and select the user to be deleted.
Battery Power Indicators
The « » button on the blood pressure monitor may show the
following:
• No Light: The battery is completely charged.
• Blue Light: The battery is over 20% charged.
• Yellow Light: The battery is less than 20% charged. Charge the battery.
• Blue and Yellow Lights Flashing Alternately: The battery is defective.
Do not let the battery run down completely, as this shortens the
battery’s service life.
Managing a User Prole Appendix

EN
12
Error Description Potential cause and remedy
«ERR 1»Signal too weak The pulse signals on the cuff are
too weak. Re-position the cuff and
repeat the measurement.*
«ERR 2»Arm movement During the measurement, error
signals were detected by the cuff,
caused, for instance, by movement
or muscle tension. Repeat the
measurement, keeping your arm still.
«ERR 3»No pressure in
the cuff
Adequate pressure cannot be
generated in the cuff.Aleak may
have occurred. Check that the
cuff is correctly connected and
not too loose. Recharge the
batteries if necessary. Repeat the
measurement.
«ERR 5»Abnormal result The measuring signals are
inaccurate and no result, therefore,
can be displayed. Read through
the checklist for performing reliable
measurements and then repeat the
measurement.*
«ERR 6»MAM mode error There were errors during the
measurement in MAM mode,
making it impossible to obtain
a nal result. Read through the
checklist for performing reliable
measurements and then repeat the
measurement.*
Low battery The battery power in the Microlife
Cardio+ Blood Pressure Monitor
Dock is too low. Charge the dock
before taking any measurements.
* Consult your doctor, if this or any other problem occurs repeatedly.
Error Messages
If an error occurs during the measurement, the measurement is
interrupted and an error message, e.g., «ERR 3», is displayed.

13
Facts about Blood Pressure and Self-
Measurement
• Blood pressure is the pressure of the blood owing in the arteries,
generated by the pumping of the heart.
• Two values, the systolic (upper) value and the diastolic (lower) value,
are always measured. This device also indicates pulse rate (the
number of times the heart beats in a minute).
• Permanently high blood pressure can damage your health and must
be treated by your doctor.
• Always discuss your results with your doctor if you have noticed
anything unusual or feel unsure about the results. Never rely on a
single blood pressure reading.
• Under no circumstances should you alter the dosages of any drugs
prescribed by your doctor.
• Depending on physical exertion and other conditions, blood pressure
is subject to wide uctuations, especially as the day progresses.
You should, therefore, take your measurements under the same
conditions, when you are relaxed.
• Take at least two measurements per day - one in the morning and
one in the evening.
• It is quite normal for two measurements taken in quick succession to
produce signicantly different results.
• Differences in measurements taken by your doctor or at the
pharmacy and those taken at home are quite normal, as these
environments are very different.
Safety and Protection
• This device and cuff have sensitive components and must be
treated with care.
• Protect this device from:
- water and moisture.
- extreme temperatures.
- damage from impact or drops.
- contamination and dust.
- direct sunlight.
- heat and cold.

EN
14
• Do not use the device if you think it is damaged or if you notice
anything unusual about it.
• Never open the device.
• Use only the cuff provided.
Ensure that children do not use the device unsupervised;
some parts are small enough to be swallowed.
Device care
Clean the device with a soft, dry cloth. Do not use gas, thinners or
similar solvents.
Cleaning the Cuff
Spots on the cuff can be removed carefully with a damp cloth and
soapsuds.
The cuff with bladder must not be washed in a dishwasher,
clothes washer, or submerged in water.
Accuracy Test
We recommend that this device is tested for accuracy every 2 years or
after any mechanical impact (e.g., being dropped). Contact Microlife’s
service center to arrange a test.
Batteries and electronic devices must be disposed of in accordance
with the locally applicable regulations, not with domestic waste.
Guarantee
This device is covered by a 2-year guarantee from the date of
purchase. The guarantee is valid only on presentation of the guarantee
card completed by the dealer (see back) conrming date of purchase
or the receipt.
• Batteries, cuff, and normal wear and tear are not included.
• Opening or altering the device invalidates the guarantee.
• The guarantee does not cover damage caused by improper
handling, discharged batteries, accidents, or non-compliance with
the operating instructions.
Contact Microlife’s customer service center for further details.

15
Technical Specications
Product name: Microlife®Cardio+ Blood Pressure Monitor
BP4GAPO-2M
Runs on Apple iOS
devices:
iPod touch (4th generation), iPod touch (3rd
generation), iPhone 4S, iPhone 4, iPhone
3GS, iPad (3rd generation), iPad 2, iPad.
Operating system: Apple iOS 5.0 or higher
Operating temperature: +10 °C to +40 °C, 15 - 90% humidity
Storage temperature: -20 °C to +55 °C, 15 - 90% humidity
Weight: Approx. 213 g
Dimensions (ø x H): Approx. 120 mm x 93.5 mm
Cuff size: 22 - 42 cm adult cuff; supports size M to L
Measuring procedure: Oscillometric; single or MAM readings
Measurement range: 30 - 280 mmHg: blood pressure
40 - 200 beats per minute: pulse
Cuff pressure display
range:
0 - 299 mmHg
Resolution: 1 mmHg
Static accuracy: Pressure within ±3 mmHg or
2% of reading > 200 mmHg
Pulse accuracy: ± 5% of the readout value
Voltage source: Via USB (5 V , 500 mAh) or integrated
battery (3.7 V , 500 mAh)
Reference to standards: ANSI/AAMI SP10, IEC 60601-1,
IEC 60601-1-2, EN 1060 -1/-3/-4
This device complies with the requirements of the Medical Device
Directive 93/42/EEC. Technical alterations reserved.

EN
16
Guidance and manufacturer's declaration - electromagnetic emissions
The BP4GAPO-2M is intended for use in the electromagnetic environment specied below. The customer or the user of the BP4GAPO-2M should assure that
it is used in such an environment.
Emission test Compliance Electromagnetic environment-guidance
RF emissions CISPR 11 Group 1 The BP4GAPO-2M uses RF energy only for its internal function. Therefore, its
RF emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
RF emissions CISPR 11 Group B The BP4GAPO-2M is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low-voltage power
supply network that suppies buildings used for domestic purposes.
Harmonic emissions IEC 61000-3-2 Not applicable
Voltage uctuations / icker emissions
IEC 61000-3-3
Not applicable

17
Guidance and manufacturer's declaration - electromagnetic immunity
The BP4GAPO-2M is intended for use in the electromagnetic environment specied below. The customer or the user of the BP4GAPO-2M should assure that
it is used in such an environment.
Immunity test IEC 60601 test level Compliance
level
Electromagnetic environment-guidance
Electrostatic discharge
(ESD)
+ 6 kV contact
+ 8 kV air
+ 6 kV contact
+ 8 kV air
Floors should be wood, concrete or ceramic tile. If oors are covered
with synthetic material, the relative humidity should be at least 30 %
Electrical fast transient/burst
IEC 61000-4-4
+ 2kV for power supply lines
+ 1kV for input/output lines
Not applicable
Not applicable
Mains power quality should be that of a typical commerical or
hospital environment
Surge IEC 61000-4-5 + 1kV line(s) to line(s)
+ 2kV line(s) to earth
Not applicable
Not applicable
Mains power quality should be that of a typical commerical or
hospital environment
Voltage Dips, short
interruption and voltage
variations on power supply
input lines IEC 61000-4-11
<5% UT (>95% dip in UT) for 0,5 cycle
40% UT (60% dip in UT) for 5 cycles
70% UT (30% dip in UT) for 25 cycles
<5% UT (>95% dip in UT) for 5 s
Not applicable
Not applicable
Not applicable
Not applicable
Mains power quality should be that of a typical commerical or
hospital environment. If the user of the BP4GAPO-2M requires
continued operation during power mains interruptions, it is
recommended that the BP4GAPO-2M be powered from an
uninterruptible power supply or a battery.
Power frequency (50/60 Hz)
magnetic eld
IEC 61000-4-8
3A/m 3A/m The BP4GAPO-2M power frequency magnetic elds should be at
levels characteristic of a typical location in a typical commercial or
hospital environment.
Note: UT is the a.c. mains voltage prior to application of the test level.

EN
18
Guidance and manufacturer's declaration - electromagnetic immunity
The BP4GAPO-2M is intended for use in the electromagnetic environment specied below. The customer or the user of the BP4GAPO-2M should assure that
it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment-guidance
Conducted RF
IEC 61000-4-6
3 Vrms
150 KHz to 80 MHz
Not applicable Portable and mobile RF communications equipment should be used no closer to any part of the
BP4GAPO-2M including cables, than the recommended separation distance calculated from
the equation applicable to the frequency of the transmitter.
Radiated RF
IEC 61000-4-3
3 V/m
80MHz to 2,5 GHz
3 V/m Recommended separation distance:
d = 1,2 √P d = 1,2 √P 80MHz to 800 MHz d = 2,3 √P 800MHz to 2,5 GHz
Where P is the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer and dis the recommended separation distance in meters (m)
Field strengths from xed RF transmitters, as determined by an electromagnetic site
survey, ashould be less than the compliance level in each frequency range. b
Interference may occur in the vicinity of equipment marked with the following symbol:
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reection from structures, objects and people.
aField strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio
broad-cast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to xed RF transmitters, an electromagnetic site
survey should be considered. If the measured eld strength in the location in which the BP4GAPO-2M is used exceeds the applicable RF compliance level
above, the BP4GAPO-2M should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such
as re-orienting or relocating the BP4GAPO-2M.
b Over the frequency range 150 kHz to 80 MHz, eld strenghts should be less than 3 V/m.

19
Recommended separation distance between portable and mobile RF communication equipment and
the BP4GAPO-2M
The BP4GAPO-2M is intended for use in a electromagnetic environment in which radiated RF disturbance are controlled. The customer or the user of
the BP4GAPO-2M can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications
equipment (transmitters) and the BP4GAPO-2M as recommended below, according to the maximum output power of the communications equipment.
Rated maximum output power of
transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d = 1,2√P
80 MHz to 800 MHz
d = 1,2√P
800 MHz to 2,5 GHz
d = 2,3√P
0,01 N/A 0,12 0,23
0,1 N/A 0,38 0,73
1N/A 1,2 2,3
10 N/A 3,8 7,3
100 N/A 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the
equation applicable to the frequency of the transmitter, wher P is the maximum output power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
Note 1: At 80 MHz and 800 MHz the separation distance for the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reection from structures,
objects and people.
