Microscan MicroHAWK MV-20 User manual

Step 4 — Install AutoVISION
AutoVISION can also be installed from the Download Center at www.microscan.com and can also be
found on the Microscan Tools Drive that is packaged with the camera.
1. Follow the prompts to install AutoVISION from the Tools Drive.
2. Click on the AutoVISION icon to run the program.
Minimum System Requirements
• Intel Core i3 Processor @ 1.6 GHz
• Internet Explorer 11 or higher / Google Chrome
• 2GB RAM (Windows 7 SP1 / Windows 7 Embedded Standard SP1)
• 3GB hard drive space
• 32-bit color display, 1366 x 768
• 4.0 Windows Experience Index (particularly for graphics)
• 1 USB 2.0 port and 1 Network port
Step 3 — Mount and Position the Camera
1. Position the camera at a focal distance of one inch or more from a test object.
2. Tip the camera relative to the object to avoid the glare of direct (specular) reflection. The case parting
line should be perpendicular to the plane of the symbol by either pitching the symbol or the camera.
Avoid excessive skew or pitch. Maximum skew is ±30°; maximum pitch is ±30°.
Proper lighting is critical to the success of a machine vision application. Depending on the requirements
of your application, you may need to add external lighting from Microscan’s NERLITE family of machine
vision lighting products.
Consider the following:
• Is the surface of the object flat, slightly bumpy, or very bumpy?
• Is the surface matte or shiny?
• Is the object curved or flat?
• What is the color of the object or area being inspected?
• Is the object moving or stationary?
Machine vision lighting should maximize contrast of the areas or features being inspected while
minimizing the contrast of everything else.
Step 5 — Connect to the Camera
After you launch AutoVISION, you will see the Select a device to start editing a job view.
Note: If there is a default job on the camera, AutoVISION will automatically skip the Connect step and you
will see the Image view.
1. Select your camera from the Select Device dropdown menu.
2. Click the Modify button beneath the camera settings details to change camera settings.
3. Choose whether you want to create a new job, load a job (.avp), or upload a job from the camera.
Note: If you are using an MV-20 or MV-30 with a USB cable, the driver has already configured your
PC address. If you are using an MV-40, you must set the PC to the same IP range as the default IP
address. Default IP address: 192.168.188.2 . Set the PC to the same IP range (example: 192.168.188.100 ).
Step 6 — Evaluate a Captured Image and Auto Calibrate
You will see the Image view after selecting your device. This view allows you to evaluate your first image
capture, providing information such as image size and a histogram. Click the Auto Calibration button to
set optimal camera parameters automatically. You can also adjust Exposure, Gain, and Focus as needed,
and set the desired Lighting Mode.
Step 7 — Create Your First Job with AutoVISION
After you have evaluated a captured image and Auto Calibrated the camera in the Image view, you will
move to the Edit view. This interface allows you to set camera parameters, add machine vision tools to
captured images, set tool parameters, and configure I/O inspection outputs.
Step 8 — Explore the Interface
The Edit view features a large image area with tool icons above and tool parameters below or to the right
depending on user preference. When a tool is selected, its specific parameters appear.
Tools that have been added are shown in the job list to the left of the image area, below Camera.
Image settings can be controlled using the icons in the corners of the image area.
Note: A Color Tool is also
available, but is not shown in
these images. The Color
Tool proves Color ID and
Color Match functionality.
Quick Start Guide
MicroHAWK MV-20 / MV-30 / MV-40
Copyright ©2017 Microscan Systems, Inc. P/N 83-9137432-02 Rev B
Step 1 — Check Hardware
Note: Full configuration diagrams are available in the MicroHAWK MV-20 / MV-30 / MV-40 Configuration Guide.
Item Description Part Number
1MicroHAWK MV-20, MicroHAWK MV-30, or MicroHAWK MV-40 7AXY-YZZZ-LPPP
2Cable, USB A to Micro B, 6 ft., MV-20 61-9000034-01
3Cable, USB A to Micro B, 3 ft., MV-20 61-9000045-01
4Power Supply, 5V 97-9000006-01
5Cable, DB15 to Ext. Power/USB, MV-30 61-9000038-01
6Power Supply, 100-240VAC, +24VDC, M12 12-Pin Socket 97-000012-01
7Cordset, Host, Ethernet, M12 8-Pin Plug (Screw-On) to RJ45, 1 m. 61-000160-03
Step 2 — Connect the System
MV-20 – Standalone USB Configuration
To Host
USB Type A
Plug
Micro-USB
Type B Plug 1
2 or 3
MV-30 – Standalone USB Configuration
1
1
MV-40 – Standalone Ethernet Configuration
To Power
Note: An accessory USB cable is required
between the 15-pin corner-exit cable and
the host’s USB port.
To Host
To Host
Power
Supply
Integrated
Corner-Exit
Cable
Accessory
USB Cable
to Host
Note: The MV-40 can be configured as an RS-232 camera with the QX-1 Interface Device.
See the MicroHAWK MV-20 / MV-30 / MV-40 Configuration Guide for more detail.
5
4
6
7
Note: There are two USB connection options – one is BUS-powered
and the other is externally powered. BUS-powered cable delivers
reduced illumination – approximately 30% less brightness.

Step 12 — Run the Job
When all job parameters are set, click on the Run step at the top of the interface. The software will download the
vision job just created to the camera and will begin the inspection
. Inspection results and the list of active tools
are shown at the right of the image view. That information can also be moved below the image area by
clicking the orientation buttons above the inspection results area.
Test Jobs
Note: For descriptions of more advanced functionality, such as setting Inspection Outputs or using the
Locate Tool and Decode Tool’s Dynamic Locate functionality to track multiple tools from image to image,
see the help documentation in AutoVISION software.
Decode Tool, OCR Tool, Match Strings Tool,
String Format Tool
Measure Tool,
Count Tool
LOT 123456
DATE 05/2024
VISION
SIMPLIFIED
Measure:
Measure the distance between
the jaws of the caliper gauges at left.
Count:
Count the circles on the dice shown
at right.
Step 9 — Set Camera Parameters
1. Click on the Camera box to the left of the image area.
2. In the camera parameters below the image area, select the desired type of Trigger, Trigger Polarity,
Photometry (Exposure and Gain), Focus, and Lighting.
Step 10 — Add Tools to the Job
1. Click on the Decode Tool or drag it onto the image area.
2. Use the anchor points at the corners of the region of interest to form a box around the Data Matrix
symbol. Leave plenty of space on each side of the symbol.
3. Now add a second Decode Tool and do the same for the 1D symbol below the Data Matrix symbol.
4. Finally, add an OCR Tool and drag the region of interest around the area of the image where “123456”
is printed.
Step 11 — Try Out the Job
Once you have configured the tools as desired, use the arrow icons in the Job area to try the job you have
just created.
Note: Most jobs will inspect multiple captured images. If only one image is being inspected, the effect of the
arrow icons will not be evident.
Try Out Job
Once
Try Out Job
in Loop
Copyright ©2017 Microscan Systems, Inc.
Power Requirements and Pin Assignments
MicroHAWK MV-20: 5VDC ± 5%; 350mA at 5VDC (typ.)
MicroHAWK MV-30: 5V ± 5%; 600mA at 5VDC (typ.)
MicroHAWK MV-40: 4.75V – 30V; 150mA at 24VDC (typ.)
Important: See the MicroHAWK MV-20 / MV-30 / MV-40 Configuration Guide for information about
Microscan’s Isolation Mounting Kit (P/N 98-9000064-01) to eliminate ground loops or other external
electrical noise through your MicroHAWK MV-30 or MV-40 camera.
MicroHAWK MV-20 Micro-USB Type B Socket
Pin Function
1Vbus (5V)
2D–
3D+
4N/C
5Ground
MicroHAWK MV-30 High-Density 15-Pin Dsub
USB/Serial Socket
MicroHAWK MV-40 M12 Connectors
Pin Function
1+5VDC
2TX232
3RX232
4GND
5D+
6N/C
7Output 1+
8Default+
9Trigger+
10 D–
11 Output 3+
12 Input+ (New Master+)
13 Chassis
14 Output 2+
15 Vbus
Ground
Output 3
Output 1
Output 2
New Master Default
Power
Input Common
Output Common
RS-232 (Host) RxD
Trigger
RS-232
(Host) TxD
M12 12-pin Plug
Note: An accessory
cable is required
between the MV-30’s
15-pin corner-exit
cable and the host’s
USB port.
TX (+)
RX (–)
RX (+)
TX (–)
V+
V–
M12 8-Pin Socket (Ethernet)
V+
V–
MicroHAWK MV Part Numbers
MicroHAWK MV part numbers follow the format 7ABX-YZZZ-LPPP.
7 = MicroHAWK.
Example Part Number: 7412-2000-2104
Description: MicroHAWK MV-40, IP65 Case, 24V, Ethernet, Machine Vision, SXGA, 1.2 Megapixel, Mono, High Density,
Autofocus, White Outer LEDs, AutoVISION + Verification + Visionscape.
(A) Model
1: Engine, No Case, USB
2: MV-20, IP40 Case, USB
3: MV-30, IP54 Case, 5V, USB
4: MV-40, IP65 Case, 24V, Ethernet
(B) Application Type
1: Auto ID and Machine Vision
(X) Sensor
1: WVGA 0.3 Megapixel, Mono
2: SXGA, 1.2 Megapixel, Mono
3: QSXGA, 5 Megapixel, Color
(Y) Optics
0: Custom
1: Standard Density
2: High Density
(ZZZ) Focus Distance
000: Autofocus
050: 50 mm = 1.96 in.
102: 102 mm = 4.02 in.
190: 190 mm = 7.48 in.
300: 300 mm = 11.81 in.
(L) Illumination
0: Inner LEDs Only
1: Red Outer LEDs
2: White Outer LEDs
(PPP) Software License Bundles
100: AutoVISION Sensor
101: AutoVISION
102: AutoVISION + Visionscape
103: AutoVISION + Verification
104: AutoVISION + Verification + Visionscape
Notes:
•(A) Model: The MicroHAWK Engine is available for OEM-certified partners only.
•(L) Illumination: Outer LEDs provide extra illumination. Base level illumination included with all cameras.
•Field Upgrades: Not available for optics or illumination due to factory settings for optical alignment, LED balancing, and
sealing for IP enclosure rating. However, the camera’s software is field-upgradeable via licenses.
