Microsoft Lumia 650 Dual SIM User manual

Quick Guide
Lumia 650 Dual SIM
[ERROR: book part number not defined] Issue
1 EN RM-1154

Keys and parts
1Maincamera
2 Audio connector
3Earpiece
4 Front camera
5 Volume keys
6 Power/Lock key
7Microphone
8 Charger connector
9Loudspeaker
10 Flash

Insert the SIM and memory cards
Note: Your SIM card has an effect on important
settings. Insert the SIM card before switching the
phone on.
1. Put your finger in the recess at the bottom edge
of the back cover.
2. Press the middle of the back cover, bend the cover
open, and remove it.
3. If the battery is in, put your fingernail in the recess
on its top edge, and lift it out.
4. Push the nano-SIM card into the SIM slot with the
metal contact area down, until you hear a click.
Tip: To remove the SIM, push the card in until it's
released, then pull it out.
Use only original nano-SIM cards. Use of
incompatible SIM cards may damage the card or the
device, and may corrupt data stored on the card.
5. For Lumia 650 Dual SIM: If you have a second SIM
card, push it into the SIM2 slot, until it locks into
place.

6. If you have a memory card, slide the card into the
memory card slot.

Replace the battery and back cover
1. Line up the battery contacts, and put the battery
in.
2. Press the top edge of the back cover against the
top edge of your phone, and snap the cover into
place, locking all the hooks around the edges of the
cover.

Switch your phone on and charge
the battery
Note: Your SIM card has an effect on important
settings. Insert the SIM card before switching the
phone on.
1. To switch your phone on, press and hold the
power key until the phone vibrates. It takes a while
for the phone to walk you through the setup and
get all the apps installed. Your phone’s screen may
even be black at times, so wait patiently.
2. When asked, make sure you select your language
and region correctly. You may not be able to
change some of the settings later on.
To charge your phone, plug a compatible charger
into a wall outlet, and connect the cable to your
phone. You can also charge your phone from a
computer with a USB cable, but it may take a longer
time.
If the battery is completely discharged, it may take
up to 20 minutes before the charging indicator is
displayed.

Set up your Microsoft account
When you connect your Microsoft account to your
phone, you can get all the cool apps and games
from Windows Store and keep your stuff safe with
automatic backups to the cloud with OneDrive.
During the setup, you can create a new account. If
you sign in to any Microsoft service, such as
Outlook.com (or Hotmail), Office, OneDrive, or
Xbox, you already have a Microsoft account. Sign in
with the same username and password.
When asked, fill in your account details, and select
how you want to get your one-time verification
code. Type in your mail address or the last 4 digits
of your phone number. Make sure you remember
your credentials for the account. You may need
them later.
Tip: If your screen switches off, press the power
key, and drag the lock screen up.

Navigate by touch
Go back to the start screen
In any view, tap the start key .
Switch between open apps
Tap and hold the back key , and choose the app
you want.
To close an app, tap .
Check the available options
Depending on the app, tap at the bottom right
corner or at the top left corner.
Discover all your apps
On the start screen, swipe left to see the apps menu.
To go back, swipe right.
View notifications and access settings
To quickly view missed calls and unread mails and
messages, and to access settings, open the action
centre. Place a finger at the top of the screen, and
slide it down.

Zoom in or out
Place 2 fingers on an item, such as a photo or a web
page, and slide your fingers apart or together.
