MicroSys Electronics miriac SBC-LS1043A2 User manual

miriac SBC-LS1043A2
User Manual (CRX05 Revision 2)
V 2.2

Table of Contents
miriac SBC-LS1043A2 User Manual
V 2.2
2/72
© MicroSys Electronics GmbH 2017
Table of Contents
1General Notes..............................................4
1.1 Warranty........................................................4
1.2 Links..............................................................4
1.3 Liability..........................................................4
1.4 Offer to Provide Source Code of Certain
Software........................................................5
1.5 Symbols, Conventions and Abbreviations.....6
1.5.1 Symbols ........................................................6
1.5.2 Conventions ..................................................6
2Introduction .................................................7
2.1 Safety and Handling Precautions..................7
2.2 Short Description...........................................8
2.3 Shipping List..................................................8
2.4 Feature Changelist for HW Revision 2..........9
2.5 Functional Coverage...................................10
3Quick Start Guide......................................11
3.1 Prerequisites ...............................................11
3.1.1 Minimum Requirements ..............................11
3.1.2 Recommended Items..................................11
3.2 Board Preparation and Power-Up ...............12
3.3 Operation ....................................................13
3.3.1 U-Boot Startup.............................................13
3.3.2 Linux............................................................14
4System Description...................................15
4.1 Block Diagram.............................................15
4.2 Feature Overview........................................15
4.3 Mechanical Dimensions ..............................17
4.3.1 MPX-LS1043A2...........................................17
4.3.2 SBC-LS1043A2...........................................18
4.4 Connector Layout –Top..............................19
4.5 Connector Layout –Bottom.........................20
4.6 Power Supply..............................................21
4.6.1 Input Supply Rating.....................................21
4.6.2 Input Power Connector................................21
4.6.3 Power Supply Structure...............................21
4.6.4 RTC Backup Battery....................................22
4.6.5 Current Measurement .................................23
4.6.6 Fuses ..........................................................23
5System Core, Boot Configuration and
On-Board Memory.....................................24
5.1 Processor NXP LS1043A............................24
5.2Nomenclature..............................................24
5.3 JTAG Chain.................................................24
5.4 Reset Structure ...........................................24
5.5 Clock Distribution ........................................27
5.6 Boot Configuration.......................................29
5.7 NAND Flash.................................................30
5.8 QSPI Flash..................................................31
5.9 I²C Bus.........................................................32
5.9.1 I2C-1............................................................32
5.9.2 I2C-2............................................................33
6Peripherals.................................................35
6.1 Connector References.................................35
6.2 Module Connector.......................................36
6.3 LAN Connections.........................................36
6.3.1 Port 1...........................................................37
6.3.2 Port 2...........................................................37
6.3.3 Port 3...........................................................37
6.3.4 Port 4...........................................................38
6.4 PCIe Connections........................................39
6.4.1 Mini-PCIe Slot..............................................39
6.4.2 Mini-PCIe Slot / mSATA Slot.......................42
6.4.3 PCIe Extension Connector 1 .......................44
6.4.4 PCIe Extension Connector 2 .......................45
6.5 SATA...........................................................47
6.6 MicroSD Card Slot.......................................48
6.7 USB.............................................................49
6.7.1 USB1...........................................................49
6.7.2 USB2...........................................................50
6.7.3 USB3...........................................................51
6.8 UART...........................................................52
6.9 MCU Connector...........................................53
6.10 JTAG Connector..........................................54
6.11 Aurora Connectors (optional).......................55
6.12 General Purpose Inputs / Outputs...............56
6.13 Fan Connector.............................................58
6.14 Smart Card Connector.................................59
6.15 emBRICK Connector...................................60
7Switches, Buttons and Jumpers ..............61
7.1 Boot Device Switch......................................61
7.2 Board Configuration Switch.........................62
7.3 Reset Button................................................63
8LEDs ...........................................................64
8.1 RJ45 LEDs ..................................................64
8.2 Power And Reset LEDs...............................65
8.3 RGB LEDs...................................................66
9Software .....................................................67
9.1 U-Boot .........................................................67
9.2 Operating System Support ..........................67

Table of Contents
miriac SBC-LS1043A2 User Manual
V 2.2
3/72
© MicroSys Electronics GmbH 2017
9.3 Flash Layout................................................68
9.3.1 NAND Flash ................................................68
9.3.2 SD Card ......................................................68
9.3.3 QSPI Flash..................................................68
10 Appendix....................................................69
10.1 Acronyms ....................................................69
10.2 Table of Figures...........................................70
10.3 Table of Tables............................................70
11 History........................................................72

General Notes 1
miriac SBC-LS1043A2 User Manual
V 2.2
4/72
© MicroSys Electronics GmbH 2017
1 General Notes
Copyright MicroSys Electronics GmbH, January 2017
All rights reserved. All rights in any information which appears in this document
belong to MicroSys Electronics GmbH or our licensors. You may copy the
information in this manual for your personal, non-commercial use.
Copyrighted products are not explicitly indicated in this manual. The absence of the
copyright (©) and trademark (TM or ®) symbols does not imply that a product is not
protected. Additionally, registered patents and trademarks are similarly not
expressly indicated in this manual.
1.1 Warranty
To the extent permissible by applicable law all information in this document is
provided without warranty of any kind, whether expressed or implied, including but
not limited to any implied warranty of satisfactory quality or fitness for a particular
purpose, or of non-infringement of any third party’s rights. We try to keep this
document accurate and up-to-date but we do not make any warranty or
representation about such matters. In particular we assume no liability or
responsibility for any errors or omissions in this document.
MicroSys Electronics GmbH neither gives any guarantee nor accepts any liability
whatsoever for consequential damages resulting from the use of this manual or its
associated product.
MicroSys Electronics GmbH further reserves the right to alter the layout and/or
design of the hardware without prior notification and accepts no liability for doing
so.
1.2 Links
We make no warranty about any other sites that are linked to or from this
document, whether we authorise such links or not.
1.3 Liability
To the extent permissible by applicable law, in no circumstance, including (but not
limited to) negligence, shall we be liable for your reliance on any information in this
document, nor shall we be liable for any direct, incidental, special, consequential,
indirect or punitive damages nor any loss of profit that result from the use of, or the
inability to use, this document or any material on any site linked to this document
even if we have been advised of the possibility of such damage. In no event shall
our liability to you for all damages, losses and causes of action whatsoever,
whether in contract, tort (including but not limited to negligence) or otherwise
exceed the amount, if any, paid by you to us for gaining access to this document.
MicroSys Electronics GmbH
Muehlweg 1
D-82054 Sauerlach
Germany
Phone: [phone]
Fax: [phone]

General Notes 1
miriac SBC-LS1043A2 User Manual
V 2.2
5/72
© MicroSys Electronics GmbH 2017
1.4 Offer to Provide Source Code of Certain
Software
This product contains copyrighted software that is licensed under the General
Public License (“GPL”) and under the Lesser General Public License Version
(“LGPL”). The GPL and LGPL licensed code in this product is distributed without
any warranty. Copies of these licenses are included in this product.
You may obtain the complete corresponding source code (as defined in the GPL)
for the GPL Software, and/or the complete corresponding source code of the LGPL
Software (with the complete machine-readable “work that uses the Library”) for a
period of three years after our last shipment of the product including the GPL
Software and/or LGPL Software, which will be no earlier than December 1, 2010,
for the cost of reproduction and shipment, which is dependent on the preferred
carrier and the location where you want to have it shipped to, by sending a request
to:
MicroSys Electronics GmbH
Muehlweg 1
D-82054 Sauerlach
Germany
In your request please provide the product name and version for which you wish to
obtain the corresponding source code and your contact details so that we can
coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed
under the same license as the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
MicroSys Electronics GmbH is eager to duly provide complete source code as
required under various Free Open Source Software licenses. If however you
encounter any problems in obtaining the full corresponding source code we would
be much obliged if you give us a notification to the email address
[e-mail], stating the product and describing the problem (please do NOT
send large attachments such as source code archives etc to this email address)

General Notes 1
miriac SBC-LS1043A2 User Manual
V 2.2
6/72
© MicroSys Electronics GmbH 2017
1.5 Symbols, Conventions and Abbreviations
1.5.1 Symbols
Throughout this document, the following symbols will be used:
Information marked with this symbol MUST be
obeyed to avoid the risk of severe injury, health
danger, or major destruction of the unit and its
environment
Information marked with this symbol MUST be
obeyed to avoid the risk of possible injury,
permanent damage or malfunction of the unit.
Information marked with this symbol gives important
hints upon details of this manual, or in order to get
the best use out of the product and its features.
Table 1-1 Symbols
1.5.2 Conventions
Symbol
explanation
#
denotes a low active signal
←
denotes the signal flow in the shown direction
→
denotes the signal flow in the shown direction
↔
denotes the signal flow in both directions
→
denotes the signal flow in the shown direction with additional logic /
additional ICs in the signal path
I/O
denotes a bidirectional pin
Input
denotes an input pin
matched
denotes the according signal to be routed impedance controlled and
length matched
Output
denotes an output pin
Pin 1
refers to the numeric pin of a component package
Pin a1
refers to the array position of a pin within a component package
XXX-
denotes the negative signal of a differential pair
XXX+
denotes the positive signal of a differential pair
XXX
denotes an optional not mounted or fitted part
Table 1-2 Conventions

Introduction 2
miriac SBC-LS1043A2 User Manual
V 2.2
7/72
© MicroSys Electronics GmbH 2017
2 Introduction
Thank you for choosing the MicroSys SBC-LS1043A2 Single Board Computer
system. This manual should help you to get the best performance and details out
all of its features.
2.1 Safety and Handling Precautions
ALWAYS use the correct type and polarity of the power supply!
DO NOT exceed the rated maximum values for the power
supply! This may result in severe permanent damage to the
unit, as well as possible serious injury.
ALWAYS keep the unit dry, clean and free of foreign objects.
Otherwise, irreparable damage may occur.
Parts of the unit may become hot during operation. Take care
not to touch any parts of the circuitry during operation to avoid
burns, and operate the unit in a well-ventilated location.
Provide an appropriate cooling solution as required.
ALWAYS take care of ESD-safe handling!
Many pins on external connectors are directly connected to the
CPU or other ESD sensitive devices.
Make or break ANY connections ONLY while the unit is
switched OFF.
Otherwise, permanent damage to the unit may occur, which is
not covered by warranty.
There is no separate SHIELD connection.
All the metal sheaths of shielded connectors are connected to
GND.
Also, all mounting holes of the carrier board are connected to
GND.
The module’s mounting holes are not connected to GND
Take this into account when handling and mounting the unit.
Table 2-1 Safety and Handling Precautions

Introduction 2
miriac SBC-LS1043A2 User Manual
V 2.2
8/72
© MicroSys Electronics GmbH 2017
2.2 Short Description
The SBC-LS1043A2 is a small computer system consisting of
■the MPX-LS1043A2 module, based on NXP’s LS1043A Multicore
Communications Processors
■and the CRX05 carrier board.
It targets both
■evaluation of the respective MPX-LS1043A2 SOM
■direct usage as an industrial computing solution
This document gives you an overview on the board's connectors and how to take the
first steps on the initial setup.
2.3 Shipping List
The SBC-LS1043A2 EvalKit package contains the following items:
■The SBC-LS1043A2 system, mounted with cooling solution
■Power Supply 12V DC stabilized / 2 A
■Cable adapter for the power supply
■USB cable type A –mini B
■Micro-SD-Card with U-Boot and root file system

Introduction 2
miriac SBC-LS1043A2 User Manual
V 2.2
9/72
© MicroSys Electronics GmbH 2017
2.4 Feature Changelist for HW Revision 2
The revision 2 of the carrier board provides new features:
■Added LED driver with 4x RGB LEDs
■Added 12 GPIOs (6x in / 6x out) addressable via I²C
oOutput voltage level maximum 24V (according to the input voltage
of the carrier board)
oInput voltage range 24V maximum
■Added SuperCap for RTC backup battery (CR2032 coin cell as assembly
option still available)
■Added prerequisites for support of emBRICK devices
■Added current shunt for current measurements
■Added optional (by assembly option) support for onboard current
measurements of the CPU module consumption via I²C current sense
amplifier
■Added LAN interrupt support
■Added SMART CARD connector
■Added optional (by assembly option) extension connector (for example for
additional GPIOs or graphic support if provided by the CPU)
■Added mounting holes for the carrierboard
■Added a fan connector
■Added connector labeling (silkscreen) on the PCB
Some features were changed:
■SerDes 6 and SerDes 7 lanes were swapped in order to achieve a wider
functional coverage within the MPX2 module family
oSerDes 6 is now connected to the SATA connector (ST10)
oSerDes 7 is now connected to the mPCIe / mSATA slot (ST7)
■Improved power input section with filters
■Improved mechanical mounting of the CPU module and mPCIe/ mSATA
cards
■Replaced PCIe x1 edge card connector with second PCIe extension
connector

Introduction 2
miriac SBC-LS1043A2 User Manual
V 2.2
10/72
© MicroSys Electronics GmbH 2017
2.5 Functional Coverage
The following table shows the coverage achieved by the SBC-LS1043A2 com-
pared to the features which are available on the carrierboard:
Interfaces provided by CRX05 carrierboard
Interfaces available with the SBC-
LS1043A2
SerDes 0
PCIe
-
SerDes 1
SGMII
✓
SerDes 2
SGMII
-
SerDes 3
SGMII
✓
SerDes 4
mPCIe / Aurora
-
SerDes 5
PCIe
✓
SerDes 6
SATA
-
SerDes 7
mPCIe / mSATA
✓
RGMII 1
PHY
✓
USB 1
2.0 / 3.0
✓(2.0)
USB 2
2.0 / 3.0
✓(2.0)
SD-Card
1bit / 4 bit & boot device
✓
UART 1
UART to USB
(debug console)
✓
UART 2
TTL only
✓
I²C 1
Multiple devices
✓
I²C 2
Multiple devices
✓
JTAG
Signals on non-standard
connector
✓
Watchdog
Hardware watchdog with
trigger signal from module
✓
RTC backup
Supercap
✓
Manual Reset
Button
✓
Reset LEDs
2x red
✓
Power LED
1x green
✓
Table 2-2 Functional coverage

Quick Start Guide 3
miriac SBC-LS1043A2 User Manual
V 2.2
11/72
© MicroSys Electronics GmbH 2017
3 Quick Start Guide
3.1 Prerequisites
Always make sure to handle the SBC-LS1043A2 unit ESD-safe!
Otherwise, the unit may suffer permanent damage.
However, do not place the unit directly flat on a metal surface,
as this may result in short circuits and damage to the board.
At first time operation unpack the unit and make sure that is clean and free of visible
damage or foreign objects.
3.1.1 Minimum Requirements
To operate the board, you will at least need the following items:
■an adequate power supply, delivering 12V DC (stabilized) / 2A minimum.
■an USB cable (type A –mini B) adapted to connector ST5
■a serial terminal, such as a PC with an USB port running a terminal Software
(e.g. TeraTerm, HyperTerminal, putty, ckermit...), or else a hardware serial
console. Choose the following parameters:
(a) 115200 Bd
(b) 8 Data bits
(c) No parity
(d) 1 Stop Bit
3.1.2 Recommended Items
The following items are not absolutely necessary, but strongly recommended for
practical operation and development purposes:
■Network connection via Port3 to your local network installation
■TFTP server available for downloading within the network (Hint: may run on the
same PC as the serial Terminal)
■SATA HDD/SSD and/or SD card as mass storage and/or boot media

Quick Start Guide 3
miriac SBC-LS1043A2 User Manual
V 2.2
12/72
© MicroSys Electronics GmbH 2017
3.2 Board Preparation and Power-Up
■Make sure the switches SW1 and SW2 are set properly in order to select the
correct boot source and board configuration
■The board comes preconfigured to boot correctly on arrival.
■Connect the mini USB cable to ST5.
■Connect other peripherals (USB, LAN, SATA, ...) as far as intended.
■Connect the power line to the ST3 connector, while the power supply is still
switched off.
■Switch on the power.
Figure 3-1 System setup example (LAN port 3)

Quick Start Guide 3
miriac SBC-LS1043A2 User Manual
V 2.2
13/72
© MicroSys Electronics GmbH 2017
3.3 Operation
After Power-up, the green LED on the module should light up
and any red LED should be off.
IF NOT, DISCONNECT THE UNIT FROM POWER AND CHECK
FOR FAULTS!
3.3.1 U-Boot Startup
When power is supplied the system will start.
On startup, U-Boot will come up similar to the following:
The exact output may vary, depending on U-Boot and MPX-LS1043A2 module
versions in use.
U-Boot 2016.09 (May 08 2017 - 14:45:17 +0200)
SoC: unknown (0x87920610)
Clock Configuration:
CPU0(A53):1600 MHz CPU1(A53):1600 MHz CPU2(A53):1600
MHz
CPU3(A53):1600 MHz
Bus: 400 MHz DDR: 1600 MT/s FMAN: 500
MHz
Reset Configuration Word (RCW):
00000000: 08100010 0a000000 00000000 00000000
00000010: 33580002 00000002 60044000 c1002000
00000020: 00000000 00000000 00000000 01036ffc
00000030: 20004504 00001200 00000096 00000001
Model: MPXLS1043 Board
Board: MPXLS1043-A2, boot from SD
I2C: ready
DRAM: Detected UDIMM Fixed DDR on board
2 GiB (DDR4, 32-bit, CL=11, ECC on)
Waking secondary cores to start from ffd0b000
All (4) cores are up.
Using SERDES1 Protocol: 13144 (0x3358)
NAND: 512 MiB
MMC: FSL_SDHC: 0
In: serial
Out: serial
Err: serial
SEC0: RNG instantiated
SATA link 0 timeout.
AHCI 0001.0301 32 slots 1 ports 6 Gbps 0x1 impl SATA mode

Quick Start Guide 3
miriac SBC-LS1043A2 User Manual
V 2.2
14/72
© MicroSys Electronics GmbH 2017
flags: 64bit ncq pm clo only pmp fbss pio slum part ccc apst
Found 0 device(s).
SCSI: Net:
MMC read: dev # 0, block # 2080, count 128 ...
Fman1: Uploading microcode version 106.4.15
Could not get PHY for FSL_MDIO0: addr 2
Failed to connect
Could not get PHY for FSL_MDIO0: addr 3
Failed to connect
PCIe0: pcie@3400000 disabled
PCIe1: pcie@3500000 Root Complex: no link
PCIe2: pcie@3600000 disabled
FM1@DTSEC2 [PRIME], FM1@DTSEC3, FM1@DTSEC9
=>
3.3.2 Linux
For detailed setup instructions, refer to the text document “linux-test-mpxls1043-
A2.txt” delivered in the "Linux" directory along with the unit!
The text document mentioned here may refer to an older version.

System Description 4
miriac SBC-LS1043A2 User Manual
V 2.2
15/72
© MicroSys Electronics GmbH 2017
4 System Description
This section describes all parts of the SBC-LS1043A2 system.
4.1 Block Diagram
4.2 Feature Overview
The SBC-LS1043A2 offers the following features:
QorIQ ARM Cortex A53 cores 4xCPU Processor
SDRAM
32-bit DDR4 interface
Default: 2GByte
up to 4GByte
up to 1600MT/s
2 x DDR4 (x16)
single bank
Synchronous Memory
8-bit NAND Flash
Default: 512 MB
up to 2 GByte
Hard Disk Drives
Interface
Not available
PCI Express port
2.0 / 5Gbps
Lane x1
Root complex operations
1x PCIe extension
connector
2.0 / 5Gbps
Lane x1
Root complex operations
1x Mini PCIe/mSata Slot
USB
USB 3.0 Phy
USB connector type A
USB 3.0 Phy
USB connector type A
Expansion Cards
MMC/SD/SDIO
micro SD card holder
Figure 4-1 Block Diagram (MPX-LS1043A2 Revision 2 on carrier CRX05 Revision 2)

System Description 4
miriac SBC-LS1043A2 User Manual
V 2.2
16/72
© MicroSys Electronics GmbH 2017
QorIQ ARM Cortex A53 cores 4xCPU Processor
Serial Interfaces
UART1
Converted to USB
(FT232),
Available on USB
connector type mini B
UART2
4-wire
Extension Port
LVTTL
I2C
I2C-1
400 kbps
Connected Devices:
TMP451AIDQF
Temperature Sensor
2x BR24G128NUX-3
EEPROM
RX-8803
RTC
IDT6V49205B
Clock Generator
TLC59116
RGB LED Driver
MAX7325
GPIO Port Expander
I2C-2
400 kbps
Connected Devices:
SC18IS602BIPW
I2C-to-SPI Bridge
MAX9611AUB
Current monitor
TCA9544APWR
I²C Multiplexer
Gigabit Ethernet
Controller
RGMII
10/100/1000 Mbps
SGMII
10/100/1000 Mbps
SGMII
10/100/1000 Mbps
System JTAG
Controller
JTAG
10 pin layout for TAG-
connect
Power Management
Primary Supply
LM25116MH
Input:
9-30V DC
Output:
5V DC / peak 8A
Backup Supply
(RTC backup)
Supercap
Table 4-1 Feature Overview

System Description 4
miriac SBC-LS1043A2 User Manual
V 2.2
17/72
© MicroSys Electronics GmbH 2017
4.3 Mechanical Dimensions
4.3.1 MPX-LS1043A2
The following drawing shows the mechanical outline of the MPX-LS1043A2 module
that is plugged in the CRX05 carrier board.
This drawing is not to scale.
For 3D data files please contact MicroSys.
Figure 4-2 Mechanical Dimensions Modul

System Description 4
miriac SBC-LS1043A2 User Manual
V 2.2
18/72
© MicroSys Electronics GmbH 2017
4.3.2 SBC-LS1043A2
The following drawing shows the mechanical outline of the SBC-LS1043A2
assembly.
This drawing is not to scale.
For 3D data files please contact MicroSys.
Figure 4-3 SBC-LS1043A2 Mechanical Dimensions

System Description 4
miriac SBC-LS1043A2 User Manual
V 2.2
19/72
© MicroSys Electronics GmbH 2017
4.4 Connector Layout – Top
Figure 4-4 Top connectors

System Description 4
miriac SBC-LS1043A2 User Manual
V 2.2
20/72
© MicroSys Electronics GmbH 2017
4.5 Connector Layout – Bottom
Figure 4-5 Bottom connectors
