IEI Technology KINO-PV-D5253-D4253 User manual

Page i
K INO-PV-D5253-D4253 Mini-ITX Motherboard
IE I Technology Corp.
User Manual
Mini-ITX Motherboard with Intel® Atom™ Processor D525
/D 425, DDR 3, VGA, LAN, S ATA 3G b /s ,
PCIe x1, USB , HD Audio, R oHS Compliant
MODE L:
K INO-PV-D5253-D4253
Rev. 1.02 – 7 February, 2012

Page ii
K INO-PV-D5253-D4253 Mini-ITX Motherboard
R evis ion
Date Version Changes
7 February, 2012 1.02 Modify Section E.3. Assembly Language Example
7 February, 2012 1.01 Modify Motherboard’s picture because V1.02 removed
JCOM63, JCOM64, CN8, CN9 and IR1 connectors
Modified Dimension in Figure 1-3.
7 February, 2012 1.00 Initial release

Page iii
K INO-PV-D5253-D4253 Mini-ITX Motherboard
Copyright
COPYR IGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

Page iv
K INO-PV-D5253-D4253 Mini-ITX Motherboard
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 BENEFITS ................................................................................................................... 2
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 3
1.5 DIMENSIONS............................................................................................................... 4
1.6 DATA FLOW................................................................................................................ 5
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 5
2 PACKING LIST............................................................................................................. 8
2.1ANTI-STATIC PRECAUTIONS........................................................................................ 9
2.2 UNPACKING PRECAUTIONS......................................................................................... 9
2.3 PACKING LIST........................................................................................................... 10
2.4 OPTIONAL ITEMS.......................................................................................................11
3 CONNECTORS ........................................................................................................... 13
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 14
3.1.1 Layout .............................................................................................................. 14
3.1.2 Peripheral Interface Connectors ..................................................................... 14
3.1.3 External Interface Panel Connectors............................................................... 15
3.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 16
3.2.1 Battery Connector............................................................................................ 16
3.2.2 CPU Fan Connector........................................................................................ 17
3.2.3 System Fan Connector..................................................................................... 18
3.2.4 Standard ATX power connector ....................................................................... 19
3.2.5 Digital I/O Connector...................................................................................... 20
3.2.6 Front Panel Connector .................................................................................... 21
3.2.7 Memory Slot..................................................................................................... 22
3.2.8 Parallel Port Connector .................................................................................. 23
3.2.9 RS-232/422/485 Serial Port Connector........................................................... 24
3.2.10 SATA Drive Connectors ................................................................................. 26

Page v
K INO-PV-D5253-D4253 Mini-ITX Motherboard
3.2.11 SMBus Connector........................................................................................... 27
3.2.12 SPI Flash Connector...................................................................................... 28
3.2.13 USB Connectors............................................................................................. 29
3.2.14 TPM Connector.............................................................................................. 29
3.2.15 Keyboard/Mouse Wafer.................................................................................. 30
3.2.16 PCIe Mini Card Slot ...................................................................................... 31
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 32
3.3.1 Audio Connector.............................................................................................. 33
3.3.2 LAN Connector ................................................................................................ 33
3.3.3 Serial Port Connectors (COM1)...................................................................... 34
3.3.4 Serial Port Connectors (COM1_2, COM3_4)................................................. 34
3.3.5 USB Connector ................................................................................................ 35
3.3.6 VGA Connector................................................................................................ 35
4 INSTALLATION ......................................................................................................... 37
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 38
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 38
4.3 BASIC INSTALLATION ............................................................................................... 40
4.3.1 SO-DIMM Installation..................................................................................... 40
4.3.2 Motherboard Installation................................................................................. 40
4.4 JUMPER SETTINGS .................................................................................................... 41
4.4.1 Clear CMOS Jumper........................................................................................ 41
4.4.2 USB6, 7 power Jumper.................................................................................... 42
4.4.3 COM 6 Function Select Jumper....................................................................... 43
4.5 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 44
4.5.1 SATA Drive Connection ................................................................................... 44
4.5.2 Single RS-232 Cable (w/o Bracket) ................................................................. 46
4.6 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 47
4.6.1 Audio Connector.............................................................................................. 47
4.6.2 LAN Connection............................................................................................... 48
4.6.3 Serial Device Connection ................................................................................ 49
4.6.4 USB Device Connection................................................................................... 50
4.6.5 VGA Monitor Connection ................................................................................ 51
4.7 SOFTWARE INSTALLATION ........................................................................................ 52
5 BIOS.............................................................................................................................. 53

Page vi
K INO-PV-D5253-D4253 Mini-ITX Motherboard
5.1 INTRODUCTION......................................................................................................... 54
5.1.1 Starting Setup................................................................................................... 54
5.1.2 Using Setup...................................................................................................... 54
5.1.3 Getting Help..................................................................................................... 55
5.1.4 Unable to Reboot after Configuration Changes.............................................. 55
5.1.5 BIOS Menu Bar................................................................................................ 55
5.2 MAIN........................................................................................................................ 56
5.3ADVANCED............................................................................................................... 57
5.3.1 ACPI Settings................................................................................................... 57
5.3.2 Trusted Computing........................................................................................... 58
5.3.3 CPU Configuration.......................................................................................... 59
5.3.4 SATA Configuration ......................................................................................... 61
5.3.5 USB Configuration........................................................................................... 62
5.3.6 Super IO Configuration ................................................................................... 63
5.3.6.1 Serial Port n Configuration....................................................................... 64
5.3.6.2 Parallel Port Configuration ....................................................................... 69
5.3.7 H/W Monitor.................................................................................................... 70
5.3.8 Serial Port Console Redirection ...................................................................... 71
5.4 CHIPSET ................................................................................................................... 73
5.4.1 Host Bridge Configuration .............................................................................. 74
5.4.2 South Bridge Configuration............................................................................. 75
5.4.3 Intel IGD SWSCI OpRegion............................................................................. 77
5.5 BOOT........................................................................................................................ 78
5.6 SECURITY................................................................................................................. 79
5.7 SAVE&EXIT.............................................................................................................. 81
ABIOS Options.................................................................................................................. 83
B Terminology .................................................................................................................... 86
C One Key Recovery.......................................................................................................... 90
D Watchdog Timer............................................................................................................118
E Digital I/O Interface..................................................................................................... 121
F Hazardous Materials Disclosure ................................................................................. 124

Page vii
K INO-PV-D5253-D4253 Mini-ITX Motherboard
Lis t of Figures
Figure 1-1: KINO-PV-D5253/D4253................................................................................................2
Figure 1-2: Connectors ..................................................................................................................3
Figure 1-3: Dimensions (mm)........................................................................................................4
Figure 1-4: Data Flow Diagram......................................................................................................5
Figure 3-1: Connectors and Jumpers.........................................................................................14
Figure 3-2: Battery Connector Location.....................................................................................17
Figure 3-3: CPU Fan Connector Location..................................................................................18
Figure 3-4: System Fan Connector Location.............................................................................19
Figure 3-5: ATX Power Input Connector Location ....................................................................20
Figure 3-6: Digital I/O Connector Locations ..............................................................................21
Figure 3-7: Front Panel Connector Location .............................................................................22
Figure 3-8: Memory Card Slot Location .....................................................................................23
Figure 3-9: Parallel Port Connector Location............................................................................24
Figure 3-10: RS-232/422/485 Serial Port Connector..................................................................25
Figure 3-11: SATA Drive Connector Location ...........................................................................26
Figure 3-12: SMBus Connector Location...................................................................................27
Figure 3-13: SPI Flash Connector...............................................................................................28
Figure 3-14: USB Connector Pinout Locations .........................................................................29
Figure 3-15: TPM Connector........................................................................................................30
Figure 3-16: Keyboard/Mouse Connector Location..................................................................31
Figure 3-17: PCIe Mini Card Slot Location.................................................................................32
Figure 3-18: External Peripheral Interface Connector..............................................................32
Figure 3-19: Audio Connector.....................................................................................................33
Figure 3-20: Serial Port Pinouts..................................................................................................34
Figure 3-21: VGA Connector .......................................................................................................36
Figure 4-1: SO-DIMM Installation ................................................................................................40
Figure 4-2: Clear BIOS Jumper Location ...................................................................................42
Figure 4-3: USB6, 7 power Jumper Location.............................................................................43
Figure 4-4: COM 6 Function Select Jumper Location...............................................................44
Figure 4-5: SATA Drive Cable Connection.................................................................................45

Page viii
K INO-PV-D5253-D4253 Mini-ITX Motherboard
Figure 4-6: SATA Power Drive Connection................................................................................46
Figure 4-7: Single RS-232 Cable Installation .............................................................................47
Figure 4-8: Audio Connector.......................................................................................................48
Figure 4-9: LAN Connection........................................................................................................49
Figure 4-10: Serial Device Connector.........................................................................................50
Figure 4-11: USB Connector........................................................................................................51
Figure 4-12: VGA Connector .......................................................................................................52
Figure C-1: IEI One Key Recovery Tool Menu...........................................................................91
Figure C-2: Launching the Recovery Tool.................................................................................95
Figure C-3: Recovery Tool Setup Menu .....................................................................................96
Figure C-4: Command Mode........................................................................................................96
Figure C-5: Partition Creation Commands.................................................................................97
Figure C-6: Launching the Recovery Tool.................................................................................99
Figure C-7: System Configuration for Windows .......................................................................99
Figure C-8: Build-up Recovery Partition..................................................................................100
Figure C-9: Press any key to continue.....................................................................................100
Figure C-10: Press F3 to Boot into Recovery Mode................................................................101
Figure C-11: Recovery Tool Menu ............................................................................................101
Figure C-12: About Symantec Ghost Window.........................................................................102
Figure C-13: Symantec Ghost Path ..........................................................................................102
Figure C-14: Select a Local Source Drive ................................................................................103
Figure C-15: Select a Source Partition from Basic Drive .......................................................103
Figure C-16: File Name to Copy Image to ................................................................................104
Figure C-17: Compress Image...................................................................................................104
Figure C-18: Image Creation Confirmation..............................................................................105
Figure C-19: Image Creation Process.......................................................................................105
Figure C-20: Image Creation Complete....................................................................................105
Figure C-21: Press Any Key to Continue .................................................................................106
Figure C-22: Partitions for Linux...............................................................................................107
Figure C-23: System Configuration for Linux..........................................................................108
Figure C-24: Access menu.lst in Linux (Text Mode)...............................................................108
Figure C-25: Recovery Tool Menu ............................................................................................109
Figure C-26: Recovery Tool Main Menu...................................................................................110
Figure C-27: Restore Factory Default.......................................................................................111
Figure C-28: Recovery Complete Window...............................................................................111

Page ix
K INO-PV-D5253-D4253 Mini-ITX Motherboard
Figure C-29: Backup System.....................................................................................................112
Figure C-30: System Backup Complete Window ....................................................................112
Figure C-31: Restore Backup ....................................................................................................113
Figure C-32: Restore System Backup Complete Window......................................................113
Figure C-33: Symantec Ghost Window ....................................................................................114

Page x
K INO-PV-D5253-D4253 Mini-ITX Motherboard
Lis t of Tables
Table 1-1: Technical Specifications..............................................................................................7
Table 2-1: Packing List.................................................................................................................11
Table 2-2: Optional Items.............................................................................................................12
Table 3–1: Internal Peripheral Connectors ................................................................................15
Table 3–2: External Peripheral Connectors...............................................................................16
Table 3-3: Battery Connector Pinouts........................................................................................17
Table 3-4: CPU Fan Connector Pinouts .....................................................................................18
Table 3-5: System Fan Connector Pinouts ................................................................................19
Table 3-6: Digital I/O Connector Pinouts....................................................................................21
Table 3-7: Front Panel Connector Pinouts.................................................................................22
Table 3-8: Parallel Port Connector Pinouts ...............................................................................24
Table 3-9: RS-232/422/485 Serial Port Connector Pinouts.......................................................26
Table 3-10: SATA Drive Connector Pinouts...............................................................................27
Table 3-11: SMBus Connector Pinouts ......................................................................................28
Table 3-12: SPI Flash Connector.................................................................................................28
Table 3-13: USB Port Connector Pinouts...................................................................................29
Table 3-14: TPM Connector Pinouts...........................................................................................30
Table 3-15: Keyboard Connector Pinouts..................................................................................31
Table 3-16: LAN Pinouts ..............................................................................................................33
Table 3-17: Serial Port Pinouts....................................................................................................34
Table 3-18: Serial Port Pinouts....................................................................................................35
Table 3-19: USB Port Pinouts......................................................................................................35
Table 3-20: VGA Connector Pinouts...........................................................................................36
Table 4-1: Jumpers.......................................................................................................................41
Table 4-2: Clear BIOS Jumper Settings......................................................................................42
Table 4-3: USB6, 7 power Jumper Settings ...............................................................................42
Table 4-4: COM 6 Function Select Jumper Settings.................................................................43
Table 5-1: BIOS Navigation Keys................................................................................................55

Page xi
K INO-PV-D5253-D4253 Mini-ITX Motherboard
B IOS Menus
BIOS Menu 1: Main.......................................................................................................................56
BIOS Menu 2: Advanced..............................................................................................................57
BIOS Menu 3: ACPI Settings .......................................................................................................58
BIOS Menu 4: TPM Configuration...............................................................................................59
BIOS Menu 5: CPU Configuration...............................................................................................60
BIOS Menu 6: IDE Configuration.................................................................................................61
BIOS Menu 7: USB Configuration...............................................................................................62
BIOS Menu 8: Super IO Configuration........................................................................................63
BIOS Menu 9: Serial Port n Configuration Menu.......................................................................64
BIOS Menu 10: Parallel Port Configuration Menu.....................................................................69
BIOS Menu 11: Hardware Health Configuration........................................................................70
BIOS Menu 12: Serial Port Console Redirection.......................................................................72
BIOS Menu 13: Chipset................................................................................................................73
BIOS Menu 14: Host Bridge Chipset Configuration..................................................................74
BIOS Menu 15: South Bridge Chipset Configuration................................................................75
BIOS Menu 16: South Bridge Chipset Configuration................................................................77
BIOS Menu 17: Boot.....................................................................................................................78
BIOS Menu 18: Security...............................................................................................................80
BIOS Menu 19:Exit........................................................................................................................81

Page 1
K INO-PV-D5253-D4253 Mini-ITX Motherboard
C hapter
1
1Introduction

Page 2
K INO-PV-D5253-D4253 Mini-ITX Motherboard
1.1 Introduc tion
Figure 1-1: KINO-PV-D5253/D4253
The KINO-PV-D5253/D4253 Mini-ITX motherboard is a Intel® Atom™ processor D525 or
D425 platform. Supports two DDR3 SO-DIMMs up to 2.0 GB each (4.0 GB total),
The integrated Intel® ICH8M Chipset supports Three GbE LAN ports through the Realtek
RTL8111E Ethernet controller (with ASF 2.0 support), also supports two SATA 3Gb/s
drives.
The KINO-PV-D5253/D4253 includes one VGA output, Eight USB2.0, two PCIe mini
sockets, one PCI slot, one PCIe x1 slot, one parallel port, audio jacks provides flexible
expansion options. Serial device connectivity is provided by four RS-232 serial ports
(RJ-45), one RS-232 serial ports (DB-9), and one internal RS-232/422/485 connectors.
1.2 B enefits
Some of the KINO-PV-D5253/D4253 motherboard benefits include:
Powerful graphics
Staying connected with both wired LAN connections
Speedy running of multiple programs and applications

Page 3
K INO-PV-D5253-D4253 Mini-ITX Motherboard
1.3 Features
Some of the KINO-PV-D5253/D4253 motherboard features are listed below:
Mini-ITX form factor
Intel® Atom™ D525 /D425 Processor
Supports two DDR3 SODIMM
Three Gigabit Ethernet connectors
Two SATA connectors
Eight USB ports
Six serial ports
RoHS compliant
1.4 Connectors
The connectors on the KINO-PV-D5253/D4253 are shown in the figure below.
Figure 1-2: Connectors

Page 4
K INO-PV-D5253-D4253 Mini-ITX Motherboard
1.5 Dimensions
The main dimensions of the KINO-PV-D5253/D4253 are shown in the diagram below.
Figure 1-3: Dimensions (mm)

Page 5
K INO-PV-D5253-D4253 Mini-ITX Motherboard
1.6 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram
1.7 Technical Specifications
KINO-PV-D5253/D4253 technical specifications are shown below.
S pecification K INO-PV-D5253/D4253
Form Factor Mini-ITX

Page 6
K INO-PV-D5253-D4253 Mini-ITX Motherboard
S pecification K INO-PV-D5253/D4253
CPU options Intel® Atom™ processor D525, 1.8 GHz/1 MB L2 cache
Intel® Atom™ processor D425, 1.8 GHz/512 KB L2 cache
Express Chips et Intel® ICH8M
Memory 2 x SO-DIMM DDR3 800MHz up to 4GB
Audio Realtek ALC888 HD 7.1 channel audio codec
LAN 3 x Realtek RTL8111E PCIe GbE controller with ASF 2.0
support
S u p e r I /O Fintek F81865
B IOS uEFI BIOS
EC IT8519
Digital I/O 8-bit, 4-bit input/4-bit output
Watchdog Timer Software programmable supports 1~255 sec. system reset
E xpans ion
PC Ie 2 x PCIe Mini slots
1 x PCIe x1 slot
PCI 1 x PCI slot
I/O Interface Connectors
Audio Connector 1 x Line-out
1 x Mic-in
Dis play Ports 1 x VGA port (2048x1536)
E thernet 3 x RJ-45 GbE ports
Fan connector 1 x 4-pin CPU fan connector with smart fan control
1 x 3-pin system fan
S MB us 1 x 4-pin wafer connector
TPM 2 x 10-pin header
Keyboard/Mouse 1 x KB/MS pin header

Page 7
K INO-PV-D5253-D4253 Mini-ITX Motherboard
S pecification K INO-PV-D5253/D4253
S erial P orts 4 x RS-232 (RJ-45)
1 x RS-232 (DB-9)
1 x RS-232/422/485 (pin header)
US B 2.0/1.1 Ports 6 x External USB ports
2 x Internal USB ports via one 8-pin headers
Parallel Ports 1 x LPT connector via 26-pin header
S torage
S erial AT A 2 x SATA 3.0 Gb/s connectors.
Environmental and Power S pecifications
Power S upply ATX and AT power supported
Power Connector One internal 20-pin power connector for power supply
Power Consumption 5 V @ 2.62 A, Vcore_12 V @ 0.76 A
(1.8 GHz Intel® Atom™D525 dual-core CPU with one 1 GB
DDR3 SO-DIMM)
Operating Temperature -20°C ~ 60°C with free air, -20°C ~ 70°C with force air for
D525 processor
-20°C ~ 65°C with free air, -20°C ~ 70°C with force air for
D425 processor
Humidity 5% ~ 95% (non-condensing)
Phys ical S pecifications
Dimens ions 170 mm x 170 mm
Weight GW/NW 900 g / 360 g
Table 1-1: Technical Specifications

Page 8
K INO-PV-D5253-D4253 Mini-ITX Motherboard
C hapter
2
2Packing Lis t
