MicroSys miriac SBC-T1024 User manual

miriac SBC-T1024
User Manual (CRX05 Revision 2 + Revision 3)
V 2.3

Table of Contents
miriac SBC-T1024 User Manual
V 2.3
2/70
© MicroSys Electronics GmbH 2017
Table of Contents
1General Notes..............................................4
1.1 Warranty........................................................4
1.2 Links..............................................................4
1.3 Liability..........................................................4
1.4 Offer to Provide Source Code of Certain
Software........................................................5
1.5 Symbols, Conventions and Abbreviations.....6
1.5.1 Symbols ........................................................6
1.5.2 Conventions ..................................................6
2Introduction .................................................7
2.1 Safety and Handling Precautions..................7
2.2 Short Description...........................................8
2.3 Shipping List..................................................8
2.4 Feature Changelist for HW Revisions ...........8
2.4.1 Changes from revision 2 to revision 3...........8
2.4.2 Feature Changelist for HW Revision 2..........9
2.5 Functional Coverage...................................10
3Quick Start Guide......................................11
3.1 Prerequisites ...............................................11
3.1.1 Minimum Requirements ..............................11
3.1.2 Recommended Items..................................11
3.2 Board Preparation and Power-Up ...............12
3.3 Operation ....................................................13
3.3.1 U-Boot Startup.............................................13
3.3.2 Linux............................................................14
4System Description...................................15
4.1 Block Diagram.............................................15
4.2 Feature Overview........................................15
4.3 Mechanical Dimensions ..............................17
4.3.1 MPX-T1024.................................................17
4.3.2 SBC-T1024 .................................................18
4.4 Connector Layout –Top..............................19
4.5 Connector Layout –Bottom.........................20
4.6 Power Supply..............................................21
4.6.1 Input Supply Rating.....................................21
4.6.2 Input Power Connector................................21
4.6.3 Power Supply Structure...............................21
4.6.4 RTC Backup Battery....................................22
4.6.5 Current Measurement .................................23
4.6.6 Fuses ..........................................................23
5System Core, Boot Configuration and
On-Board Memory.....................................24
5.1 Processor NXP T1024.................................24
5.2 JTAG Chain.................................................24
5.3 Reset Structure ...........................................24
5.4 Clock Distribution.........................................26
5.5 Boot Configuration.......................................28
5.6 NAND Flash.................................................29
5.7 SPI Flash.....................................................30
5.8 I²C Bus.........................................................31
5.8.1 I2C-1............................................................31
5.8.2 I2C-2............................................................32
6Peripherals.................................................34
6.1 Connector References.................................34
6.2 Module Connector.......................................35
6.3 LAN Connections.........................................35
6.3.1 Port 1 / 2 / 3.................................................36
6.3.2 Port 4...........................................................36
6.4 PCIe Connections........................................38
6.4.1 Mini-PCIe Slot..............................................38
6.4.2 Mini-PCIe Slot / mSATA Slot.......................40
6.4.3 PCIe Extension Connector 1 .......................42
6.4.4 PCIe Extension Connector 2 .......................43
6.4.5 PCIe with external clock ..............................44
6.5 SATA...........................................................45
6.6 MicroSD Card Slot.......................................46
6.7 USB.............................................................47
6.7.1 USB1...........................................................47
6.7.2 USB2...........................................................48
6.7.3 USB3...........................................................49
6.8 UART...........................................................50
6.9 MCU Connector...........................................51
6.10 JTAG Connector..........................................52
6.10.1 JTAG on Revision R3..................................52
6.10.2 JTAG on Revision R2..................................53
6.11 Aurora Connectors (optional).......................54
6.12 General Purpose Inputs / Outputs...............55
6.13 Fan Connector.............................................57
6.14 Smart Card Connector.................................58
6.15 emBRICK Connector...................................59
7Switches, Buttons and Jumpers ..............60
7.1 Boot Device Switch......................................60
7.2 Board Configuration Switch.........................61
7.3 PCIe selection: root complex / endpoint......61
7.4 Reset Button................................................62
8LEDs ...........................................................63
8.1 RJ45 LEDs ..................................................63
8.2 Power And Reset LEDs...............................64
8.3 RGB LEDs...................................................65

Table of Contents
miriac SBC-T1024 User Manual
V 2.3
3/70
© MicroSys Electronics GmbH 2017
9Software.....................................................66
9.1 U-Boot.........................................................66
9.2 Operating System Support..........................66
9.3 Flash Layout................................................66
9.3.1 NAND Flash ................................................66
9.3.2 SD Card ......................................................66
9.3.3 SPI Flash.....................................................66
10 Appendix....................................................67
10.1 Acronyms.....................................................67
10.2 Table of Figures...........................................68
10.3 Table of Tables............................................68
11 History........................................................70

General Notes 1
miriac SBC-T1024 User Manual
V 2.3
4/70
© MicroSys Electronics GmbH 2017
1 General Notes
Copyright MicroSys Electronics GmbH, January 2017
All rights reserved. All rights in any information which appears in this document
belong to MicroSys Electronics GmbH or our licensors. You may copy the
information in this manual for your personal, non-commercial use.
Copyrighted products are not explicitly indicated in this manual. The absence of the
copyright (©) and trademark (TM or ®) symbols does not imply that a product is not
protected. Additionally, registered patents and trademarks are similarly not
expressly indicated in this manual.
1.1 Warranty
To the extent permissible by applicable law all information in this document is
provided without warranty of any kind, whether expressed or implied, including but
not limited to any implied warranty of satisfactory quality or fitness for a particular
purpose, or of non-infringement of any third party’s rights. We try to keep this
document accurate and up-to-date but we do not make any warranty or
representation about such matters. In particular we assume no liability or
responsibility for any errors or omissions in this document.
MicroSys Electronics GmbH neither gives any guarantee nor accepts any liability
whatsoever for consequential damages resulting from the use of this manual or its
associated product.
MicroSys Electronics GmbH further reserves the right to alter the layout and/or
design of the hardware without prior notification and accepts no liability for doing
so.
1.2 Links
We make no warranty about any other sites that are linked to or from this
document, whether we authorise such links or not.
1.3 Liability
To the extent permissible by applicable law, in no circumstance, including (but not
limited to) negligence, shall we be liable for your reliance on any information in this
document, nor shall we be liable for any direct, incidental, special, consequential,
indirect or punitive damages nor any loss of profit that result from the use of, or the
inability to use, this document or any material on any site linked to this document
even if we have been advised of the possibility of such damage. In no event shall
our liability to you for all damages, losses and causes of action whatsoever,
whether in contract, tort (including but not limited to negligence) or otherwise
exceed the amount, if any, paid by you to us for gaining access to this document.
MicroSys Electronics GmbH
Muehlweg 1
D-82054 Sauerlach
Germany
Phone: [phone]
Fax: [phone]

General Notes 1
miriac SBC-T1024 User Manual
V 2.3
5/70
© MicroSys Electronics GmbH 2017
1.4 Offer to Provide Source Code of Certain
Software
This product contains copyrighted software that is licensed under the General
Public License (“GPL”) and under the Lesser General Public License Version
(“LGPL”). The GPL and LGPL licensed code in this product is distributed without
any warranty. Copies of these licenses are included in this product.
You may obtain the complete corresponding source code (as defined in the GPL)
for the GPL Software, and/or the complete corresponding source code of the LGPL
Software (with the complete machine-readable “work that uses the Library”) for a
period of three years after our last shipment of the product including the GPL
Software and/or LGPL Software, which will be no earlier than December 1, 2010,
for the cost of reproduction and shipment, which is dependent on the preferred
carrier and the location where you want to have it shipped to, by sending a request
to:
MicroSys Electronics GmbH
Muehlweg 1
D-82054 Sauerlach
Germany
In your request please provide the product name and version for which you wish to
obtain the corresponding source code and your contact details so that we can
coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed
under the same license as the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
MicroSys Electronics GmbH is eager to duly provide complete source code as
required under various Free Open Source Software licenses. If however you
encounter any problems in obtaining the full corresponding source code we would
be much obliged if you give us a notification to the email address
[e-mail], stating the product and describing the problem (please do NOT
send large attachments such as source code archives etc to this email address)

General Notes 1
miriac SBC-T1024 User Manual
V 2.3
6/70
© MicroSys Electronics GmbH 2017
1.5 Symbols, Conventions and Abbreviations
1.5.1 Symbols
Throughout this document, the following symbols will be used:
Information marked with this symbol MUST be
obeyed to avoid the risk of severe injury, health
danger, or major destruction of the unit and its
environment
Information marked with this symbol MUST be
obeyed to avoid the risk of possible injury,
permanent damage or malfunction of the unit.
Information marked with this symbol gives important
hints upon details of this manual, or in order to get
the best use out of the product and its features.
Table 1-1 Symbols
1.5.2 Conventions
Symbol
explanation
#
denotes a low active signal
←
denotes the signal flow in the shown direction
→
denotes the signal flow in the shown direction
↔
denotes the signal flow in both directions
→
denotes the signal flow in the shown direction with additional logic /
additional ICs in the signal path
I/O
denotes a bidirectional pin
Input
denotes an input pin
matched
denotes the according signal to be routed impedance controlled and
length matched
Output
denotes an output pin
Pin 1
refers to the numeric pin of a component package
Pin a1
refers to the array position of a pin within a component package
XXX-
denotes the negative signal of a differential pair
XXX+
denotes the positive signal of a differential pair
XXX
denotes an optional not mounted or fitted part
Table 1-2 Conventions

Introduction 2
miriac SBC-T1024 User Manual
V 2.3
7/70
© MicroSys Electronics GmbH 2017
2 Introduction
Thank you for choosing the MicroSys SBC-T1024 Single Board Computer system.
This manual should help you to get the best performance and details out all of its
features.
2.1 Safety and Handling Precautions
ALWAYS use the correct type and polarity of the power supply!
DO NOT exceed the rated maximum values for the power
supply! This may result in severe permanent damage to the
unit, as well as possible serious injury.
ALWAYS keep the unit dry, clean and free of foreign objects.
Otherwise, irreparable damage may occur.
Parts of the unit may become hot during operation. Take care
not to touch any parts of the circuitry during operation to avoid
burns, and operate the unit in a well-ventilated location.
Provide an appropriate cooling solution as required.
ALWAYS take care of ESD-safe handling!
Many pins on external connectors are directly connected to the
CPU or other ESD sensitive devices.
Make or break ANY connections ONLY while the unit is
switched OFF.
Otherwise, permanent damage to the unit may occur, which is
not covered by warranty.
There is no separate SHIELD connection.
All the metal sheaths of shielded connectors are connected to
GND.
Also, all mounting holes of the carrier board are connected to
GND.
The module’s mounting holes are not connected to GND
Take this into account when handling and mounting the unit.
Table 2-1 Safety and Handling Precautions

Introduction 2
miriac SBC-T1024 User Manual
V 2.3
8/70
© MicroSys Electronics GmbH 2017
2.2 Short Description
The SBC-T1024 is a small computer system consisting of
■the MPX-T1024 module, based on NXP’s T1024 Multicore Communications
Processors
■and the CRX05 carrier board.
It targets both
■evaluation of the respective MPX-T1024 SOM
■direct usage as an industrial computing solution
This document gives you an overview on the board's connectors and how to take the
first steps on the initial setup.
2.3 Shipping List
The SBC-T1024 EvalKit package contains the following items:
■The SBC-T1024 system, mounted with cooling solution
■Power Supply 12V DC stabilized / 2 A
■Cable adapter for the power supply
■USB cable type A –mini B
■Micro-SD-Card with U-Boot and root file system
2.4 Feature Changelist for HW Revisions
2.4.1 Changes from revision 2 to revision 3
The revision 3 of the carrier board provides following changes:
■Added SW4 to switch between root complex and endpoint
■Added 2 header for GND interconnection (JP1, JP2)
■Addes buffer to SPI-CLK
■Added possibility to modify board to run with external PCIe-clock, requires
hardwaremodification (default assembled to use internal clock)
■Type of “JTG-connector” changed to JST-BM14B-SRSS-TB

Introduction 2
miriac SBC-T1024 User Manual
V 2.3
9/70
© MicroSys Electronics GmbH 2017
2.4.2 Feature Changelist for HW Revision 2
The revision 2 of the carrier board provides new features:
■Added LED driver with 4x RGB LEDs
■Added 12 GPIOs (6x in / 6x out) addressable via I²C
oOutput voltage level maximum 24V (according to the input voltage
of the carrier board)
oInput voltage range 24V maximum
■Added SuperCap for RTC backup battery (CR2032 coin cell as assembly
option still available)
■Added prerequisites for support of emBRICK devices
■Added current shunt for current measurements
■Added optional (by assembly option) support for onboard current
measurements of the CPU module consumption via I²C current sense
amplifier
■Added LAN interrupt support
■Added SMART CARD connector
■Added optional (by assembly option) extension connector (for example for
additional GPIOs or graphic support if provided by the CPU)
■Added mounting holes for the carrierboard
■Added a fan connector
■Added connector labeling (silkscreen) on the PCB
Some features were changed:
■SerDes 6 and SerDes 7 lanes were swapped in order to achieve a wider
functional coverage within the MPX2 module family
oSerDes 6 is now connected to the SATA connector (ST10)
oSerDes 7 is now connected to the mPCIe / mSATA slot (ST7)
■Improved power input section with filters
■Improved mechanical mounting of the CPU module and mPCIe/ mSATA
cards
■Replaced PCIe x1 edge card connector with second PCIe extension
connector

Introduction 2
miriac SBC-T1024 User Manual
V 2.3
10/70
© MicroSys Electronics GmbH 2017
2.5 Functional Coverage
The following table shows the coverage achieved by the SBC-T1024 compared to
the features which are available on the carrierboard:
Interfaces provided by CRX05 carrierboard
Interfaces available with the SBC-
T1024
SerDes 0
PCIe
-
SerDes 1
SGMII
-
SerDes 2
SGMII
-
SerDes 3
SGMII
-
SerDes 4
mPCIe / Aurora
✓(mPCIe)
SerDes 5
PCIe
✓
SerDes 6
SATA
-
SerDes 7
mPCIe / mSATA
✓(mSATA)
RGMII 1
PHY
✓
USB 1
2.0 / 3.0
✓(2.0)
USB 2
2.0 / 3.0
✓(2.0)
SD-Card
1bit / 4 bit & boot device
✓
UART 1
UART to USB
(debug console)
✓
UART 2
TTL only
✓
I²C 1
Multiple devices
✓
I²C 2
Multiple devices
✓
JTAG
Signals on non-standard
connector
✓
Watchdog
Hardware watchdog with
trigger signal from module
✓
RTC backup
Supercap
✓
Manual Reset
Button
✓
Reset LEDs
2x red
✓
Power LED
1x green
✓
Table 2-2 Functional coverage

Quick Start Guide 3
miriac SBC-T1024 User Manual
V 2.3
11/70
© MicroSys Electronics GmbH 2017
3 Quick Start Guide
3.1 Prerequisites
Always make sure to handle the SBC-T1024 unit ESD-safe!
Otherwise, the unit may suffer permanent damage.
However, do not place the unit directly flat on a metal surface,
as this may result in short circuits and damage to the board.
At first time operation unpack the unit and make sure that is clean and free of visible
damage or foreign objects.
3.1.1 Minimum Requirements
To operate the board, you will at least need the following items:
■an adequate power supply, delivering 12V DC (stabilized) / 2A minimum.
■an USB cable (type A –mini B) adapted to connector ST5
■a serial terminal, such as a PC with an USB port running a terminal Software
(e.g. TeraTerm, HyperTerminal, putty, ckermit...), or else a hardware serial
console. Choose the following parameters:
(a) 115200 Bd
(b) 8 Data bits
(c) No parity
(d) 1 Stop Bit
3.1.2 Recommended Items
The following items are not absolutely necessary, but strongly recommended for
practical operation and development purposes:
■Network connection via Port4 to your local network installation
■TFTP server available for downloading within the network (Hint: may run on the
same PC as the serial Terminal)
■SATA HDD/SSD and/or SD card as mass storage and/or boot media

Quick Start Guide 3
miriac SBC-T1024 User Manual
V 2.3
12/70
© MicroSys Electronics GmbH 2017
3.2 Board Preparation and Power-Up
■Make sure the switches SW1 and SW2 are set properly in order to select the
correct boot source and board configuration
■The board comes preconfigured to boot correctly on arrival.
■Connect the mini USB cable to ST5.
■Connect other peripherals (USB, LAN, SATA, ...) as far as intended.
■Connect the power line to the ST3 connector, while the power supply is still
switched off.
■Switch on the power.
Figure 3-1 System setup example (LAN port 4)

Quick Start Guide 3
miriac SBC-T1024 User Manual
V 2.3
13/70
© MicroSys Electronics GmbH 2017
3.3 Operation
After Power-up, the green LED on the module should light up
and any red LED should be off.
IF NOT, DISCONNECT THE UNIT FROM POWER AND CHECK
FOR FAULTS!
3.3.1 U-Boot Startup
When power is supplied the system will start.
On startup, U-Boot will come up similar to the following:
The exact output may vary, depending on U-Boot and MPX-T1024 module versions in
use.
U-Boot 2016.09 (Oct 20 2016 - 15:19:01 +0200)
CPU0: T1024, Version: 1.0, (0x85400010)
Core: e5500, Version: 2.1, (0x80241021)
Clock Configuration:
CPU0:1400 MHz, CPU1:1400 MHz,
CCB:400 MHz,
DDR:800 MHz (1600 MT/s data rate) (Asynchronous),
IFC:100 MHz
FMAN1: 700 MHz
QMAN: 400 MHz
L1: D-cache 32 KiB enabled
I-cache 32 KiB enabled
Reset Configuration Word (RCW):
00000000: 0810000e 00000000 00000000 00000000
00000010: 2d000001 00000002 68040000 21002000
00000020: 00000000 00000000 00000000 00036700
00000030: 00000000 076e0a00 00000000 00000006
Board: MPXT1024
I2C: ready
SPI: ready
DRAM: Detected UDIMM Fixed DDR4 on board
2 GiB (DDR4, 64-bit, CL=12, ECC on)
L2: 256 KiB enabled
Corenet Platform Cache: 256 KiB enabled
Using SERDES1 Protocol: 90 (0x5a)
NAND: 512 MiB
MMC: FSL_SDHC: 0
*** Warning - bad CRC, using default environment

Quick Start Guide 3
miriac SBC-T1024 User Manual
V 2.3
14/70
© MicroSys Electronics GmbH 2017
PCIe1: Root Complex, no link, regs @ 0xfe240000
PCIe1: Bus 00 - 00
PCIe2: disabled
PCIe3: Root Complex, no link, regs @ 0xfe260000
PCIe3: Bus 01 - 01
In: serial
Out: serial
Err: serial
USB: 100MHz SYSCLK
Net: Initializing Fman
MMC read: dev # 0, block # 2080, count 128 ...
Fman1: Uploading microcode version 107.4.2
FM1@DTSEC4 [PRIME]
Hit any key to stop autoboot: 0
=>
3.3.2 Linux
For detailed setup instructions, refer to the text document “linux-4.1.8-mpx1024.txt”
delivered in the "Linux" directory along with the unit!
The text document mentioned here may refer to an older version.

System Description 4
miriac SBC-T1024 User Manual
V 2.3
15/70
© MicroSys Electronics GmbH 2017
4 System Description
This section describes all parts of the SBC-T1024 system.
4.1 Block Diagram
4.2 Feature Overview
The SBC-T1024 offers the following features:
QorIQ e5500 cores 2xCPU Processor
SDRAM
64-bit DDR4 interface
Default: 2GByte
up to 8GByte
up to 1600MT/s
4 x DDR4 (x16)
single bank
Synchronous Memory
8-bit NAND Flash
Default: 512 MB
up to 2 GByte
Hard Disk Drives
Interface
SATA 2.0
mSATA slot
PCI Express port
2.0 / 5Gbps
Lane x1
Root complex operations
1x PCIe extension
connector
2.0 / 5Gbps
Lane x1
Root complex operations
1x Mini PCIe Slot
USB
USB 2.0 Phy
USB connector type A
USB 2.0 Phy
USB connector type A
Expansion Cards
MMC/SD/SDIO
micro SD card holder
Figure 4-1 Block Diagram (MPX-T1024 Revision 4 on carrier CRX05 Revision 2)

System Description 4
miriac SBC-T1024 User Manual
V 2.3
16/70
© MicroSys Electronics GmbH 2017
QorIQ e5500 cores 2xCPU Processor
Serial Interfaces
UART1
Converted to USB
(FT232),
Available on USB
connector type mini B
UART2
4-wire
Extension Port
LVTTL
I2C
I2C-1
400 kbps
Connected Devices:
LM95245
Temperature Sensor
AT24C128C
EEPROM
BR24G128NUX-3
EEPROM
RX-8803
RTC
IDT6V49205B
Clock Generator
TLC59116
RGB LED Driver
MAX7325
GPIO Port Expander
I2C-2
400 kbps
Connected Devices:
SC18IS602BIPW
I2C-to-SPI Bridge
MAX9611AUB
Current monitor
TCA9544APWR
I²C Multiplexer
Gigabit Ethernet
Controller
RGMII
10/100/1000 Mbps
System JTAG
Controller
JTAG
Different connector on
CRX05-R2 and R3
Power Management
Primary Supply
LM25116MH
Input:
9-30V DC
Output:
5V DC / peak 8A
Backup Supply
(RTC backup)
Supercap
Table 4-1 Feature Overview

System Description 4
miriac SBC-T1024 User Manual
V 2.3
17/70
© MicroSys Electronics GmbH 2017
4.3 Mechanical Dimensions
4.3.1 MPX-T1024
The following drawing shows the mechanical outline of the MPX-T1024 module
that is plugged in the CRX05 carrier board.
This drawing is not to scale.
For 3D data files please contact MicroSys.
Figure 4-2 Mechanical Dimensions Modul

System Description 4
miriac SBC-T1024 User Manual
V 2.3
18/70
© MicroSys Electronics GmbH 2017
4.3.2 SBC-T1024
The following drawing shows the mechanical outline of the SBC-T1024 assembly.
This drawing is not to scale.
For 3D data files please contact MicroSys.
Figure 4-3 SBC-T1024 Mechanical Dimensions

System Description 4
miriac SBC-T1024 User Manual
V 2.3
19/70
© MicroSys Electronics GmbH 2017
4.4 Connector Layout – Top
Figure 4-4 Top connectors

System Description 4
miriac SBC-T1024 User Manual
V 2.3
20/70
© MicroSys Electronics GmbH 2017
4.5 Connector Layout – Bottom
Figure 4-5 Bottom connectors
