Aaeon GENE-5315-A13 User manual

SubCompact Board
GENE -5315
GENE-5315 Manual Rev.A + B 5th Ed.
November 2020
GENE-5315
AMD®Geode
LX800/900 series Processors
RTL8139DL for 10/100Mbps
Type II CompactFlash
2 COM (Rev.A), 5 COM(Rev.B)
4 USB2.0, 1 IrDA
Type III Mini PCI

SubCompact Board
GENE -5315
Copyright Notice
This document is copyrighted, 2009. All rights are reserved. The
original manufacturer reserves the right to make improvements
to the products described in this manual at any time without
notice.
No part of this manual may be reproduced, copied, translated,
or transmitted in any form or by any means without the prior
written permission of the original manufacturer. Information
provided in this manual is intended to be accurate and reliable.
However, the original manufacturer assumes no responsibility
for its use, or for any infringements upon the rights of third
parties that may result from its use.
The material in this document is for product information only
and is subject to change without notice. While reasonable
efforts have been made in the preparation of this document to
assure its accuracy, AAEON assumes no liabilities resulting
from errors or omissions in this document, or from the use of the
information contained herein.
AAEON reserves the right to make changes in the product
design without notice to its users.
i

SubCompact Board
GENE -5315
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
 Award is a trademark of Award Software International, Inc.
 CompactFlash™ is a trademark of the Compact Flash
Association.
 AMD, the AMD Arrow logo and combinations thereof are
trademarks of Advanced Micro Devices, Inc.
®
 Microsoft Windows is a registered trademark of Microsoft Corp.
 ITE is a trademark of Integrated Technology Express,Inc.
 IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
 SoundBlaster is a trademark of Creative Labs, Inc.
All other product names or trademarks are properties of their
respective owners.
ii

SubCompact Board
GENE -5315
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•1 9681531501 Cable Kit for GENE-5315
➢
1700060192
Keyboard & Mouse Cable
➢
1709100201
USB Cable
➢
1701440500
IDE Cable 3.5”
•
1
9657666600 Jumper Cap
•
1
Quick Installation Guide
•
1
CD-ROM for manual (in PDF format) and drivers
•
1
GENE-5315
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
iii

SubCompact Board
GENE -5315
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features ....................................................................1-3
1.3 Specifications ............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions .................................................... 2-2
2.2 Connectors, Jumpers and Mechanical Drawings......2-3
2.3 List of Jumpers.......................................................... 2-9
2.4 List of Connectors ..................................................... 2-10
2.5 Setting Jumpers ........................................................2-12
2.6 AT/ATX Power Type Selection (JP1)........................ 2-13
2.7 CFD Master/ Slave Selection (JP2)...........................2-13
2.8 Clear CMOS (JP3) .................................................... 2-13
2.9 LCD Clock and LVDS Operating Voltage Selection (JP4)
......................................................................................... 2-13
2.10 COM Ports RI/+5V/+12V Selection (JP5) ............... 2-14
2.11 Inverter Voltage Connector (JP6)............................2-14
2.12 CFD Voltage Selection (JP7) (For Rev.B only).......2-14
2.13 IDE Hard Drive Connector (CN1)............................2-14
2.14 Floppy Connector (CN2) .........................................2-15
2.15 Parallel Port Connector (CN3).................................2-16
2.16 Front Panel Connector (CN4)..................................2-17
iv

SubCompact Board
GENE -5315
2.17 USB Port #1 and Port #2 (CN5)..............................2-17
2.18 Digital I/O Connector (CN6) .................................... 2-17
2.19 Audio Input/Output/Cdin/MIC (CN7)........................ 2-18
2.20 ATX External 5VSB (CN8) ......................................2-18
2.21 4P Power Socket (CN9).......................................... 2-19
2.22 LVDS Connector (CN10).........................................2-19
2.23 PC/104 (CN11) (For Rev.A only)............................. 2-20
2.24 TTL LCD (CN12) .....................................................2-22
2.25 Serial Port #2 (CN13).............................................. 2-24
2.26 Fan Connector (CN14)............................................2-24
2.27 Ethernet 10/100Base-TX RJ-45 Phone Jack #1(CN15)
......................................................................................... 2-25
2.28 Ethernet 10/100Base-TX RJ-45 Phone Jack #2(CN16)
......................................................................................... 2-25
2.29 IrDA Connector (CN17)...........................................2-25
2.30 Mini-DIN PS/2 Keyboard/Mouse Connector (CN18)2-26
2.31 Serial Port #1 Connector (CN19) ............................2-26
2.32 CRT Display Connector (CN20)..............................2-26
2.33 USB Port #3 and Port #4 (CN21) ............................2-27
2.34 Inverter Voltage (CN22)...........................................2-27
2.35 Serial Port #3 (CN23)(For Rev.B only)....................2-27
2.36 Serial Port #5 (CN24)(For Rev.B only)....................2-28
2.37 Serial Port #4 (CN25)(For Rev.B only)....................2-28
2.38 Serial Port #6 (CN26) (TTL/GPS) (For Rev.B only) 2-28
2.39 External Battery (BAT1)........................................... 2-29
v

SubCompact Board
GENE -5315
2.40 Compact Flash Disk Slot (CFD1)............................2-29
2.41 Mini-PCI Slot (MPCI1)............................................. 2-30
2.42 DDR SODIMM Slot (DIMM1)................................... 2-30
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 Award BIOS Setup .................................................... 3-3
Chapter 4 Driver Installation
4.1 Software Drivers........................................................ 4-2
4.2 Necessary to know.................................................... 4-3
4.3 Installing VGA Driver.................................................4-4
4.4 Installing AES Driver ................................................. 4-5
4.5 Installing PCI to ISA Bridge Driver ............................4-6
4.6 Installing Ethernet Driver...........................................4-7
4.7 Ethernet Software Configuration...............................4-7
4.8 Installing Audio Driver ............................................... 4-8
Appendix A I/O Information
A.1 I/O Address Map.................................................... A-2
A.2 1st MB Memory Address Map................................ A-2
A.3 IRQ Mapping Chart for Rev.A............................... A-3
A.4 IRQ Mapping Chart for Rev.B............................... A-3
A.5 DMA Channel Assignments...................................A-3
vi

SubCompact Board
GENE -5315
Appendix B Mating Connector
B.1 List of Mating Connectors and Cables.................. B-2
vii

SubCompact Board
GENE -5315
Chapter
1
General
Information
Chapter 1 General Information 1-1

SubCompact Board
GENE -5315
1.1 Introduction
AAEON, a leading embedded boards manufacturer, is pleased to
announce the debut of their new generation 3.5” SubCompact
Board—GENE-5315. The GENE-5315 not only completes
AAEON’s product line of Subcompact boards, but also balances
performance and cost in the embedded market.
GENE-5315 adopts optional onboard AMD Geode LX800 and
LX900. The system memory is deployed with SODIMM DDR
333/400 up to 1GB. In addition, Realtek RTL8139DL supports
two 10/100Base-TX that allows network connections. This
model applies a Type III Mini PCI socket for expansion.
Moreover, four USB 2.0, IDE, RS-232, RS-232/422/485 and
parallel ports are configured on the GENE-5315. Full functions
make GENE-5315 user friendly. With the GENE-5315, there are
no more worries about installing many necessary devices to
complete the functions of your system.
The display of GENE-5315 supports CRT/LCD simultaneous
display and is up to 24-bit single channel TTL/LVDS TFT LCD.
These great features fit into the needs of digital signage.
Furthermore, this brand new SubCompact board is developed to
cater to the requirements of Automation, Medical, ticket machine,
transportation, gaming, KIOSK, and POS/POI applications.
Chapter 1 General Information 1- 2

SubCompact Board
GENE -5315
1.2 Features
 Onboard AMD Geode LX 800/LX900 processors
 SODIMM DDR 333 Max. 1GB, DDR 400 Max. 512MB
 Up to 24-bit Single Channel LVDS TFT LCD
 Dual 10/100Mbps Ethernet
 Type III Mini-PCI and PC/104 (For Rev.A Only)Expansions
 IDE, Floppy Disk Drive & Compactflash Slot
 AC97 Codec 2 CH Audio
 COM, Parallel x 1, USB2.0 x 4, 8-bit Digital I/O, IrDA
 +5V Only Operation
Chapter 1 General Information 1 - 3

SubCompact Board
GENE -5315
1.3 Specifications
System
 Processor Onboard AMD Geode LX800/ LX900
Series Processor
 System Memory 200-pin DDR SODIMM x 1,
Max. 1GB for DDR333 and 512MB
for DDR 400
 Chipset AMD LX series + CS5536
 I/O Chipset ITE IT8712+ IT8888G
 Ethernet Realtek RTL8139DL, 10/100Mbps,
RJ-45 x 2
 BIOS Award Plug & Play BIOS –1MB
ROM
 Watchdog Timer Generates a time-out system
reset
 H/W Monitor Chipset Supports power supply voltages
and temperature monitoring
 Expansion Interface PC/104 x 1 (For Rev.A only),
Mini PCI x 1
 Power Requirement +5V/AT/ATX
 Board Size 5.75”(L) x 4”(W) (146mm x 101.6mm)
 Operating Temperature 32˚F~ 140˚F (0˚C ~ 60˚C)
-4˚F~ 158˚F (-20˚C~70˚C) (for
GENE-5315W1 only)
Chapter 1 General Information 1- 4

SubCompact Board
GENE -5315
Display Supports CRT/LCD simultaneous display
 Chipset AMD LX series + TI SN75LVDS83
 Memory Shared system memory up to 254MB
 LCD Interface Up to 24-bit TTL/LVDS TFT LCD
 Resolution Up to 1920 x 1440 @ 24bpp for CRT
Up to 1600 x 1200 @ 24bpp for LCD
I/O
 Storage EIDE x 1 (UDMA-33 x 1); FloppyDisk
Drive x 1; Type II CompactFlash x 1
 Serial Port RS-232 x 1 (Rev.A)/ RS-232 x 4 &
TTL UART x 1 (Rev.B),
RS-232/422/485 x 1
 Parallel Port SPP/EPP/ECP mode
 USB Port USB2.0 x 4
 PS/2 Port Keyboard & Mouse x 1
 Digital I/O Supports 8-bit(Programmable)
 IrDA One IrDA Tx/Rx header
 Audio Realtek ALC203 2CH AC97 Codec,
MIC-in/ Line-in/ Line-out/ CD-in
Chapter 1 General Information 1 - 5

SubCompact Board
GENE -5315
Chapter
2
Quick
Installation
Guide
Notice:
The Quick Installation Guide is derived
from Chapter 2 of user manual. For other
chapters and further installation
instructions, please refer to the user
manual CD-ROM that came with the
product.
Part No. 2007531522 Printed in Taiwan November 2008
Chapter 2 Quick Installation Guide 2 - 1

SubCompact Board
GENE -5315
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis
Chapter 2 Quick Installation Guide 2 - 2

SubCompact Board
GENE -5315
2.2 Jumpers, Connectors, and Mechanical Drawings
GENE-5315 Rev.A
Component Side
CN9
CN8
CN3
CN7
CN6
CN5
CN21
CN2
JP4
CN20
CN14
CN18
CN1
JP5
CN19
CN13
BAT1 CN16
CN15
CN11
CN4
CN17
Chapter 2 Quick Installation Guide 2 - 3
JP3
JP1
JP6 JP2
CN22
CN10
MPCI1
CN12

SubCompact Board
GENE -5315
132.84
DIMM1
66.04
52.59
CFD1
12.43
0.00
Solder Side
Chapter 2 Quick Installation Guide 2 - 4
34.84
30.49
0.00

SubCompact Board
GENE -5315
123.73
131.95
86.17
50.09
38.31
4.70
7.24 5.14
18.84
Mechanical Drawings
HEATSINK HEIGHT (13.20)
133.93
132.56
125.56
120.27
137.16
133.93
132.27
125.81
119.27
108.27
106.68
97.98
92.07
87.14
91.07
78.73
50.46
61.13
53.95
47.18
37.73 38.11
17.40
10.77
19.06
0.00
7.35
8.89
0.00
6.10
Chapter 2 Quick Installation Guide 2 - 5
(12.55)
(1.60)
(13.00)
(15.35)
0.60
3.22
1.19
0.00
0.00 0.63 5.13 9.42
8.42
13.34
12.39
13.44
20.71
11.41
14.55
18.67
26.62
27.87
29.17
53.28
68.34
85.33
86.12
79.15
82.66
85.76
88.21
87.67
91.93 95.20 98.38
95.20
96.14
91.73
(122.55)
(103.50)
(77.67)
(46.99)
(22.22)

SubCompact Board
GENE -5315
GENE-5315 Rev.B
Component Side
JP1
CN9
CN8
CN7
CN3
CN6
CN21
CN5
CN20
CN14
CN18
CN2 JP5
CN19
CN1
BAT1
CN13
CN16
CN15
JP3
JP2
JP7
CN4
Chapter 2 Quick Installation Guide 2 - 6
JP6
CN9
CN22
CN26
CN24
MPCI1
CN10
CN25
CN12
CN23
JP4
CN17

SubCompact Board
GENE -5315
Solder Side
8.89
Chapter 2 Quick Installation Guide 2 - 7
132.84
DIMM1
66.04
52.53
CFD1
12.43
0.00
98.38
34.84
30.49
0.00
