Micsig MDP Series User manual

5. Operation Steps
6. Warranty
1) Micsig warrants the main body of this differential probe for 1 year.
During the warranty period, Micsig will be responsible for free maintenance for
any failure caused by the quality of the product under normal use.
2) Under the following circumstances, Micsig will refuse to provide maintenance
services or charge for a fee:
a. No packaging or anti-counterfeiting label.
b.Anti-counterfeit label has been altered or blurred beyond recognition.
c. Unauthorized disassembly, such as: changing wires, dismantling internal
components, etc.
d. No sales voucher or the content of sales voucher does not match the product.
7. Safety Precautions
1) Non-professionals do not open the product casing;
2) Do not use while case is open;
3) Do not touch any bare metal while testing;
4) Disconnect the power supply and circuit immediately when over range;
5) Do not use in flammable and explosive environments;
Shenzhen Micsig Technology Co., Ltd.
Tel: [phone] Email: [e-mail]
Add: A106, Huafeng Robot Industrial Park, Hangcheng Rd, Bao’an, Shenzhen,
Guangdong, China, 518126
Quick Guide
High Voltage Differential Probe -- MDP series
Bandwidth: 300MHz / 400MHz / 500MHz
1. Overview
Originated from Micsig’s cutting-edge SigOFITTM technology, the MDP series high-
voltage differential probe has very low noise floor, excellent amplitude-frequency
characteristics and industry-leading common mode rejection capability, allow users
to test high-frequency and high-voltage signals with ease.
* Extension leads,
twist together can
lower noise
1) Power the probe: Connect the probe to the oscilloscope USB via USB-C cable;
2) Connect to oscilloscope: Connect the BNC end of the probe to oscilloscope
channel (make sure the oscilloscope is grounded);
3) Select Range: Select appropriate voltage range according to the signal;
4) Connect the DUT: Use clips or hooks to connect the DUT, if an over-voltage
alarm occurs, disconnect the power supply and the circuit immediately;
5) Set on the oscilloscope.
*Note: Try not to use extension leads when measuring, it could bring more noise floor. If must use the
extension leads, please twist the leads together to reduce noise, and the input frequency should not
exceed 5MHz. If it exceeds 5MHz, the output will have a certain error.

2. Characteristics
Model
MDP703MDP704 MDP705 MDP1503 MDP1504 MDP1505 MDP3003 MDP3004 MDP3005
Bandwidth
300MHz 400MHz 500MHz 300MHz 400MHz 500MHz 300MHz 400MHz 500MHz
Rise time
≤1.2ns ≤0.87ns ≤0.7ns ≤1.2ns ≤0.87ns ≤0.7ns ≤1.2ns ≤0.87ns ≤0.7ns
Attenuation
20X / 200X
50X / 500X
100X / 1000X
Accuracy
±2%
±2%
±2%
Max. input
Differential
Voltage
(DC+AC PK)
70V（20X）
700V（200X）
150V（50X）
1500V（500X）
300V（100X）
3000V（1000X）
Max.
Voltage to
ground
CAT I 600V
CAT II 450V
CAT II 1000V
CAT III 600V
CAT III 1000V
Noise
Full Bandwidth:
20X: ≤ 80mVrms
200X: ≤ 100mVrms
Full Bandwidth:
50X: ≤ 200mVrms
500X: ≤ 250mVrms
Full Bandwidth:
100X: ≤ 400mVrms
1000X: ≤ 500mVrms
CMRR
DC: >-80dB；100kHz: >-70dB
10MHz: >-40dB；120MHz: >-26dB
Input
impedance
16MΩ/0.5pF(differential)
8MΩ/1pF(each input to
ground)
16MΩ/0.5pF(differential)
8MΩ/1pF(each input to
ground)
20MΩ/0.5pF(differential)
10MΩ/1pF(each input to
ground)
Delay
8.44ns(20X)
7.9ns(200X)
8.44ns(50X)
7.9ns(500X)
8.44ns(100X)
7.9ns(1000X)
Output
voltage
≤3V
Output
impedance 50Ω
Overrange
LED flashes, Buzzer beeps
Dimensions
Control module: L*W*H: 91 *33 *15 /mm
Signal box: L*W*H：100 * 36 * 20 /mm
Cable length
Approx. 8 cm (Input); Approx. 120cm (Output)
Temperature
Operating: 0℃~ 40 ℃
Non-operating: -30 ℃~ 70 ℃
Humidity
Operating: 5 ~ 85% RH ( 0℃~ 40 ℃)
Non-operating: 5% ~ 85% RH (≤40 ℃) ; 5% ~ 45% RH (40 ℃~70 ℃)
3. Panel Description
⚫Control Module
⚫Signal Box
4. Precautions
1) Calibrate the probe before use:
Short-circuit the input ends, power on, press “Zero” button, Range indicator
lights flash alternately; if hearing a “Di” sound, means calibration succeeded; if
hearing a “DiDiDi” sound, means calibration failed, needs to recalibration;
2) The bandwidth of the oscilloscope should be no less than the bandwidth of
the probe, channel input impedance should be 50Ω.
3) Recommend to use after 10 minutes warm-up to get more accurate result.
4) When Range LED indicator flashes and beeps rapidly, indicating Over-
voltage warning, please switch to higher range.
Cable to signal box
Range Selection Button
BNC signal output
Range LED Indicator
Auto Zero Button
Button Panel
Signal input：Positive
Cable to Control Module
Signal input：Negative
