Micsig Smart Series User manual

Version Info
Version
Date
Remarks
V2.0
2019.10

Preface
Preface
Dear customers,
Congratulations! Thank you for buying Micsig instrument. Please read this manual carefully before use and
particularly pay attention to the “Safety Precautions”.
If you have read this manual, please keep it properly for future reference.
The information contained herein are furnished in an “as-is” state, and may be subject to change in future versions
without notice.
The standard applicable for this product: GB/T15289-2013.

Table of Contents
i
Table of Contents
TABLE OF CONTENTS........................................................................................................................................I
CHAPTER 1. SAFETY PRECAUTIONS.................................................................................... 1
1.1 SAFETY PRECAUTIONS ................................................................................................................................1
1.2 SAFETY TERMS AND SYMBOLS ...................................................................................................................5
CHAPTER 2. QUICK START GUIDE OF OSCILLOSCOPE .................................................... 8
2.1 INSPECT PACKAGE CONTENTS ....................................................................................................................9
2.2 USE THE BRACKET ....................................................................................................................................10
2.3 SIDE PANEL ...............................................................................................................................................11
2.4 REAR PANEL..............................................................................................................................................12
2.5 FRONT PANEL............................................................................................................................................13

ii
2.6 POWER ON/OFF THE OSCILLOSCOPE..........................................................................................................14
2.7 UNDERSTAND THE OSCILLOSCOPE DISPLAY INTERFACE ..........................................................................15
2.8 INTRODUCTION BASIC OPERATIONS OF TOUCH SCREEN..........................................................................20
2.9 MOUSE OPERATION ...................................................................................................................................23
2.10 CONNECT PROBE TO THE OSCILLOSCOPE ...............................................................................................24
2.11 USE AUTO................................................................................................................................................25
2.12 LOAD FACTORY SETTINGS ......................................................................................................................30
2.13 USE AUTO-CALIBRATION ........................................................................................................................30
2.14 PASSIVE PROBE COMPENSATION.............................................................................................................31
2.15 MODIFY THE LANGUAGE.........................................................................................................................35
CHAPTER 3 OPERATE THE OSCILLOSCOPE WITH BUTTONS........................................ 36
3.1 FUNCTION BUTTONS .................................................................................................................................38

Table of Contents
iii
3.2 MULTIFUNCTIONAL AREA.........................................................................................................................39
3.3 CURSOR .....................................................................................................................................................40
3.4 HORIZONTAL SYSTEM ...............................................................................................................................40
3.5 VERTICAL SYSTEM ....................................................................................................................................41
3.6 TRIGGER SYSTEM......................................................................................................................................42
3.7 HOMEPAGE, SCREEN CAPTURE .................................................................................................................44
3.8 SECOND FUNCTION BUTTON.....................................................................................................................44
CHAPTER 4 HORIZONTAL SYSTEM .................................................................................... 46
4.1 MOVE THE WAVEFORM HORIZONTALLY...................................................................................................48
4.2 ADJUST THE HORIZONTAL TIME BASE (TIME/DIV)...................................................................................49
4.3 PAN AND ZOOM SINGLE OR STOPPED ACQUISITIONS ...............................................................................51
4.4 ROLL, XY ..................................................................................................................................................52

iv
4.5 ZOOM MODE..............................................................................................................................................60
CHAPTER 5 VERTICAL SYSTEM .......................................................................................... 63
5.1 OPEN/CLOSE WAVEFORM (CHANNEL, MATH, REFERENCE WAVEFORMS)...............................................65
5.2 ADJUST VERTICAL SENSITIVITY ...............................................................................................................70
5.3 ADJUST VERTICAL POSITION.....................................................................................................................71
5.4 OPEN CHANNEL MENU..............................................................................................................................71
5.4.1 Set Channel Coupling.................................................................................................................................... 72
5.4.2 Set Bandwidth Limit...................................................................................................................................... 76
5.4.3 Waveform Inversion ...................................................................................................................................... 78
5.4.4 Set Probe Type............................................................................................................................................... 79
5.4.5 Set Probe Attenuation Coefficient................................................................................................................. 80
5.4.6 Vertical Expansion Reference........................................................................................................................ 82

Table of Contents
v
CHAPTER 6 TRIGGER SYSTEM ............................................................................................ 83
6.1 TRIGGER AND TRIGGER ADJUSTMENT ......................................................................................................84
6.2 EDGE TRIGGER ..........................................................................................................................................96
6.3 PULSE WIDTH TRIGGER ..........................................................................................................................100
6.4 LOGIC TRIGGER.......................................................................................................................................108
6.5 NTH EDGE TRIGGER (OPTIONAL)...........................................................................................................113
6.6 RUNT TRIGGER (OPTIONAL)...................................................................................................................116
6.7 SLOPE TRIGGER.......................................................................................................................................118
6.8 TIMEOUT TRIGGER (OPTIONAL)..............................................................................................................123
6.9 VIDEO TRIGGER.......................................................................................................................................126
6.10 SERIAL BUS TRIGGER............................................................................................................................131

vi
CHAPTER 7 ANALYSIS SYSTEM ........................................................................................ 132
7.1 AUTOMATIC MEASUREMENT ..................................................................................................................133
7.2 FREQUENCY METER MEASUREMENT......................................................................................................144
7.3 CURSOR ...................................................................................................................................................146
CHAPTER 8 SCREEN CAPTURE, MEMORY DEPTH AND WAVEFORM STORAGE ..... 152
8.1 SCREEN CAPTURE FUNCTION..................................................................................................................153
8.2 VIDEO RECORDING..................................................................................................................................155
8.3 WAVEFORM STORAGE .............................................................................................................................156
CHAPTER 9 MATH AND REFERENCE................................................................................ 165
9.1 DUAL WAVEFORM CALCULATION...........................................................................................................166
9.2 FFT MEASUREMENT ...............................................................................................................................171
9.3 REFERENCE WAVEFORM CALL ...............................................................................................................178

Table of Contents
vii
CHAPTER 10 DISPLAY SETTINGS ...................................................................................... 183
10.1 WAVEFORM SETTINGS...........................................................................................................................185
10.2 GRATICULE SETTING .............................................................................................................................185
10.3 PERSISTENCE SETTING ..........................................................................................................................186
10.4 HORIZONTAL EXPANSION CENTER........................................................................................................189
10.5 COLOR TEMPERATURE SETTING ...........................................................................................................189
10.6 TIME BASE MODE SELECTION ..............................................................................................................190
CHAPTER 11 SAMPLING SYSTEM ..................................................................................... 191
11.1 SAMPLING OVERVIEW ...........................................................................................................................192
11.2 RUN/STOP KEY AND SINGLE SEQ KEY.................................................................................................198
11.3 SELECT SAMPLING MODE .....................................................................................................................199
11.4 RECORD LENGTH AND SAMPLING RATE ...............................................................................................205

viii
CHAPTER 12 SERIAL BUS TRIGGER AND DECODE (OPTIONAL)................................ 209
12.1 UART (RS232/RS422/RS485) BUS TRIGGER AND DECODE................................................................214
12.2 LIN BUS TRIGGER AND DECODE ..........................................................................................................225
12.3 CAN BUS TRIGGER AND DECODE.........................................................................................................233
12.4 SPI BUS TRIGGER AND DECODE ...........................................................................................................240
12.5 I2C BUS TRIGGER AND DECODE ...........................................................................................................247
12.6 ARINC429 BUS TRIGGER AND DECODE...............................................................................................255
12.7 1553B BUS TRIGGER AND DECODE ......................................................................................................263
CHAPTER 13 HOMEPAGE FUNCTIONS ............................................................................. 271
13.1 OSCILLOSCOPE (SEE CHAPTERS 2~12)..................................................................................................273
13.2 APP STORE.............................................................................................................................................273
13.3 SETTINGS...............................................................................................................................................277

Table of Contents
ix
13.4 FILE MANAGER .....................................................................................................................................287
13.5 CALCULATOR.........................................................................................................................................288
13.6 BROWSER ..............................................................................................................................................288
13.7 GALLERY ...............................................................................................................................................289
13.8 CALENDAR ............................................................................................................................................292
13.9 ELECTRONIC TOOLS ..............................................................................................................................292
13.10 CLOCK .................................................................................................................................................293
13.11 POWER OFF..........................................................................................................................................296
13.12 POWER OFF LOCK ...............................................................................................................................298
CHAPTER 14 REMOTE CONTROL...................................................................................... 299
14.1 HOST COMPUTER ..................................................................................................................................300
14.1.1 Installation of Host Computer Software.................................................................................................... 300

x
14.1.2 Connection of Host Computer................................................................................................................... 301
14.1.3 Main Interface Introduction....................................................................................................................... 302
14.1.4 Operation Interface Introduction............................................................................................................... 305
14.1.5 Storage and View of Pictures and Videos.................................................................................................. 306
14.2 MOBILE REMOTE CONTROL..................................................................................................................309
14.3 FTP........................................................................................................................................................311
14.4 SCPI ......................................................................................................................................................317
CHAPTER 15 UPDATE AND UPGRADE FUNCTIONS....................................................... 318
15.1 SOFTWARE UPDATE ...............................................................................................................................319
15.2 ADD OPTIONAL FUNCTIONS..................................................................................................................320
CHAPTER 16 REFERENCE ................................................................................................... 323
16.1 MEASUREMENT CATEGORY...................................................................................................................324

Table of Contents
xi
16.2 POLLUTION DEGREE..............................................................................................................................325
CHAPTER 17 TROUBLESHOOTING.................................................................................... 327
CHAPTER 18 SERVICES AND SUPPORT ............................................................................ 334
ANNEX.................................................................................................................................... 336
ANNEX A:MAINTENANCE AND CARE OF OSCILLOSCOPE.............................................................................336
ANNEX B: ACCESSORIES...............................................................................................................................338

Chapter 1. Safety Precautions
1
Chapter 1. Safety Precautions
1.1 Safety Precautions
The following safety precautions must be understood to avoid personal injury and prevent damage to this product or
any products connected to it. To avoid possible safety hazards, it is essential to follow these precautions while using
this product.
⚫Only professionally trained personnel can operate the maintenance procedure.
⚫Avoid fire and personal injury.
⚫Use proper power cord. Use only the power cord specified for this product and certified for the country/region
of use.
⚫Connect and disconnect probes properly. Connect the instrument probe correctly, and its ground terminal is
ground phase. Do not connect or disconnect probes or test leads while they are connected to a voltage source.

2
Disconnect the probe input and the probe reference lead from the circuit under test before disconnecting the
probe from the measurement product.
⚫Ground the product. To avoid electric shock, the instrument grounding conductor must be connected to
earth ground.
⚫Observe all terminal ratings. To avoid fire or shock hazard, observe all rating and markings on the product.
Consult the product manual for further information of ratings before making connections to the product.
⚫User correct probes. To avoid excessive electric shock, use only correct rated probes for any measurement.
⚫Disconnect AC power. The adapter can be disconnected from AC power and the user must be able to access the
adapter at any time.
⚫Do not operate without covers. Do not operate the product with covers or panels removed.
⚫Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected
by service personnel designated by Micsig.

Chapter 1. Safety Precautions
3
⚫Use adapter correctly. Supply power or charge the equipment by power adapter designated by Micsig, and
charge the battery according to the recommended charging cycle.
⚫Avoid exposed circuitry. Do not touch exposed connections and components when power is present.
⚫Provide proper ventilation.
⚫Do not operate in wet/damp conditions.
⚫Do not operate in a flammable and explosive atmosphere.
⚫Keep product surfaces clean and dry.
⚫The disturbance test of all models complies with Class A standards, based on EN61326:1997+A1+A2+A3,
but do not meet Class B standards.
Measurement Category
The STO1000 series oscilloscope is intended to be used for measurements in Measurement Category I.

4
Measurement Category Definition
Measurement category I is for measurements performed on circuits not directly connected to the MAINS. Examples
are measurements on circuits not derived from MAINS, and specially protected (internal) MAINS derived circuits.
In the latter case, transient stresses are variable; for that reason, the user must understand the transient withstand
capability of the equipment.
Warning
IEC Measurement Category. Under IEC Category I mounting conditions, the input terminal can be connected to the
circuit terminal with a maximum line voltage of 300Vrms. To avoid the risk of electric shock, the input terminal
should not be connected to the circuit with a line voltage greater than 300Vrms. Instantaneous overvoltage is
present in circuits that are isolated from the mains supply. The STO1000 series digital oscilloscope is designed to
safely withstand sporadic transient overvoltage up to 1000Vpk. Do not use this equipment for any measurements in
circuits where the instantaneous overvoltage exceeds this value.

Chapter 1. Safety Precautions
5
1.2 Safety Terms and Symbols
Terms in the manual
These terms may appear in this manual:
Warning. Warning statements indicate conditions or practices that could result in injury or loss of life.
Caution. Caution statements indicate conditions or practices that could result in damage to this product or
other property.
Terms on the product
These terms may appear on the product:
Danger indicates an injury hazard immediately accessible as you read the marking.
Warning indicates an injury hazard not immediately accessible as you read the marking.
Caution indicates a hazard to this product or other properties.

6
Symbols on the product
The following symbols may appear on the product:
Hazardous Voltage Caution Refer to Manual Protective Ground Terminal
Chassis Ground Measurement Ground Terminal
Please read the following safety precautions to avoid personal injury and prevent damage to this product or
any products connected to it. To avoid possible hazards, this product can only be used within the specified
scope.
Warning
If the instrument input port is connected to a circuit with the peak voltage higher than 42V or the power exceeding
4800VA, to avoid electric shock or fire:
