Middle Atlantic Products DWR/SR Series User manual

I-00819 Rev B
DWR/SR Series
Fan Kit
Instruction Sheet
Thank you for purchasing the DWR/SR series fan kit. Please read these instructions thoroughly
before installing and assembling this product.
• Extend equipment life by removing excess heat.
• Vent blockers provided to control airflow.
THANK YOU
PRODUCT FEATURES

Page 2
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Failure to read, understand and follow the following information can result in serious personal injury, damage to the
equipment or voiding of the warranty.
CAUTION : The following parts are not effectively bonded to the protective earth terminal: Rack rails, lace bars, Lever Lock™, shelves,
baffle, blanking panels, fans, and cable management. If any part needs to be bonded to the protective earth terminal it shall be done in
accordance with Article 250 of the National Electrical Code.
DANGER HAZARDOUS VOLTAGE: The lightning flash with the arrowhead symbol, within an equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
WARNING: A warning alerts you to a situation that could result in serious personal injury or death.
CAUTION: A caution alerts you to a situation that may result in minor personal injury or damage to the product and/or property.
NOTE: A note is used to highlight procedures pertaining to the installation, operation, or maintenance of the product.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Clean only with dry cloth.
• Only use attachments/accessories specified by the manufacturer.
CAUTION: Use indoor in dry locations only.
INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ
• Lire ces instructions.
• Conservez ces instructions.
• Respectez tous les avertissements.
• Suivez toutes les instructions.
• Nettoyer uniquement avec un chiffon sec.
• N'utilisez que des accessoires spécifiés par le fabricant.
AVERTISSEMENT: Ne pas lire, comprendre et suivre les informations suivantes peut entraîner des blessures graves, des
dommages à l'équipement ou de la nullité de la garantie.
DANGER TENSION DANGEREUSE: Le symbole de la pointe de flèche, dans un triangle équilatéral, est destiné à alerter l'utilisateur sur la
présence de tension dangereuse non isolée dans l'enceinte du produit qui peut être d'une ampleur suffisante pour constituer un risque
d'électrocution.
AVERTISSEMENT: Un avertissement vous avertit d'une situation pouvant entraîner des blessures graves ou la mort.
ATTENTION: Une attention vous avertit d'une situation pouvant entraîner des blessures mineures ou des dommages au produit et/ou à la
REMARQUE: Une remarque est utilisée pour mettre en évidence les procédures relatives à l'installation, au fonctionnement ou à l'entretien du
produit.
ATTENTION : Les pièces suivantes ne sont pas correctement liés à la borne de terre de protection: rails de rack, des bars de dentelle,
Lever Lock™, des étagères, des chicanes, des panneaux d'obturation, ventilateurs, et la gestion des câbles. Si une partie doit être lié
à la borne de terre de protection, il doit être fait conformément à l'article 250 du Code national de l'électricité.
ATTENTION: Pour être utilisé en intérieur dans un endroit sec seulement.

Page 3
(2x) 6” Fan
A
(4x) 6” Fan
Guard Nut
C
(4x) 6” Fan
Guard Screw
D
(4x) 6” Fan
Guard
B
Front Vent
Blocker
G
(2x) Side
Vent Blocker
F
Power Cord
E
6” FAN KIT (DWR-FK6-26, DWR-FK6-32, AND SR28-FK)
(2x) 4” Fan
A
(8x) 4” Fan
Guard Nut
C
(8x) 4” Fan
Guard Screw
D
(4x) 4” Fan
Guard
B
Front Vent
Blocker
G
(2x) Side
Vent Blocker
F
SUPPLIED COMPONENTS AND HARDWARE
Power Cord
E
4” FAN KIT (DWR-FK17 AND DWR-FK22)

Page 4
NOTE:
• Arrow on side of fan (A) indicates the air flow
direction. Install with arrow pointing outside of
the enclosure. (FIGURE A)
• Install fans with plugs facing each other as
shown. This will ensure that the power cord
(E) (and bonding wire) is able to reach both
fans. (FIGURE B)
FIGURE A
E
FIGURE B
1. Use a rubber mallet to clear desired
fan knockouts from the inside out of your
enclosure.
SUPPLIED COMPONENTS AND HARDWARE (CONTINUED)
INSTALLATION
OPTIONAL PROTECTIVE EARTH TERMINAL KIT (PET-K-DWRFK)
REQUIRED TOOLS
• Rubber Mallet
• No. 2 Phillips Driver
• 5/16” Wrench or Socket
• Scissors
10-32 Locking
Flange Nut
H
(2x) M4 x 8MM Phil.
Head Combo Screw
K
Split Bonding Wire
J
WARNING: Use tools with caution and follow all necessary safety
protocols.
AVERTISSEMENT: Utiliser des outils avec prudence et suivre
tous les protocoles de sécurité nécessaires.

Page 5
A
BCFIGURE C
NOTE: DWR enclosures are pictured in
these instructions, however, the installation is
similar for both DWR and SR series products.
2. Install fan (A), guard (B) and hardware
(C and D) as shown. (FIGURE C and
FIGURE D, respectively)
4” Fan Installation
• The 4” fans (DWR-FK17 and DWR-FK22)
use (8x) screws (D) and (8x) nuts (C) in
total. (Meaning, (4x) screws and nuts for
each fan.) (FIGURE C)
INSTALLATION (CONTINUED)
Rear View Inside of DWR
FGF
FIGURE E
3. Install vent blockers (F and G) as shown.
(FIGURE E)
NOTE: If your enclosure has the Decora™
cutout, use a scissor to cut the front vent blocker
(G) into 3 pieces to match the correct widths.
FIGURE D
C
D
D
B
B
B
A
6” Fan Installation
4” Fan
Installation
6” Fan Installation
• The 6” fans (DWR-FK6-26, DWR-FK6-32, and SR28-FK)
use (4x) screws (D) and (4x) nuts (C) in total.
(Meaning, (2x) screws and nuts for each fan).
(FIGURE D)
NOTE: DWR enclosures are pictured in these instructions,
however, the installation is similar for both DWR and SR
series products.

Page 6
For warranty information, refer to www.middleatlantic.com/terms.
Corporate Headquarters
Corporate Voice: 973-839-1011 - Fax: [phone] / International Voice: [phone] -
Fax: [phone]
www.middleatlantic.com - [email protected]
Middle Atlantic Canada
Voice: 613-836-2501 - Fax: [phone] / www.middleatlantic.ca -
[email protected]
Factory Distribution
USA: NJ - CA - IL Canada: ON - BC
At Middle Atlantic Products we are always listening. Your comments are welcome.
Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company.
WARRANTY
BONDING THE FAN TO THE ENCLOSURE TOP
1. Use the locking nut (H) to connect the center eyelet on the bonding wire (J) to a bonding point on the
underside of the enclosure top. (FIGURE F)
2. Use the M4 screws (K) to connect the remaining bonding wire eyelets to the ground points (GND) on
the fans. (FIGURE F)
Protective Earth Terminals (PET) are located in the rack. These terminals are marked with the symbol .
Rack parts, center section and door, contain or are provided with bonding points for connection to the backpan / PET.
Protective earth and bonding connections shall be in accordance with Article 250 of the National Electric Code.
FIGURE F
4” Fan
GND GND
6” Fan
Upward View of Enclosure Tops
(With 4” and 6” Fan Knockouts)
Bonding
Points Bonding
Points
